2.7 V to 5.5 V, 2 ms, 10-Bit ADC in 8-Lead microSOIC/DIP Features: 10-Bit ADC with 2.3 µs Conversion Time Small Footprint 8-Lead microSOIC Package Specified Over a –40°C to +105°C Temperature Range Inherent Track-and-Hold Functionality Operating Supply Range: 2.7 V to 5.5 V Specifications at 2.7 V to 5.5 V Microcontroller-Compatible Serial Interface Optional Automatic Power-Down at End of Conversion Low Power Operation: 270 µW at 10 kSPS Throughput Rate 2.7 mW at 100 kSPS Throughput Rate Analog Input Range: 0 V to VREF Reference Input Range: 0 V to VDD

Temperature Sensor (On Chip) 4-Channel, 9 s, 10-Bit ADC Features: 10-Bit ADC with 9 µs Conversion Time The AD7816 Is a Temperature Measurement Only Device On-Chip Temperature Sensor Resolution of 0.25°C ±2°C Error from −40°C to +85°C −55°C to +125°C Operating Range Wide Operating Supply Range 2.7 V to 5.5 V On-Chip Reference (2.5 V ± 1%) Over-Temperature Indicator Automatic Power-Down at the End of a Conversion Low Power Operation 4 µW at a Throughput Rate of 10 SPS 40 µW at a Throughput Rate of 1 kSPS 400 µW at a Throughput Rate of 10 kSPS See data sheet for additional features

Temperature Sensor (On Chip) 4-Channel, 9 s, 10-Bit ADC Features: 10-Bit ADC with 9 µs Conversion Time The AD7816 Is a Temperature Measurement Only Device On-Chip Temperature Sensor Resolution of 0.25°C ±2°C Error from −40°C to +85°C −55°C to +125°C Operating Range Wide Operating Supply Range 2.7 V to 5.5 V On-Chip Reference (2.5 V ± 1%) Over-Temperature Indicator Automatic Power-Down at the End of a Conversion Low Power Operation 4 µW at a Throughput Rate of 10 SPS 40 µW at a Throughput Rate of 1 kSPS 400 µW at a Throughput Rate of 10 kSPS See data sheet for additional features

+2.7 V to +5.5 V, 200 kSPS 8-Bit Sampling ADC Features: 8-Bit ADC with 4.5 µs Conversion Time On-Chip Track and Hold Operating Supply Range: 2.7 V to 5.5 V 8-Bit Parallel Interface 8-Bit Read Analog Input Range: 0 V to VREF Reference Input Range: 1.2 V to VDD Specifications at 2.7 V–3.6 V and 5 V ± 10% Power Performance Normal Operation    10.5 mW, VDD = 3 V Automatic Power-Down    57.75 µW @ 1 kSPS, VDD = 3 V

+2.7 V to +5.5 V, 200 kSPS 8-Bit Sampling ADC Features: 8-Bit ADC with 4.5 µs Conversion Time On-Chip Track and Hold Operating Supply Range: 2.7 V to 5.5 V 8-Bit Parallel Interface 8-Bit Read Analog Input Range: 0 V to VREF Reference Input Range: 1.2 V to VDD Specifications at 2.7 V–3.6 V and 5 V ± 10% Power Performance Normal Operation    10.5 mW, VDD = 3 V Automatic Power-Down    57.75 µW @ 1 kSPS, VDD = 3 V

Complete 14-Bit CMOS DAC Features: Complete 14-Bit Voltage Output DAC Parallel and Serial Interface Capability 80 dB Signal-to-Noise Ratio Interfaces to High Speed DSP Processors e.g. ADSP-2100, TMS32010, TMS32020 45 ns min WR Pulse Width Interfaces to High Speed DSP Processors e.g. ADSP-2100, TMS32010, TMS32020 Low Power- 70 mW typ Operates from ±5 V Supplies

Complete 12-Bit CMOS Multiplying DAC Features: 12-Bit CMOS MDAC with Output Amplifier 4-Quadrant Multiplication Low Power LC2MOS Guaranteed Monotonic (Tmin to Tmax) Space-Saving 0.3' DIPS and 24- or 28- Terminal Surface Mount Packages Application Resistors On Chip for Gain Ranging, etc.

LC2MOS Complete, Dual 12-Bit MDAC, Parallel Loading Structure Features: Two 12-Bit MDACs with Output Amplifiers Space-Saving 0.3', 24-Lead DIP an 24-Terminal SOIC Package 4-Quadrant Multiplication Parallel Loading Structure: AD7847 (8+4) Loading Structure: AD7837

Simultaneous Sampling Dual 250 kSPS 12-Bit ADC Features: Two Fast 12-Bit ADCs Four Input Channels Simultaneous Sampling & Conversion 4 µs Throughput Time Single Supply Operation High Speed Parallel Interface Low Power, 60 mW typ Selection of Input Ranges: ±10 V for AD7862-10 ±2.5 V for AD7862-3 0 V to 2.5 V for AD7862-2 Power Saving Mode, 50 µW typ Overvoltage Protection on Analog Inputs 14-Bit Pin Compatible Upgrade (AD7863)

High Speed, Low Power, 4-channel Simultaneous Sampling, 12-Bit ADC Features:High speed (1.65 s) 12-bit ADC4 simultaneously sampled inputs4 track-and-hold amplifiers0.35 s track-and-hold acquisition time1.65 s conversion time per channelHW/SW select of channel sequence for conversionSingle-supply operationSelection of input ranges10 V, 5 V for AD7864-12.5 V for AD7864-3 0 V to 2.5 V, 0 V to 5 V for AD7864-2High speed parallel interface that allowsInterfacing to 3 V processorsSee data sheet for additional features

True Bipolar Input, Single Supply, Parallel, 8-Channel, 12-Bit High Speed Data Acquisition System Features: Fast 12-Bit ADC with 1.6 µs Conversion Time 8 Single-Ended Analog Input Channels Overvoltage Protection on Each Channel Selection of Input Ranges: ±5 V, ±10 V for AD7891-1 0 to +2.5 V, 0 to +5 V, ±2.5 V for AD7891-2 Parallel and Serial Interface On-Chip Track/Hold Amplifier On-Chip Reference Single-Supply, Low Power Operation (100 mW Max) Power-Down Mode (75 µW Typ)

True Bipolar Input, Single Supply, Parallel, 12-Bit 600 kSPS ADC Features: Fast 12-Bit ADC with 1.47 µs Conversion Time 600 kSPS Throughput Rate (AD7892-3) 500 kSPS Throughput Rate (AD7892-1, AD7892-2) Single Supply Operation On-Chip Track/Hold Amplifier High Speed Serial and Parallel Interface Low Power, 60 mW typ Selection of Input Ranges: ±10 V or ±5 V for AD7892-1 0 V to +2.5 V for AD7892-2 ±2.5 V for AD7892-3 Overvoltage Protection on Analog Inputs (AD7892-1 and AD7892-3)

True Bipolar Input, Single Supply, Parallel, 12-Bit 600 kSPS ADC Features: Fast 12-Bit ADC with 1.47 µs Conversion Time 600 kSPS Throughput Rate (AD7892-3) 500 kSPS Throughput Rate (AD7892-1, AD7892-2) Single Supply Operation On-Chip Track/Hold Amplifier High Speed Serial and Parallel Interface Low Power, 60 mW typ Selection of Input Ranges: ±10 V or ±5 V for AD7892-1 0 V to +2.5 V for AD7892-2 ±2.5 V for AD7892-3 Overvoltage Protection on Analog Inputs (AD7892-1 and AD7892-3)

True Bipolar Input, 5 V Single Supply, 14-Bit, Serial 4.5 s ADC in 8-Pin Package Features: Fast 14-Bit ADC with 5 µs Conversion Time 8-Lead SOIC Package Single 5 V Supply Operation High Speed, Easy-to-Use, Serial Interface On-Chip Track/Hold Amplifier High Input Impedance Selection of Input Ranges: ±10 V for AD7894-10 ±2.5 V for AD7894-3 0 V to +2.5 V for AD7894-2 Low Power: 20 mW Typ Pin Compatible Upgrade of 12-Bit AD7895

5 V Single Supply 14-Bit 400 kSPS ADC Features: Fast (2.2 µs) 14-Bit ADC 400 kSPS Throughput Rate 0.3 µs Track/Hold Acquisition Time Single Supply Operation High-Speed Parallel Interface which Also Allows Interfacing to 3 V Processors Low Power, 80 mW Typ Selection of Input Ranges: ±10 V, ±5 V and ±2.5 V 0 V to 2.5 V and 0 V to 5 V Power-Saving Mode, 20 µW Typ Overvoltage Protection on Analog Inputs Power-Down Mode via STBY Pin

Dual 600 MHz, 50 mW Current Feedback Amplifier Features: Excellent video specifications (RL = 150 Ω, G = +2) Gain flatness: 0.1 dB to 60 MHz Differential gain error: 0.01% Differential phase error: 0.02° Low power Maximum power supply current (50 mW): 5.0 mA/amp High speed and fast settling −3 dB bandwidth (G = +1): 600 MHz −3 dB bandwidth (G = +2): 500 MHz Slew rate: 1200 V/μs Settling time to 0.1%: 16 ns Low distortion THD at fC = 5 MHz: −65 dBc Third-order intercept at f1 = 10 MHz: 33 dBm SFDR at f = 5 MHz: −66 dB Crosstalk at f = 5 MHz: −60 dB High output drive Over 70 mA output current Drives up to eight back terminated 75 Ω loads (four loads/side) while maintaining good differential gain/phase performance (0.01%/0.17°) Available in 8-lead SOIC and MSOP packages

Low Distortion, High Speed Rail-to-Rail Input/Output Amplifier Features: Download AD8028-KGD Data Sheet. Available as Known Good Die and fully guaranteed to data sheet specifications. High speed 190 MHz, −3 dB bandwidth (G = +1) 100 V/µs slew rate Low distortion 120 dBc at 1 MHz SFDR 80 dBc at 5 MHz SFDR Selectable input crossover threshold Low noise 4.3 nV/√Hz 1.6 pA/√Hz Low offset voltage: 900 µV maximum Low power: 6.5 mA per amplifier supply current Power-down mode No phase reversal: VIN > |VS| + 200 mV Wide supply range: 2.7 V to 12 V Small packaging: 8-lead SOIC, 6-lead SOT-23, 10-lead MSOP Qualified for automotive applications (AD8028WARMZ-R7 only)

High Performance, 145 MHz FastFET Op Amps Features: Qualified for automotive applications FET input amplifier 1 pA input bias current Low cost High speed: 145 MHz, −3 dB bandwidth (G = +1) 180 V/µs slew rate (G = +2) Low noise 7 nV/√Hz (f = 10 kHz) 0.6 fA/√Hz (f = 10 kHz) Wide supply voltage range: 5 V to 24 V Single-supply and rail-to-rail output Low offset voltage 1.5 mV maximum High common-mode rejection ratio: −100 dB Excellent distortion specifications SFDR −88 dBc @ 1 MHz Low power: 6.4 mA/amplifier typical supply current No phase reversal Small packaging: SOIC-8, SOT-23-5, and MSOP-8 Download AD8065-KGD-CHIPS Data Sheet

Dual 260 MHz Gain = +2.0 & +2.2 Buffer Features: Factory Set Gain Gain of 2.2 Compensates for System Gain Loss Minimizes External Components Tight Control of Gain and Gain Matching (0.1%) Optimum Dual Pinout Simplifies PCB Layout Low Crosstalk of -70dB @ 5MHz Excellent Video Specifications (RL=150 ) Gain Flatness 0.1dB to 50MHz 0.01% Differential Gain Error 0.02° Differential Phase Error Low Power of 50 mW/Amplifier (5mA) High Speed and Fast Settling 260MHz, -3dB Bandwidth 750 V/µs Slew Rate (2 V Step), 800 V/µs 4 V Step) 40 ns Settling Time to 0.1% (2V Step) Low Distortion of -65dBc THD, fc=5MHz High Output Drive of Over 70mA

Low Cost, High Speed Rail-to-Rail Amplifier (Dual) Features:Low cost single (AD8091) and dual (AD8092) amplifiers Fully specified at +3 V, +5 V, and 5 V supplies Single-supply operation Output swings to within 25 mV of either rail High speed and fast settling on 5 V110 MHz, 3 dB bandwidth (G = +1)145 V/s slew rate50 ns settling time to 0.1% Good video specifications (G = +2)Gain flatness of 0.1 dB to 20 MHz; RL = 150 0.03% differential gain error; RL = 1 k0.03%differential phase error; RL = 1 kLow distortion 80 dBc total harmonic @ 1 MHz; RL = 100 Outstanding load drive capabilityDrives 45 mA, 0.5 V from supply railsDrives 50 pF capacitive load (G = +1) Low power of 4.4 mA per amplifier
