Evaluation Kits

Displaying 5201 - 5220 of 12849

Evaluation Kits

Dual Source USB AC Li Chemistry Charger IC for Portable Applications

Texas Instruments

Dual Source USB AC Li Chemistry Charger IC for Portable Applications

Evaluation Kit Parts

DRV8884 1.0A Stepper Motor Driver with Integrated Sense Resistor Evaluation Module

Texas Instruments

DRV8884 1.0A Stepper Motor Driver with Integrated Sense Resistor Evaluation Module

Evaluation Kit Parts

Hercules RM46x Three Phase BLDC, PMSM Motor Control Kit with DRV8301 and Encoder

Texas Instruments

Hercules RM46x Three Phase BLDC, PMSM Motor Control Kit with DRV8301 and Encoder

Evaluation Kit Parts

LTC4557EUD | Dual SIM Card Power Supply and Interface

Analog Devices Inc.

DC709A: Demo Board for the LTC4557 Dual SIM/Smart Card Power Supply and Interface.

Evaluation Kit

TLV320AIC29EVM-PDK

Texas Instruments

KIT EVAL FOR TLV320AIC29 W/BOARD

Evaluation Kit Parts

The LTC3524 is an integrated BIAS and white LED power converter solution for small/medium-sized polysilicon thin ?lm transistor (TFT) liquid crystal (LCD) display panels. The device operates from a single Lithium-Ion/polymer battery or any voltage source between 2.5V and 6V. A 1.5MHz synchronous boost converter generates a programmable low noise, high efficiency 25mA TFT supply of up to 6.0V. Regulated, low ripple charge pumps are used to generate up to +20V and ?20V at 2mA. Output sequencing is internally controlled to insure proper initialization and rapid discharge of the LCD panel in shutdown. A second 1.5MHz boost converter powers one or two LED strings with up to ?ve series elements each. LED current and display brightness can be controlled over a wide range using analog or digital means up to 25mA.The LTC3524 is offered in the 4mm ? 4mm 24-pin QFN package, minimizing the total solution footprint.Applications PDAs, Palmtop Computers Digital Still and Video Cameras Handheld GPS Portable Instrument Displays Portable Media Players

Evaluation Kit

DC2293A-A

Analog Devices Inc.

The LTC2933 is an EEPROM configurable voltage supervisor which can simultaneously monitor up to six power supply voltage inputs. Each voltage detector offers I2C programmable over/undervoltage thresholds in various ranges and increments.Two general purpose inputs (GPI) can be configured as programmable manual reset (MR), UV disable (UVDIS), margin (MARG) or auxiliary comparator (AUXC) inputs. Three general purpose pins (GPIO) can be configured for input or output operation. When configured as an input, a GPIO pin can be mapped to any other GPIO configured as output. The GPIO pins can also be configured as ALERT or fault outputs. Faults can be configured with programmable delay-on-release times. Output type and polarity are also configurable.Status and history registers log faults and can be polled via the I2C interface. A fault log snapshot is also backed up in internal EEPROM. All parameters are programmable via the I2C interface. Configuration EEPROM supports autonomous operation without additional software.Applications High Availability Computer Systems Network Servers Telecom Equipment Data Storage

Evaluation Kit

EV1HMC1113LP5

Analog Devices Inc.

The HMC1113LP5E is a compact GaAs MMIC I/Q downconverter in a leadless 5 x 5 mm low stress injection molded plastic surface mount package. This device provides a small signal conversion gain of 12 dB with a noise figure of 1.8 dB and 25 dBc of image rejection. The HMC1113LP5E utilizes an LNA followed by an image reject mixer which is driven by an LO buffer amplifier. The image reject mixer eliminates the need for a filter following the LNA, and removes thermal noise at the image frequency. I/Q mixer outputs are provided and an external 90? hybrid is needed to select the required sideband. The HMC1113LP5E is a much smaller alternative to hybrid style image reject mixer downconverter assemblies, and it eliminates the need for wire bonding by allowing the use of surface mount manufacturing techniques.Applications Point-to-Point &?Point-to-Multi-Point Radio Military Radar, EW & ELINT Satellite Communications Maritime & Mobile Radios
