The EBV designed MercuryCode reference board supports the Cyclone III EP3C40-type FPGA with doubled the logic elements for designs with greatly increased complexity: but at a reasonable price point. The board supports multiple interfaces making it suitable to prototype a wide range of industrial applications.

Virtex™-II Design 1 - Module-based (PTHxxxx series) Power Management Solution Providing ICCINT = 6 A from VIN = 3.3 V.

This reference design is for a concept demonstration of how a driver's pulse rate: respiration rate: and ECG based heart rate can be obtained from a vehicle steering wheel. AFE4400 and AFE4300 from TI's biometric family of analog front-ends (AFE): enables acquisition of all three parameters via simple hand contacts on the steering wheel. This reference design also includes a full BLE connectivity design for easy interface to BLE enabled smartphones: tablets: etc

This design is a digitally controlled: two phase interleaved: 700W power factor correction converter with added power metering functionality. A C2000™ Piccolo™ microcontroller is the controller for the two 180 ° phase shifted boost power stages that comprise the power factor correction converter: and: additionally: it monitors the line and neutral voltage waveforms to implement power metering functions. This design is able to achieve 97% efficiency and 1.5% THD at full load with power factor greater than 0.98. By minimizing power loss in the power stage: reducing reliability impacts of harmonic distortion: and providing near unity power factor: this design is a great choice for off-line applications and AC/DC power supplies.

This is a dual-phase: synchronous buck converter with an input voltage range of 33V-to-55Vin and an output of 28Vout@14A.

This PMP4507 delivers 3.3V@3A or 5V@2A from a PoE source: standard 13W limit. The converter accepts also an external voltage from an adapter ranging 12V to 54V input.

The TIDA-00262 Reference Design is a high speed serial video interface to connect a remote automotive camera module to a display or machine vision processing system. It uses TIs FPD-Link III SerDes technology to transmit uncompressed MegaPixel video data: bidirectional control signals and power either over shielded twisted pair or coax cable.

PMP5140 is a single-phase synchronous switching regulator accepting input voltages of 3.3Vin or 12Vin and providing an output voltage of 1.2Vout capable of supplying 10A of current.

Design features low component count and low cost isolated flyback: converting the universal mains (85Vac…275Vac) to 5.2V@200mA. Due to primary side regulation of the controller UCC28700: no optocoupler is needed to close the loop.

30W telecom active clamp forward converter w/ 4-bit VID i/f to modulate output voltage in a range 26Vdc to 33Vdc

PMP2844 uses two UCC2897s to generate two isolated outputs from 36V – 72V. The 3.3V at 20A converter uses an active clamp forward topology with synchronous rectifiers. The 15V at 1.5A converter uses a flyback topology. Both converters are operating at 200KHz to keep the efficiency high.

TI's optimized solution for power regulation: distribution: and sequencing for Intel SkyLake™ Processor platform. Utilizing high efficiency DC/DC switching regulators and integrated load switches: this design demonstrates regulation of four unique power rails and distribution of 21 different points-of-load. Significant reduction in board area is accomplished with quad-channel load switches and high-efficiency: integrated DC/DC step-down converters. Furthermore: hybrid I2C/GPIO control reduces or eliminates GPIO requirements: thereby simplifying PCB layout. This design operates with an input voltage range of 4.5V to 15V: simulating 2S/3S Li-Ion battery topologies. A PC-based GUI controls on-board power components over a standard USB cable. Real-time power delivery status feedback is provided via on-board LEDs as well as PC graphics.

The CC25XX Folded Dipole reference design contains schematics and layout files for a CC2500EM with a folded dipole PCB antenna. This antenna requires maximum two capacitors in the matching network and can be used together with the following products; CC2500: CC2510: CC2511 and CC2511The reference design shows the dimensions of the antenna and how it should be connected to the radio. For more information about antenna dimensions and performance please see Design Note 004.

The CC1101-CC1190EM 869MHz reference design contains schematics and layout files for the CC1101-CC1190EM 869MHz evaluation module. The reference design demonstrates good techniques for CC1101-CC1190 decoupling and RF layout. For optimum RF performance: these parts should be copied accurately. This is a 4-layer reference design with a discrete balun and an SMA antenna connector designed for a single ended 50 ohm antenna. The RF section has been designed and characterized for operation in the 869.4 - 869.65 MHz frequency sub-band (g3): but can also be used for other frequencies in the European 863 - 870 MHz band.

PMP8877 is a full-function 1/8th brick isolated DC/DC telecom power module based on the UCD3138 digital power controller. The reference design features secondary side control and hard switching full bridge power topology to deliver 12V/180W of output power operating across a wide range 36V-72V input source. The highlights of the reference design include 94% peak efficiency: fast input voltage feedforward response to input voltage surges: constant current/constant power overload protection: pre-bias start-up: current sharing control for paralleled module applications and PMBUS support for communication with peer controllers. The bias supply block employs the UCC25230: while the gate drivers used in this design include UCC27524 for driving the SR MOSFETs and UCC27211 for driving the primary side Half-Bridge MOSFETs. Other components include the ISO7240 for sending signals across the isolation barrier.

This design uses low cost primary side regulation (PSR) IC UCC28700 with a SiC-FET for 300VDC-800VDC input range. Four outputs with separated grounds: 25V/19W: 25V/17W: 25V/10.1W: and 25V/8W are generated.

80W non synchronous boost converter to generate 32V out of 24V

The PMP7022 is 1mW (3.1V at 300uA) galvanic isolated DC/DC reference design built to supply a MSP430 metering unit. The design utilising again MSP430 open loop push-pull stage. Very efficient design with current supply (inclusive load current) as low as 800uA. Input voltage range: 3.1VDC-3.3VDC; Output current: 300uA; Output voltage: 3.1VDC

This TI Precision Verified Design provides the theory: component selection: simulation: PCB design: and measurement details for a single ended input to differential output circuit which converts a single ended input of +0.1V to +2.4V into a differential output of ± 2.3V on a single +2.7V supply. The output range is intentionally limited to maximize linearity. The circuit is composed of 2 amplifiers. One amplifier acts as a buffer and creates a voltage: Vout+. The second amplifier inverts the input and adds a reference voltage to generate Vout-. Both Vout+ and Vout- range from 0.1V to 2.4V. The difference: Vdiff: is the difference between Vout+ and Vout-. This makes the differential output voltage range +2.3V.

This design demonstrates high power density 3A sync-buck converter solution using TPS54478. The input voltage range is 3-6V. The overall form factor is 15.5mmx7.8mm.
