Precision, Very Low Noise, Low Input Bias Current, Wide Bandwidth JFET Dual Operational Amplifier Features: Fast settling time: 500 ns to 0.1% Low offset voltage: 400 μV maximumLow input bias current:25 pA typical at VS = ±15 V Dual-supply operation: ±5 V to ±15 V Low noise: 8 nV/√Hz typical at f = 1 kHz Low distortion: 0.0005% No phase reversal Unity-gain stableAD8512-EP supports defense and aerospace applications (AQEC standard) Download AD8512-EP data sheet (pdf) Military temperature range (−55°C to +125°C) Controlled manufacturing baseline 1 assembly/test site 1 fabrication site Product change notification Qualification data available on requestV62/18919 DSCC Drawing Number

Low Power, Precision, Auto-Zero Op Amp Features: Low offset voltage: 13 μV maximum Input offset drift: 0.03 μV/°C Single-supply operation: 2.7 V to 5.5 V High gain, CMRR, and PSRR Low input bias current: 25 pA Low supply current: 180 μA

Digitally Programmable Sensor Signal Zero-Drift Amplifier Features: Very low offset voltage: 10 μV maximum over temperature Very low input offset voltage drift: 60 nV/°C maximum High CMRR: 96 dB minimum Digitally programmable gain and output offset voltage Single-wire serial interface Open and short wire fault detection Low-pass filtering Stable with any capacitive load See data sheet for additional features

Aerospace 7nS Single Comparator Features:7 ns Propagation Delay at 5 V Single Supply Operation: 3 V to 10 V Low Power Latch Function

+3.3 V/+5 V Multiplying 12-Bit DAC With an 8-Bit Byte Interface Features: 12-Bit Multiplying DACs Guaranteed Specifications wth +3.3 V/+5 Supply 0.5 LSBs INL and DNL Low Power: 5 µW typ Fast Settling: 600 ns to 0.01% with AD843 Fast Interface 40 ns Strobe Pulsewidth (AD7943) 40 ns Write Pulsewidth (AD7945, A7948) Low Glitch: 60 nV-s with Amplifier Connected

8-Channel, 10-Bit ADC with I2C Compatible Interface in 20-Lead TSSOP Features: 10-Bit ADC with Fast Conversion Time: 2 µs Eight Single-Ended Analog Input Channels Specified for VDD of 2.7 V to 5.5 V Low Power Consumption Fast Throughput Rate: up to 188 kSPS Sequencer Operation Automatic Cycle Mode I2C® Compatible Serial Interface I2C® Interface supports: Standard, Fast, and High-Speed Modes Out of Range Indicator Pin-Selectable Addressing via AS Automatic Shutdown Mode: 1 µA max

DigiTrim RRIO Quad Op Amp with Very Low Offset Voltage Features: Low Offset Voltage: 500 µV Max Single-Supply Operation: 2.7 V to 5.5 V Low Supply Current: 750 µA/Amplifier Wide Bandwidth: 8 MHz Slew Rate: 5 V/µs Low Distortion No Phase Reversal Low Input Currents Unity Gain Stable

Low Noise, Precision, Rail-to-Rail Output, JFET Single Op Amp Features: Low offset voltage B grade: 0.4 mV maximum A grade: 1 mV maximum Low offset voltage drift B grade: 2 µV/°C maximum A grade: 8 µV/°C maximum (SOIC, MSOP, LFCSP packages) Low input bias current: 5 pA typical Dual-supply operation: ±5 V to ±15 V Low voltage noise: 0.45 µV p-p at 0.1 Hz to 10 Hz Voltage noise density: 7.30 nV/√Hz at f = 1 kHz Low THD + N: 0.00025% No phase reversal Rail-to-rail output Unity-gain stable Long-term offset voltage drift (10,000 hours): 5 µV typical Temperature hysteresis: 8 µV typical

Low Noise, Precision, Rail-to-Rail Output, JFET Single Op Amp Features: Low offset voltage B grade: 0.4 mV maximum A grade: 1 mV maximum Low offset voltage drift B grade: 2 µV/°C maximum A grade: 8 µV/°C maximum (SOIC, MSOP, LFCSP packages) Low input bias current: 5 pA typical Dual-supply operation: ±5 V to ±15 V Low voltage noise: 0.45 µV p-p at 0.1 Hz to 10 Hz Voltage noise density: 7.30 nV/√Hz at f = 1 kHz Low THD + N: 0.00025% No phase reversal Rail-to-rail output Unity-gain stable Long-term offset voltage drift (10,000 hours): 5 µV typical Temperature hysteresis: 8 µV typical

36 V, 18 MHz, Low Noise, Fast Settling Single Supply, RRO, JFET Op Amp Features:Wide gain bandwidth product: 18 MHz typical High slew rate: 48 V/µs typical Low voltage noise density: 3.3 nV/√Hz typical at 1 kHz Low peak-to-peak noise: 0.15 µV p-p, 0.1 Hz to 10 Hz Low input bias current: ±15 pA typical at TA = 25°C Low offset voltage: ±80 µV maximum at TA = 25°C Offset voltage drift: ±1.2 µV/°C maximum at TA = −40°C to 85°C Fast settling: 0.01% in 700 ns typicalWide range of operating voltages Dual-supply operation: ±2.5 V to ±18 V Single-supply operation: 5 V to 36 V Input voltage range includes V− Rail-to-rail output High capacitive load drive capability Output short-circuit current: ±46 mA No phase reversal Unity-gain stable

18 V, 725 A, 4 MHz CMOS RRIO Operational Amplifier Features: Low power at high voltage (18 V): 725 μA maximum Low offset voltage: 2.2 mV maximum over entire common-mode range Low input bias current: 15 pA maximum Gain bandwidth product: 4 MHz typical at Av = 100 Unity-gain crossover: 4 MHz typical −3 dB closed-loop bandwidth: 2.1 MHz typical Single-supply operation: 3 V to 18 V Dual-supply operation: ±1.5 V to ±9 V Unity-gain stable

100 V, Precision Operational Amplifier Features: Low input offset voltage: ≤0.2 mV typical  High output current drive: 30 mA  Wide range of operating voltage: ±5 V to ±50 V  High slew rate: 20 V/μs typical  High gain bandwidth product: 3.5 MHz typical  Thermal regulation at junction temperature >145°C  Ambient temperature range of -40° C to +85° C  Low input bias current ≤ 15 nA typical

Low Power, High Speed CCD Buffer Amplifier Features: Download ADA4800-KGD Data Sheet. Available as Known Good Die and fully guaranteed to data sheet specifications. Integrated active load and gain of 1 buffer Very low buffer power consumption as low as 20 mW on chip Power save feature to reduce active load current by GPO control Fast settling time to 1%, 2 V step: 5 ns High buffer speed 400 MHz, −3 dB bandwidth 415 V/μs slew rate Adjustable buffer bandwidth Push-pull output stage Adjustable active load current Small package: 1.6 mm × 1.6 mm × 0.55 mm

3.1 nV/Hz, 1 mA, 180 MHz, Rail-to-Rail Input/Output Amplifier Features: Low Noise 3.1 nV/√Hz at 100 kHz 0.7 pA/√Hz at 100 kHz Low Distortion (HD2/HD3) -141/-144 dBc at 1 kHz -112/-115 dBc at 100 kHz -95/-79 dBc at 1 MHz High speed performance -3dB bandwidth: 200 MHz Slew Rate: 225 V/µs 0.1% Settling Time: 47 ns Low input offset voltage and drift ±20 / ±125 µV (typical / max) 0.7 /3.7 µV/°C (typical) Low input offset current and drift 8 / 100 nA (typical / max) 30 / 250 pA/°C (typical / max) Rail-to-Rail Input and Output Low quiescent current: Enabled: 1 mA at ±5V Disabled: 2.4 µA at ±5V Wide supply range: 2.7 V to 11 V Small Packaging: 6-lead SC70, 6-lead SOT-23

Low Power, Low Noise and Distortion, Rail-to-Rail Output Amplifier Features: Low power: 1.1 mA/amp Low wideband noise 2.1 nV/√Hz 1.4 pA/√Hz Low 1/f noise 7 nV/√Hz @ 10 Hz 13 pA/√Hz @ 10 Hz Low distortion: −105 dBc @ 100 kHz, VO = 2 V p-p High speed 80 MHz, −3 dB bandwidth (G = +1) 12 V/μs slew rate 175 ns settling time to 0.1% Low offset voltage: 0.3 mV maximum Rail-to-rail output Power down Wide supply range: 2.7 V to 12 V

Ultralow Distortion, Low Power, Low Noise, High Speed Op Amp Features: High speed 850 MHz, -3 dB bandwidth (G = +1, RL = 1kΩ), LFSCP 750 MHz, −3 dB bandwidth (G = +1, RL = 1 kΩ, SOIC) 2800 V/µs slew rate Low distortion: -88 dBc @ 10 MHz (G = +1, RL = 1kΩ) Low power: 5 mA/amplifier @ 10 V Low noise: 4.4 nV/√Hz Wide supply voltage range: 5 V to 10 V Power-down feature Available in 3 mm × 3 mm 8-lead LFCSP (single), 8-lead SOIC (single), and 4 mm × 4 mm 16-lead LFCSP (dual)

Low Power, 1 nV/Hz, G 10 Stable, Rail-to-Rail Output Amplifier Features: Low wideband noise 1 nV/√Hz 1.6 pA/√Hz Low 1/f noise: 2 nV/√Hz at 10 Hz Low distortion (SFDR): −96 dBc at 100 kHz, VOUT = 2 V p-p Low power: 3 mA per amplifier Low input offset voltage: 350 μV maximum High speed 236 MHz, −3 dB bandwidth (G = +10) 943 V/μs slew rate 22 ns settling time to 0.1% Rail-to-rail output Wide supply range: 3 V to 10 V Disable feature

Low Power Differential ADC Driver Features: High performance at low power High speed −3 dB bandwidth of 560 MHz, G = 1 0.1 dB gain flatness to 300 MHz Slew rate: 2800 V/μs, 25% to 75% Fast 0.1% settling time of 9 ns Low power: 9.6 mA per amplifier Low harmonic distortion 100 dB SFDR at 10 MHz 90 dB SFDR at 20 MHz Low input voltage noise: 3.6 nV/√Hz ±0.5 mV typical input offset voltage Externally adjustable gain Can be used with gains less than 1 Differential-to-differential or single-ended-to-differential operation Adjustable output common-mode voltage Input common-mode range shifted down by 1 VBE Wide supply range: +3 V to ±5 V Available in 16-lead and 24-lead LFCSP packages

18-Bit, 2 MSPS, Module Data Acquisition Solution Features: Improved design journey Fully differential ADC driver with selectable input range Input ranges with 5 V VREF: ±10 V, ±5 V, or ±2.5 V Essential passive components included ±0.005% iPassives matched resistor array Wide input common-mode voltage range High common-mode rejection ratio Single-ended to differential conversion Increased signal chain density Small, 7 mm × 7 mm, 0.80 mm pitch, 49-ball CSP_BGA 4× footprint reduction vs. discrete solution On-board reference buffer with VCM generation High performance Throughput: 2 MSPS, no pipeline delay Guaranteed 18-bit no missing codes INL: ±3 ppm typical, ±8 ppm guaranteed SINAD: 99 dB typical (G = 0.454) Offset error drift: 0.7 ppm/°C typical (G = 0.454) Gain error drift: ±0.5 ppm/°C typical Low total power dissipation: 51.6 mW typical at 2 MSPS SPI-/QSPI-/MICROWIRE-/DSP-compatible serial interface Versatile logic interface supply with 1.8 V, 2.5 V, 3 V, or 5 V

8 GHz to 16 GHz, 4-Channel, X Band and Ku Band Beamformer Features: 8 GHz to 16 GHz frequency range Half-duplex for transmit and receive modes Single-pin transmit and receive control 360° phase adjustment range 2.8° phase resolution ≥31 dB gain adjustment range ≤0.5 dB gain resolution Bias and control for external transmit and receive modules Memory for 121 prestored beam positions Four −20 dBm to +10 dBm power detectors Integrated temperature sensor Integrated 8-bit ADC for power detectors and temperature sensor Programmable bias modes 4-wire SPI interface
