SSR 75A 24-690VAC; Contact Configuration:-; Load Current:75A; Operating Voltage Max:690Vrms; Relay Mounting:Panel; Relay Terminals:Screw; Switching Mode:Zero Crossing; Operating Voltage Min:24Vrms; Control Voltage Min:3.5VDC; Control Voltage Max:32VDC; Product Range:-; SVHC:No SVHC (07-Jul-2017); Control Current Max:13mA; Control Current Min:10mA; Control Voltage AC Max:690VAC; Control Voltage AC Min:24VAC; Control Voltage DC Max:32VDC; Control Voltage DC Min:3.5VDC; Control Voltage Range:3.5V DC to 32V DC; Control Voltage Type:DC; Isolation Voltage:4kV; Load Current Min:5mA; Load Current RMS Max:75A; Load Voltage DC Max:32V; Load Voltage DC Min:3.5VDC; Operating Voltage Range:24Vrms to 690Vrms; Output Type:Thyristor; Output Voltage Max:690V; Output Voltage Min:24V; Peak Load Voltage +:1600V; RMS Load Current Min:5mA; Surge Current:1200A

Single phase Power Solid State Relay Output: 12-280VAC 25A

Single phase Power Solid State Relay Output: 12-280VAC 25A

Single phase Power Solid State Relay Output: 50-265VAC 125A

Single phase Power Solid State Relay Output: 24-600VAC 50A

Single phase Power Solid State Relay Output: 12-275VAC 25A

Single phase Power Solid State Relay Output: 24-510VAC 50A

Single phase Power Solid State Relay Output: 24-510VAC 50A

Power Solid State Relay Output: 12A/12-280VAC

SSR 25A; Contact Configuration:-; Load Current:25A; Operating Voltage Max:275VAC; Relay Mounting:Panel; Relay Terminals:Screw; Switching Mode:Zero Crossing; Operating Voltage Min:12VAC; Control Voltage Min:3VDC; Control Voltage Max:32VDC; Product Range:-; SVHC:No SVHC (07-Jul-2017); Control Voltage DC Max:32VDC; Control Voltage DC Min:3VDC; Control Voltage Range:3V DC to 32V DC; Control Voltage Type:DC; External Depth:91mm; External Length / Height:70mm; External Width:22.5mm; Isolation Voltage:4kV; Load Current RMS Max:25A; Operating Temperature Max:80°C; Operating Temperature Min:-40°C; Operating Voltage Range:12V AC to 275V AC; RMS Load Current Min:0.05A; RMS Load Voltage Max:275V; RMS Load Voltage Min:12V; Surge Current:250A

Single phase Power Solid State Relay Output: 24-600VAC 75A

SSR 35A; Contact Configuration:-; Load Current:35A; Operating Voltage Max:600Vrms; Relay Mounting:Panel; Relay Terminals:Screw; Switching Mode:Zero Crossing; Operating Voltage Min:24Vrms; Control Voltage Min:3.5VDC; Control Voltage Max:32VDC; Product Range:SU Series; SVHC:No SVHC (07-Jul-2017); Control Voltage DC Max:32VDC; Control Voltage DC Min:3.5VDC; Control Voltage Range:3.5V DC to 32V DC; Control Voltage Type:DC; External Depth:91mm; External Length / Height:70mm; External Width:22.5mm; Isolation Voltage:4kV; Load Current RMS Max:32A; Operating Temperature Max:80°C; Operating Temperature Min:-40°C; Operating Voltage Range:24Vrms to 600Vrms; RMS Load Current Min:0.05A; RMS Load Voltage Max:600V; RMS Load Voltage Min:24V; Surge Current:400A

SSR 25A; Contact Configuration:-; Load Current:25A; Operating Voltage Max:275VAC; Relay Mounting:DIN Rail; Relay Terminals:Screw; Switching Mode:Zero Crossing; Operating Voltage Min:12VAC; Control Voltage Min:3VDC; Control Voltage Max:32VDC; Product Range:-; SVHC:No SVHC (07-Jul-2017); Control Voltage DC Max:32VDC; Control Voltage DC Min:3VDC; Control Voltage Range:3V DC to 32V DC; Control Voltage Type:DC; External Depth:91mm; External Length / Height:70mm; External Width:22.5mm; Load Current RMS Max:20A; Operating Temperature Max:80°C; Operating Temperature Min:-40°C; Operating Voltage Range:12V AC to 275V AC; Peak Surge Current:250A; RMS Load Current Min:0.05A; RMS Load Voltage Max:275V; RMS Load Voltage Min:12V; Surge Current:250A

Single phase Power Solid contactor Output: 24-600VAC 32A (*)

Single phase Power Solid contactor Output: 24-600VAC 35A (*)

RELAY DIN RAIL 4A; Contact Configuration:-; SVHC:No SVHC (17-Dec-2015); Load Current:4A; Relay Mounting:DIN Rail; Relay Terminals:Screw; Operating Voltage Min:12Vrms; Operating Voltage Max:275Vrms; Control Voltage Min:15VDC; Control Voltage Max:30VDC; Switching Mode:Zero Crossing; Product Range:-; Control Voltage AC Max:30VAC; Control Voltage AC Min:15VAC; Control Voltage DC Max:30VDC; Control Voltage DC Min:15VDC; Control Voltage Range:15V AC to 30V AC 15V DC to 30V DC; Control Voltage Type:AC DC; Current Rating:4A; External Width:11.5mm; Input Voltage Max:280VAC; Input Voltage Min:12VAC; Load Current Min:5mA; Load Current RMS Max:4A; Operating Temperature Max:80°C; Operating Temperature Min:-40°C; Operating Voltage Range:12Vrms to 275Vrms; Output Type:Triac; Peak Surge Current:100A; RMS Load Current Min:5mA; RMS Load Voltage Max:275VAC; RMS Load Voltage Min:12VAC

Solid State Relay for DIN rail fixation Output: 4A/ 230VAC

Solid State Relay for DIN rail fixation Output: 4A/ 230VAC

Solid State Relay for DIN rail fixation Output: 4A/ 400VAC

one phase SSR
