LTC2481 16-Bit, Delta-Sigma ADC (Requires DC590)
Analog Devices Inc.DC951A: Demo Board for the LTC2481 16-Bit Delta Sigma ADC with Easy Drive Input Current Cancellation and I2C Interface.
LT6402-6 300MHz differential In/Out ADC Driver
Analog Devices Inc.DC954A-A: Demo Board for the LT6402-6 300MHz Low Distortion, Low Noise Differential Amplifier/ADC Driver (AV = 6dB).
LTC2483 16-Bit Delta-Sigma ADC Demo Board (Requires DC590)
Analog Devices Inc.DC955A: Demo Board for the LTC2483 16-Bit Delta Sigma ADC with Easy Drive Input Current Cancellation and I2C Interface.
LTC2485 24-Bit Delta-Sigma ADC Demo Board (Requires DC590)
Analog Devices Inc.DC956A: Demo Board for the LTC2485 24-Bit Delta Sigma ADC with Easy Drive Input Current Cancellation and I2C Interface.
LT6600-10 Frequency (Fc) = 10MHz
Analog Devices Inc.DC962A-C: Demo Board for the LT6600-10 Very Low Noise, Differential Amplifier and 10MHz Lowpass Filter.
LT5560EDD | Low Power Up-Converting Mixer, Input 45-190MHz, Output 850-935MHz.
Analog Devices Inc.DC963B: Demo Board for the LT5560 0.01MHz to 4GHz Low Power Active Mixer.
LT5568EUF | 900MHz I/Q Modulator
Analog Devices Inc.DC966A: Demo Board for the LT5568 700MHz to 1050MHz High Linearity Direct Quadrature Modulator.
LTC3835EFE Demo Board | 4.5V ≤ VIN ≤ 36V, VOUT = 3.3V @ 5A
Analog Devices Inc.Demonstration circuit 967B is a single output high frequency step-down DC/DC controller featuring the low quiescent current LTC3835 in a 20-pin exposed pad TSSOP package. The DC967B is designed to generate a regulated 3.3V@5A output from 4.5V to 36V input voltage.
LTC2241CUP-10 | LVDS OUT, VCC = 2.5V, 210Msps, 10-Bit, 10MHz < AIN < 250MHz (Requires DC890 & LVDS_XFMR)
Analog Devices Inc.DC997B-E - Demo Board for the LTC2241-10 10-Bit, 210Msps ADC.
LTC4261 –48V Hot Swap w/ADC (Requires DC590)
Analog Devices Inc.DC998A - Demo Board for the LTC4261 Negative Voltage Hot Swap Controllers with ADC and I2C Monitoring.
EK1HMC8200LP5M
Analog Devices Inc.The HMC8200LP5ME is a highly integrated intermediatefrequency (IF) transmitter chip that converts the industrystandard 300 MHz to 400 MHz IF input signals to an 800 MHz to4000 MHz single-ended radio frequency (RF) signal at its output.The IF transmitter chip is housed in a compact 5 mm ? 5 mmLFCSP package and supports complex modulations up to1024 QAM. The HMC8200LP5ME simultaneously reduces thedesign complexity of traditional microwave radios while realizingsignificant size and cost improvements. With IF input powerranges from ?31 dBm to +4 dBm, the HMC8200LP5MEprovides 35 dB of digital gain control in 1 dB steps and ananalog voltage gain amplifier (VGA) continuously controls thetransmitter output power from ?20 dBm to +5 dBm.The device also features three integrated power detectors. Thefirst detector (LOG_IF) can be utilized to monitor the IF inputpower. The second detector (SLPD_OUT) is a square law powerdetector that monitors the power entering the mixer. The thirdpower detector (LOG_RF) is used to monitor the output power,which can be used for fine output power adjustment.Applications Point to point communications Satellite communications Wireless microwave backhaul systemsPlease also view complementary product HMC8100, Intermediate Frequency Receiver 800 MHz - 4000 MHz
EK1HMC832ALP6G
Analog Devices Inc.The HMC832A is a 3.3 V, high performance, wideband, fractional-N, phase-locked loop (PLL) that features an integrated voltage controlled oscillator (VCO) with a fundamental frequency of 1500 MHz to 3000 MHz and an integrated VCO output divider (divide by 1, 2, 4, 6, ? 62) that enables the HMC832A to generate continuous frequencies from 25 MHz to 3000 MHz. The integrated phase detector (PD) and ?-? modulator, capable of operating at up to 100 MHz, permit wider loop bandwidths and faster frequency tuning with excellent spectral performance.Industry leading phase noise and spurious performance, across all frequencies, enable the HMC832A to minimize blocker effects, and to improve receiver sensitivity and transmitter spectral purity. A low noise floor (?160 dBc/Hz) eliminates any contribution to modulator/mixer noise floor in transmitter applications.The HMC832A is footprint compatible to the market leading HMC830 PLL with an integrated VCO. It features 3.3 V supply and an innovative programmable performance technology that enables the HMC832A to tailor current consumption and corresponding noise floor performance to individual applications by selecting either a low current consumption mode or a high performance mode for an improved noise floor performance.Additional features of the HMC832A include 12 dB of RF output gain control in 1 dB steps; an output mute function to automatically mute the output during frequency changes when the device is not locked; selectable output return loss; programmable differential or single-ended outputs, with the ability to select either output in single-ended mode; and a ?-? modulator exact frequency mode that enables users to generate output frequencies with 0 Hz frequency error; and a register configurable 3.3 V or 1.8 V serial port interface (SPI).Applications Cellular infrastructure Microwave radios WiMax, WiFi Communications test equipment CATV equipment DDS replacement Military Tunable reference sources for spurious-free performance
EKIT01-HMC1023LP5
Analog Devices Inc.The HMC1023 is a 6th order, programmable bandwidth, fully calibrated, dual low pass filter. It features programmable 0 or 10 dB gain and supports arbitrary bandwidths from 5 MHz to 72 MHz. When calibrated, the bandwidth is accurate to +/-2.5%. Built-in filter bypass option enables wider bandwidths while maintaining programmed gain and common mode control settings.Integrated ADC driver, programmable input impedance, and adjustable output common mode voltage from 0.9 V to 3 V with 2 Vppd signal, or lower than 0.9 V common mode with lower signal swing enables simple interface while achieving maximum performance. Programmable bias settings enable performance/power dissipation trade-off optimized for each application.Filter calibration is accomplished with any reference clock rate from 20 to 80 MHz. One time programmable (OTP) memory offers unsurpassed flexibility allowing the user ?set and forget? parameters like gain and bandwidth setting.Housed in a compact 5x5 mm SMT QFN package, the HMC1023 is pin and register compatible to the existing HMC900 programmable bandwidth Low Pass Filter. It requires minimal external components and provides a low cost alternative to more complicated switched discrete filter architectures.The 6th order Butterworth transfer function delivers superior stop band rejection while maintaining both a flat passband and minimal group delay variation.Applications Baseband filtering before or after?data converters for point-to-point fixed?wireless and cellular infrastructure?transceivers Software defined radio applications Anti-aliasing and reconstruction filters Test and measurement equipment ADC driver applications
LTC1422 | 2.7V to 12V 8-Pin Hot Swap Controller
Analog Devices Inc.DC1357A: Demo Board for the LTC1422 Hot Swap Controller
DC1366B
Analog Devices Inc.The LTC4266 is a quad PSE controller designed for use in IEEE 802.3 Type 1 and Type 2 (high power) compliant Power over Ethernet systems. External power MOSFETs enhance system reliability and minimize channel resistance, cutting power dissipation and eliminating the need for heatsinks even at Type 2 power levels. External power components also allow use at very high power levels while remaining otherwise compatible with the IEEE standard. 80V-rated port pins provide robust protection against external faults.The LTC4266 includes advanced power management features, including current and voltage readback and programmable ICUT and ILIM thresholds. Available C libraries simplify power-management software development; an optional AUTO pin mode provides fully IEEE-compliant standalone operation with no software required. Proprietary 4-point PD detection circuitry minimizes false PD detection while supporting legacy phone operation. Midspan operation is supported with built-in 2-event classification and backoff timing. Host communication is via a 1MHz I2C serial interface.The LTC4266 is available in a 5mm ? 7mm QFN package that significantly reduces board space compared with competing solutions. A legacy-compatible 36-pin SSOP package is also available.Applications High Power PSE Switches/Routers High Power PSE Midspans
LTC2260-14 | 14-Bit, 105Msps ADC, CMOS Outputs, 5-170MHz, Requires DC890 and DC1075
Analog Devices Inc.DC1370A-B: Demo Board for the LTC2260-14 14-Bit, 105Msps Ultra-Low Power 1.8V ADCs
LTC2261-12 | 12-Bit, 125Msps ADC, CMOS Outputs, 5-170MHz, Requires DC890 and DC1075
Analog Devices Inc.DC1370A-G: Demo Board for the LTC2261-12 12-Bit, 125Msps Ultralow Power 1.8V ADCs
DC1370A-L
Analog Devices Inc.The LTC2258-12/LTC2257-12/LTC2256-12 are sampling 12-bit A/D converters designed for digitizing high frequency, wide dynamic range signals. They are perfect for demanding communications applications with AC performance that includes 71.1dB SNR and 88dB spurious free dynamic range (SFDR). Ultralow jitter of 0.17psRMS allows undersampling of IF frequencies with excellent noise performance.DC specs include ?0.3LSB INL (typical), ?0.1LSB DNL (typical) and no missing codes over temperature. The transition noise is a low 0.3LSBRMS.The digital outputs can be either full rate CMOS, double data rate CMOS, or double data rate LVDS. A separate output power supply allows the CMOS output swing to range from 1.2V to 1.8V.The ENC+ and ENC? inputs may be driven differentially or single-ended with a sine wave, PECL, LVDS, TTL or CMOS inputs. An optional clock duty cycle stabilizer allows high performance at full speed for a wide range of clock duty cycles. Bits LTC2256-12 12 LTC2256-14 14 Applications Communications Cellular Base Stations Software Defined Radios Portable Medical Imaging Multi-Channel Data Acquisition Nondestructive Testing
DC1372A
Analog Devices Inc.The LTM8023 is a complete 2A, DC/DC step-down power supply. Included in the package are the switching controller, power switches, inductor, and all support components. Operating over an input voltage range of 3.6V to 36V, the LTM8023 supports an output voltage range of 0.8V to 10V, and a switching frequency range of 200kHz to 2.4MHz, each set by a single resistor. Only the bulk input and output filter capacitors are needed to finish the design.The low profile package enables utilization of unused space on the bottom of PC boards for high density point of load regulation.The LTM8023 is packaged in a thermally enhanced, compact and low profile over-molded land grid array (LGA) and ball grid array (BGA) packages suitable for automated assembly by standard surface mount equipment. The LTM8023 is available with SnPb (BGA) or RoHS compliant terminal finish.Applications Automotive Battery Regulation Power for Portable Products Distributed Supply Regulation Industrial Supplies Wall Transformer Regulation
DC1374B
Analog Devices Inc.The LTM4616 is a complete dual 2-phase 8A per channel switch mode DC/DC power regulator system in a 15mm ? 15mm surface mount LGA or BGA package. Included in the package are the switching controller, power FETs, inductor and all support components. Operating from an input voltage range of 2.7V to 5.5V, the LTM4616 supports two outputs within a voltage range of 0.6V to 5V, each set by a single external resistor. This high efficiency design delivers up to 8A continuous current (10A peak) for each output. Only bulk input and output capacitors are needed, depending on ripple requirement. The part can also be configured for a 2-phase single output at up to 16A.The low profile package enables utilization of unused space on the back side of PC boards for high density point-ofload regulation.Fault protection features include overvoltage protection, overcurrent protection and thermal shutdown. The power module is offered in space saving and thermally enhanced 15mm ? 15mm ? 2.82mm LGA and 15mm ? 15mm ? 3.42mm BGA packages. The LTM4616 is available with SnPb (BGA) or RoHS compliant terminal finish.Applications Telecom, Networking and Industrial Equipment Storage and ATCA, PCI Express Cards Battery Operated Equipment
