Evaluation Kits

Displaying 5241 - 5260 of 12879

Evaluation Kits

EVAL-ADF7023DB5Z

The ADF7023 is a very low power, high performance, highly integrated 2FSK/GFSK/OOK/MSK/GMSK transceiver designed for operation in the 862 MHz to 928 MHz and 431 MHz to 464 MHz frequency bands, which cover the worldwide license-free ISM bands at 433 MHz, 868 MHz, and 915 MHz. It is suitable for circuit applications that operate under the European ETSI EN300-220, the North American FCC (Part 15), the Chinese short-range wireless regulatory standards, or other similar regional standards. Data rates from 1 kbps to 300 kbps are supported.The transmit RF synthesizer contains a VCO and a low noise fractional-N PLL with an output channel frequency resolution of 400 Hz. The VCO operates at 2? or 4?, the fundamental frequency to reduce spurious emissions. The receive and transmit synthesizer bandwidths are automatically, and independently, configured to achieve optimum phase noise, modulation quality, and settling time. The transmitter output power is programmable from ?20 dBm to +13.5 dBm, with automatic PA ramping to meet transient spurious specifications. The part possesses both single-ended and differential PAs, which allows for Tx antenna diversity.The receiver is exceptionally linear, achieving an IP3 specification of ?12.2 dBm and ?11.5 dBm at maximum gain and minimum gain, respectively, and an IP2 specification of 18.5 dBm and 27 dBm at maximum gain and minimum gain, respectively. The receiver achieves an interference blocking specification of 66 dB at ?2 MHz offset and 74 dB at ?10 MHz offset. Thus, the part is extremely resilient to the presence of interferers in spectrally noisy environments. The receiver features a novel, high speed, automatic frequency control (AFC) loop, allowing the PLL to find and correct any RF frequency errors in the recovered packet.A patent pending, image rejection calibration scheme is available through a program download. The algorithm does not require the use of an external RF source nor does it require any user intervention once initiated. The results of the calibration can be stored in nonvolatile memory for use on subsequent power-ups of the transceiver.See data sheet for additional information.Applications Smart metering IEEE 802.15.4g Wireless MBUS Home automation Process and building control Wireless sensor networks (WSNs) Wireless healthcare

Evaluation Kit

EVAL-ADG4612EBZ

Analog Devices Inc.

The ADG4612 & ADG4613?contain four independent single-pole/single-throw (SPST) switches. The ADG4612 switches areturned on with Logic 1 on the appropriate control input. TheADG4613 has two switches with digital control logic similar tothat of the ADG4612; the logic is inverted on the other twoswitches. Each switch conducts equally well in both directionswhen on and has an input signal range that extends to thesupplies. The ADG4613 exhibits break-before-make switchingaction for use in multiplexer applications.When no power supplies are present the switch remains in theOFF condition and the switch inputs are high impedanceinputs. This ensures that no current flows that may damage theswitch. This is very useful in application where analog signalsmay be present at the switch inputs before power or where theuser has no control over the Power Supply Sequence.In the off condition, signal levels up to 16V are blocked. Also, ifthe analog input signal levels exceed VDD by VT then the switchwill turn off.The ultralow on resistance of these switches make them idealsolutions for data acquisition and gain switching applicationswhere low on resistance and distortion is critical. The onresistance profile is very flat over the full analog input rangeensuring excellent linearity and low distortion when switchingaudio signals.APPLICATIONS Hot swap applications Data acquisition systems Battery-powered systems Automatic test equipment Communication systems Relay ReplacementPRODUCT HIGHLIGHTS Power-Off Protection On Both S and D Pins. PSS Robustness. Overvoltage Protection up to 16 V. 5.2 ? On Resistance. 16-Lead TSSOP and 3 mm ? 3 mm LFCSP Packages.

Evaluation Kit

EVAL-ADG5249FEBZ

Analog Devices Inc.

The ADG5248F and ADG5249F are 8:1 and dual 4:1 analog multiplexers. The ADG5248F switches one of eight inputs to a common output and the ADG5249F switches one of four differential inputs to a common differential output. Each channel conducts equally well in both directions when on, and each channel has an input signal range that extends to the supplies. The primary supply voltages define the on-resistance profile, whereas the secondary supply voltages define the voltage level at which the overvoltage protection engages.When no power supplies are present, the channel remains in the off condition, and the switch inputs are high impedance. Under normal operating conditions, if the analog input signal levels on any Sx pin exceed positive fault voltage (POSFV) or negative fault voltage (NEGFV) by a threshold voltage (VT), the channel turns off and that Sx pin becomes high impedance. If the switch is selected to be on, then the drain pin is pulled to the secondary supply voltage that was exceeded. Input signal levels up to +55 V or ?55 V relative to ground are blocked, in both the powered and unpowered condition.The low capacitance and charge injection of these switches make them ideal solutions for data acquisition and sample-and-hold applications, where low glitch switching and fast settling times are required.?Note that, throughout this data sheet, multifunction pins, such as A0/F2, are referred to either by the entire pin name or by a single function of the pin, for example, A0, when only that function is relevant.?Product Highlights Source pins are protected against voltages greater than the secondary supply rails, up to ?55 V and +55 V. Source pins are protected against voltages between ?55 V and +55 V in an unpowered state. Overvoltage detection with digital output indicates operating state of switches. Trench isolation guards against latch-up. Optimized for low charge injection and on-capacitance. The ADG5248F/ADG5249F can be operated from a dual?supply of ?5 V to ?22 V or a single power supply of 8 V to 44 V.Applications Analog input/output modules Process control/distributed control systems Data acquisition Instrumentation Avionics Automatic test equipment Communication systems Relay replacement

Evaluation Kit

EVAL-ADG5412FEBZ

Analog Devices Inc.

The ADG5412F and ADG5413F contain four independently controlled single-pole/single-throw (SPST) switches. The ADG5412F has four switches that turn on with Logic 1 inputs. The ADG5413F has two switches with that turn on and two switches that turn off with Logic 1 inputs. Each switch conducts equally well in both directions when on, and each switch has an input signal range that extends to the supplies. The digital inputs are compatible with 3 V logic inputs over the full operating supply range.When no power supplies are present, the switch remains in the off condition, and the switch inputs are high impedance. Under normal operating conditions, if the analog input signal levels on any Sx pin exceed VDD or VSS by a threshold voltage, VT, then the switch turns off. Input signal levels up to +55 V or ?55 V relative to ground are blocked, in both the powered and unpowered condition.The low on resistance of these switches, combined with on-resistance flatness over a significant portion of the signal range make them an ideal solution for data acquisition and gain switching applications where excellent linearity and low distortion are critical.Product Highlights Source pins are protected against voltages greater than the supply rails, up to ?55 V and +55 V. Source pins are protected against voltages between ?55 V and +55 V, in an unpowered state. Overvoltage detection with digital output indicates operating state of switches. Trench isolation guards against latch-up. Optimized for low on resistance and on-resistance flatness. The ADG5412F/ADG5413F can be operated from a dual?supply of ?5 V up to ?22 V or a single power supply of 8 V up to 44 V.Applications Analog input/output modules Process control/distributed control systems Data acquisition Instrumentation Avionics Automatic test equipment Communication systems Relay replacement

Evaluation Kit

EVAL-ADG5436FEBZ

Analog Devices Inc.

The ADG5436 is a monolithic CMOS device containing twoindependently selectable single-pole/double-throw (SPDT)switches. An EN input on the LFCSP package enables or disablesthe device. When disabled, all channels switch off. Each switch conducts equally well in both directions when on and has aninput signal range that extends to the supplies. In the off condition,signal levels up to the supplies are blocked. Both switches exhibitbreak-before-make switching action for use in multiplexerapplications.The on-resistance profile is very flat over the full analog input range, ensuring excellent linearity and low distortion when switching audio signals.Product Highlights Trench isolation guards against latch-up. A dielectric trench separates the P and N channel transistors thereby preventing latch-up even under severe overvoltage conditions. Low RON. Dual-supply operation. For applications where the analog signal is bipolar, the ADG5436 can be operated from dual supplies up to ?22 V. Single-supply operation. For applications where the analog signal is unipolar, the ADG5436 can be operated from a single-rail power supply up to 40 V. 3 V logic compatible digital inputs: VINH = 2.0 V, VINL = 0.8 V. No VL logic power supply required.Applications Relay replacement Automatic test equipment Data acquisition Instrumentation Avionics Audio and video switching Communication systems

Evaluation Kit

EVAL-ADG918EBZ

Analog Devices Inc.

The ADG918/ADG919 are wideband switches using a CMOSprocess to provide high isolation and low insertion loss to1 GHz. The ADG918 is an absorptive (matched) switch having50 ? terminated shunt legs, whereas the ADG919 is a reflectiveswitch. These devices are designed such that the isolation ishigh over the dc to 1 GHz frequency range. They have on-boardCMOS control logic, thus eliminating the need for externalcontrolling circuitry. The control inputs are both CMOS andLVTTL compatible. The low power consumption of theseCMOS devices makes them ideally suited to wireless andgeneral-purpose high frequency switching applications.Product Highlights ?43 dB off isolation at 1 GHz. 0.8 dB insertion loss at 1 GHz. Tiny 8-lead MSOP/LFCSP.Applications Wireless communications General-purpose RF switching Dual-band applications High speed filter selection Digital transceiver front end switch IF switching Tuner modules Antenna diversity switching

Evaluation Kit

EVAL-ADGM1304SDZ

Analog Devices Inc.

The ADGM1304 is a wideband, single-pole, four-throw (SP4T) switch, fabricated using Analog Devices, Inc., microelectro-mechanical system (MEMS) switch technology. This technology enables a small form factor, wide RF bandwidth, highly linear, low insertion loss switch that is operational from 0 Hz/dc to 14 GHz, making the ADGM1304 an ideal solution for a wide range of RF and precision equipment switching needs.An integrated driver chip generates a high voltage to electrostatically actuate a switch that can be controlled by a parallel interface and a serial peripheral interface (SPI). All four switches are independently controllable.The device is packaged in a 24-lead, 5 mm ? 4 mm ? 0.95 mm, lead frame chip-scale package (LFCSP).To ensure optimum operation of the ADGM1304, the Critical Operational Requirements section must be followed exactly.The on resistance (RON) performance of the ADGM1304 is affected by device to device variation, channel to channel variation, cycle actuations, settling time post turn on, bias voltage, and temperature changes.APPLICATIONS Relay replacements Automatic test equipment: RF/high speed digital and mixed signals Load and probe boards: RF/high speed digital and mixed signals RF test instrumentation Reconfigurable filters and attenuators High performance RF switching

Evaluation Kit
