0.1 μF, 5 V Powered CMOS RS-232 Drivers/Receivers

Dual High IP3, 700 MHz to 2800 MHz, Double Balanced, Passive Mixer, IF Amplifier, and Wideband LO Amplifier

Dual, 16-Bit, 1230 MSPS, TxDAC+ Digital-to-Analog Converter

Dual IF Receiver

14-Bit, 170 MSPS/210 MSPS/250 MSPS, 1.8 V Dual Analog-to-Digital Converter (ADC) Features: SNR = 70.6 dBFS at 185 MHz AIN and 250 MSPS SFDR = 85 dBc at 185 MHz AIN and 250 MSPS −151.6 dBFS/Hz input noise at 185 MHz, −1 dBFS AIN and 250 MSPS Total power consumption: 785 mW at 250 MSPS 1.8 V supply voltages LVDS (ANSI-644 levels) outputs Integer 1-to-8 input clock divider (625 MHz maximum input) Sample rates of up to 250 MSPS IF sampling frequencies of up to 400 MHz Internal ADC voltage reference Flexible analog input range 1.4 V p-p to 2.0 V p-p (1.75 V p-p nominal) ADC clock duty cycle stabilizer 95 dB channel isolation/crosstalk Serial port control Energy saving power-down modes

14-Bit, 170 MSPS/210 MSPS/250 MSPS, 1.8 V Dual Analog-to-Digital Converter (ADC) Features: SNR = 70.6 dBFS at 185 MHz AIN and 250 MSPS SFDR = 85 dBc at 185 MHz AIN and 250 MSPS −151.6 dBFS/Hz input noise at 185 MHz, −1 dBFS AIN and 250 MSPS Total power consumption: 785 mW at 250 MSPS 1.8 V supply voltages LVDS (ANSI-644 levels) outputs Integer 1-to-8 input clock divider (625 MHz maximum input) Sample rates of up to 250 MSPS IF sampling frequencies of up to 400 MHz Internal ADC voltage reference Flexible analog input range 1.4 V p-p to 2.0 V p-p (1.75 V p-p nominal) ADC clock duty cycle stabilizer 95 dB channel isolation/crosstalk Serial port control Energy saving power-down modes

12-bit, 170/210/250 MSPS, 1.8 V Dual Analog-to-Digital Converter (ADC) Features: SNR = 69.6 dBFS at 185 MHz fIN and 250 MSPS SFDR = 86 dBc at 185 MHz fIN and 250 MSPS −149.9 dBFS/Hz input noise at 185 MHz, −1 dBFS AIN and 250 MSPS Total power consumption: 770 mW at 250 MSPS 1.8 V supply voltages LVDS (ANSI-644 levels) outputs Integer 1-to-8 input clock divider (625 MHz maximum input) Sample rates of up to 250 MSPS IF sampling frequencies of up to 400 MHz Internal ADC voltage reference Flexible analog input range 1.4 V p-p to 2.0 V p-p (1.75 V p-p nominal) ADC clock duty cycle stabilizer 95 dB channel isolation/crosstalk Serial port control Energy-saving power-down modes

12-bit, 170/210/250 MSPS, 1.8 V Dual Analog-to-Digital Converter (ADC) Features: SNR = 69.6 dBFS at 185 MHz fIN and 250 MSPS SFDR = 86 dBc at 185 MHz fIN and 250 MSPS −149.9 dBFS/Hz input noise at 185 MHz, −1 dBFS AIN and 250 MSPS Total power consumption: 770 mW at 250 MSPS 1.8 V supply voltages LVDS (ANSI-644 levels) outputs Integer 1-to-8 input clock divider (625 MHz maximum input) Sample rates of up to 250 MSPS IF sampling frequencies of up to 400 MHz Internal ADC voltage reference Flexible analog input range 1.4 V p-p to 2.0 V p-p (1.75 V p-p nominal) ADC clock duty cycle stabilizer 95 dB channel isolation/crosstalk Serial port control Energy-saving power-down modes

8-Channel Differential DAS with 18-Bit, Bipolar, Simultaneous Sampling ADC Features: 8 simultaneously sampled inputs True differential inputs True bipolar analog input ranges: ±20 V, ±10 V Single 5 V analog supply and 2.3 V to 5.25 V VDRIVE Fully integrated data acquisition solution Analog input clamp protection Input buffer with 1 MΩ analog input impedance Second-order antialiasing analog filter On-chip accurate reference and reference buffer 18-bit ADC with 200 kSPS on all channels Oversampling capability with digital filter Flexible parallel/serial interface SPI/QSPI™/MICROWIRE™/DSP compatible Performance 7 kV ESD rating on analog input channels 98 dB SNR, −107 dB THD Dynamic range: up to 105 dB typical Low power: 100 mW Standby mode: 25 mW 64-lead LQFP package

Precision Analog Microcontroller, 12-Bit Analog I/O, ARM7TDMI MCU

Low Power, Precision Analog Microcontroller, Dual Sigma-Delta ADCs, Flash/EE, ARM7TDMI

Nonvolatile Memory, Dual 1024-Position Digital Potentiometer Features: Dual-channel, 1024-position resolution 25 kΩ, 250 kΩ nominal resistance Maximum ±8% nominal resistor tolerance error Low temperature coefficient: 35 ppm/°C 2.7 V to 5 V single supply or ±2.5 V dual supply SPI-compatible serial interface Nonvolatile memory stores wiper settings Power-on refreshed with EEMEM settings Permanent memory write protection Resistance tolerance stored in EEMEM See data sheet for additional featuresAD5235-EP supports defense and aerospace applications (AQEC standard) Download AD5235-EP data sheet (pdf) Temperature range:  −40°C to +125°C Controlled manufacturing baseline 1 assembly/test site 1 fabrication site Enhanced product change notification Qualification data available on request V62/11605 DSCC Drawing Number

Synchronous Buck Controller with Constant On-Time and Valley Current Mode

Single-Supply, Rail-to-Rail, Low Power FET-Input Op Amp Features: True single-supply operation Output swings rail-to-rail Input voltage range extends below ground Single-supply capability from 5 V to 36 V Dual-supply capability from ±2.5 V to ±18 V  Excellent load drive Capacitive load drive up to 350 pF Minimum output current of 15 mA  Excellent ac performance for low power 800 μA maximum quiescent current Unity-gain bandwidth: 1.8 MHz Slew rate of 3 V/μs  Excellent dc performance 800 μV maximum input offset voltage 2 μV/°C typical offset voltage drift 25 pA maximum input bias current  Low noise: 13 nV/√Hz @ 10 kHz

Zero-Drift, Single-Supply, Rail-to-Rail Input/Output Operational Amplifiers

Micro PMU with 800 mA Buck, 300 mA LDO, Supervisory, Watchdog, and Manual Reset Features: Input voltage range: 2.3 V to 5.5 V One 800 mA buck regulator One 300 mA LDO 20-lead, 4 mm × 4 mm LFCSP package Initial regulator accuracy: ±1% Overcurrent and thermal protection Soft start Undervoltage lockout Open-drain processor reset with threshold monitoring ±1.5% threshold accuracy over the full temperate range Guaranteed reset output valid to VCC = 1 V Dual watchdog for secure systems Watchdog 1 controls reset Watchdog 2 controls reset and regulators power cycle Buck regulator key specifications Current-mode topology for excellent transient response 3 MHz operating frequency Uses tiny multilayer inductors and capacitors Mode pin selects forced PWM or auto PFM/PSM modes 100% duty cycle low dropout mode LDO key specifications Low VIN from 1.7 V to 5.5 V Stable with1 μF ceramic output capacitors High PSRR, 60 dB up to 1 kHz/10 kHz Low output noise Low dropout voltage: 150 mV at 300 mA load −40°C to +125°C junction temperature range

1 nV/Hz Low Noise 210C Instrumentation Amplifier Features: Designed for 210°C operation Low noise 1 nV/√Hz input noise 45 nV/√Hz output noise High CMRR 126 dB (min) at G = 100 80 dB (min) to 5 kHz, G = 1 See data sheet for additional features Download AD8229-KGD Data Sheet. Available As Known Good Die and fully guaranteed to data sheet specifications.

AD532 - Internally Trimmed Multiplier

Internally Trimmed Integrated Circuit Multiplier Features: Pretrimmed to ±1.0% (AD532K) No external components required Guaranteed ±1.0% maximum 4-quadrant error (AD532K) Differential inputs for (X1 - X2) (Y1 - Y2)/10 V transfer function Monolithic construction, low cost

Six Degrees of Freedom Sensor
