ADP1660CB-EVALZ
Analog Devices Inc.The ADP1660 is a very compact, highly efficient, dual white LEDflash driver for high-resolution camera phones that improvespicture and video quality in low light environments. The deviceintegrates a programmable 1.5 MHz or 3.0 MHz synchronousinductive boost converter, an I2C-compatible interface, and two 750 mA current sources. The high switching frequency enablesthe use of a tiny, 1 mm high, low cost, 1 ?H power inductor,and the parallel current sources permit LED cathode groundingfor thermally enhanced, low EMI, and compact layouts.The LED driver maximizes efficiency over the entire battery voltage range to maximize the input-power-to-LED-power conversion and minimize battery current draw during flash events.The LED driver maximizes efficiency over the entire batteryvoltage range to maximize the input-power-to-LED-powerconversion and minimize battery current draw during flashevents. A programmable DC battery current limit safely maximizesLED current for all LED VF and battery voltage conditions.A TxMASK input permits the flash LED currents and batterycurrent to reduce quickly during a power amplifier current burst.The I2C-compatible interface enables the programmability oftimers, currents, and status bit readback for operationmonitoring and safety control.ADP1660 comes in a compact 12-ball, 0.5 mm pitch packageand operates within specification over the full ?40?C to +125?Cjunction temperature range.APPLICATIONS Camera-enabled cellular phones and smart phones Digital still cameras, camcorders, and PDAs
ADP1660SHIELD-EVALZ
Analog Devices Inc.The ADP1660 is a very compact, highly efficient, dual white LEDflash driver for high-resolution camera phones that improvespicture and video quality in low light environments. The deviceintegrates a programmable 1.5 MHz or 3.0 MHz synchronousinductive boost converter, an I2C-compatible interface, and two 750 mA current sources. The high switching frequency enablesthe use of a tiny, 1 mm high, low cost, 1 ?H power inductor,and the parallel current sources permit LED cathode groundingfor thermally enhanced, low EMI, and compact layouts.The LED driver maximizes efficiency over the entire battery voltage range to maximize the input-power-to-LED-power conversion and minimize battery current draw during flash events.The LED driver maximizes efficiency over the entire batteryvoltage range to maximize the input-power-to-LED-powerconversion and minimize battery current draw during flashevents. A programmable DC battery current limit safely maximizesLED current for all LED VF and battery voltage conditions.A TxMASK input permits the flash LED currents and batterycurrent to reduce quickly during a power amplifier current burst.The I2C-compatible interface enables the programmability oftimers, currents, and status bit readback for operationmonitoring and safety control.ADP1660 comes in a compact 12-ball, 0.5 mm pitch packageand operates within specification over the full ?40?C to +125?Cjunction temperature range.APPLICATIONS Camera-enabled cellular phones and smart phones Digital still cameras, camcorders, and PDAs
ADP166UJ-EVALZ
Analog Devices Inc.The ADP165?/ ADP166 are very low quiescent current, low dropout, linear regulator that operate from 2.2 V to 5.5 V and provides up to 150 mA of output current. The low 120 mV dropout voltage at 150 mA load improves efficiency and allows operation over a wide input voltage range.The ADP165 / ADP166 are specifically designed for stable operation with a tiny 1 ?F ? 30% ceramic input and output capacitors to meet the requirements of high performance, space-constrained applications.The ADP165 / ADP166 are available in seven fixed output voltage options, ranging from 1.2 V to 3.3 V, and an adjustable output option. The ADP165 also include a switched resistor to discharge the output automatically when the LDO is disabled. The ADP166 is identical to the ADP165, but does not include the output discharge function.Short-circuit and thermal overload protection circuits prevent damage in adverse conditions. The ADP165 / ADP166 are available in a tiny 5-lead TSOT, a 6-lead LFCSP and a 4-ball, 0.5 mm pitch WLCSP package for the smallest footprint solution to meet a variety of portable power applications.APPLICATIONS Portable and battery-powered equipment Post dc-to-dc regulation Portable medical devices Wireless sensor network (WSN) devices
ADP1707-3.3-EVALZ
Analog Devices Inc.The ADP1706?/ ADP1707 / ADP1708?are CMOS, low dropout linear regulators that operate from 2.5 V to 5.5 V and provide up to 1 A of output current. Using an advanced proprietary architecture, they provide high power supply rejection and achieve excellent line and load transient response with a small 4.7 ?F ceramic output capacitor.The ADP1706 / ADP1707 are available in 16 fixed output volt-age options. The ADP1708 is available in an adjustable version, which allows output voltages that range from 0.8 V to 5.0 V via an external divider. The ADP1706 allows an external soft start capacitor to be connected to program the start-up time; the ADP1707 and ADP1708 contain internal soft start capacitors that give a typical start-up time of 100 ?s. The ADP1707 includes a tracking feature that allows the output to follow an external voltage rail or reference.The ADP1706 / ADP1707 / ADP1708 are available in an 8-lead, exposed paddle SOIC package and an 8-lead, 3 mm ? 3 mm exposed paddle LFCSP, making them not only very compact solutions but also providing excellent thermal performance for applications requiring up to 1 A of output current in a small, low profile footprint.APPLICATIONS Notebook computers Memory components Telecommunications equipment Network equipment DSP/FPGA/microprocessor supplies Instrumentation equipment/data acquisition systems
ADP1711-2.5-EVALZ
Analog Devices Inc.The ADP1710/ADP1711 are low dropout linear regulators that operate from 2.5 V to 5.5 V and provide up to 150 mA of output current. Utilizing a novel scaling architecture, ground current drawn is a very low 40 ?A, when driving a 100 ?A load, making the ADP1710/ADP1711 ideal for battery-operated portable equipment.The ADP1710 and the ADP1711 are each available in sixteen fixed output voltage options. The ADP1710 is also available in an adjustable version, which allows output voltages that range from 0.8 V to 5 V via an external divider. The ADP1711 allows for a reference bypass capacitor to be connected, which reduces output voltage noise and improves power supply rejection. The ADP1710/ADP1711 are optimized for stable operation with small 1 ?F ceramic output capacitors, allowing for good transient performance while occupying minimal board space. An enable pin controls the output voltage on both devices. There is also an under-voltage lockout circuit on both devices, which disables the regulator if IN drops below a minimum threshold. An internal soft start gives a typical start-up time of 80 ?s. Short-circuit protection and thermal overload protection circuits prevent damage to the devices in adverse conditions. Both the ADP1710 and the ADP1711 are available in tiny 5 leadTSOT packages, for the smallest footprint solution to all your power needs.ApplicationsMobile phones Digital camera and audio devices Portable and battery-powered equipment Post dc-dc regulation
ADP1715-1.8-EVALZ
Analog Devices Inc.The ADP1715 / ADP1716?are low dropout, CMOS linear regulators that operate from 2.5 V to 5.5 V and provide up to 500 mA of output current. Using an advanced proprietary architecture, they provide high power supply rejection and achieve excellent line and load transient response with just a small 2.2 ?F ceramic output capacitor.Three versions of this part are available, one with fixed output voltage options and variable soft start (ADP1715), one with adjustable output voltage and fixed soft start (ADP1715 Adjustable), and one with voltage tracking in fixed output voltage options (ADP1716). The fixed output voltage options are internally set to one of sixteen values between 0.75 V and 3.3 V; the adjustable output voltage can be set to any value between 0.8 V and 5.0 V by an external voltage divider connected from OUT to ADJ. The variable soft start uses an external capacitor at SS to control the output voltage ramp. Tracking limits the output voltage to the at-or-below voltage at the TRK pin.The ADP1715 / ADP1716 are available in 8-lead thermally enhanced MSOP packages, making them not only a very compact solution but also providing excellent thermal performance for applications requiring up to 500 mA of output current in a small, low profile footprint.APPLICATIONS Notebook computers Memory components Telecommunications equipment Network Equipment DSP/FPGA/?P supplies Instrumentation equipment/data acquisition systems
ADP171-EVALZ
Analog Devices Inc.The?ADP170?/ ADP171 /?ADP172 are low voltage input, low quiescentcurrent, low-dropout (LDO) linear regulators that operate from1.6 V to 3.6 V and provide up to 300 mA of output current. Thelow 55 mV dropout voltage at 300 mA load improves efficiencyand allows operation over a wide input voltage range. The low23 ?A of quiescent current at no load makes theADP170 / ADP171 / ADP172?ideal for battery-operated portable equipment.TheADP170 is capable of 31 fixed-output voltage options, ranging from 0.8 V to 3.0 V. ADP171 is an adjustable version, which allows output voltages that range from 0.8 V to3.0 V via an external divider. The ADP170 / ADP171 areoptimized for stable operation with small 1 ?F ceramic outputcapacitors. Ideal for powering digital processors, the ADP170 / ADP171 exhibit good transient performance andoccupy minimal board space. Compared with commodity typesof LDOs, the ADP170 / ADP171 provide 20 dB to 40 dB betterpower supply rejection ratio (PSRR) at 100 kHz, making the ADP170 / ADP171 an ideal power source for analog-to-digitalconverter (ADC) mixed-signal processor systems and allowinguse of smaller size bypass capacitors. In addition, low outputnoise performance without the need for an additional bypasscapacitor further reduces printed circuit board (PCB)component count.Short-circuit protection and thermal overload protectioncircuits prevent damage in adverse conditions. TheADP170 / ADP171 are available in tiny 5-lead TSOT for thesmallest footprint solution to meet a variety of portable powerapplications.APPLICATIONS Mobile phones Digital camera and audio devices Portable and battery-powered equipment DSP/FPGA/microprocessor supplies Post dc-dc regulation
ADP1753-EVALZ
Analog Devices Inc.The?ADP1752?/ ADP1753 are CMOS, low dropout linear regulators that operate from 1.6 V to 3.6 V and provide up to 800mA of output current. These low VIN?& VOUT?LDOs are ideal for regulation of nanometer FPGA geometries operating from 2.5V down to 1.8V I/O rails, and powering core voltages down to 0.75V. Using an advanced proprietary architecture, they provide high power supply rejection, low noise, and achieve excellent line and load transient response with a small 4.7 ?F ceramic output capacitor.The ADP1752?is available in 7 fixed output voltage options. The ADP1753 is available in an adjustable version, which allows output voltages that range from 0.75 V to 3.0 V via an external divider. The ADP1752 / ADP1753 allows an external soft start capacitor to be connected to program the start-up. A power good output allows power system monitors to digitally check the health of the output power rail voltage.The ADP1752 / ADP1753 are available in a 16-lead, 4 mm ? 4 mm LFCSP, making them not only very compact solutions, but also providing excellent thermal performance for applications requiring up to 800mA of output current in a small, low profile footprint.APPLICATIONS Server computers Memory components Telecommunications equipment Network equipment DSP/FPGA/microprocessor supplies Instrumentation equipment/data acquisition systems
ADP1762-1.3-EVALZ
Analog Devices Inc.The ADP1762 is a low noise, low dropout (LDO) linear regulator. It is designed to operate from a single input supply with an input voltage as low as 1.10 V, without the requirement of an external bias supply, to increase efficiency and provide up to 2 A of output current.The low 62 mV typical dropout voltage at a 2 A load allows the ADP1762 to operate with a small headroom while maintaining regulation and providing better efficiency.The ADP1762 is optimized for stable operation with small 10 ?F ceramic output capacitors. The ADP1762 delivers optimal transient performance with minimal board area.The ADP1762 is available in fixed output voltages ranging from 0.9 V to 1.5 V. The output of the adjustable output model can be set from 0.5 V to 1.5 V through an external resistor connected between VADJ and ground.The ADP1762 has an externally programmable soft start time by connecting a capacitor to the SS pin. Short-circuit and thermal overload protection circuits prevent damage in adverse conditions. The ADP1762 is available in a small 16-lead LFCSP package for the smallest footprint solution to meet a variety of applications.APPLICATIONS Regulation to noise sensitive applications such as radio frequency (RF) transceivers, analog-to-digital converter (ADC) and digital-to-analog converter (DAC) circuits, phase-locked loops (PLLs), voltage controlled oscillators (VCOs) and clocking integrated circuits Field-programmable gate array (FPGA) and digital signal processor (DSP) supplies Medical and healthcare Industrial and instrumentation?
ADP1763-ADJ-EVALZ
Analog Devices Inc.The ADP1763 is a low noise, low dropout (LDO) linear regulator. Itis designed to operate from a single input supply with an inputvoltage as low as 1.10 V without the requirement of an external biassupply to increase efficiency and provide up to 3 A of output current.The low 95 mV typical dropout voltage at a 3 A load allows theADP1763 to operate with a small headroom while maintainingregulation and providing better efficiency.The ADP1763 is optimized for stable operation with small 10 ?Fceramic output capacitors. The ADP1763 delivers optimaltransient performance with minimal board area.The ADP1763 is available in fixed output voltages ranging from0.9 V to 1.5 V. The output of the adjustable output model can beset from 0.5 V to 1.5 V through an external resistor connectedbetween VADJ and ground.The ADP1763 has an externally programmable soft start time byconnecting a capacitor to the SS pin. Short-circuit and thermaloverload protection circuits prevent damage in adverse conditions.The ADP1763 is available in a small 16-lead LFCSP package for thesmallest footprint solution to meet a variety of applications.APPLICATIONS Regulation to noise sensitive applications such as RF transceivers, analog-to-digital converter (ADC) and digital-to-analog converter (DAC) circuits, phase-locked loops (PLLs), voltage controlled oscillators (VCOs) and clocking integrated circuits Field-programmable gate array (FPGA) and digital signal processor (DSP) supplies Medical and healthcare Industrial and instrumentation Automotive
ADP1765-ADJ-EVALZ
Analog Devices Inc.The ADP1765 is a low noise, low dropout (LDO) linear regulator. It is designed to operate from a single input supply with an input voltage as low as 1.10 V without the requirement of an external bias supply to increase efficiency and provide up to 5 A of output current (IOUT).The low 59 mV typical dropout voltage at a 5 A load allows the ADP1765 to operate with a small headroom while maintaining regulation and providing better efficiency.The ADP1765 is optimized for stable operation with small 22 ?F ceramic output capacitors. The ADP1765 delivers optimal transient performance with minimal printed circuit board (PCB) area.The ADP1765 is available in fixed output voltages ranging from 0.55 V to 1.5 V. The output voltage (VOUT) of the adjustable output model can be set from 0.5 V to 1.5 V through an external resistor connected between VADJ and ground.The ADP1765 has an externally programmable soft start time by connecting a capacitor to the SS pin. Short-circuit and thermal overload protection circuits prevent damage in adverse conditions. The ADP1765 is available in a small, 16-lead LFCSP package for the smallest footprint solution to meet a variety of applications.Applications Regulation to noise sensitive applications such as radio frequency (RF) transceivers, analog-to-digital converter (ADC) and digital-to-analog converter (DAC) circuits, phase-locked loops (PLLs), voltage controlled oscillators (VCOs) and clocking integrated circuits Field-programmable gate array (FPGA) and digital signal processor (DSP) supplies Medical and healthcare Industrial and instrumentation
ADP1829-EVALZ
Analog Devices Inc.The ADP1829 is a versatile, dual, interleaved, synchronousPWM buck controller that generates two independent output rails from an input of 3.0 V to 20 V, with power input voltageranging from 1.0 V to 24 V. Each controller can be configured to provide output voltages from 0.6 V to 85% of the inputvoltage and is sized to handle large MOSFETs for point-of-loadregulators. The two channels operate 180? out of phase, reducing stress on the input capacitor and allowing smaller, lowcost components. The ADP1829 is ideal for a wide range of high power applications, such as DSP and processor core I/Opower, and general-purpose power in telecommunications,medical imaging, PC, gaming, and industrial applications.The ADP1829 operates at a pin-selectable, fixed switchingfrequency of either 300 kHz or 600 kHz, minimizing external component size and cost. For noise-sensitive applications, it canalso be synchronized to an external clock to achieve switching frequencies between 300 kHz and 1 MHz. The ADP1829includes soft start protection to prevent inrush current from theinput supply during startup, reverse current protection during soft start for precharged outputs, as well as a unique adjustablelossless current-limit scheme utilizing external MOSFET sensing.For applications requiring power supply sequencing, theADP1829 also provides tracking inputs that allow the output voltages to track during startup, shutdown, and faults. Thisfeature can also be used to implement DDR memory bustermination.The ADP1829 is specified over the ?40?C to +125?C junction temperature range and is available in a 32-lead LFCSP package.Applications Telecommunications and networking systems Medical imaging systems Base station power Set-top boxes Printers DDR termination
ADP1850DP-EVALZ
Analog Devices Inc.The ADP1850 is a configurable dual output or two-phase, singleoutput dc-to-dc synchronous buck controller capable of runningfrom commonly used 3.3 V to 12 V (up to 20 V) voltage inputs.The device operates in current mode for improved transientresponse and uses valley current sensing for enhanced noiseimmunity.The architecture enables accurate current sharing betweeninterleaved phases for high current outputs.The ADP1850 is ideal in system applications requiring multipleoutput voltages: the ADP1850 includes a synchronization featureto eliminate beat frequencies between switching devices;provides accurate tracking capability between supplies andincludes precision enable for simple, robust sequencing.The ADP1850 provides high speed, high peak current drivecapability with dead-time optimization to enable energyefficient power conversion. For low load operation, the devicecan be configured to operate in power saving mode (PSM) byskipping pulses and reducing switching losses to improve theenergy efficiency at light load and standby conditions.The accurate current limit (?6%) allows the power architect todesign within a narrower range of tolerances and can reduceoverall converter size and cost.The ADP1850 provides a configurable architecture capableof wide range input operation to provide the designer withmaximum re-use opportunities and improved time to market.Additional flexibility is provided by external programmabilityof loop compensation, soft start, frequency setting, powersaving mode, current limit and current sense gain can all beprogrammed using external components.The ADP1850 includes a high level of integration in a small sizepackage. The start-up linear regulator and the boot-strap diodefor the high side drive are included. Protection features include:undervoltage lock-out, overvoltage, overcurrent/short-circuitand over temperature. The ADP1850 is available in a compact32-lead LFCSP 5 mm ? 5 mm thermally enhanced package.ApplicationsHigh current single and dual output intermediate bus andpoint of load converters requiring sequencing andtracking capability, including converters for:Point-of-load power suppliesTelecom base station and networkingConsumerIndustrial and instrumentationHealthcare and medical
ADP1874-0.6-EVALZ
Analog Devices Inc.The ADP1874 / ADP1875?are versatile current mode, synchronous step-down controllers. They provide superior transient response, optimal stability, and current-limit protection by using a constant on-time, pseudo fixed frequency with a programmable current limit, current control scheme. In addition, these devices offer optimum performance at low duty cycles by using a valley, current mode control architecture. This allows the ADP1874 / ADP1875 to drive all N-channel power stages to regulate output voltages to as low as 0.6 V.The ADP1875 is the power saving mode (PSM) version of the device and is capable of pulse skipping to maintain output regulation while achieving improved system efficiency at light loads (see the ADP1875 Power Saving Mode (PSM) section for more information).Available in three frequency options (300 kHz, 600 kHz, and 1.0 MHz, plus the PSM option), the ADP1874 / ADP1875 are well suited for a wide range of applications that require a single-input power supply range from 2.95 V to 20 V. Low voltage biasing is supplied via a 5 V internal low dropout regulator (LDO).In addition, soft start programmability is included to limit input inrush current from the input supply during startup and to provide reverse current protection during precharged output conditions. The low-side current sense, current gain scheme, and integration of a boost diode, along with the PSM/forced pulsewidth modulation (PWM) option, reduce the external part count and improve efficiency.The ADP1874 / ADP1875 operate over the ?40?C to +125?C junction temperature range and are available in a 16-lead QSOP package.APPLICATIONS Telecom and networking systems Mid- to high-end servers Set-top boxes DSP core power supplies
ADP1874-1.0-EVALZ
Analog Devices Inc.The ADP1874 / ADP1875?are versatile current mode, synchronous step-down controllers. They provide superior transient response, optimal stability, and current-limit protection by using a constant on-time, pseudo fixed frequency with a programmable current limit, current control scheme. In addition, these devices offer optimum performance at low duty cycles by using a valley, current mode control architecture. This allows the ADP1874 / ADP1875 to drive all N-channel power stages to regulate output voltages to as low as 0.6 V.The ADP1875 is the power saving mode (PSM) version of the device and is capable of pulse skipping to maintain output regulation while achieving improved system efficiency at light loads (see the ADP1875 Power Saving Mode (PSM) section for more information).Available in three frequency options (300 kHz, 600 kHz, and 1.0 MHz, plus the PSM option), the ADP1874 / ADP1875 are well suited for a wide range of applications that require a single-input power supply range from 2.95 V to 20 V. Low voltage biasing is supplied via a 5 V internal low dropout regulator (LDO).In addition, soft start programmability is included to limit input inrush current from the input supply during startup and to provide reverse current protection during precharged output conditions. The low-side current sense, current gain scheme, and integration of a boost diode, along with the PSM/forced pulsewidth modulation (PWM) option, reduce the external part count and improve efficiency.The ADP1874 / ADP1875 operate over the ?40?C to +125?C junction temperature range and are available in a 16-lead QSOP package.APPLICATIONS Telecom and networking systems Mid- to high-end servers Set-top boxes DSP core power supplies
ADP1878-0.6-EVALZ
Analog Devices Inc.The ADP1878 / ADP1879?are versatile current mode, synchronous step-down controllers. They provide superior transient response, optimal stability, and current-limit protection by using a constant on-time, pseudo fixed frequency with a programmable current limit, current control scheme. In addition, these devices offer optimum performance at low duty cycles by using a valley, current mode control architecture. This allows the ADP1878 / ADP1879 to drive all N-channel power stages to regulate output voltages to as low as 0.6 V.The ADP1879 is the power saving mode (PSM) version of thedevice and is capable of pulse skipping to maintain outputregulation while achieving improved system efficiency at lightloads (see the ADP1879 Power Saving Mode (PSM) section formore information).Available in three frequency options (300 kHz, 600 kHz, and1.0 MHz, plus the PSM option), the ADP1878 / ADP1879 are wellsuited for a wide range of applications that require a single-inputpower supply range from 2.95 V to 20 V. Low voltage biasing issupplied via a 5 V internal low dropout regulator (LDO).In addition, soft start, programmability is included to limitinput in-rush current from the input supply during startup andto provide reverse current protection during precharged outputconditions. The low-side current sense, current gain scheme andintegration of a boost diode, along with the PSM/forced pulsewidthmodulation (PWM) option, reduce the external part countand improve efficiency.The ADP1878 / ADP1879 operate over the ?40?C to +125?Cjunction temperature range and are available in a 14-LeadLFCSP_WD package.APPLICATIONS Telecom and networking systems Mid to high-end servers Set-top boxes DSP core power supplies
ADP1879-0.3-EVALZ
Analog Devices Inc.The ADP1878?/ ADP1879 are versatile current mode, synchronous step-down controllers. They provide superior transient response, optimal stability, and current-limit protection by using a constant on-time, pseudo fixed frequency with a programmable current limit, current control scheme. In addition, these devices offer optimum performance at low duty cycles by using a valley, current mode control architecture. This allows the ADP1878 / ADP1879 to drive all N-channel power stages to regulate output voltages to as low as 0.6 V.The ADP1879 is the power saving mode (PSM) version of thedevice and is capable of pulse skipping to maintain outputregulation while achieving improved system efficiency at lightloads (see the ADP1879 Power Saving Mode (PSM) section formore information).Available in three frequency options (300 kHz, 600 kHz, and1.0 MHz, plus the PSM option), the ADP1878 / ADP1879 are wellsuited for a wide range of applications that require a single-inputpower supply range from 2.95 V to 20 V. Low voltage biasing issupplied via a 5 V internal low dropout regulator (LDO).In addition, soft start, programmability is included to limitinput in-rush current from the input supply during startup andto provide reverse current protection during precharged outputconditions. The low-side current sense, current gain scheme andintegration of a boost diode, along with the PSM/forced pulsewidthmodulation (PWM) option, reduce the external part countand improve efficiency.The ADP1878/ADP1879 operate over the ?40?C to +125?Cjunction temperature range and are available in a 14-LeadLFCSP_WD package.APPLICATIONS Telecom and networking systems Mid to high-end servers Set-top boxes DSP core power supplies
ADP190CB-EVALZ
Analog Devices Inc.The ADP190 is a high-side load switch designed for operationfrom 1.2 V to 3.6 V. This load switch provides power domainisolation for extended power battery life. The device contains alow on-resistance P-channel MOSFET that supports more than500 mA of continuous current and minimizes power loss. Thelow 2 ?A (maximum) of ground current and ultralow shutdowncurrent make the ADP190 ideal for battery-operated portableequipment. The built-in level shifter for enable logic makes theADP190 compatible with modern processors and GPIOcontrollers.Beyond operating performance, the ADP190 occupies minimalprinted circuit board (PCB) space with an area less than 0.64 mm2and a height of 0.60 mm. It is available in an ultrasmall 0.8 mm ?0.8 mm, 4-ball, 0.4 mm pitch WLCSP.ApplicationsMobile phonesDigital cameras and audio devicesPortable and battery-powered equipment
ADP194CB-EVALZ
Analog Devices Inc.The ADP194 is a high-side load switch designed for operation from 1.1 V to 3.6 V and is protected against reverse current flow from output to input. This load switch provides power domain isolation for extended power battery life. The device contains a low on-resistance P-channel MOSFET that supports more than 500 mA of continuous load current and minimizes power loss. The low 2 ?A (maximum) ground current and ultralow shutdown current makes the ADP194 ideal for battery-operated portable equipment. The built-in level shifter in the enable logic input makes the ADP194 compatible with modern processors and GPIO controllers.Beyond operating performance, the ADP194 occupies minimal printed circuit board (PCB) space with an area less than 0.64 mm2 and a height of 0.50 mm. The ADP194 is available in an ultrasmall 0.8 mm x 0.8 mm, 4-ball, 0.4 mm pitch WLCSP.APPLICATIONS- Mobile phones- Digital cameras and audio devices- Portable and battery-powered equipment
LTC4425EDD Demo Board | Linear SuperCap Charger with Current-Limited Ideal Diode and V/I Monitor
Analog Devices Inc.DC1589A: Demo Board for the LTC4425 Linear SuperCap Charger with Current-Limited Ideal Diode and V/I Monitor.
