1.25 Gbps Clock and Data Recovery IC Features:Locks to 1.25 Gbps NRZ serial data input Patented clock recovery architecture No reference clock required Loss-of-lock indicator I2C interface to access optional features Single-supply operation: 3.3 V Low power: 390 mW typical 5 mm 5 mm 32-lead LFCSP, Pb free

3.3 V, 50 Mbps to 4.25 Gbps, Single-Loop, Laser Diode Driver Features: SFP/SFF and SFF-8472 MSA compliant SFP reference design available 50 Mbps to 4.25 Gbps operation Automatic average power control Typical 60 ps output rise/fall time VCSEL, DFB, and FP laser support Bias current range: from 2 mA to 100 mA Modulation current range: from 5 mA to 90 mA Laser fail alarm and automatic laser shutdown (ALS) Bias and modulation current monitoring Voltage setpoint control Resistor setpoint control 3.3 V supply 24-lead 4 mm × 4 mm LFCSP Pin compatible with ADN2870

3.75 kV rms Dual LVDS 2 Gbps Isolator (1 Reverse Channels) Features: 3.75 kV rms LVDS isolators Complies with TIA/EIA-644-A LVDS signal levels Dual-channel configuration (ADN4620: 2 + 0, ADN4621: 1 + 1) Any data rate up to 2.5 Gbps switching with low jitter 5 Gbps total bandwidth across two channels 2.15 ns typical propagation delay Typical jitter: 0.82 ps rms random, 40 ps total peak-to-peak Lower power 1.8 V supplies with 3.3 V supplies for I/O ±7 kV IEC 61000-4-2 ESD protection across isolation barrier High common-mode transient immunity: 70 kV/μs typical Safety and regulatory approvals (20-lead SSOP package) UL (pending): 3750 V rms for 1 minute per UL 1577 CSA Component Acceptance Notice 5A (pending) VDE certificate of conformity, reinforced insulation (pending) DIN V VDE V 0884-11 (VDE V 0884-11):2017-01 VIORM = 1500 VPEAK (maximum working insulation voltage) Enable or disable refresh (low speed output correctness check) Operating temperature range: −40°C to +125°C Compact SSOP package with 5.3 mm creepage

3.75 kV rms Dual LVDS 2 Gbps Isolator (1 Reverse Channels) Features: 3.75 kV rms LVDS isolators Complies with TIA/EIA-644-A LVDS signal levels Dual-channel configuration (ADN4620: 2 + 0, ADN4621: 1 + 1) Any data rate up to 2.5 Gbps switching with low jitter 5 Gbps total bandwidth across two channels 2.15 ns typical propagation delay Typical jitter: 0.82 ps rms random, 40 ps total peak-to-peak Lower power 1.8 V supplies with 3.3 V supplies for I/O ±7 kV IEC 61000-4-2 ESD protection across isolation barrier High common-mode transient immunity: 70 kV/μs typical Safety and regulatory approvals (20-lead SSOP package) UL (pending): 3750 V rms for 1 minute per UL 1577 CSA Component Acceptance Notice 5A (pending) VDE certificate of conformity, reinforced insulation (pending) DIN V VDE V 0884-11 (VDE V 0884-11):2017-01 VIORM = 1500 VPEAK (maximum working insulation voltage) Enable or disable refresh (low speed output correctness check) Operating temperature range: −40°C to +125°C Compact SSOP package with 5.3 mm creepage

5.7 kV RMS/1.5 kV RMS, Quad-Channel LVDS 2.5 Gigabit Isolator (0 Reverse Channels) Features: 5.7 kV rms and 1.5 kV rms LVDS isolators Complies with TIA/EIA-644-A LVDS signal levels Quad-channel configuration Any data rate up to 2.5 Gbps switching with low jitter 10 Gbps total bandwidth across four channels 2.15 ns typical propagation delay Typical jitter: 0.82 ps rms random, 40 ps total peak Lower power 1.8 V supplies ±8 kV IEC 61000-4-2 ESD protection across isolation barrier High common-mode transient immunity: 100 kV/μs typical Safety and regulatory approvals (28-lead SOIC_W_FP package) UL (pending): 5700 V rms for 1 minute per UL 1577 CSA Component Acceptance Notice 5A (pending) VDE certificate of conformity (pending) DIN V VDE V 0884-11 (VDE V 0884-11):2017-01 VIORM = 849 VPEAK (working voltage) Enable or disable refresh (low speed output correctness check) Operating temperature range: −40°C to +125°C 28-lead, wide-body, finer pitch SOIC_W_FP package with 8.3 mm creepage and clearance or 6 mm × 6 mm LFCSP package with 1.27 mm creepage and clearance

5 kV RMS/3.75 kV RMS, Dual LVDS Gigabit Isolator (Second Channel Reversed) Features: 5 kV rms and 3.75 kV rms LVDS isolators Complies with TIA/EIA-644-A LVDS standard Multiple dual-channel configurations Any data rate up to 1.1 Gbps switching with low jitter 4 ns typical propagation delay 2.6 ps rms typical random jitter, rms 90 ps typical peak-to-peak total jitter at 1.1 Gbps 2.5 V or 3.3 V supplies −75 dBc power supply ripple rejection, phase spur level Glitch immunity ±8 kV IEC 61000-4-2 ESD protection across isolation barrier High common-mode transient immunity: >25 kV/μs Passes EN 55022 Class B radiated emissions limits with 1.1 Gbps PRBS Safety and regulatory approvals (20-lead SOIC_W package) UL (pending): 5000 V rms for 1 minute per UL 1577 CSA Component Acceptance Notice 5A (pending) VDE certificate of conformity (pending) DIN V VDE V 0884-10 (VDE V 0884-10):2006-12 VIORM = 424 VPEAK Fail-safe output high for open, short, and terminated input conditions (ADN4655/ADN4656) Operating temperature range: −40°C to +125°C 7.8 mm minimum creepage and clearance

5 kV RMS/3.75 kV RMS, Dual LVDS Gigabit Isolator (First Channel Reversed) Features: 5 kV rms and 3.75 kV rms LVDS isolators Complies with TIA/EIA-644-A LVDS standard Multiple dual-channel configurations Any data rate up to 1.1 Gbps switching with low jitter 4 ns typical propagation delay 2.6 ps rms typical random jitter, rms 90 ps typical peak-to-peak total jitter at 1.1 Gbps 2.5 V or 3.3 V supplies −75 dBc power supply ripple rejection, phase spur level Glitch immunity ±8 kV IEC 61000-4-2 ESD protection across isolation barrier High common-mode transient immunity: >25 kV/μs Passes EN 55022 Class B radiated emissions limits with 1.1 Gbps PRBS Safety and regulatory approvals (20-lead SOIC_W package) UL (pending): 5000 V rms for 1 minute per UL 1577 CSA Component Acceptance Notice 5A (pending) VDE certificate of conformity (pending) DIN V VDE V 0884-10 (VDE V 0884-10):2006-12 VIORM = 424 VPEAK Fail-safe output high for open, short, and terminated input conditions (ADN4655/ADN4656) Operating temperature range: −40°C to +125°C 7.8 mm minimum creepage and clearance

250 Mbps, Half Duplex, Quad M-LVDS Transceivers Features: Four M-LVDS transceivers (driver and receiver pairs) Switching rate: 250 Mbps (125 MHz) Independent pin select for each receiver, two modes: Type 1: input hysteresis of 15 mV typical Type 2: differential input threshold voltage offset by 100 mV to support open-circuit, short-circuit, and bus idle fail-safe Compatible with the TIA/EIA-899 standard for M-LVDS Glitch free power-up/power-down on the M-LVDS bus Controlled transition times on the driver output Common-mode range: −1 V to +3.4 V, allowing communication with ±2 V of ground noise Driver outputs high-Z when disabled or powered off Independent enable pins for each driver and receiver Enhanced ESD protection on bus pins ≥±15 kV HBM, air discharge ≥±8 kV HBM, contact discharge ≥±10 kV IEC 61000-4-2, air discharge ≥±8 kV IEC 61000-4-2, contact discharge Enhanced ±8 kV HBM ESD protection for all pins, contact discharge Operating temperature range: −40°C to +105°C Available in 48-lead, 7 mm x 7 mm LFCSP

A High Efficiency TEC Controller Solution Features: Two integrated zero drift, rail-to-rail, chop amplifiers TEC voltage and current operation monitoring Programmable TEC maximum voltage and current Programmable TEC current heating and cooling limits Configurable PWM switching frequency up to 1 MHz Power efficiency: > 90% Temperature lock indication Optional internal or external clock source Clock phase adjustment for multiple drop operation Supports negative temperature coefficient (NTC) thermistors or positive temperature coefficient (PTC) resistance thermal detectors (RTDs) 5 V typical and optional 3 V supplies Standby and shutdown mode availability Adjustable soft start feature 5 mm × 5 mm 32-lead LFCSP

Ultracompact, 1 A Thermoelectric Cooler (TEC) Driver for Digital Control Systems Features: Patented high efficiency single inductor architecture Integrated low RDSON MOSFETs for TEC driver TEC voltage and current operation monitoring No external sense resistor required Programmable maximum TEC voltage External synchronization  Independent TEC heating and cooling current limit settings 2 MHz PWM switching frequency Digital thermal control loop compatible 2.50 V reference output with 1% accuracy Available in a 25-ball, 2.5 mm x 2.5 mm WLCSP or in a 24-lead, 4 mm x 4 mm LFCSP

Ultracompact 1.5 A Thermoelectric Cooler (TEC) Controller Features: Patented high efficiency single inductor architecture Integrated low RDSON MOSFETs for the TEC controller TEC voltage and current operation monitoring No external sense resistor required Independent TEC heating and cooling current limits settings Programmable maximum TEC voltage 2.0 MHz PWM driver switching frequency External synchronization Two integrated zero drift, rail-to-rail chopper amplifiers Capable of NTC or RTD thermal sensors 2.50 V reference output with 1% accuracy Temperature lock indicator Available in a 25-ball, 2.5 mm × 2.5 mm WLCSP or in a 24-lead, 4 mm × 4 mm LFCSP AEC-Q100 qualified for automotive applications

Three-Channel, Isolated Micropower Management Unit with Seven Digital Isolators Features: Wide input supply voltage range: 4.5 V to 60 V Integrated flyback power switch Generates isolated, independent bipolar outputs and factory programmable buck output VOUT1: 21 V, 24 V or 6 V to 28 V VOUT2: 5.15 V, 5.0 V, or 3.3 V VOUT3: −24 V to −5 V Uses a 1:1 ratio transformer for simplified transformer design Peak current limiting and OVP for flyback, buck, and inverting regulators Precision enable input and power-good output Adjustable switching frequency via SYNC input Internal compensation and soft start control per regulator High speed, low propagation delay, SPI signal isolation channels Three, 100 kbps general-purpose isolated data channels 9 mm × 7 mm LFCSP form factor enables small overall solution size −40°C to +125°C operating junction temperature range Conforms to CISPR11 Class B radiated emission limits Safety and regulatory approvals (pending) UL recognition: 2500 V rms for 1 minute per UL 1577 CSA Component Acceptance Notice 5A 300 V rms basic insulation between slave, master, and field power domains (IEC 61010-1, pending) VDE certificate of conformity DIN V VDE 0884-10 (VDE 0884-10):2006-12 VIORM = 565 VPEAK

Two-Channel, Isolated Micropower Management Unit with Seven Digital Isolators Features: Wide input supply voltage range: 4.5 V to 60 V Integrated flyback power switch Generates two isolated, well regulated independent outputs VOUT1: 24 V or 6 V to 28 V VOUT2: 3.3 V, 5.0 V, or 5.15 V Uses a 1:1 ratio transformer for simplified transformer design Peak current limiting and OVP for flyback and buck regulators Precision enable input and power-good output Adjustable switching frequency via SYNC input Internal compensation and soft start control per regulator High speed, low propagation delay, SPI signal isolation channels Three 100 kbps general-purpose isolated data channels 41-lead, 9 mm × 7 mm LFCSP form factor enables small overall solution size −40°C to +125°C operating junction temperature range Safety and regulatory approvals (pending) CISPR11 Class B radiated emission UL recognition: 2500 V rms for 1 minute duration per UL 1577 CSA Component Acceptance Notice 5A 300 V rms basic insulation between slave, master, and field power domains (IEC 61010-1, pending) VDE certificate of conformity DIN V VDE 0884-10 (VDE 0884-10):2006-12 VIORM = 565 VPEAK

Two-Channel, Isolated Micropower Management Unit with Seven Digital Isolators Features: Wide input supply voltage range: 4.5 V to 60 V Integrated flyback power switch Generates two isolated, well regulated independent outputs VOUT1: 24 V or 6 V to 28 V VOUT2: 3.3 V, 5.0 V, or 5.15 V Uses a 1:1 ratio transformer for simplified transformer design Peak current limiting and OVP for flyback and buck regulators Precision enable input and power-good output Adjustable switching frequency via SYNC input Internal compensation and soft start control per regulator High speed, low propagation delay, SPI signal isolation channels Three 100 kbps general-purpose isolated data channels 41-lead, 9 mm × 7 mm LFCSP form factor enables small overall solution size −40°C to +125°C operating junction temperature range Safety and regulatory approvals (pending) CISPR11 Class B radiated emission UL recognition: 2500 V rms for 1 minute duration per UL 1577 CSA Component Acceptance Notice 5A 300 V rms basic insulation between slave, master, and field power domains (IEC 61010-1, pending) VDE certificate of conformity DIN V VDE 0884-10 (VDE 0884-10):2006-12 VIORM = 565 VPEAK

Two-Channel, Isolated Micropower Management Unit with Seven Digital Isolators Features: Wide input supply voltage range: 4.5 V to 60 V Integrated flyback power switch Generates two isolated, well regulated independent outputs VOUT1: 24 V or 6 V to 28 V VOUT2: 3.3 V, 5.0 V, or 5.15 V Uses a 1:1 ratio transformer for simplified transformer design Peak current limiting and OVP for flyback and buck regulators Precision enable input and power-good output Adjustable switching frequency via SYNC input Internal compensation and soft start control per regulator High speed, low propagation delay, SPI signal isolation channels Three 100 kbps general-purpose isolated data channels 41-lead, 9 mm × 7 mm LFCSP form factor enables small overall solution size −40°C to +125°C operating junction temperature range Safety and regulatory approvals (pending) CISPR11 Class B radiated emission UL recognition: 2500 V rms for 1 minute duration per UL 1577 CSA Component Acceptance Notice 5A 300 V rms basic insulation between slave, master, and field power domains (IEC 61010-1, pending) VDE certificate of conformity DIN V VDE 0884-10 (VDE 0884-10):2006-12 VIORM = 565 VPEAK

Two-Channel, Isolated Micropower Management Unit with Seven Digital Isolators Features: Wide input supply voltage range: 4.5 V to 60 V Integrated flyback power switch Generates two isolated, well regulated independent outputs VOUT1: 24 V or 6 V to 28 V VOUT2: 3.3 V, 5.0 V, or 5.15 V Uses a 1:1 ratio transformer for simplified transformer design Peak current limiting and OVP for flyback and buck regulators Precision enable input and power-good output Adjustable switching frequency via SYNC input Internal compensation and soft start control per regulator High speed, low propagation delay, SPI signal isolation channels Three 100 kbps general-purpose isolated data channels 41-lead, 9 mm × 7 mm LFCSP form factor enables small overall solution size −40°C to +125°C operating junction temperature range Safety and regulatory approvals (pending) CISPR11 Class B radiated emission UL recognition: 2500 V rms for 1 minute duration per UL 1577 CSA Component Acceptance Notice 5A 300 V rms basic insulation between slave, master, and field power domains (IEC 61010-1, pending) VDE certificate of conformity DIN V VDE 0884-10 (VDE 0884-10):2006-12 VIORM = 565 VPEAK

3-Channel Isolated Micropower Management Unit with Seven Digital Isolators and Programmable Power Control Features: Wide input supply voltage range: 4.5 V to 60 V Integrated flyback power switch Generates isolated, independent, resistor-programmable bipolar outputs and factory-programmable buck output VOUT1: 6 V to 28 V VOUT2: 5.0 V VOUT3: −24 V to −2 V 86% typical efficiency at 2.61 W output power Programmable power control pin (PPC_IN) for adjusting VOUT1 through serial command Uses a 1:1 ratio transformer for simplified transformer design Adjustable switching frequency via SYNC input Peak current limiting and overvoltage protection Internal compensation and soft start control per regulator Precision enable input High speed, low propagation delay, SPI signal isolation channels Three 100 kbps general-purpose isolated data channels 41-lead, 9 mm × 7 mm LFCSP form factor enables small overall solution size −40°C to +125°C operating junction temperature range Safety and regulatory approvals (pending) CISPR11 Class B radiated emission UL recognition: 2500 V rms for 1 minute per UL 1577 CSA Component Acceptance Notice 5A 300 V rms basic insulation between slave, master, and field power domains (IEC 61010-1, pending) VDE certificate of conformity DIN V VDE 0884-10 (VDE 0884-10):2006-12 VIORM = 565 V peak

Isolated, Synchronous Forward Controller with Active Clamp and iCoupler Features: Current mode controller for active clamp forward topology Integrated 5 kV (wide body SOIC package) or 3.0 kV (LGA package) rated dielectric isolation voltage with Analog Devices, Inc., patented iCoupler technology Wide voltage supply range Primary VIN: up to 60 V Secondary VDD2: up to 36 V Integrated 1 A primary side MOSFET driver for power switch and active clamp reset switch Integrated 1 A secondary side MOSFET drivers for synchronous rectification Integrated error amplifier and <1% accurate reference voltage Programmable slope compensation Programmable frequency range: 50 kHz to 600 kHz typical Frequency synchronization Programmable maximum duty cycle limit Programmable soft start Smooth soft start from precharged load Programmable dead time Power saving light load mode using MODE pin Protection features such as short circuit, output overvoltage, and overtemperature protection Cycle-by-cycle input overcurrent protection Precision enable UVLO with hysteresis PGOOD pin for system flagging Tracking function from secondary side Remote (secondary side) shutdown/reset function Safety and regulatory approvals (pending) UL recognition 5000 V rms for 1 minute per UL 1577 (for wide body SOIC package) 3000 V rms for 1 minute per UL 1577 (for LGA package) CSA component acceptance notice 5A VDE certificate of conformity DIN V VDE V 0884-10 (VDE V 0884-10):2006-12 VIORM = 849 V peak (for wide body SOIC package) VIORM = 560 V peak (for LGA package) CQC certification per GB4943.1-2011 Available in 24-lead SOIC_W package and 24-terminal LGA package AEC-Q100 Qualified for Automotive Applications

Ultralow Noise, 150 mA CMOS Linear Regulator Features: Chinese data sheet available Ultralow noise: 9 μV rms, independent of VOUT No additional noise bypass capacitor required Stable with 1 μF ceramic input and output capacitors Maximum output current: 150 mA Input voltage range: 2.2 V to 5.5 V Low quiescent current IGND = 10 μA with zero load Low shutdown current: <1 μA Low dropout voltage: 105 mV at 150 mA load Initial output voltage accuracy: ±1% Up to 14 fixed output voltage options: 1.8 V to 3.3 V PSRR performance of 70 dB at 10 kHz Current limit and thermal overload protection Logic-controlled enable 5-lead TSOT package 4-ball, 0.8 mm × 0.8 mm, 0.4 mm pitch WLCSP AEC-Q100 qualified for automotive applications

Ultralow Noise, 150 mA CMOS Linear Regulator Features: Chinese data sheet available Ultralow noise: 9 μV rms, independent of VOUT No additional noise bypass capacitor required Stable with 1 μF ceramic input and output capacitors Maximum output current: 150 mA Input voltage range: 2.2 V to 5.5 V Low quiescent current IGND = 10 μA with zero load Low shutdown current: <1 μA Low dropout voltage: 105 mV at 150 mA load Initial output voltage accuracy: ±1% Up to 14 fixed output voltage options: 1.8 V to 3.3 V PSRR performance of 70 dB at 10 kHz Current limit and thermal overload protection Logic-controlled enable 5-lead TSOT package 4-ball, 0.8 mm × 0.8 mm, 0.4 mm pitch WLCSP AEC-Q100 qualified for automotive applications
