Renesas Electronics Corporation
MCU 16-Bit RL78/G1x RL78 CISC 256KB Flash 1.8V/2.5V/3.3V/5V 44-Pin LQFP Tray
Low Power, High Function, General Purpose Microcontrollers for Motor Control, Industrial and Metering Applications
RL78/G14 microcontrollers balance the industry's lowest level of consumption current (CPU: 66 μA/MHz, standby (STOP): 240 nA) and a high calculation performance of 51.2 DMIPS (32 MHz). The built-in high-function timer supports three-phase motor control using three-phase complementary PWM output. They have an on-chip oscillator, data flash, A/D and D/A converters, comparator, and more. Built-in safety features (function that detects illegal operation of hardware) enable support for the household appliance safety standard (IEC/UL 60730). With a broad 30 to 100-pin lineup and up to 512 KB on-chip flash memory, these microcontrollers can be used in a wide variety of applications such as motor control and consumer and industrial equipment.
Features:
CPU: RL78 core, Max. 32MHz
Voltage: 1.6V to 5.5V
Package: 32 to 48-pin HWQFN, 48 to 100-pin LFQFP, 32 to 100-pin LQFP, 30-pin LSSOP, 36 to 64-pin WFLGA
Memory: SRAM Max. 48KB, Program Flash Max. 512KB
Timer: 16-bit Timer (ch) x 8, 8-bit Timer (ch) x 8, Watchdog Timer (ch) x 1, 12-bit Interval Timer x 1 ch
PWM: PWM Output x 13, 3-phase PWM Output Function
Analog function: 10-bit A/D Converter (ch) x 9, 8-bit D/A Converter (ch) x 2
On-chip Oscillator Freq. (MHz): High-Speed: 64, 48, 32, 24, 16, 12, 8, 6, 4, 3, 2, 1MHzLow-speed: 15kHz
Others: RTC, Power-On Reset, Low Voltage Detection
Applications:
Industrial Sensing with IO-Link Interface
HVAC Humidity Sensor
HVAC Air Quality Sensor
Air Quality Control for IoT Building Automation
Refrigerator Compressor Digital Inverter
Electric Vehicle (EV) Charger
Biosensing with Wireless Charging and Bluetooth
Refrigerator Odor Detector
High-End Electric Fan with BLDC Control
Battery Management System
In-Home Air Quality Monitor System
Modbus ASCII/RTU Slave Board
USB-PD with Turbo Boost
LoRaWAN-Based Gas Meter
Sensor Signal Conditioner to Linearize Results
Cordless Single-Phase BLDC Hand Blender
Pure Sine Wave Home Inverter
LoRa-based Solutions for RL78 Family
