500mA High Efficiency, Low Noise, Inductorless Step-Down DC/DC Converters Features: Up to 500mA Output Current No Inductors 2.7V to 5.5V Input Voltage Range 2x Efficiency Improvement Over LDOs 2-Phase, Spread Spectrum Operation for Low Input and Output Noise Shutdown Disconnects Load from VIN Adjustable Output Voltage Range: 0.9V to 1.6V Fixed Output Voltages: 1.2V, 1.5V Super Burst, Burst and Burst Defeat Operating Modes Low Operating Current: IIN = 35µA (Burst Mode® Operation) Super Burst Operating Current: IIN = 10µA Low Shutdown Current: IIN = 0.01µA Typ Soft-Start Limits Inrush Current at Turn-On Short-Circuit and Overtemperature Protected Available in a Thermally Enhanced 10-Pin MSOP Package

1.25A, 4MHz, Synchronous Step-Down DC/DC Converter Features: High Efficiency: Up to 95% VIN Range: 2.5V to 5.5V High Frequency Operation: Up to 4MHz Selectable Low Ripple (Typical 25mVp-p) Burst Mode® Operation: IQ = 40μA Stable with Ceramic Capacitors Uses Tiny Capacitors and Inductor Low RDS(ON) Internal Switches: 0.15Ω Current Mode Operation for Excellent Line and Load Transient Response Short-Circuit Protected Low Dropout Operation: 100% Duty Cycle Low Shutdown Current: IQ ≤ 1μA Output Voltages from 0.6V to 5V Synchronizable to External Clock Supports Pre-Biased Outputs Small 10-Lead (3mm × 3mm) DFN or MSOP Package

Low IQ, 60V Synchronous Step-Down Controller Features: Wide VIN Range: 4V to 60V (65V Abs Max) Low Operating IQ: 50μA Wide Output Voltage Range: 0.8V ≤ VOUT ≤ 24V RSENSE or DCR Current Sensing Phase-Lockable Frequency (75kHz to 750kHz) Programmable Fixed Frequency (50kHz to 900kHz) Selectable Continuous, Pulse-Skipping or Low Ripple Burst Mode® Operation at Light Load Selectable Current Limit Very Low Dropout Operation: 99% Duty Cycle Adjustable Output Voltage Soft-Start or Tracking Power Good Output Voltage Monitor Output Overvoltage Protection Low Shutdown IQ: < 14μA Internal LDO Powers Gate Drive from VIN or EXTVCC No Current Foldback During Start-Up Small 20-Pin 3mm × 4mm QFN and TSSOP Packages

LTC6991 - TimerBlox: Resettable, Low Frequency Oscillator

8-Channel JFET Analog Multiplexers (Overvoltage & Power Supply Loss Protected) Features: JFET Switches Rather than CMOS Low 'ON' Resistance: 220Ω Highly Resistant to Static Discharge Damage NO SCR Latch-Up Problems 125°C Temperature Tested Dice Available MUX-08 Pin Compatible with DG508, HI-508A, IH5108, IH6108, LF11508, 12508, 13508, AD7506 See datasheet for additional features

IC A/D CONVERTER SINGLE 16-BIT HYBRID SOP 28PIN

Quad-Channel Isolators with Integrated DC/DC Converter (1/3 channel directionality) Features: isoPower integrated, isolated DC/DC converter Regulated 3.3 V or 5 V output Up to 400 mW output power Quad dc-to-25 Mbps (NRZ) signal isolation channels Schmitt trigger inputs 16-lead SOIC package with 7.6 mm creepage High temperature operation: 105°C High common-mode transient immunity: >25 kV/μs See data sheet for additional features

ADV476 - CMOS Monolithic 256 X 18 Color PALETTE RAM-DAC

16 Bit Digital to Analog Converter 4 64-QFN (9x9)

Switching Voltage Regulators 17V, 1A, 1MHz Synchronous Step-Down Regulator with Ultralow Quiescent Current

HMC-ALH444G - GaAs HEMT WBand lo Noise amp, 1 - 12 GHz

HMC284A - SPDT, Hi Isolation Switch , DC - 3.5 GHz

13 Gbps, Fast Rise Time XOR/XNOR Gate with Programmable Output Voltage and Positive Supply Features: Inputs terminated internally at 50 Differential and single-ended operation Fast rise and fall times: 21/19 ps Low power consumption: 240 mW (typical) Programmable Differential Output voltage swing: 600 mV to 1200 mV Propagation delay: 95 ps Single supply: 3.3 V 16-terminal, ceramic 3 mm 3 mm LCC package

GaAs MMIC I/Q Downconverter, 17 - 24 GHz Features: Conversion Gain: 12 dB Image Rejection: 30 dB 2 LO to RF Isolation: 45 dB Noise Figure: 3 dB Input IP3: 0 dBm 32 Lead 5x5mm SMT Package: 25mm2

Half-/Full-Bridge N-Channel Power MOSFET Drivers Features: Floating Top Driver Switches Up to 60V Drives Gate of Top N-Channel MOSFET above Load HV Supply 180ns Transition Times Driving 10,000pF Adaptive Nonoverlapping Gate Drives Prevent Shoot-Through Top Drive Protection at High Duty Cycles TTL/CMOS Input Levels Undervoltage Lockout with Hysteresis Operates at Supply Voltages from 10V to 15V Separate Top and Bottom Drive Pins

Micropower, Single Supply, Precision Op Amp Features: 60µA Max Supply Current 40µV Max Offset Voltage 350pA Max Offset Current 0.5µVp-p 0.1Hz to 10Hz Voltage Noise 2.5pAp-p 0.1Hz to 10Hz Current Noise 0.4µV/°C Offset Voltage Drift 250kHz Gain-Bandwidth Product 0.12V/µs Slew Rate Single Supply Operation Input Voltage Range Includes Ground Output Swings to Ground while Sinking Current No Pull-Down Resistors are Needed Output Sources and Sinks 5mA Load Current

1.5A, Low Noise, Fast Transient Response LDO Regulators Features: Optimized for Fast Transient Response Output Current: 1.5A Dropout Voltage: 340mV Low Noise: 40μVRMS (10Hz to 100kHz) 1mA Quiescent Current No Protection Diodes Needed Controlled Quiescent Current in Dropout Fixed Output Voltages: 1.5V, 1.8V, 2.5V, 3.3V Adjustable Output from 1.21V to 20V <1μA Quiescent Current in Shutdown Stable with 10μF Output Capacitor Reverse Battery Protection No Reverse Current Thermal Limiting 5-Lead TO-220, DD, 3-Lead SOT-223, 8-Lead SO and 16-Lead TSSOP Packages

45V VIN, Micropower, Low Noise, 100mA Low Dropout, Linear Regulator Features: Input Voltage Range: 1.6V to 45V Output Current: 100mA Quiescent Current: 40μA Dropout Voltage: 300mV Low Noise: 30μVRMS (10Hz to 100kHz) Adjustable Output: VREF = 600mV Fixed Output Voltages: 1.2V, 1.5V, 1.8V, 2.5V, 3.3V, 5V, 15V Output Tolerance: ±2% Over Line, Load and Temperature Single Capacitor Soft-Starts Reference and Lowers Output Noise Shutdown Current: < 1μA Reverse Battery Protection Current Limit Foldback Protection Thermal Limit Protection 8-Lead 2mm × 2mm × 0.75mm DFN and 8-Lead ThinSOT™ Packages AEC-Q100 Qualified for Automotive Applications

Precision, 100A Gain Selectable Amplifier Features: Pin Configurable as a Difference Amplifier, Inverting and Noninverting Amplifier Difference Amplifier Gain Range 1 to 13 CMRR >75dB Noninverting Amplifier Gain Range 0.07 to 14 Inverting Amplifier Gain Range -0.08 to -13 Gain Error <0.04% Gain Drift < 3ppm/°C Wide Supply Range: Single 2.7V to Split ±18V Micropower: 100µA Supply Current Precision: 50µV Maximum Input Offset Voltage 560kHz Gain Bandwidth Product Rail-to-Rail Output Space Saving 10-Lead MSOP and DFN Packages

Single/Dual/Quad 100V/s, 85MHz, Rail-to-Rail Input and Output Op Amps Features: Slew Rate: 100V/µs Gain Bandwidth Product: 85MHz Input Common Mode Range Includes Both Rails Output Swings Rail-to-Rail Low Quiescent Current: 3mA Max per Amplifier Large Output Current: 42mA Voltage Noise: 21nV/√Hz Power Supply Rejection: 90dB Open-Loop Gain: 60V/mV Operating Temperature Range: -40°C to 85°C Single Available in the 8-Pin SO and 5-Pin Low Profile (1mm) SOT-23 (ThinSOT™) Package Dual Available in 8-Lead DFN and SO Packages Quad Available in the 14-Pin Narrow SO Package
