500kHz and 1MHz High Efficiency 1.5A Switching Regulators Features: Faster Switching with Increased Efficiency Uses Small Inductors: 4.7µH All Surface Mount Components Only 0.5 Square Inch of Board Space Low Minimum Supply Voltage: 2.7V Quiescent Current: 4mA Typ Current Limited Power Switch: 1.5A Regulates Positive or Negative Outputs Shutdown Supply Current: 12µA Typ Easy External Synchronization 8-Pin SO or PDIP Packages

Nanopower Precision Shunt Voltage Reference Features: Initial Voltage Accuracy: 0.05% Low Operating Current: 800nA Low Drift: 10ppm/°C Max Less Than 1 Dynamic Impedance Available in 1.25V, 2.5V, 4.096V and 5V SO-8 Packages

Nanopower Precision Shunt Voltage Reference Features: Initial Voltage Accuracy: 0.05% Low Operating Current: 800nA Low Drift: 10ppm/°C Max Less Than 1 Dynamic Impedance Available in 1.25V, 2.5V, 4.096V and 5V SO-8 Packages

Super Sequencer with Inter-chip Cascade' Bus and Nonvolatile Fault Recording Supports 4 Devices Features: Complete supervisory and sequencing solution for up to 10 supplies per device Interchip bus (ICB) simplifies multidevice connections and sequencing system operation Supports up to 4 devices 16 event deep black box nonvolatile fault recording 10 supply fault detectors enable supervision of supplies <0.5% accuracy at all voltages at 25°C <1.0% accuracy across all voltages and temperatures 5 selectable input attenuators allow supervision of supplies 14.4 V on VH and 6.0 V on VP1 to VP4 (VPx) 5 dual function inputs: VX1 to VX5 (VXx) High impedance input to supply fault detector with thresholds between 0.573 V and 1.375 V General-purpose logic input See datasheet for additional features

Hot Swap Controller and Digital Power and Energy Monitoringwith PMBus Interface Features: Controls supply voltages from 2 V to 20 V 370 ns response time to short circuit Resistor-programmable 5 mV to 25 mV current limit ±1% accurate, 12-bit ADC for current, VIN/VOUT readback Charge pumped gate drive for multiple external N-channel FETs High gate drive voltage to ensure lowest RDSON Foldback for tighter FET SOA protection Automatic retry or latch-off on current fault Programmable current-limit timer for SOA See data sheet for additional features

500 kbps, 5.7 kV RMS, Signal Isolated Half Duplex RS-485 Transceiver with 15 kV IEC ESD Features: 5.7 kV rms, signal isolated RS-485/RS-422 transceiver Low radiated emissions, passes EN55032 Class B with margin on a 2-layer PCB Cable inversion smart feature Correction for reversed cable connection on A, B, Y, and Z bus pins while maintaining full receiver fail-safe ESD protection on the RS-485 A, B, Y, and Z bus pins ≥±12 kV IEC61000-4-2 contact discharge ≥±15 kV IEC61000-4-2 air discharge Low speed 500 kbps data rate for EMI control Flexible power supply inputs Primary VDD1 supply of 1.7 V to 5.5 V Isolated VDD2 supply of 3.0 V to 5.5 V Profibus® compliant for 5 V VDD2 Wide −40°C to +125°C operating temperature range High common-mode transient immunity: >250 kV/μs Short-circuit, open-circuit, and floating input receiver fail-safe Supports 192 bus nodes (72 kΩ receiver input impedance) Full hot swap support (glitch free power-up and power-down) Safety and regulatory approvals (pending) CSA Component Acceptance Notice 5A, DIN V VDE V 0884-11, UL 1577, CQC11-471543-2012, IEC 61010-1 16-lead, wide body, SOIC_W package with >8.0 mm creepage and clearance in standard pinout

2.5 kV Signal Isolated, ESD Protected, Full/Half Duplex RS-485 Transceiver w/ Transformer Driver (16 Mbps) Features: Isolated RS-485/RS-422 transceiver, configurable as half or full duplex Integrated oscillator driver for external transformer ±15 kV ESD protection on RS485 input/output pins Complies with TIA/EIA-485-A-98 and ISO 8482:1987(E) Data rate: 16 Mbps 5 V or 3.3 V operation (VDD1) 256 nodes on bus True fail-safe receiver inputs Safety and regulatory approval UL recognition: 2500 V rms for 1 minute per UL 1577 VDE certificates of conformity DIN VVDE V 0884-10 (VDE V 0884-10):2006-12 VIORM = 560 V peak Thermal shutdown protection Operating temperature range: −40°C to +85°C Wide-body, 16-lead SOIC package

5.7 kV RMS 500kbps Full Duplex Signal and Power Isolated RS-485 Transceiver with 15 kV IEC ESD Features: 5.7 kV rms isolated RS-485/RS-422 transceiver Low radiated emissions, integrated, isolated dc-to-dc converter Passes EN 55032 Class B with margin on a 2-layer PCB Cable invert smart feature Correct reversed cable connection on A, B, Y, and Z bus pins while maintaining full receiver fail-safe feature ESD protection on RS-485 A, B, Y, and Z pins 12 kV IEC61000-4-2 contact discharge 15 kV IEC61000-4-2 air discharge High speed 25 Mbps data rate (ADM2865E/ADM2867E) Low speed 500 kbps data rate for EMI control (ADM2861E/ADM2863E) Flexible power supplies Input VCC supply of 3 V to 5.5 V Logic VIO supply of 1.7 V to 5.5 V VSEL pin to select VISO supply of 5 V (VCC > 4.5 V) or 3.3 V PROFIBUS compliant for 5 V VISO Wide operating temperature range: −40°C to +105°C High common-mode transient immunity: 250 kV/μs Short-circuit, open-circuit, and floating input receiver fail-safe Supports 192 bus nodes (72 k receiver input impedance) Full hot swap support (glitch free power-up/power-down) Safety and regulatory approvals (pending) CSA Component Acceptance Notice 5A, DIN V VDE V 0884-11, UL 1577, CQC11-471543-2012, IEC 61010-1 Complies with ANSI/TIA/EIA-485-A-98 and ISO 8482:1987(E) 28-lead, fine pitch SOIC_W package (10.15 mm 10.05 mm) with >8.0 mm creepage and clearance

3.0 V to 5.5 V, 12 kV IEC ESD Protected, Full Duplex 500 kbps RS-485 Transceiver Features: TIA/EIA RS-485 compliant over full supply range 3.0 V to 5.5 V operating voltage range on VCC 1.62 V to 5.5 V VIO logic supply option available ESD protection on the bus pins IEC 61000-4-2 ±12 kV contact discharge IEC 61000-4-2 ≥ ±12 kV air discharge HBM: ≥ ±30 kV Full hot swap support (glitch free power-up/power-down) High speed 50 Mbps data rate (ADM3065E/ADM3066E/ADM3067E) Low speed 500 kbps data rate for long cables (ADM3061E/ADM3062E/ADM3063E) Full receiver short-circuit, open circuit, and bus idle fail-safe Extended temperature range up to 125°C PROFIBUS compliant at VCC ≥ 4.5 V Half duplex and full duplex models available Allows connection of up to 128 transceivers onto the bus Space-saving package options 10-lead, 3 mm × 3 mm LFCSP 8-lead and 10-lead, 3 mm × 3 mm MSOP 8-lead and 14-lead, narrow body SOIC

3.0 V to 5.5 V, 12 kV IEC ESD Protected, 500 kbps/50 Mbps RS-485 Transceivers Features: TIA/EIA RS-485 compliant over full supply range 3.0 V to 5.5 V operating voltage range on VCC 1.62 V to 5.5 V VIO logic supply option available ESD protection on the bus pins IEC 61000-4-2 ≥ ±12 kV contact discharge IEC 61000-4-2 ≥ ±12 kV air discharge HBM ≥ ±30 kV Full hot swap support (glitch free power-up/power-down) High speed 50 Mbps data rate (ADM3065E/ADM3066E/ADM3067E/ADM3068E) Low speed 500 kbps data rate for long cables (ADM3061E/ADM3062E/ADM3063E/ADM3064E) Full receiver short-circuit, open circuit, and bus idle fail-safe Extended temperature range up to 125°C PROFIBUS compliant at VCC ≥ 4.5 V Half duplex and full duplex models available Allows connection of up to 128 transceivers onto the bus Space-saving package options 10-lead, 3 mm × 3 mm LFCSP 8-lead and 10-lead, 3 mm × 3 mm MSOP 8-lead and 14-lead, narrow body SOIC

3.0 V to 5.5 V, 12 kV IEC ESD Protected, Half Duplex 50 Mbps RS-485 Transceiver Features: TIA/EIA RS-485 compliant over full supply range 3.0 V to 5.5 V operating voltage range on VCC 1.62 V to 5.5 V VIO logic supply option available ESD protection on the bus pins IEC 61000-4-2 ±12 kV contact discharge IEC 61000-4-2 ≥ ±12 kV air discharge HBM: ≥ ±30 kV Full hot swap support (glitch free power-up/power-down) High speed 50 Mbps data rate (ADM3065E/ADM3066E/ADM3067E/ADM3068E) Low speed 500 kbps data rate for long cables (ADM3061E/ADM3062E/ADM3063E) Full receiver short-circuit, open circuit, and bus idle fail-safe Extended temperature range up to 125°C PROFIBUS compliant at VCC ≥ 4.5 V Half duplex and full duplex models available Allows connection of up to 128 transceivers onto the bus Space-saving package options 10-lead, 3 mm × 3 mm LFCSP 8-lead and 10-lead, 3 mm × 3 mm MSOP 8-lead and 14-lead, narrow body SOICSupports defense and aerospace applications (AQEC standard) Download ADM3065E-EP/ADM3066E-EP/ADM3067E-EP Data Sheet (PDF) Extended industrial temperature range: −55°C to +125°C Controlled manufacturing baseline 1 assembly/test site 1 fabrication site Product change notification Qualification data available on requestV62/19613

3.0 V to 5.5 V, 12 kV IEC ESD Protected, Full Duplex 50 Mbps RS-485 Transceiver Features: TIA/EIA RS-485 compliant over full supply range 3.0 V to 5.5 V operating voltage range on VCC 1.62 V to 5.5 V VIO logic supply option available ESD protection on the bus pins IEC 61000-4-2 ±12 kV contact discharge IEC 61000-4-2 ≥ ±12 kV air discharge HBM: ≥ ±30 kV Full hot swap support (glitch free power-up/power-down) High speed 50 Mbps data rate (ADM3065E/ADM3066E/ADM3067E/ADM3068E) Low speed 500 kbps data rate for long cables (ADM3061E/ADM3062E/ADM3063E) Full receiver short-circuit, open circuit, and bus idle fail-safe Extended temperature range up to 125°C PROFIBUS compliant at VCC ≥ 4.5 V Half duplex and full duplex models available Allows connection of up to 128 transceivers onto the bus Space-saving package options 10-lead, 3 mm × 3 mm LFCSP 8-lead and 10-lead, 3 mm × 3 mm MSOP 8-lead and 14-lead, narrow body SOIC Supports defense and aerospace applications (AQEC standard) Download ADM3065E-EP/ADM3066E-EP/ADM3067E-EP Data Sheet (PDF) Extended industrial temperature range: −55°C to +125°C Controlled manufacturing baseline 1 assembly/test site 1 fabrication site Product change notification Qualification data available on request

Hot Swappable, Dual I2C Isolators with Integrated DC-to-DC Converter Features: isoPower integrated, isolated dc-to-dc converter Regulated 3.15 V to 5.25 V output Up to 150 mW output power High common-mode transient immunity: >25 kV/μs iCoupler integrated I2C digital isolator Bidirectional I2C communication 3.0 V to 5.5 V supply/logic levels Open-drain interfaces Suitable for hot swap applications 30 mA current sink capability 1000 kHz maximum frequency 20-lead SSOP package with 5.3 mm creepage High temperature operation: 105°C See data sheet for additional features

5.7 kV RMS/1.5 kV RMS, Quad-Channel LVDS 2.5 Gigabit Isolator (0 Reverse Channels) Features: 5.7 kV rms and 1.5 kV rms LVDS isolators Complies with TIA/EIA-644-A LVDS signal levels Quad-channel configuration Any data rate up to 2.5 Gbps switching with low jitter 10 Gbps total bandwidth across four channels 2.15 ns typical propagation delay Typical jitter: 0.82 ps rms random, 40 ps total peak Lower power 1.8 V supplies ±8 kV IEC 61000-4-2 ESD protection across isolation barrier High common-mode transient immunity: 100 kV/μs typical Safety and regulatory approvals (28-lead SOIC_W_FP package) UL (pending): 5700 V rms for 1 minute per UL 1577 CSA Component Acceptance Notice 5A (pending) VDE certificate of conformity (pending) DIN V VDE V 0884-11 (VDE V 0884-11):2017-01 VIORM = 849 VPEAK (working voltage) Enable or disable refresh (low speed output correctness check) Operating temperature range: −40°C to +125°C 28-lead, wide-body, finer pitch SOIC_W_FP package with 8.3 mm creepage and clearance or 6 mm × 6 mm LFCSP package with 1.27 mm creepage and clearance

5 kV rms, 600 Mbps Dual Tx and Rx Channel LVDS Isolator Features: 5 kV rms/3.75 kV rms LVDS isolator Complies with TIA/EIA-644-A LVDS standard Multiple dual-channel configurations Up to 600 Mbps switching with low jitter 4.5 ns maximum propagation delay 151 ps maximum peak-to-peak total jitter at 600 Mbps 100 ps maximum pulse skew 600 ps maximum part to part skew 2.5 V or 3.3 V supplies −75 dBc power supply ripple rejection and glitch immunity ±8 kV IEC 61000-4-2 ESD protection across isolation barrier High common-mode transient immunity: >25 kV/μs Passes EN55022 Class B radiated emissions limits with 600 Mbps PRBS Safety and regulatory approvals (20-lead SOIC package) UL: 5000 V rms for 1 minute per UL 1577 CSA Component Acceptance Notice 5A VDE certificate of conformity DIN V VDE V 0884-10 (VDE V 0884-10):2006-12 VIORM = 424 V peak Fail-safe output high for open, short, and terminated input conditions Operating temperature range: −40°C to +125°C Choice of package and isolation options 3.75 kV rms in highly integrated 20-lead SSOP 5 kV rms in 20-lead SOIC with 7.8 mm creepage/clearance

5 kV/3.75 kV rms, 600 Mbps Dual Channel LVDS Isolator Features: 5 kV rms/3.75 kV rms LVDS isolator Complies with TIA/EIA-644-A LVDS standard Multiple dual-channel configurations Up to 600 Mbps switching with low jitter 4.5 ns maximum propagation delay 151 ps maximum peak-to-peak total jitter at 600 Mbps 100 ps maximum pulse skew 600 ps maximum part to part skew 2.5 V or 3.3 V supplies −75 dBc power supply ripple rejection and glitch immunity ±8 kV IEC 61000-4-2 ESD protection across isolation barrier High common-mode transient immunity: >25 kV/μs Passes EN55022 Class B radiated emissions limits with 600 Mbps PRBS Safety and regulatory approvals (20-lead SOIC package) UL: 5000 V rms for 1 minute per UL 1577 CSA Component Acceptance Notice 5A VDE certificate of conformity DIN V VDE V 0884-10 (VDE V 0884-10):2006-12 VIORM = 424 V peak Fail-safe output high for open, short, and terminated input conditions Operating temperature range: −40°C to +125°C Choice of package and isolation options 3.75 kV rms in highly integrated 20-lead SSOP 5 kV rms in 20-lead SOIC with 7.8 mm creepage/clearance

3.3 V, 200 Mbps, Full-Duplex, High Speed M-LVDS Transceiver Features: Full Duplex M-LVDS transceiver (driver and receiver pair) Switching rate: 200 Mbps (100 MHz) Type 1 receiver with hysteresis of 25 mV Compatible with the TIA/EIA-899 standard for M-LVDS Glitch free power-up/power-down on M-LVDS bus Controlled transition times on driver output Common-mode range: −1 V to +3.4 V, allowing communication with 2 V of ground noise Driver outputs high-Z when disabled or powered off Enhanced ESD protection on bus pins ≥±15 kV HBM, air discharge ≥±8 kV HBM, contact discharge ≥±10 kV IEC 61000-4-2, air discharge ≥±8 kV IEC 61000-4-2, contact discharge Operating junction temperature range: −40°C to +120°C 16-lead, 4 mm x 4 mm LFCSP package

Photometric Front Ends Features: Multifunction photometric front end Fully integrated AFE, ADC, LED drivers, and timing core Enables ambient light rejection capability without the need for photodiode optical filters Three 370 mA LED peak current drivers Flexible, multiple, short LED pulses per optical sample 20-bit burst accumulator enabling 20 bits per sample period On-board sample to sample accumulator, enabling up to 27 bits per data read Low power operation SPI, I2C interface, and 1.8 V analog/digital core Flexible sampling frequency ranging from 0.122Hz to 2700 Hz FIFO data operation Qualified for automotive applications

Multimodal Sensor Front End Features: Multimodal analog front end 8 input channels with multiple operation modes for various sensor measurements Dual-channel processing with simultaneous sampling 12 programmable time slots for synchronized sensor measurements Flexible input multiplexing to support differential and single-ended sensor measurements 8 LED drivers, 4 of which can be driven simultaneously Flexible sampling rate from 0.004 Hz to 9 kHz using internal oscillators On-chip digital filtering SNR of transmit and receive signal chain: 100 dB AC ambient light rejection: 60 dB up to 1 kHz 400 mA total LED peak drive current Total system power dissipation: 30 µW (combined LED and AFE power), continuous PPG measurement at 75 dB SNR, 25 Hz ODR, 100 nA/mA CTR SPI communications supported 512-byte FIFO size

100 MHz TO 2400 MHz I/Q Modulator with Integrated Fractional-N PLL and VCO Features: I/Q modulator with integrated fractional-N PLL and VCO Gain control span: 47 dB in 1 dB steps Output frequency range: 100 MHz to 2400 MHz Output IP3: 20.5 dBm at LO = 1800 MHz Noise floor: −161 dBm/Hz at LO = 1800 MHz Baseband modulation bandwidth: 600 MHz (3 dB) See datasheet for additional features
