8 GHz to 16 GHz, 4-Channel, X Band and Ku Band Beamformer Features: 8 GHz to 16 GHz frequency range Half-duplex for transmit and receive modes Single-pin transmit and receive control 360° phase adjustment range 2.8° phase resolution ≥31 dB gain adjustment range ≤0.5 dB gain resolution Bias and control for external transmit and receive modules Memory for 121 prestored beam positions Four −20 dBm to +10 dBm power detectors Integrated temperature sensor Integrated 8-bit ADC for power detectors and temperature sensor Programmable bias modes 4-wire SPI interface

10 GHz to 40 GHz, 4-Channel Rx Mixer with 4 LO Multiplier/Filter Features: Quad LNA, mixer, IF VGA 4 LO multiplier with programmable harmonic filter RF input frequency range: 10 GHz to 40 GHz IF output frequency range: 0 MHz to 800 MHz LO input frequency range: 2.4 GHz to 10.1 GHz Gain range: 21 dB to 41 dB Input P1dB: 20 dBm typical (at minimum gain) Noise figure: 9 dB typical (at maximum gain) 3-Wire or 4-Wire SPI Control On-Chip Programmable State Machines for fast multiplier/filter and receiver switching and control On-Chip Temperature Sensor and ADC DC power: 910 mW (2.5 V supply) 7 mm 7 mm, 48-terminal LGA package

Low Power, 5-Electrode Electrocardiogram (ECG) Analog Front End with respiration measurement and pace detection) Features: Biopotential signals in; digitized signals out 5 acquisition (ECG) channels and one driven lead Parallel ICs for up to 10+ electrode measurements Master ADAS1000 or ADAS1000-1 used with slave ADAS1000-2 AC and dc lead-off detection Internal pace detection algorithm on 3 leads Support for user’s own pace Thoracic impedance measurement (internal/external path) Selectable reference lead Scalable noise vs. power control, power-down modes Low power operation from 11 mW (1 lead), 15 mW (3 leads), 21 mW (all electrodes) Lead or electrode data available Supports AAMI EC11:1991/(R)2001/(R)2007, AAMI EC38 R2007, EC13:2002/(R)2007, IEC60601-1 ed. 3.0 b:2005, IEC60601-2-25 ed. 2.0 :2011, IEC60601-2-27 ed. 2.0 b:2005, IEC60601-2-51 ed. 1.0 b: 2005 Fast overload recovery Low or high speed data output rates Serial interface SPI-/QSPI™-/DSP-compatible 56-lead LFCSP package (9 mm × 9 mm) 64-lead LQFP package (10 mm × 10 mm body size)

15 Lead ECG Vital Signs Monitor Module with Temperature and Blood Pressure Measurement Features: Biopotential signals to included digital signal processor Cortex-M4 based processor (ADSP-CM403F) for customizable measurement and analysis Highly flexible configuration management, incorporating a user configurable field programmable gate array (FPGA) (Lattice iCE40HX1K-TQ144) 12 fully integrated electrocardiogram (ECG) electrode inputs 3 temperature channels 3 invasive blood pressure (IBP) channels Source and detection circuitry for thoracic impedance measurement 1 driver output Wideband performance for pacer detection (available on 2 electrode channels) supporting the user algorithm Self diagnostic and calibration circuitry Configurable lead detection Connector interfaced, small form factor module for ease of system design and implementation Robust, with electromagnetic interference (EMI), shock, and vibration resistant packaging

SigmaDSP Digital Audio Processor Features: Qualified for automotive applications Fully programmable audio DSP for enhanced sound processing Features SigmaStudio, a proprietary graphical programming tool for the development of custom signal flows Clock oscillator for generating master clock from crystal Up to 294.912 MHz, 32-bit SigmaDSP core at 1.2 V Up to 6144 SIMD instructions per sample at 48 kHz Up to 40 kWords of parameter/data RAM Up to 800 ms digital audio delay pool at 48 kHz Audio input/output and routing 4 serial input ports, 4 serial output ports 48-channel, 32-bit digital input/output up to a sample rate of 192 kHz Flexible configuration for TDM, I2S, left and right justified formats, and PCM Up to 8 stereo ASRCs from 1:8 up to 7.75:1 ratio and 139 dB DNR Stereo S/PDIF input and output Four PDM microphone input channels Multichannel, byte addressable, TDM serial ports Integer PLL and flexible clock generators Integrated die temperature sensor

Dual Channel, Configurable, IsolatedDigital Input Features: Dual channel, configurable, isolated digital input Programmable trip threshold On-chip debounce filter On-chip data and power Isolation Application circuit monitors wide voltage range 10 V dc to 300 V dc 8 V rms to 240 V rms ac (with 10 ms + pickup) Negative dc protected Programmable wetting current Pulse up to 50 mA Constant current up to 6.3 mA Safety and regulatory approvals UL recognition 3750 V rms for 1 minute per UL 1577 CSA Component Acceptance Notice #5A (pending) CSA 61010-1: 300 V rms VDE certificate of conformity (pending) DIN V VDE V 0884-11 (VDE V 0884-11):2017-1 VIORM = 565 V peak EMC robust solution supports relay protection system level requirements ADC samples available for system diagnostics Internal SAR ADC with PGA Single 3.3 V Supply Integrated isoPower, isolated dc-to-dc converter Interfaces SPI DOUTx output reflects state of digital input IRQ interrupt pin Operating temperature: −40°C to +125°C 20-lead, LGA package with 6.8 mm creepage

Dual Channel, Configurable, IsolatedDigital Input Features: Dual channel, configurable, isolated digital input Programmable trip threshold On-chip debounce filter On-chip data and power Isolation Application circuit monitors wide voltage range 10 V dc to 300 V dc 8 V rms to 240 V rms ac (with 10 ms + pickup) Negative dc protected Programmable wetting current Pulse up to 50 mA Constant current up to 6.3 mA Safety and regulatory approvals UL recognition 3750 V rms for 1 minute per UL 1577 CSA Component Acceptance Notice #5A (pending) CSA 61010-1: 300 V rms VDE certificate of conformity (pending) DIN V VDE V 0884-11 (VDE V 0884-11):2017-1 VIORM = 565 V peak EMC robust solution supports relay protection system level requirements ADC samples available for system diagnostics Internal SAR ADC with PGA Single 3.3 V Supply Integrated isoPower, isolated dc-to-dc converter Interfaces SPI DOUTx output reflects state of digital input IRQ interrupt pin Operating temperature: −40°C to +125°C 20-lead, LGA package with 6.8 mm creepage

Digital, Polyphase, Metrology IC with ADC Bit Stream Interface Features: Digital, metrology IC, shunt-based polyphase meters Use in the mSure® system with the ADE9322B High accuracy, supports EN50470-1, EN50470-3, IEC62053-21, IEC62053-22, IEC62053-23, IEC62053-24, ANSIC12.20, and IEEE1459 standards Neutral current calculation Compatible with 3-phase, 3-wire or 4-wire (delta or wye) meters, and other 3-phase services Computes active, reactive, and apparent energy on each phase and for the overall system Power quality measurements including THD Single 3.3 V supply Operating temperature: 40°C to +85°C Flexible I2C, SPI, and HSDC serial interfaces

Energy Metering IC with Sensor Monitoring and Self-Calibration Features: mSure sensor monitoring Noninvasive, real-time, direct, precision measurement of the input signal path Detects changes in meter accuracy and amount of drift over the life of the meter Identifies sensor malfunction Enables advanced tamper detection methods Companion MCU firmware to facilitate diagnostic data reporting Supported for shunts on the phase line and CTs on the neutral line mSure self-calibration Self-calibration based on a direct measurement of the full signal path Calibration procedure not requiring a reference meter 3 high performance ADCs 86 dB SNR High gain current channel: ±26.04 mV peak, 18.4 mV rms input at highest gain setting Advanced metrology feature set Watt, VAR, VA, Wh, VARh, and VAh Supports active energy standards: IEC 62053-21; IEC 62053-22; EN50470-3; OIML R46; and ANSI C12.20 Supports reactive energy standards: IEC 62053-23 and IEC 62053-24 Current and voltage rms measurement Operating temperature, industrial range: −40°C to +85°C Integrated temperature sensor with a 12-bit successive approximation register (SAR) ADC

Op Amp - Improved Second Source to the EL2020 Features: High Speed 90 MHz Bandwidth (-3 dB) 500 V/µs Slew Rate 60 ns Settling Time to 0.1% (Vo = 10 V Step) Low Noise 2.9 nV/rt Hz Input Voltage Noise Low Power 6.8 mA Supply Current 2.1 mA Supply Current (Power-Down Mode) High Performance Disable Function Turn-Off Time of 100 ns Input to Output Isolation of 54 dB (Off State)

200 MHz Clock Generator PLL Features: 200 MHz Bandwidth 2.7 V to 5.5 V Power Supply Programmable Charge Pump Currents 3-Wire Serial Interface Hardware and Software Power-Down Mode Analog and Digital Lock Detect

Aerospace PLL Frequency Synthesizer Features: 7.0 GHz bandwidth 3.2 V to 3.6 V power supply Separate charge pump supply (VP) allows extended tuning voltage in 3.3 V systems Programmable, dual-modulus prescaler 8/9, 16/17, 32/33, or 64/65 Programmable charge pump currents Programmable antibacklash pulse width 3-wire serial interface Analog and digital lock detect Hardware and software power-down mode Loop filter design possible with ADIsimPLL

High Voltage Charge Pump, PLL Synthesizer Features: High voltage charge pump (15 V) 2.7 V to 5.5 V power supply Pin compatible with ADF4110, ADF4111, ADF4112, ADF4113 ADF4106, and ADF4002 synthesizers 200 MHz to 4.0 GHz frequency range Two selectable charge pump currents Digital lock detect Power-down mode Loop filter design possible with ADIsimPLL™

Single, Integer-N 1.2 GHz PLL Features: ADF4116: 550 MHz ADF4117: 1.2 GHz ADF4118: 3.0 GHz +2.7 V to +5.5 V Power Supply Dual Modulus Prescaler ADF4116: 8/9 ADF4117/ADF4118: 32/33 Separate VP Allows Extended Tuning Voltage in 3V Systems 3-Wire Serial Interface Digital Lock Detect Power Down Mode Fastlock Mode

Single, Integer-N, 3.0 GHz PLL Features: ADF4116: 550 MHz ADF4117: 1.2 GHz ADF4118: 3.0 GHz +2.7 V to +5.5 V Power Supply ADF4116: 8/9   ADF4117/ADF4118: 32/33 Separate VP Allows Extended Tuning Voltage in 3V Systems 3-Wire Serial Interface Digital Lock Detect Power Down Mode Fastlock Mode

Integer-N / Fractional-N PLL Synthesizer Features: Input frequency range: 500 MHz to 8000 MHz Fractional-N synthesizer and integer-N synthesizer Phase frequency detector (PFD) up to 125 MHz High resolution 38-bit modulus Separate charge pump supply (VP) allows extended tuning voltage in 5 V systems Programmable divide by 1, 2, 4, 8, 16, 32, or 64 output Differential and single-ended reference inputs Power supply: 3.3 V ± 5% Logic compatibility: 1.8 V Programmable dual-modulus prescaler (P) of 4/5 or 8/9 Programmable output power level 3-wire serial interface Analog and digital lock detect

Direct Modulation/Fast Waveform Generating, 13.5 GHz, Fractional-N Frequency Synthesizer Features: RF bandwidth to 13.5 GHz High and low speed FMCW ramp generation 25-bit fixed modulus allows subhertz frequency resolution PFD frequencies up to 130 MHz Normalized phase noise floor of −224 dBc/Hz FSK and PSK functions Sawtooth, triangular, and parabolic waveform generation Ramp superimposed with FSK Ramp with 2 different sweep rates Ramp delay, frequency readback, and interrupt functions Programmable phase control See datasheet for additional features

Microwave Wideband Synthesizer with Integrated VCO Features: RF output frequency range: 62.5 MHz to 32,000 MHz Fractional-N synthesizer and Integer N synthesizer High resolution 39-bit fractional modulus Typical spurious PFD: −90 dBc Integrated rms jitter: 38 fs (1 kHz to 100 MHz) Normalized phase noise floor: −234 dBc/Hz PFD operation to 250 MHz Reference frequency operation to 600 MHz Programmable divide by 1, 2, 4, 8, 16, 32, or 64 output 62.5 MHz to 8,000 MHz output at RF8x and RFAUX8x 8,000 MHz to 16,000 MHz output at RF16x 16,000 MHz to 32,000 MHz output at RF32x Lock time approximately 3 ms with automatic calibration Lock time <30 μs with autocalibration bypassed Analog and digital power supplies: 3.3 V VCO power supply: 3.3 V and 5 V RF output mute function 7mm × 7mm, 48-terminal LGA package

Microwave Wideband Synthesizer with Integrated VCO Features:RF output frequency range: 53.125 MHz to 13,600 MHz Noise floor integer channel: −227 dBc/Hz Noise floor fractional channel: −225 dBc/Hz Integrated rms jitter (1 kHz to 20 MHz): 97 fs for 6 GHz output Fractional-N synthesizer and integer N synthesizer Pin compatible to the ADF5355 High resolution, 52-bit modulus Phase frequency detector (PFD) operation to 125 MHz Reference input frequency operation to 600 MHzMaintains frequency lock over −40°C to +85°C Low phase noise, voltage controlled oscillator (VCO) Programmable divide by 1, 2, 4, 8, 16, 32, or 64 output Analog and digital power supplies: 3.3 V Charge pump and VCO power supplies: 5.0 V typical Logic compatibility: 1.8 V Programmable output power level RF output mute function Supported by the ADIsimPLL design tool
