Digital Isolators Dual-Channel Isolators with Integrated DC-to-DC Converter (1/1 Channel Directionality) The ADuM6210 / ADuM6211 / ADuM6212 represent dual-channel digital isolators featuring isoPower, an integrated, isolated dc-to-dc converter. Leveraging Analog Devices, Inc.'s iCoupler technology, the dc-to-dc converter delivers regulated, isolated power with an adjustable range between 3.135 V and 5.25 V. These isolators accommodate input supply voltages ranging from slightly below the required output to significantly higher values, as detailed in Table 2 for popular voltage combinations and their corresponding power levels. In low-power, isolated designs, the ADuM6210 / ADuM6211 / ADuM6212 negate the necessity for a separate, isolated dc-to-dc converter. The iCoupler chip-scale transformer technology is utilized for both isolated logic signals and the magnetic components of the dc-to-dc converter. The outcome is a compact, all-encompassing isolation solution. isoPower employs high-frequency switching elements to transfer power through its transformer. Careful attention must be given to printed circuit board (PCB) layout to meet emissions standards. Refer to the AN-0971 Application Note for recommended board layout practices. Features and Benefits: isoPower integrated, isolated dc-to-dc converter Regulated 3.135 V to 5.25 V output Up to 150 mW output power Dual dc-to-100 Mbps (NRZ) signal isolation channels Soft start power supply 20-lead SSOP package with 5.3 mm creepage Supports SPI up to 15 MHz High temperature operation: 105°C High common-mode transient immunity: >25 kV/μs Safety and regulatory approvals UL recognition 3750 V rms for 1 minute per UL 1577 CSA Component Acceptance Notice 5A VDE certificate of conformity DIN V VDE V 0884-10 (VDE V 0884-10):2006-12 VIORM = 849 V peak Applications: RS-232 transceivers Power supply start-up bias and gate drives Isolated sensor interfaces Industrial PLCs

DIGITAL ISOLATOR 45NS WSOIC-16; No. of Channels:4 Channel; Propagation Delay:45ns; Supply Voltage Min:3V; Supply Voltage Max:5.5V; Interface Case Style:WSOIC; No. of Pins:16Pins; Operating Temperature Min:-40°C; Operating Temperature Max:105°C; Packaging:Cut Tape; Product Range:ADUM6402 Series; Automotive Qualification Standard:-; MSL:MSL 3 - 168 hours; SVHC:No SVHC (20-Jun-2016); No. of Channels:4Channels

DIGITAL ISOLATOR 65NS WSOIC-16; No. of Channels:3 Channel; Propagation Delay:65ns; Supply Voltage Min:2.7V; Supply Voltage Max:5.5V; Interface Case Style:WSOIC; No. of Pins:16Pins; Operating Temperature Min:-40°C; Operating Temperature Max:105°C; Packaging:Each; Product Range:ADUM3300 Series; Automotive Qualification Standard:-; MSL:MSL 1 - Unlimited; SVHC:No SVHC (20-Jun-2016); No. of Channels:3Channels

ANALOGUE SWITCH SINGLE SPST SC-70-6; Analog Switch Type:SPST; No. of Channels:1Channels; On State Resistance Max:2ohm; Supply Voltage Range:1.8V to 5.5V; Analog Switch Case:SC-70; No. of Pins:6Pins; Operating Temperature Min:-40 C

SUPERVISOR CIRCUIT MPU #1 SOT-143-4; Threshold Voltage:3.08V; No. of Supervisors / Monitors:1Monitors; Supply Voltage Min:3.15V; Supply Voltage Max:3.6V; Reset Type:Manual Active-Low; Digital IC Case:SOT-143; No. of Pins:4Pins; Delay Time:-; Operating Temperature Min:-40°C; Operating Temperature Max:85°C; Packaging:Cut Tape; Product Range:ADM811 Series; Automotive Qualification Standard:-; MSL:MSL 1 - Unlimited; SVHC:No SVHC (20-Jun-2016)

COMPARATOR DUAL MSOP-10; Comparator Type:General Purpose; No. of Comparators:2; Response Time:-; Supply Voltage Range:2.3V to 5.5V; Comparator Case Style:MSOP; No. of Pins:10Pins; IC Output Type:Open Drain; Operating Temperature Min:-40°C; Operating Temperature Max:125°C; Packaging:Cut Tape; Product Range:-; Automotive Qualification Standard:-; MSL:-; SVHC:No SVHC (20-Jun-2016)

DRIVER/RECEIVER RS232 230KBPS DIP-16; Device Type:Line Driver / Receiver; IC Interface Type:RS232; No. of Drivers:2Drivers; No. of Receivers:2Receivers; Supply Voltage Min:4.5V; Supply Voltage Max:5.5V; Driver Case Style:DIP; No. of Pins:16Pins; Operating Temperature Min:-40°C; Operating Temperature Max:85°C; Packaging:Each; Product Range:ADM1181A Series; Automotive Qualification Standard:-; MSL:-; IC Generic Number:ADM1181A; SVHC:No SVHC (20-Jun-2016)

SUPERVISOR CIRCUIT MPU #1 SOT-23-5; Threshold Voltage:4.5V; No. of Supervisors / Monitors:1Monitors; Supply Voltage Min:1V; Supply Voltage Max:5.5V; Reset Type:Manual Active-Low; Digital IC Case:SOT-23; No. of Pins:5Pins; Delay Time:-; Operating Temperature Min:-40°C; Operating Temperature Max:85°C; Packaging:Cut Tape; Product Range:ADM6320 Series; Automotive Qualification Standard:-; MSL:MSL 1 - Unlimited; SVHC:No SVHC (20-Jun-2016)

SEQUENCER FET DRIVE #2 SOT-23-6; Threshold Voltage:618mV; No. of Supervisors / Monitors:2; Supply Voltage Min:900mV; Supply Voltage Max:5.5V; Reset Type:Active-High; Digital IC Case:SOT-23; No. of Pins:6; Delay Time:300ms; ;RoHS Compliant: Yes

DAC 16BIT TSSOP-16; Resolution (Bits):16bit; Sampling Rate:-; Input Channel Type:Serial; Supply Voltage Range:4.75V to 30V; ADC / DAC Case Style:TSSOP; No. of Pins:16Pins; Data Interface:SPI; Operating Temperature Min:-40°C; Operating Temperature Max:125°C; Packaging:Each; Product Range:AD5761R Series; Automotive Qualification Standard:-; MSL:MSL 1 - Unlimited; SVHC:No SVHC (20-Jun-2016)

ADC 24BIT 31.25KSPS SPI LFCSP-32; Resolution (Bits):24bit; Sampling Rate:31.25kSPS; Supply Voltage Type:Single; Supply Voltage Min:2V; Supply Voltage Max:5.5V; ADC / DAC Case Style:LFCSP; No. of Pins:32; Data Interface:SPI ;RoHS Compliant: Yes

OP-AMP 3.5MHZ 1.5V/US NSOIC-8; No. of Amplifiers:1 Amplifier; Bandwidth:3.5MHz; Slew Rate:1.5V/ s; Supply Voltage Range: 5V to 15V; Amplifier Case Style:NSOIC; No. of Pins:8Pins; Operating Temperature Min:-40 C; Packaging:Each ;RoHS Compliant: Yes

Operational Amplifier 3.5 MHz 4 1.5 V/ s 5V to 15V NSOIC 14 ;RoHS Compliant: Yes

POWER AMP 22DB 24-27GHZ 5V LCC-24; Frequency Min:24GHz; Frequency Max:27GHz; Gain:22dB; Noise Figure Typ:-; RF IC Case Style:LCC; No. of Pins:24Pins; Supply Voltage Min:-; Supply Voltage Max:5V; Operating Temperature Min:-40 C

ADC 16BIT 200KSPS WSOIC-28; Resolution (Bits):16bit; Sampling Rate:200kSPS; Supply Voltage Type:Single; Supply Voltage Min:4.75V; Supply Voltage Max:5.25V; ADC / DAC Case Style:WSOIC; No. of Pins:28Pins; Input Channel Type:Single Ended; Data Interface:SPI; Operating Temperature Min:-40°C; Operating Temperature Max:85°C; Packaging:Each; Product Range:Quad 16-Bit SAR ADCs; Automotive Qualification Standard:-; MSL:MSL 3 - 168 hours; SVHC:No SVHC (20-Jun-2016); Supply Current:14mA

DAC 12BIT TSSOP-38; Resolution (Bits):12bit; Sampling Rate:125kSPS; Input Channel Type:Parallel; Supply Voltage Range:2.5V to 5.5V; ADC / DAC Case Style:TSSOP; No. of Pins:38Pins; Data Interface:Parallel; Operating Temperature Min:-40°C; Operating Temperature Max:105°C; Packaging:Each; Product Range:AD5348 Series; Automotive Qualification Standard:-; MSL:MSL 1 - Unlimited; SVHC:No SVHC (20-Jun-2016); Supply Current:1mA

RF/IF AMPLIFIER 19.5DB 1MHZ-2.7GHZ LFCSP-8; Frequency Min:1MHz; Frequency Max:2.7GHz; Gain:19.5dB; Noise Figure Typ:5.6dB; RF IC Case Style:LFCSP; No. of Pins:8Pins; Supply Voltage Min:2.7V; Supply Voltage Max:5.5V

12-BIT EVAL BOARD 1200 MSPS DAC; Silicon Manufacturer:Analog Devices; Silicon Core Number:AD9735; Kit Application Type:Data Converter; Application Sub Type:DAC; Kit Contents:Eval Board AD9735; Product Range:AD9735 Series; SVHC:No SVHC (20-Jun-2016); Features:LVDS Sampling Integrity Built-in Self Test Adjustable Analog Output

EVALUATION MODULE DAC; Silicon Manufacturer:Analog Devices; Silicon Core Number:AD5544; Kit Application Type:Data Converter; Application Sub Type:DAC; Kit Contents:Eval Board AD5544 AD5545 Software CD; Product Range:AD5544 Series; SVHC:No SVHC (20-Jun-2016); Features:Graphic User Interface Software For Board Control & Data Analysis Various Power Supply Options

EVALUATION BOARD PLL FREQUENCY SYNTHESIZER; Silicon Manufacturer:Analog Devices; Silicon Core Number:ADF4360-5; Kit Application Type:Clock & Timing; Application Sub Type:PLL Frequency Synthesizer; Kit Contents:Eval Board ADF4360-5 ;RoHS Compliant: Yes
