10-Bit, 1 MSPS, Low-Power A/D Converter in SC70 and MSOP Packages Features: Fast throughput rate: 1 MSPS Specified for VDD of 2.35 V to 5.25 V Low power 3.6 mW at 1 MSPS with 3 V supplies 12.5 mW at 1 MSPS with 5 V supplies Wide input bandwidth 71 dB SNR at 100 kHz input frequency No pipeline delays Flexible power/serial clock speed management High speed serial interface SPI/QSPI™/MICROWIRE/DSP compatible Standby mode: 1 µA maximum 6-lead SC70 package 8-lead MSOP Qualified for automotive applications

400 MSPS 10-Bit DAC 1.8 V CMOS Direct Digital Synthesizer Features: 400 MSPS internal clock speed Integrated 10-bit DAC 32-bit tuning word Phase noise ≤ –120 dBc/Hz at 1 kHz offset (DAC output) Excellent dynamic performance >75 dB SFDR at 160 MHz (±100 kHz offset) AOUT Serial input/output (I/O) control 1.8 V power supply Software and hardware controlled power-down 48-lead TQFP/EP package PLL REFCLK multiplier (4× to 20×) Internal oscillator; can be driven by a single crystal Phase modulation capability Multichip synchronization

CMOS,12-Bit, Monolithic Multiplying DAC Features: Improved version of the obsoleted product, AD7541 Full 4 quadrant multiplication 12-bit linearity (endpoint) All parts guaranteed monotonic TTL/CMOS compatible Protection Schottky diodes not required Low logic input leakage

Precision 12-Bit CMOS Multiplying IOUT DAC, 4-Bit Bus Features: Resolution: 12 Bits Nonlinearity: ±1/2 LSB Tmin to Tmax Low Gain Drift: 2ppm/°C typ, 5ppm/°C max Microprocessor Compatible Full 4-Quadrant Multiplication Fast Interface Timing Low Power Dissipation: 40 mW max Low Cost Small Size: 16-pin DIP and 20-Terminal Surface Mount Package Latch Free (Protection Schottky Not Required)

10-Bit, 8-Channel, 350 kSPS, Serial A/D Converter Features: 10-Bit ADC with 2.3 µs Conversion Time The AD7812 has Eight Single-Ended Inputs that Can Be Configured as Seven Pseudo Differential Inputs with Respect to a Common, or as Four Independent Pseudo Differential Channels Onboard Track and Hold Onboard Reference 2.5 V ± 2.5% Operating Supply Range: 2.7 V to 5.5 V Specifications at 2.7 V-3.6 V and 5 V ± 10% DSP-/Microcontroller-Compatible Serial Interface High Speed Sampling and Automatic Power-Down Modes Package Address Pin on the AD7811 and AD7812 Allows Sharing of Serial Bus in Multipackage Applications Input Signal Range: 0 V to VREF Reference Input Range: 1.2 V to VDD

10-Bit, 8-Channel, 350 kSPS, Serial A/D Converter Features: 10-Bit ADC with 2.3 µs Conversion Time The AD7812 has Eight Single-Ended Inputs that Can Be Configured as Seven Pseudo Differential Inputs with Respect to a Common, or as Four Independent Pseudo Differential Channels Onboard Track and Hold Onboard Reference 2.5 V ± 2.5% Operating Supply Range: 2.7 V to 5.5 V Specifications at 2.7 V-3.6 V and 5 V ± 10% DSP-/Microcontroller-Compatible Serial Interface High Speed Sampling and Automatic Power-Down Modes Package Address Pin on the AD7811 and AD7812 Allows Sharing of Serial Bus in Multipackage Applications Input Signal Range: 0 V to VREF Reference Input Range: 1.2 V to VDD

CMOS 12-Bit Buffered Multiplying DAC With Onboard Data Latches Features: 12-Bit Resolution Low Gain TC: 2ppm/°C typ Fast TTL Compatible Data Latches Small 20-Lead 0.3" DIP and 20-Terminal Surface Mount Packages Single +5 V to +15 V Supply Latch Free (Schottky Protection Diode not Required) Low Cost Ideal for Battery Operated Equipment

Dual 12-Bit CMOS DAC with Parallel Load Input Structure Features: Two 12-bit DACs in One Package DAC Ladder Resistance Matching: 0.5% Space Saving Skinny DIP and Suface Mount Packages 4-Quadrant Multiplication Low Gain Error (1 LSB max Over Temperature) Fast Interface Timing

LC2MOS Complete, High Speed 12-Bit ADC Features:Improved AD7572Faster Conversion Time- AD7572AXX03: 3 s- AD7572AXX10: 10 s5 V and -12 V or -15 V Power Supply OperationBetter Offset and Gain Error Specifications Extended Plastic Temperature Range (-40C to +85C) Low Power: 100 mW Small 24-Pin, 0.3' Wide DIP and SOIC DIP Packages

LC2MOS Complete, High Speed 12-Bit ADC Features:12-Bit Resolution and AccuracyFast Conversion Time- AD7572XX06: 5 µs- AD7572XX12: 12.5 µsComplete with On-Chip ReferenceFast Bus Access Time: 90 nsLow Power: 135 mWSmall, 0.3', 24-Pin Package and28-Terminal Surface Mount Packages

CMOS, 5s 8-Bit Sampling ADC Features: Fast Conversion Time: 5 µs On-Chip Track/Hold Low Total Unadjusted Error: 1 LSB Full Power Signal Bandwidth: 50 kHz Single +5 V Supply 100 ns Data Access Time Low Power (15 mW typ) Low Cost Standard 18-Lead DlPs or 20-Terminal Surface Mount Packages

16-Bit, 100 kSPS PulSAR Unipolar ADC with Ref Features: 2.5 V Internal Reference:  Typical Drift 3 ppm/°C - Guaranteed Max Drift: 15 ppm/°C Throughput: 100 kSPS INL: ±2.5 LSB Max (±0.0038% of Full Scale) 16 Bits Resolution with No Missing Codes S/(N+D): 88 dB max @ 20 kHz; THD: -96 dB max @ 20 kHz Analog Input Voltage Range: 0 V to 2.5 V No Pipeline Delay Parallel and Serial 5 V/3 V Interface SPI®/QSPI™/MICROWIRE™/DSP Compatible Single 5 V Supply Operation Package: 48-Lead Quad Flat Pack (LQFP) 48-Lead Chip Scale Package (LFCSP) Pin-to-Pin Compatible with  PulSAR® ADCs See datasheet for additional features

AD7688 - 16-Bit, 1.5 LSB INL, 250 KSPS PULSAR 16-Bit, Differential ADC

20-Bit A/D Converter Features: Monolithic 16-Bit ADC 0.0015% Linearity Error On-Chip Self-Calibration Circuitry Programmable Low-Pass Filter 0.1 Hz to 10 Hz Corner Frequency 0 V to +2.5 V or 2.5 V Analog Input Range 4 kSPS Output Data Rate Flexible Serial Interface Ultralow Power

CMOS, 24-Bit Sigma-Delta, Signal Conditioning ADC with Matched RTD Excitation Currents Features: Charge-Balancing ADC 24 Bits, No Missing Codes ±0.0015% Nonlinearity 2-Channel Programmable Gain Front End Gains from 1 to 128 1 Differential Input 1 Single-Ended Input Low-Pass Filter with Programmable Filter Cutoffs Ability to Read/Write Calibration Coefficients RTD Excitation Current Sources Bidirectional Microcontroller Serial Interface Internal/External Reference Option Single- or Dual-Supply Operation Low Power (25 mW typ) with Power-Down Mode (7 mW typ)

High Current Output, Triple Video Amplifier Features: Drives 13 V Output Drives Unlimited Capacitive Load High Current Output Drive: 70 mA Excellent Video Specifications (RL = 150 Ω) Gain Flatness 0.1 dB to 10 MHz 0.06% Differential Gain Error 0.02° Differential Phase Error Power Operates on ±2.5 V to ±7.5 V Supply 10.0 mA/Amplifier Max Power Supply Current High Speed 250 MHz Unity Gain Bandwidth (3 dB) 1200 V/µs Slew Rate Fast Settling Time of 35 ns (0.1%) High Speed Disable Function Turn-Off Time 30 ns Easy to Use 200 mA Short Circuit Current Output Swing to 1 V of Rails

Dual 260 MHz Gain = +2.0 & +2.2 Buffer Features: Factory Set Gain Gain of 2.2 Compensates for System Gain Loss Minimizes External Components Tight Control of Gain and Gain Matching (0.1%) Optimum Dual Pinout Simplifies PCB Layout Low Crosstalk of -70dB @ 5MHz Excellent Video Specifications (RL=150 ) Gain Flatness 0.1dB to 50MHz 0.01% Differential Gain Error 0.02° Differential Phase Error Low Power of 50 mW/Amplifier (5mA) High Speed and Fast Settling 260MHz, -3dB Bandwidth 750 V/µs Slew Rate (2 V Step), 800 V/µs 4 V Step) 40 ns Settling Time to 0.1% (2V Step) Low Distortion of -65dBc THD, fc=5MHz High Output Drive of Over 70mA

High Voltage Current Shunt Monitor Features: Adjustable gain High common-mode voltage range 7 V to 65 V typical 7 V to >500 V with external pass transistor Current output Integrated 5 V series regulator 8-lead MSOP package Operating temperature range of −40°C to +125°C

High Speed, 4-Channel, 8-Bit CMOS ADC Features: 4 or 8 Analog Input Channels Built-In Track-and-Hold Function 10 kHz Signal Handling on Each Channel Fast Microprocessor Interface Single 5 V Supply Low Power: 50 mW Fast Conversion Rate: 2.5 µs/Channel Tight Error Specification: 1/2 LSB

3 V/5 V, 2 MSPS, 8-Bit, 1-/4-/8-Channel Sampling ADCs Features: 8-bit half-flash ADC with 420 ns conversion time 1, 4 and 8 Single-Ended Analog Input Channels Available with Input Offset Adjust On-Chip Track-and-Hold SNR Performance Given for Input Frequencies Up to 10 MHz Automatic Power-Down at the End of Conversion On-Chip Reference (2.5 V) Wide Operating Supply Range: 3 V ± 10% and 5 V ± 10% Input Ranges: 0 V to 2 V p-p, VDD = 3 V ± 10% 0 V to 2.5 V p-p, VDD = 5 V ± 10% Flexible Parallel Interface with EOC Pulse to Allow Stand-Alone Operation
