SOLID STATE RELAY 4-30V 85A PANEL; Contact Configuration:-; Load Current:85A; Operating Voltage Max:640VAC; Relay Mounting:Panel; Relay Terminals:Screw; Switching Mode:Zero Crossing; Operating Voltage Min:24VAC; Control Voltage Min:4VDC; Control Voltage Max:30VDC; Product Range:cel3pac SGB Series; SVHC:No SVHC (15-Jan-2018)

SOLID STATE RELAY 4-30V 42A PANEL; Contact Configuration:-; Load Current:42A; Operating Voltage Max:520VAC; Relay Mounting:Panel; Relay Terminals:Connector Screw; Switching Mode:Zero Crossing; Operating Voltage Min:24VAC; Control Voltage Min:4VDC; Control Voltage Max:30VDC; Product Range:cel3pac SGT Series; SVHC:No SVHC (15-Jan-2018)

SOLID STATE RELAY 24-255V 64A PANEL; Contact Configuration:-; Load Current:64A; Operating Voltage Max:520VAC; Relay Mounting:Panel; Relay Terminals:Screw; Switching Mode:Zero Crossing; Operating Voltage Min:24VAC; Control Voltage Min:24V; Control Voltage Max:255V; Product Range:cel3pac SGT Series; SVHC:No SVHC (15-Jan-2018)

SOLID STATE RELAY 4-30V 42A PANEL; Contact Configuration:-; Load Current:42A; Operating Voltage Max:640VAC; Relay Mounting:Panel; Relay Terminals:Screw; Switching Mode:Zero Crossing; Operating Voltage Min:24VAC; Control Voltage Min:4VDC; Control Voltage Max:30VDC; Product Range:cel3pac SGT Series; SVHC:No SVHC (15-Jan-2018)

SOLID STATE RELAY 24-255V PANEL; Contact Configuration:-; Load Current:17A; Operating Voltage Max:520VAC; Relay Mounting:Panel; Relay Terminals:Connector Spring; Switching Mode:Zero Crossing; Operating Voltage Min:24VAC; Control Voltage Min:24V; Control Voltage Max:255V; Product Range:sightpac SMT Series; SVHC:No SVHC (15-Jan-2018)

SOLID STATE RELAY 4-30V 54A PANEL; Contact Configuration:-; Load Current:54A; Operating Voltage Max:660VAC; Relay Mounting:Panel; Relay Terminals:Screw; Switching Mode:Zero Crossing; Operating Voltage Min:24VAC; Control Voltage Min:4VDC; Control Voltage Max:30VDC; Product Range:cel3pac SGT Series; SVHC:No SVHC (15-Jan-2018)

CABLE 10M FOR PW SERIES; Connector Type A:-; Connector Type B:-; Cable Length - Metric:10m; Cable Length - Imperial:32.81ft; Product Range:-; SVHC:No SVHC (07-Jul-2017); Accessory Type:Cable; For Use With:PW Series Sensors

SOLID STATE RELAY HIGH CURRENT KIT; Accessory Type:Power Connection; For Use With:Celduc OKPAC Series Solid State Relays; Product Range:- ;RoHS Compliant: Yes

Single phase Power Solid State Relay Output: 24-510VAC 35A

Single phase Power Solid State Relay Output: 12-280VAC 12A

RELAY SINGLE PHASE 40A 30V; Contact Configuration:-; Load Current:40A; Operating Voltage Max:280Vrms; Relay Mounting:Panel; Relay Terminals:Screw; Switching Mode:Zero Crossing; Operating Voltage Min:12Vrms; Control Voltage Min:4VDC; Control Voltage Max:30VDC; Product Range:-; SVHC:No SVHC (07-Jul-2017); Contact Voltage AC Max:600V; Control Voltage AC Max:280VAC; Control Voltage AC Min:12VAC; Control Voltage DC Max:30VDC; Control Voltage DC Min:4VDC; Control Voltage Range:4V DC to 30V DC; Control Voltage Type:DC; External Depth:27mm; External Length / Height:58.2mm; External Width:44.5mm; Isolation Voltage:4kV; Load Current Min:5mA; Load Current RMS Max:40A; Operating Temperature Max:100°C; Operating Temperature Min:-40°C; Operating Voltage Range:12Vrms to 280Vrms; RMS Load Current Min:5mA; RMS Load Voltage Max:230V; Resistance:1000ohm; Resistance Temperature:90°C; Response Time Off Max:10ms; Response Time On Max:10ms

RELAY SINGLE PHASE 50A 30V; Contact Configuration:-; Load Current:50A; Operating Voltage Max:520Vrms; Relay Mounting:Panel; Relay Terminals:Screw; Switching Mode:Zero Crossing; Operating Voltage Min:24Vrms; Control Voltage Min:5VDC; Control Voltage Max:30VDC; Product Range:-; SVHC:No SVHC (07-Jul-2017); Contact Voltage AC Max:1200V; Control Voltage AC Max:520VAC; Control Voltage AC Min:24VAC; Control Voltage DC Max:30VDC; Control Voltage DC Min:5VDC; Control Voltage Range:5V DC to 30V DC; Control Voltage Type:DC; External Depth:27mm; External Length / Height:58.2mm; External Width:44.5mm; Isolation Voltage:4kV; Load Current Min:5mA; Load Current RMS Max:50A; Operating Temperature Max:100°C; Operating Temperature Min:-40°C; Operating Voltage Range:24Vrms to 520Vrms; RMS Load Current Min:5mA; RMS Load Voltage Max:400V; Resistance:1000ohm; Resistance Temperature:90°C; Response Time Off Max:10ms; Response Time On Max:10ms; Surge Current:550A

Power Solid State Relay Output: 125A/400VAC

Power Solid State Relay Output: 50A/230VAC

Power Solid State Relay Output: 25A/400VAC

Power Solid State Relay Output: 50A/400VAC

DC Solid State Relay Output: 15A/200VDC

Power Solid State Relay Output: 25A/230VAC

RELAY SOLID STATE 4-30VDC 10A; Contact Configuration:-; Load Current:10A; Operating Voltage Max:280Vrms; Relay Mounting:Panel; Relay Terminals:Quick Connect; Switching Mode:Zero Crossing; Operating Voltage Min:12Vrms

SSR PA 22A/400V; Contact Configuration:-; Load Current:22A; Operating Voltage Max:450Vrms; Relay Mounting:DIN Rail; Relay Terminals:Screw; Switching Mode:Analogue; Operating Voltage Min:160Vrms; Control Voltage Min:-; Control Voltage Max:10VDC; Product Range:-; SVHC:No SVHC (07-Jul-2017); Control Voltage AC Max:450VAC; Control Voltage AC Min:160VAC; Control Voltage DC Max:10VDC; Control Voltage Range:0V DC to 10V DC; Control Voltage Type:DC; Isolation Voltage:4kV; Load Current Min:5mA; Load Current RMS Max:32A; Operating Temperature Max:100°C; Operating Temperature Min:-40°C; Operating Voltage Range:160Vrms to 450Vrms; Output Type:Voltage; Output Voltage Max:450V; Output Voltage Min:160V; Peak Load Voltage +:1200V; Peak Surge Current:550A; RMS Load Current Min:100mA; Surge Current:1200A
