12-Bit Digital Pre-Distortion Module Receiver Subsystem Features: Fully Integrated Receiver Subsystem for Digital Pre-Distortion Applications Down-Converting Mixer with Wide RF Frequency Range: 400MHz to 3.8GHz 125MHz Wide Bandpass Filter, <0.5dB Passband Ripple Low Power ADC with Up to 12-Bit Resolution, 250Msps Sample Rate –145.5dBm/Hz Input Noise Floor, 25.6dBm IIP3 1.5W Total Power Consumption 50Ω Single-Ended RF and LO Ports Internal Bypass Capacitance, No External Components ADC Clock Duty Cycle Stabilizer 11.25mm × 15mm LGA package

14-Bit Direct Conversion Receiver Subsystem Features: Integrated Dual 14-Bit, High-Speed ADC, Lowpass Filter, Differential Gain Stages and I/Q Demodulator Lowpass Filter for Each ADC Channel 1.92MHz (LTM9004-AA) 4.42MHz (LTM9004-AB) 9.42MHz (LTM9004-AC) 20MHz (LTM9004-AD) RF Input Frequency Range: 0.7GHz to 2.7GHz 50Ω Single-Ended RF and LO Ports I/Q Gain Mismatch: 0.2dB Typical I/Q Phase Mismatch: 1.5 Deg Typical Voltage-Adjustable Demodulator DC Offsets 76dB/1.92MHz SNR (LTM9004-AA) 63.5dB SFDR (LTM9004-AA) Clock Duty Cycle Stabilizer Low Power: 1.83W Shutdown and Nap Modes 15mm × 22mm LGA Package

14-Bit Direct Conversion Receiver Subsystem Features: Integrated Dual 14-Bit, High-Speed ADC, Lowpass Filter, Differential Gain Stages and I/Q Demodulator Lowpass Filter for Each ADC Channel 1.92MHz (LTM9004-AA) 4.42MHz (LTM9004-AB) 9.42MHz (LTM9004-AC) 20MHz (LTM9004-AD) RF Input Frequency Range: 0.7GHz to 2.7GHz 50Ω Single-Ended RF and LO Ports I/Q Gain Mismatch: 0.2dB Typical I/Q Phase Mismatch: 1.5 Deg Typical Voltage-Adjustable Demodulator DC Offsets 76dB/1.92MHz SNR (LTM9004-AA) 63.5dB SFDR (LTM9004-AA) Clock Duty Cycle Stabilizer Low Power: 1.83W Shutdown and Nap Modes 15mm × 22mm LGA Package

14-Bit Direct Conversion Receiver Subsystem Features: Integrated Dual 14-Bit, High-Speed ADC, Lowpass Filter, Differential Gain Stages and I/Q Demodulator Lowpass Filter for Each ADC Channel 1.92MHz (LTM9004-AA) 4.42MHz (LTM9004-AB) 9.42MHz (LTM9004-AC) 20MHz (LTM9004-AD) RF Input Frequency Range: 0.7GHz to 2.7GHz 50Ω Single-Ended RF and LO Ports I/Q Gain Mismatch: 0.2dB Typical I/Q Phase Mismatch: 1.5 Deg Typical Voltage-Adjustable Demodulator DC Offsets 76dB/1.92MHz SNR (LTM9004-AA) 63.5dB SFDR (LTM9004-AA) Clock Duty Cycle Stabilizer Low Power: 1.83W Shutdown and Nap Modes 15mm × 22mm LGA Package

14-Bit Direct Conversion Receiver Subsystem Features: Integrated Dual 14-Bit, High-Speed ADC, Lowpass Filter, Differential Gain Stages and I/Q Demodulator Lowpass Filter for Each ADC Channel 1.92MHz (LTM9004-AA) 4.42MHz (LTM9004-AB) 9.42MHz (LTM9004-AC) 20MHz (LTM9004-AD) RF Input Frequency Range: 0.7GHz to 2.7GHz 50Ω Single-Ended RF and LO Ports I/Q Gain Mismatch: 0.2dB Typical I/Q Phase Mismatch: 1.5 Deg Typical Voltage-Adjustable Demodulator DC Offsets 76dB/1.92MHz SNR (LTM9004-AA) 63.5dB SFDR (LTM9004-AA) Clock Duty Cycle Stabilizer Low Power: 1.83W Shutdown and Nap Modes 15mm × 22mm LGA Package

14-Bit, 40Msps Low Power Octal ADCs Features:8-Channel Simultaneous Sampling ADC73dB SNR90dB SFDRLow Power: 88mW/59mW/46mW per ChannelSingle 1.8V SupplySerial LVDS Outputs: 1 or 2 Bits per ChannelSelectable Input Ranges: 1VP-P to 2VP-P800MHz Full Power Bandwidth S/HShutdown and Nap ModesSerial SPI Port for ConfigurationInternal Bypass Capacitance, No External Components140-Pin (11.25mm × 9mm) BGA Package

SmartMesh WirelessHART Mote Module (22-pin PCBA) Features: Serves as a Wireless Node, or Mote, in a SmartMesh WirelessHART network with: >99.999% Network Reliability in the Most Challenging RF Environments Sub 50µA Routing Nodes Incorporates a 2.4 GHz, IEEE 802.15.4 System-on-Chip, Complete with Embedded SmartMesh Networking Software MMCX antenna connector, 39 mm × 24.4 mm PCBA module Compliant to the WirelessHART standard (IEC62591) These products contain encryption. Import/export restrictions may apply.

SmartMesh WirelessHART Embedded Manager Features: Serves as a Network Manager in a SmartMesh WirelessHART network to Enable: >99.999% Network Reliability in the Most Challenging RF Environments Sub 50µA Routing Nodes Single Board Computer with 2.4 GHz, IEEE 802.15.4 System-on-Chip, Complete with Embedded SmartMesh Networking Software 103mm x 56mm stacked PCB assembly

Ultra Precision Reference Features: 1.2µVP-P Noise 2µV/√kHr Long Term Stability Very Low Hysteresis 0.05ppm/°C Drift Temperature Stabilized 400°C/W Thermal Resistance for LTZ1000A Reduces Insulation Requirements Specied for –55°C to 125°C Temperature Range Offered in TO-99 package

Precision Operational Amplifier Features: Guaranteed 25µV max. Offset Voltage Guaranteed 0.6µV/°C max. Offset Voltage Drift with Temperature Excellent 1.0µV/Month max. Long Term Stability Guaranteed 0.6µVP-P max. Noise Guaranteed 2.0nA max. Input Bias Current

Low Noise, High Speed Precision Operational Amplifiers Features: Guaranteed 3.8nv/√Hz max 1kHz Noise Guaranteed 35.5nv/√Hz max 10Hz Noise Very Low Peak-to-Peak Noise, 80nV Typical Guaranteed 25µV max Offset Voltage Guaranteed 0.6µV/°C max Drift with Temperature Guaranteed 11V/µsec min Slew Rate (OP-37) Guaranteed 1 Million min Voltage Gain

Low Noise, High Speed Precision Operational Amplifiers Features: Guaranteed 3.8nv/√Hz max 1kHz Noise Guaranteed 35.5nv/√Hz max 10Hz Noise Very Low Peak-to-Peak Noise, 80nV Typical Guaranteed 25µV max Offset Voltage Guaranteed 0.6µV/°C max Drift with Temperature Guaranteed 11V/µsec min Slew Rate (OP-37) Guaranteed 1 Million min Voltage Gain

High Speed, Fast Settling Precision Operational Amplifier Features:FAST  Slew Rate: 50 V/µs Min Settling Time (0.01%): 1 µs Max Gain Bandwidth Product: 10 MHz Typ Excellent Radiation HardnessPRECISE Common Mode Rejection: 88 dB Min Open Loop Gain: 500 V/mV Min Offset Voltage: 750 µV Max Bias Current: 200 pA Max Available in Die Form

Aerospace Quad High-Speed Precision Op Amp Features:High Slew Rate: 170 V/s Wide Bandwidth: 28 MHz typical Fast Settling Time Low Offset Voltage Unity-Gain Stable Low Voltage Operation: 5 V to 15 V Low Supply Current: Drives Capacitive Loads

High Speed, Low Noise Quad Operational Amplifier Features: Excellent Speed: 8 V/µs Typ Low Noise: 11 nV/√Hz @ 1 kHz Max Unity-Gain Stable High Gain Bandwidth: 6.5 MHz Typ Low Input Offset Voltage: 0.8 mV Max Low Offset Voltage Drift: 4 µV/°C Max High Gain: 500 V/mV Min Outstanding CMR: 105 dB Min Industry Standard Quad Pinouts

+5V Precision Voltage Reference/Temperature Transducer Features: High output accuracy: 5.0 V, ±0.3% maximum Adjustable output: ± 3% minimum Excellent temperature stability: 8.5 ppm/°C maximum Low noise: 15 μV p-p typical High supply voltage range: up to 36 V maximum Low supply current: 1.4 mA maximum High load-driving capability: 10 mA maximum Temperature output function

+2.5V Low Power Precision Voltage Reference Features: +2.5 Volt Output: ±0.05% Max Low Temperature Coefficient: 10 ppm/°C Max Excellent Regulation  Load Regulation: 20 ppm/mA Max Line Regulation: 2 ppm/V Max Supply Current: 450µA Max Temperature Voltage Output: +1.9mV/°C Operating Voltage Range: +4.5V to +40V Extended Industrial Temp Range: -40°C to +85°C Available in Die Form

Radiation Hardened 2.5V Reference Features: MIL-PRF-38535 Class V Compliant Version - 5962R8961002 Voltage tolerance ±5mV up to 200Krads(Si) TID Long term stability: 20ppm/kHr Low Dynamic Impedance and Wide Operating Current Range Adjust Pin For Optional Calibration of System Errors Reverse Breakdown Current: 20mA Forward Current: 10mA Available In Metal Can, Ceramic Flatpack and as Unpackaged Dice Radiation Performance Total Ionizing Dose (TID) Tolerance, per TM1019.8, MIL-STD-883: 200kRad (Si), per condition A at 50Rads(Si)/sec 50kRad (Si), per condition D at 10mRads(Si)/sec ELDRS Pass 50kRad(Si) Displacement Damage Defect (DDD) up to 1E12 Neutrons/cm2

Voltage Comparator Features:Absolute Maximum Ratings Supply Voltage (Pin 8 to Pin 4): 36V Output to Negative Supply (Pin 7 to Pin 4): 35V Ground to Negative Supply (Pin 1 to Pin 4): 30V Differential Input Voltage: ±35V Voltage at STROBE Pin (Pin 6 to Pin 8): 5V Input Voltage (Note 1): Equal to Supplies Output Short-Circuit Duration: 10 sec Operating Temperature Range  (Note 2): –55°C to 125°C Storage Temperature Range: – 65°C to 150°C Lead Temperature (Soldering, 10 sec): 300°C

UltraFast Precision 10ns Comparator Features:Absolute Maximum Ratings Positive Supply Voltage (Note 5): 7V Negative Supply Voltage: –7V Differential Input Voltage (Note 7): ±5V +IN, –IN and LATCH ENABLE Current (Note 7): ±10mA Output Current (Continuous) (Note 7): ±20mA Operating Temperature Range: –55°C to 125°C Storage Temperature Range: –65°C to 150°C Lead Temperature (Soldering, 10 sec): 300°C
