VARISTOR, AEC-Q200, 40V, MLV, 1210 ROHS COMPLIANT: YES

CAPACITORS

VARISTOR 0603 14VDC; Voltage Rating V AC:11V; Voltage Rating V DC:14V; Product Range:CT Series; Clamping Voltage Vc Max:35V; Varistor Case Style:0603 [1608 Metric]; Varistor Type:Multilayer Varistor (MLV); Peak Surge Current @ 8/20µs:30A; Operating Temperature Min:-55°C; Operating Temperature Max:85°C; Peak Energy (10/1000uS):200mJ; Automotive Qualification Standard:-; SVHC:No SVHC (15-Jun-2015); Capacitance:100pF; Clamping Current Max:1A; Clamping Voltage:35V; Clamping Voltage @ 8/20µs Max:35V; Operating Temperature Range:-55°C to +85°C; Packaging:Cut Tape; Peak Pulse Current IPP @ 8/20µs:30A; Power Dissipation Ptot Max:0.003W; Suppressor Type:Varistor; Surge Current:30A; Transient Energy:0.2J; Varistor Voltage:18V; Varistor Voltage @ 1mA:16.2V; Varistor Voltage @ 1mA Max:19.8V; Varistor Voltage Tolerance +:10%; Varistor Voltage Tolerance -:10%

VARISTOR 0603 26VDC; Voltage Rating V AC:20V; Voltage Rating V DC:26V; Product Range:-; Clamping Voltage Vc Max:56V; Varistor Case Style:0603 [1608 Metric]; Varistor Type:Multilayer Varistor (MLV); Peak Surge Current @ 8/20µs:30A; Operating Temperature Min:-55°C; Operating Temperature Max:85°C; Peak Energy (10/1000uS):200mJ; Automotive Qualification Standard:-; SVHC:No SVHC (15-Jun-2015); Capacitance:90pF; Clamping Current Max:1A; Clamping Voltage:56V; Clamping Voltage @ 8/20µs Max:56V; Operating Temperature Range:-55°C to +85°C; Packaging:Cut Tape; Peak Pulse Current IPP @ 8/20µs:30A; Power Dissipation Ptot Max:0.003W; Suppressor Type:Varistor; Surge Current:30A; Transient Energy:0.2J; Varistor Voltage:33V; Varistor Voltage @ 1mA:29.7V; Varistor Voltage @ 1mA Max:36.3V; Varistor Voltage Tolerance +:10%; Varistor Voltage Tolerance -:10%

VARISTOR 1206 56VDC; Voltage Rating V AC:40V; Voltage Rating V DC:56V; Product Range:-; Clamping Voltage Vc Max:110V; Varistor Case Style:1206 [3216 Metric]; Varistor Type:Multilayer Varistor (MLV); Peak Surge Current @ 8/20µs:100A; Operating Temperature Min:-55°C; Operating Temperature Max:125°C; Peak Energy (10/1000uS):500mJ; Automotive Qualification Standard:-; SVHC:No SVHC (15-Jun-2015); Capacitance:250pF; Clamping Current Max:1A; Clamping Voltage:110V; Clamping Voltage @ 8/20µs Max:110V; Operating Temperature Range:-55°C to +125°C; Packaging:Cut Tape; Peak Pulse Current IPP @ 8/20µs:100A; Power Dissipation Ptot Max:0.008W; Suppressor Type:Varistor; Surge Current:100A; Transient Energy:0.5J; Varistor Voltage:68V; Varistor Voltage @ 1mA:61.2V; Varistor Voltage @ 1mA Max:74.8V; Varistor Voltage Tolerance +:10%; Varistor Voltage Tolerance -:10%

INDUCTOR KIT B82464 SERIES; Kit Contents:Power Inductors; Product Range:-; SVHC:No SVHC (15-Jun-2015); External Depth:150mm; External Width:250mm; Height:30mm; Range of Inductor Values:16 Values of 1µH to 1mH

INDUCTOR 22UH 20% 2.25A 13MHZ; Product Range:B82464G4 Series; Inductance:22µH; RMS Current (Irms):2.25A; Saturation Current (Isat):2.5A; Inductor Construction:Shielded; DC Resistance Max:0.052ohm; Power Inductor Case:10.4mm x 10.4mm x 4.8mm; Inductance Tolerance:± 20%; Packaging:Cut Tape; SVHC:No SVHC (15-Jun-2015); Climatic Category:55/125/56; External Depth:10.4mm; External Length / Height:4.8mm; External Width:10.4mm; Inductance Measurement Frequency:0.1MHz; Inductor Type:Power Inductor; No. of Pins:2Pins; Operating Temperature Max:125°C; Operating Temperature Min:-55°C; Reel Quantity:750; Resonant Frequency:13MHz; Self Resonant Frequency Min:20MHz; Tape Width:16mm; Termination Type:Surface Mount Device; Tolerance +:20%

IN STOCK SHIP TODAY

INDUCTOR 10UH 690MA 10% 2220; Product Range:B82442A Series; Inductance:10µH; DC Current Rating:690mA; High Frequency Inductor Case:2220 [5650 Metric]; Inductor Construction:Wirewound; DC Resistance Max:0.168ohm; Inductance Tolerance:± 10%; Self Resonant Frequency Min:19MHz; Packaging:Cut Tape; SVHC:No SVHC (15-Jun-2015); Approval Category:IEC 286PT3; External Depth:5mm; External Length / Height:5mm; External Width:5.6mm; Inductor Case Style:2220 [5650 Metric]

THERMISTOR NTC 100K; Zero Power Resistance at 25°C:100kohm; Product Range:B57621C Series; Beta Value (K):3950K; Thermistor Mounting:SMD; Thermistor Case Style:1206 [3216 Metric]; Thermistor Terminals:-; Operating Temperature Min:-55°C; Operating Temperature Max:125°C; Automotive Qualification Standard:-; SVHC:No SVHC (15-Jun-2015); Resistance:100kohm; Thermistor Tolerance:-5% to +5%; Thermistor Type:NTC

INDUCTOR 1210 CASE 4.7UH; Product Range:-; Inductance:4.7µH; DC Current Rating:150mA; High Frequency Inductor Case:1210 [3225 Metric]; Inductor Construction:Wirewound; DC Resistance Max:2.2ohm; Inductance Tolerance:± 10%; Self Resonant Frequency Min:110MHz; Packaging:Cut Tape; SVHC:No SVHC (15-Jun-2015); Approval Category:IEC 286PT3; External Depth:2.5mm; External Length / Height:1.9mm; External Width:3.2mm; Inductor Case Style:1210 [3225 Metric]

CAPACITOR 47000UF 40V; Capacitance:47000µF; Voltage Rating:40V; Product Range:-; Lifetime @ Temperature:3000 hours @ 105°C; Capacitance Tolerance:± 20%; Capacitor Terminals:Screw; Diameter:51.6mm; Lead Spacing:22.2mm; Operating Temperature Min:-40°C; Operating Temperature Max:105°C; Height:105mm; ESR:0.012ohm; Automotive Qualification Standard:-; SVHC:No SVHC (15-Jun-2015); Capacitance Tolerance ±:± 20%; Climatic Category:40/105/56; External Length / Height:105.7mm; Impedance:10mohm; No. of Pins:2Pins; Operating Temperature Range:-40°C to +105°C; Operating life Time:3000h; Ripple Current AC:14A; Ripple Current Temperature:105°C; Tolerance +:20%; Tolerance -:20%; Voltage Rating V DC:40V

CAP ALU ELEC 22000UF 100V SCREW; Capacitance:22000µF; Voltage Rating:100V; Product Range:B41560 Series; Lifetime @ Temperature:3000 hours @ 105°C; Capacitance Tolerance:± 20%; Capacitor Terminals:Screw; Diameter:76.9mm; Lead Spacing:31.7mm; Operating Temperature Min:-40°C; Operating Temperature Max:105°C; Height:105mm; ESR:0.01ohm; Automotive Qualification Standard:-; SVHC:No SVHC (15-Jun-2015); Capacitance Tolerance ±:± 20%; Climatic Category:40/105/56; External Length / Height:105.7mm; Impedance:11mohm; No. of Pins:2Pins; Operating Temperature Range:-40°C to +105°C; Operating life Time:3000h; Ripple Current AC:17A; Ripple Current Temperature:105°C; Tolerance +:20%; Tolerance -:20%; Voltage Rating V DC:100V

CAP ALU ELEC 68000UF 25V SCREW; Capacitance:68000µF; Voltage Rating:25V; Product Range:B41456 Series; Lifetime @ Temperature:12000 hours @ 85°C; Capacitance Tolerance:± 20%; Capacitor Terminals:Screw; Diameter:51.6mm; Lead Spacing:22.2mm; Operating Temperature Min:-40°C; Operating Temperature Max:85°C; Height:80.7mm; ESR:0.012ohm; Automotive Qualification Standard:-; SVHC:No SVHC (15-Jun-2015); Capacitance Tolerance ±:± 20%; Climatic Category:40/085/56; External Length / Height:80.7mm; Impedance:9.3mohm; No. of Pins:2Pins; Operating Temperature Range:-40°C to +85°C; Operating life Time:12000h; Ripple Current AC:13A; Ripple Current Temperature:85°C; Tolerance +:20%; Tolerance -:20%; Voltage Rating V DC:25V

CAP FILM PET 0.22UF 100V RADIAL; Capacitance:0.22µF; Voltage Rating V DC:100V; Capacitor Dielectric Type:PET (Polyester); Capacitance Tolerance:± 5%; Product Range:B32520 Series; Capacitor Case Style:-; Capacitor Terminals:Radial Leaded; Lead Spacing:7.5mm; Operating Temperature Min:-55°C; Operating Temperature Max:125°C; Packaging:Each; Automotive Qualification Standard:-; SVHC:No SVHC (12-Jan-2017)

CAP FILM PET 1UF 250V RADIAL; Capacitance:1µF; Voltage Rating V DC:250V; Capacitor Dielectric Type:PET (Polyester); Capacitance Tolerance:± 5%; Product Range:B32522 Series; Capacitor Case Style:-; Capacitor Terminals:Radial Leaded; Lead Spacing:15mm; Operating Temperature Min:-55°C; Operating Temperature Max:125°C; Packaging:Each; Automotive Qualification Standard:-; SVHC:No SVHC (12-Jan-2017)

CAP FILM PET 4700PF 100V RADIAL; Capacitance:4700pF; Voltage Rating V DC:100V; Capacitor Dielectric Type:PET (Polyester); Capacitance Tolerance:± 5%; Product Range:B32529 Series; Capacitor Case Style:-; Capacitor Terminals:Radial Leaded; Lead Spacing:5mm; Operating Temperature Min:-55°C; Operating Temperature Max:125°C; Packaging:Each; Automotive Qualification Standard:-; SVHC:No SVHC (12-Jan-2017)

CAP FILM PET 0.01UF 630V RADIAL; Capacitance:0.01µF; Voltage Rating V DC:630V; Capacitor Dielectric Type:PET (Polyester); Capacitance Tolerance:± 5%; Product Range:B32529 Series; Capacitor Case Style:-; Capacitor Terminals:Radial Leaded; Lead Spacing:5mm; Operating Temperature Min:-55°C; Operating Temperature Max:125°C; Packaging:Each; Automotive Qualification Standard:-; SVHC:No SVHC (12-Jan-2017)

CAP FILM PP 0.68UF 630V RADIAL; Capacitance:0.68µF; Voltage Rating V DC:630V; Capacitor Dielectric Type:PP (Polypropylene); Capacitance Tolerance:± 10%; Product Range:B32654 Series; Capacitor Case Style:-; Capacitor Terminals:Radial Leaded; Lead Spacing:27.5mm; Operating Temperature Min:-55°C; Operating Temperature Max:110°C; Packaging:Each; Automotive Qualification Standard:-; SVHC:No SVHC (12-Jan-2017)

CAP SUP X2 PP 0.047UF 305V RAD; Capacitance:0.047µF; Suppression Class:X2; Voltage Rating X:305V; Voltage Rating Y:-; Capacitor Dielectric Type:PP (Polypropylene); Capacitance Tolerance:± 10%; Product Range:B32921C Series; dv/dt Rating:475V/µs; Capacitor Case Style:-; Capacitor Terminals:Radial Leaded; Operating Temperature Min:-40°C; Operating Temperature Max:110°C; Packaging:Each; Automotive Qualification Standard:-; SVHC:No SVHC (12-Jan-2017); Voltage Rating V AC:305V
