Search results

Res Thin Film 0805 487 Ohm 1% 1/5W ±50ppm/°C Conformal SMD Melf T/R

FPGA Spartan-7 Family 52160 Cells 28nm Technology 1V 324-Pin CSBGA Tray

The SHARC ADSP-21488 is one of two new members of the fourth generation of SHARC® Processors that now includes the ADSP-21486, ADSP-21487, ADSP-21488, ADSP-21489 and offers increased performance, hardware-based filter accelerators, audio and application-focused peripherals, and new memory configurations capable of supporting the latest surround-sound decoder algorithms. All devices are pin-compatible with each other and completely code-compatible with all prior SHARC Processors. These newest members of the fourth generation SHARC Processor family are based on a single-instruction, multiple-data (SIMD) core, which supports both 32-bit fixed-point and 32-/40-bit floating-point arithmetic formats making them particularly suitable for high-performance audio applications.The ADSP-21488 offers the highest performance–400 MHz/2400 MFLOPs–in an LQFP package within the fourth generation SHARC Processor family. This level of performance makes the ADSP-21488 particularly well suited to address the automotive audio and industrial control segments. In addition to its high core performance, the ADSP-21488 includes additional processing blocks such as FIR, IIR, and FFT accelerators to increase the total performance of the system. There is a new feature called Variable Instruction Set Architecture (VISA) that allows the code size to be decreased by 20% to 30% and increase the memory size availability. The fourth generation DSP allows the ability to connect to external memory by providing a glueless interface to 16-bit wide SDR SDRAMs. Fourth-generation SHARC Processors also integrate application-specific peripherals designed to simplify hardware design, minimize design risks, and ultimately reduce time to market. Grouped together, and broadly named the Digital Applications Interface (DAI), these functional blocks may be connected to each other or to external pins via the software-programmable Signal Routing Unit (SRU). The SRU is an innovative architectural feature that enables complete and flexible routing amongst DAI blocks. Peripherals connected through the SRU include but are not limited to serial ports, IDP, S/PDIF Tx/Rx, and an 8-Channel asynchronous sample rate converter block. The fourth generation SHARC allows data from the serial ports to be directly transferred to external memory by the DMA controller. Other peripherals such as SPI,UART and Two-Wire Interface are routed through a Digital Peripheral Interface (DPI).

The ADA4433-1 is a differential output, fully integrated video reconstruction filter that combines overvoltage protection (short-to-battery [STB] protection) and short-to-ground (STG) protection on the outputs, with excellent video specifications and low power consumption. The combination of STB protection and robust ESD tolerance allows the ADA4433-1 to provide superior protection in the hostile automotive environment.The ADA4433-1 is a fully differential video filter that can be used as a fully differential input to a differential output or as a single-ended input to a differential output, allowing it to easily connect to both differential and single-ended sources. It is capable of driving twisted pair or coaxial cable with minimal line attenuation. Differential signal processing reduces the effects of ground noise, which can plague ground referenced systems. The ADA4433-1 is ideal for differential signal processing (gain and filtering) throughout the signal chain, simplifying the conversion between single-ended and differential components.The short-to-battery protection integrated into the ADA4433-1 protects against both dc and transient overvoltage events, caused by an accidental short to a battery voltage up to 18 V. The Analog Devices, Inc., short-to-battery protection eliminates the need for large output coupling capacitors and other complicated circuits used to protect standard video amplifiers, saving space and cost.The ADA4433-1 features a high-order filter with −3 dB cutoff frequency response at 10 MHz and 45 dB of rejection at 27 MHz. The ADA4433-1 featurea an internally fixed gain of 2 V/V. This makes the ADA4433-1 ideal for SD video applications, including NTSC and PAL.The ADA4433-1 operates on single supplies as low as 2.6 V and as high as 3.6 V while providing the dynamic range required by the most demanding video systems.The ADA4433-1 is offered in an 8-lead, 3 mm × 3 mm LFCSP package, rated for operation over the wide automotive temperature range of −40°C to +125°C.Appplications Automotive rearview cameras Automotive video electronic control units (ECUs) Surveillance video systems

Inductor RF Chip 3.6nH 0.3nH 100MHz 300mA 0402

PRESS XDCR M5601-001205-05KPS Wireless High Pressure Transducer | Part Number: M5601-001205-05KPS | Internal Number: 20014471-18 | TE Connectivity

Evaluation Module, TPS65056 Step Down Controller

Cap Ceramic 0.0018uF 50V C0G 5% Radial 2.5mm 125°C Bulk

BCR129 - Digital Transistor

Encoders INCR ENC, S, MECH, 12 PPR 12 DET, 5 Vdc, A/B, 2-bit, SW, 5 mm tbush 20 x 6 mm F shaft, vertical

Conn Unshrouded Header HDR 8 POS 2.54mm Solder ST Thru-Hole

MEMS Oscillator Low Power LVCMOS -40C-105C 25ppm 3.2x2.5mm

LM281B+ PRO 5000K 80CRI VK Quarter bin

TPS53015EVM-126

SMD Power Inductor

Cap Ceramic 0.68uF 25V X7R 10% SMD 1206 125°C Embossed T/R

Cap Ceramic 0.01uF 50V X7R 20% Radial 2.54mm 125°C T/R

Res Thick Film NET 820K Ohm 2% 1.28W ±100ppm/°C BUS Molded 16-Pin SOM Gull Wing SMD Tube

FPGA Kintex UltraScale 580440 Cells 20nm Technology 0.95V 1156-Pin FC-BGA

The ADuM520x are dual channel digital isolators with isoPower, an integrated, isolated dc-to-dc converter. Based onthe Analog Devices, Inc., iCoupler® technology, the dc-to-dcconverter provides up to 500 mW of regulated, isolated powerwith 5.0 V input and 5.0 V output voltage, or 200 mW of power with 3.3 V input and 3.3 V output voltage. This eliminates the need for a separate isolated dc-to-dc converter in low power isolated designs. The Analog Devices chip scale transformer iCoupler technology is used for the isolation of the logic signals as well as for the dc-to-dc converter. The result is a small form factor, total isolation solution.ADuM520x units may be used in combination with ADuM5401, ADuM5402, ADuM5403, ADuM5404 and ADuM5000 with isoPower® to achieve higher output power levels and greater channel counts (see the Increasing Available Power section).The ADuM520x isolators provide two independent isolationchannels in a variety of channel configurations and data rates(see the Ordering Guide for options).isoPower uses high frequency switching elements to transfer power through its transformer. Special care must be taken during printed circuit board (PCB) layout to meet emissionsstandards. Refer to the AN-0971 application note for details on board layout recommendations.APPLICATIONS RS-232/RS-422/RS-485 transceiver Industrial field bus isolation Power supply startups and gate drives Isolated sensor interfaces Industrial PLCs
