GAS DISCHARGE TUBE 3P 600V; DC Breakover Voltage:350V; Impulse Discharge Current:20kA; Impulse Sparkover Voltage:600V; GDT Case Style:Axial Leaded; Series:T23-A350X

THERMISTOR NTC 10KOHM RADIAL; Zero Power Resistance at 25 C:10kohm; Product Range:B57871S Series; Beta Value (K):3460K; Thermistor Mounting:Through Hole; Thermistor Case Style:-; Thermistor Terminals:Radial Leaded

THERMISTOR PTC 4.6 OHM 3225; Product Range:B59201 Series; Zero Power Resistance at 25 C:4.6ohm; Thermistor Mounting:SMD; Operating Voltage Max:30V; Applications:Over Current Protection Short Circuit Protection; No. of Pins:2Pins

B82559 Series 1.1 uH 10 % Tolerance 20 A Shielded SMT Power Inductor

VARISTOR 395V 7mm DISC; Voltage Rating VAC:150V; Voltage Rating VDC:200V; Product Range:AdvanceD Series; Clamping Voltage Vc Max:395V; Varistor Case Style:Disc 7mm; Peak Surge Current @ 8/20 S:1.2kA; Operating Temperature Min:-40 C

CAPACITOR POLYPROPYLENE PP FILM 0.1UF 1250V 10% RADIAL; Capacitance:0.1 F; Capacitor Dielectric Type:PP (Polypropylene); Voltage Rating:1250V; Product Range:B32653 Series; Capacitance Tolerance: 10%; Packaging:Each

NTC THERMISTOR; Product Range:B57235S0 S; NTC THERMISTOR; Product Range:B57235S0 Series; Disc Size:9.5mm; Zero Power Resistance at 25 C:10ohm; Approvals:UL; Maximum Energy Rating at 25 C:-; Maximum Steady State Current at 25 C:3A; Beta Value (K):2900K; No. of Pins:2

CAP ALU ELEC 8200UF 25V SNAP IN; Capacitance:8200µF; Voltage Rating:25V; Product Range:B41231 Series; Lifetime @ Temperature:2000 hours @ 85°C; Capacitance Tolerance:± 20%; Capacitor Terminals:Quick Connect Snap-In; Diameter:22mm; Lead Spacing:10mm; Operating Temperature Min:-40°C; Operating Temperature Max:85°C; Height:35mm; ESR:-; Automotive Qualification Standard:-; SVHC:No SVHC (15-Jun-2015); Capacitance Tolerance ±:± 20%; Operating Temperature Range:-40°C to +85°C

CAP ALU ELEC 10000UF 63V SNAP IN; Capacitance:10000µF; Voltage Rating:63V; Product Range:B41231 Series; Lifetime @ Temperature:2000 hours @ 85°C; Capacitance Tolerance:± 20%; Capacitor Terminals:Quick Connect Snap-In; Diameter:30mm; Lead Spacing:10mm; Operating Temperature Min:-40°C; Operating Temperature Max:85°C; Height:50mm; ESR:-; Automotive Qualification Standard:-; SVHC:No SVHC (15-Jun-2015); Capacitance Tolerance ±:± 20%; Operating Temperature Range:-40°C to +85°C

CAP ALU ELEC 56000UF 10V SNAP IN; Capacitance:56000µF; Voltage Rating:10V; Product Range:B41252 Series; Lifetime @ Temperature:2000 hours @ 105°C; Capacitance Tolerance:± 20%; Capacitor Terminals:Quick Connect Snap-In; Diameter:35mm; Lead Spacing:10mm; Operating Temperature Min:-40°C; Operating Temperature Max:105°C; Height:45mm; ESR:-; Automotive Qualification Standard:-; SVHC:No SVHC (15-Jun-2015); Capacitance Tolerance ±:± 20%; Operating Temperature Range:-40°C to +105°C

CAP ALU ELEC 47000UF 16V SNAP IN; Capacitance:47000µF; Voltage Rating:16V; Product Range:-; Lifetime @ Temperature:2000 hours @ 105°C; Capacitance Tolerance:± 20%; Capacitor Terminals:Quick Connect Snap-In; Diameter:35mm; Lead Spacing:10mm; Operating Temperature Min:-40°C; Operating Temperature Max:105°C; Height:45mm; ESR:-; Automotive Qualification Standard:-; SVHC:No SVHC (15-Jun-2015); Capacitance Tolerance ±:± 20%; Operating Temperature Range:-40°C to +105°C

CAP ALU ELEC 8200UF 16V SNAP IN; Capacitance:8200µF; Voltage Rating:16V; Product Range:B41252 Series; Lifetime @ Temperature:2000 hours @ 105°C; Capacitance Tolerance:± 20%; Capacitor Terminals:Quick Connect Snap-In; Diameter:22mm; Lead Spacing:10mm; Operating Temperature Min:-40°C; Operating Temperature Max:105°C; Height:25mm; ESR:-; Automotive Qualification Standard:-; SVHC:No SVHC (15-Jun-2015); Capacitance Tolerance ±:± 20%; Operating Temperature Range:-40°C to +105°C

CAP ALU ELEC 22000UF 25V SCREW; Capacitance:22000µF; Voltage Rating:25V; Product Range:-; Lifetime @ Temperature:12000 hours @ 85°C; Capacitance Tolerance:± 20%; Capacitor Terminals:Screw; Diameter:35.7mm; Lead Spacing:-; Operating Temperature Min:-40°C; Operating Temperature Max:85°C; Height:55.7mm; ESR:0.025ohm; Automotive Qualification Standard:-; SVHC:No SVHC (15-Jun-2015); Capacitance Tolerance ±:± 20%; Operating Temperature Range:-40°C to +85°C

CAP ALU ELEC 2200UF 400V SCREW; Capacitance:2200µF; Voltage Rating:400V; Product Range:B43456 Series; Lifetime @ Temperature:12000 hours @ 85°C; Capacitance Tolerance:± 20%; Capacitor Terminals:Screw; Diameter:51.6mm; Lead Spacing:-; Operating Temperature Min:-40°C; Operating Temperature Max:85°C; Height:105.7mm; ESR:0.03ohm; Automotive Qualification Standard:-; SVHC:No SVHC (15-Jun-2015); Capacitance Tolerance ±:± 20%; Operating Temperature Range:-40°C to +85°C

CORE RM4 T38 5000 +40%-30%; Core Type:RM; Core Size:RM4; Core Material Grade:T38; For Use With:-; Effective Magnetic Path Length:17.3mm; Ae Effective Cross Section Area:14.5mm²; Inductance Factor Al:5µH; Product Range:-; SVHC:No SVHC (15-Jun-2015); Accessory Type:Ferrite Core; Material Grade:T38

THERMISTOR PTC 63V RADIAL LEADED; Product Range:B59910 Series; Zero Power Resistance at 25°C:5.6ohm; Thermistor Mounting:Through Hole; Operating Voltage Max:80V; Applications:Over Current Protection Short Circuit Protection; Operating Temperature Min:-40°C; Operating Temperature Max:125°C; Automotive Qualification Standard:-; SVHC:No SVHC (15-Jun-2015); No. of Pins:2Pins; Resistance:5.6ohm; Thermistor Case Style:Radial Leaded; Thermistor Tolerance:-25% to +25%; Thermistor Type:PTC

INDUCTOR 220NH 240MA 5% FULL REEL; Product Range:B82498B Series; Inductance:220nH; DC Current Rating:240mA; High Frequency Inductor Case:0805 [2012 Metric]; Inductor Construction:Wirewound; DC Resistance Max:0.55ohm; Inductance Tolerance:± 5%; Self Resonant Frequency Min:950MHz; Packaging:Tape & Reel; SVHC:No SVHC (15-Jun-2015); Core Material:Ceramic; Inductor Case Style:0805 [2012 Metric]; Q Factor:35; Q Test Frequency:100MHz; Reel Quantity:3000

INDUCTOR 47NH 0.5A 5% FULL REEL; Product Range:-; Inductance:47nH; DC Current Rating:500mA; High Frequency Inductor Case:0805 [2012 Metric]; Inductor Construction:Wirewound; DC Resistance Max:0.13ohm; Inductance Tolerance:± 5%; Self Resonant Frequency Min:1.9GHz; Packaging:Tape & Reel; SVHC:No SVHC (15-Jun-2015); Core Material:Ceramic; Inductor Case Style:0805 [2012 Metric]; Q Factor:45; Q Test Frequency:200MHz; Reel Quantity:3000

INDUCTOR 100UH 370MA 5% FULL REEL; Product Range:-; Inductance:100µH; DC Current Rating:370mA; DC Resistance Max:1.7ohm; Inductance Tolerance:± 5%; Self Resonant Frequency Min:5MHz; Packaging:Tape & Reel; SVHC:No SVHC (15-Jun-2015); Current Rating:370mA; Inductor Case Style:Axial Leaded; No. of Pins:2Pins; Q Factor:70; Q Test Frequency:796kHz; Reel Quantity:5000

CAP FILM 1UF 900VAC SCREW; Capacitance:1µF; Voltage Rating VAC:900V; Capacitor Dielectric Type:PP (Polypropylene); Capacitance Tolerance:± 10%; Product Range:-; Capacitor Case Style:Can; Capacitor Terminals:Screw; Lead Spacing:-; Operating Temperature Min:-25°C; Operating Temperature Max:85°C; Packaging:Each; Automotive Qualification Standard:-; SVHC:No SVHC (15-Jun-2015); Capacitance Tolerance ±:± 10%; Operating Temperature Range:-25°C to +85°C; Voltage Rating:900VAC
