Description
GreenPAK Programmable Mixed-signal Matrix
The SLG46620 provides a small, low power component for commonly used mixed-signal functions. The user creates their circuit design by programming the one time Non-Volatile Memory (NVM) to configure the interconnect logic, the I/O Pins and the macro cells of the SLG46620. This highly versatile device allows a wide variety of mixed-signal functions to be designed within a very small, low power single integrated circuit.
Features:
- Logic & Mixed Signal Circuits
- Highly Versatile Macrocells
- Read Back Protection (Read Lock)
- 1.8V (±5%) to 5V (±10%) Supply
- Operating Temperature Range: -40°C to 85°C
- RoHS Compliant / Halogen-Free
Macrocells Overview:
- 8-bit Successive Approximation Register Analog-to-Digital Converter (SAR ADC)
- ADC 3-bit Programmable Gain Amplifier (PGA)
- Two Digital-to-Analog Converters (DAC)
- Six Analog Comparators (ACMP)
- Two Voltage References (Vref)
- Twenty Five Combinatorial Look Up Tables (LUTs)
- Eight 2-bit LUTs
- Sixteen 3-bit LUTs
- One 4-bit LUT
- One Combination Function Macrocells
- Pattern Generator or 4-bit LUT
- Three Digital Comparators/Pulse Width Modulators (DCMPs /PWMs) w/ Selectable Deadband
- Ten Counters / Delays (CNT/DLY)
- Two 14-bit Delay/Counter
- One 14-bit Delay/Counter (Wake-Sleep Control)
- One 14-bit Delay/Counter/Finite State Machine
- Five 8-bit Delay/Counter
- One 8-bit Delay/Counter/Finite State Machine
- Twelve D Flip-flops/Latches
- Two Pipe Delays - 16 stage/2 output
- Two Bandgaps
- Two Programmable Delays w/ Edge Detection
- Three Internal Oscillators
- Low-Frequency
- Ring
- RC 25 kHz and 2 MHz
- Power-On-Reset (POR)
- Slave SPI
Applications:
- Personal Computers and Servers
- PC Peripherals
- Consumer Electronics
- Data Communications Equipment
- Handheld and Portable Electronics
