LTC5562 - Low Power Mixer Demo Board Set Up for Downconversion Applications with IF Output Turned to 10MHz to 550MHz
Analog Devices Inc.The LTC5562 is a versatile low power mixer optimized for applications requiring very wide input bandwidth, low distortion, and low LO leakage. This mixer can be used for either upconverting or downconverting applications, and provides a nominal conversion gain of 1dB. Demonstration circuit 2483A-A showcases the LTC5562 mixer for upconverting applications while demonstration circuit 2483A-B is tuned for downconverting applications. The differential inputs are optimized for use with 1:1 transmission- line baluns, allowing very wideband impedance matching. The LTC5562 uses a 3.3V supply for low power consumption and an enable pin allows the part to be shut down for further power savings. The total mixer current is adjustable, allowing for even further power savings. The standard match frequency ranges for each board are outlined in the table below.
DC2490A
Analog Devices Inc.The LT8303 is a micropower high voltage isolated flyback converter. By sampling the isolated output voltage directly from the primary-side flyback waveform, the part requires no third winding or opto-isolator for regulation. The output voltage is programmed with a single external resistor. Internal compensation and soft-start further reduce external component count. Boundary mode operation provides a small magnetic solution with excellent load regulation. Low ripple Burst Mode operation maintains high efficiency at light load while minimizing the output voltage ripple. A 450mA, 150V DMOS power switch is integrated along with all high voltage circuitry and control logic into a 5-lead thinSOT? package.The LT8303 operates from an input voltages range of 5.5V to 100V and can deliver up to 5W of isolated output power. The high level of integration and the use of boundary and low ripple burst modes result in a simple to use, low component count, and high efficiency application solution for isolated power delivery.Applications Isolated Telecom, Datacom, Automotive, Industrial,?and Medical Power Supplies Isolated Auxiliary/Housekeeping Power Supplies
Low IQ Synchronous Boost Silent Switcher with 2.5A, 40V Switch
Analog Devices Inc.Demonstration circuit 2505A is a low IQ, Silent Switcher® synchronous boost converter featuring the LT8336. DC2505A is designed to convert an 8V to 20V source to 24V output, with up to 1.5A load current, depending on the input voltage. DC2505A operates at 2MHz switching frequency.
The DC2505A contains a selectable jumper, JP1, to aid in the selection of the desired SYNC pin mode of operation. The default setting is pulse-skipping mode of operation.
The DC2505A has an EMI filter installed. The EMI filter can be included by connecting the source to the VEMI terminal and the output to the VOUT2 terminal.
The Performance Summary section details the ratings of the DC2505A at room temperature.
The LT8336 data sheet gives a complete description of the part, operation and application information. The data sheet must be read in conjunction with this quick start
guide for DC2505A.
DC2507A
Analog Devices Inc.The LTC2986 measures a wide variety of temperature sensors and digitally outputs the result, in ?C or ?F, with 0.1?C accuracy and 0.001?C resolution. The LTC2986 can measure the temperature of virtually all standard (Type B, E, J, K, N, S, R, T) or custom thermocouples, automatically compensate for cold junction temperatures and linearize the results. The device can also measure temperature with standard 2-, 3-, or 4-wire RTDs, thermistors, and diodes. The LTC2986 includes excitation current sources and fault detection circuitry appropriate for each type of temperature sensor.The LTC2986/LTC2986-1 are 10-channel software and pin-compatible versions of the 20-channel LTC2983/LTC2984. Additional features include special modes that enable easy protection in universal multi-sensor applications, custom tables for generic ADC readings, and direct temperature readout from active analog temperature sensors. The LTC2986-1 is the EEPROM version of the LTC2986.Applications Direct Thermocouple Measurements Direct RTD Measurements Direct Thermistor Measurements Custom Sensor Applications
LTC5555 1.5GHz to 7GHz Programmable Gain Downconverting Mixer
Analog Devices Inc.Demonstration circuit 2524A is optimized for evaluation of the LTC5555 programmable gain downconverting mixer. The IC incorporates an active mixer and a digital IF VGA with 15.5dB gain control range. The IF gain is programmed in 0.5dB steps through the SPI or parallel interface. The LTC5555 has single-ended 50Ω RF input, single-ended or differential-drive LO input, and differential IF output. It features an enable pin for fast turn-on and shutdown. A reduce power mode is also available through SPI or a CMOS logic pin reducing the total current consumption by approximately 25%.
Demonstration circuit 2524A’s RF input port is 50Ω matched from 2.6GHz to 6.4GHz and can be easily tuned down to 1.5GHz or up to 7GHz. The LO port is 50Ω matched from 500MHz to 7GHz. The demo circuit’s differential IF outputs has 100Ω differential impedance and are match for 115MHz to 495MHz IF frequencies. The IF outputs can be modified for other IF frequencies or impedances. Transformer footprint pads are included on the PCB allowing the use of IF transformer to provide 50Ω single-ended IF output. See data sheet for more details on input and output impedance matching.
CAUTION: This part is sensitive to electrostatic discharge (ESD). Observe proper ESD precautions when handling the LTC5555.
DC2530A
Analog Devices Inc.The LT8640S/LT8643S synchronous step-down regulator?features second generation Silent Switcher architecture designed to minimize EMI emissions while delivering high?efficiency at high switching frequencies. This includes the integration of bypass capacitors to optimize all the?fast current loops inside and make it easy to achieve?advertised EMI performance by reducing layout sensitivity.?This performance makes the LT8640S/LT8643S ideal for?noise-sensitive applications and environments.Peak current mode control with a 30ns minimum on-time?allows high step-down ratios even at high switching frequencies. The LT8643S has external compensation to?enable current sharing and fast transient response at high?switching frequencies.Burst Mode operation enables ultralow standby current?consumption, forced continuous mode can control frequency?harmonics across the entire output load range, or spread?spectrum operation can further reduce EMI emissions.APPLICATIONS Automotive and Industrial Supplies General Purpose Step-Down
LT8653S Demo Board | Dual Channel 2A, 42V, Synchronous Step-Down Silent Switcher with 6.2μA Quiescent Current
Analog Devices Inc.Demonstration circuit 2535A is a 42V, dual channel, 2A synchronous step-down regulator featuring the LT8653S. The LT8653S is a compact, high efficiency, high speed synchronous monolithic step-down switching regulator which features the second generation Silent Switcher® technology that minimizes EMI and reduces PCB layout sensitivity. The demo board is designed for two outputs: 5V and 3.3V from a 5.5V to 42V input. Each output can source up to 2A continuous current at the same time. The wide input range allows a variety of input sources, such as automotive batteries and industrial supplies. The integrated power switches and other necessary circuitry reduce the external component count and simplify design. Selectable spread spectrum mode of operation can further improve EMI/EMC performance. Ultralow quiescent current in Burst Mode® operation achieves high efficiency at very light loads.
The DC2535A demo board is 3" by 3" in size and has four layers with 2oz copper on the outer layers and 1oz copper on the inner layers. The DC2535A operates at 2MHz switching frequency by default to minimize solution size. The LT8653S is assembled in a small thermally enhanced 4mm × 3mm LQFN package. The IC temperature rises about 50°C when both channels operate at full load, 2A each, with the default switching frequency of 2MHz.
The jumper JP2 on the demo board determines the configuration of the SYNC pin of the LT8653S. By default, the SYNC pin on the demo board is grounded for low ripple Burst Mode operation. Moving JP2 to FCM W/SSM enables the spread spectrum mode of operation by tying the SYNC pin to VCC pin. To synchronize to an external clock, move JP2 to FCM W/O SSM OR SYNC position and apply the external clock on the SYNC turret.
The jumpers JP3 and JP4 on the demo board determine the configuration of the output voltage select bit pins D0 and D1. On the DC2535A, the D0 and D1 pins are by default floating. This combination connects internal feedback resistor divider between the FB1/FB2 pins and the error amplifier which means that FB1 and FB2 pins are regulated to 5V and 3.3V respectively. On the DC2535A, FB1/FB2 pins are by default connected through 0Ω resistors to the output nodes. Refer to the LT8653S data sheet for more information on the D0 and D1 pin settings.
The demo board has an EMI filter installed. The EMI performance of the demo board (with EMI filter) is shown in Figure 1 and Figure 2. The black lines in Figure 2 are CISPR 25 class 5 limits. To achieve EMI/EMC performance as shown in Figure 2, the input EMI filter is required and the input voltage should be applied at VEMI terminal.
The LT8653S data sheet gives a complete description of the part, operation and application information. The data sheet must be read in conjunction with this manual for demo circuit 2535A.
DC2542A
Analog Devices Inc.The LTC2358-18 is an 18-bit, low noise 8-channel simultaneous sampling successive approximation register (SAR) ADC with buffered differential, wide common mode range picoamp inputs. Operating from a 5V low voltage supply, flexible high voltage supplies, and using the internal reference and buffer, each channel of this SoftSpan? ADC can be independently configured on a conversion-by-conversion basis to accept ?10.24V, 0V to 10.24V, ?5.12V, or 0V to 5.12V signals. Individual channels may also be disabled to increase throughput on the remaining channels.The integrated picoamp-input analog buffers, wide input common mode range and 128dB CMRR of the LTC2358-18 allow the ADC to directly digitize a variety of signals using minimal board space and power. This input signal flexibility, combined with ?3.5LSB INL, no missing codes at 18 bits, and 96.4dB SNR, makes the LTC2358-18 an ideal choice for many high voltage applications requiring wide dynamic range.The LTC2358-18 supports pin-selectable SPI CMOS (1.8V to 5V) and LVDS serial interfaces. Between one and eight lanes of data output may be employed in CMOS mode, allowing the user to optimize bus width and throughput.Applications Programmable Logic Controllers Industrial Process Control Power Line Monitoring Test and Measurement
DC2551A-B
Analog Devices Inc.The LT1997-2 is an attenuating (funnel) difference amplifierthat can be used to translate large differential signals tothe low voltage range compatible with ADCs. It combinesa precision operational amplifier with highly-matched resistorsto form a one-chip solution to attenuate and levelshift voltages accurately using no external components.It comes with three standard pin-selectable gain options(0.1, 0.2 and 0.25), which can be further combined toform gains from 0.0455 to 0.55 (attenuations of 1.82 to22) with accuracy of 0.006% (60ppm). The LT1997-2 alsoworks across a very wide input common-mode voltagerange (?255V), enabling robust operation in demandingindustrial environments. Its excellent resistor matchingresults in a common mode rejection ratio of greater than105dB.The resistors maintain their excellent matching overtemperature; the matching temperature coefficient isguaranteed less than 1ppm/?C. The resistors are extremelylinear with voltage, resulting in a gain nonlinearity of lessthan 2ppm.The LT1997-2 is fully specified at 5V and ?15V suppliesand from ?40?C to 125?C. The device is available in spacesaving 16-lead MSOP and 4mm ? 4mm DFN14 packages.APPLICATIONS High Voltage to Low Voltage Level Translation ADC Driver Bidirectional Wide Common Mode Range Voltage and Current Sensing Industrial Data-Acquisition Front-Ends Replacement for Isolation Circuits Differential to Single-Ended Conversion
DC2554A-B-KIT
Analog Devices Inc.The LTC4125 is a simple and high performance monolithic full bridge resonant driver capable of delivering over 5W of power wirelessly to a properly tuned receiver. The device controls the current flow in a series connected transmit coil LC network to create a simple, safe and versatile wireless power transmitter.The LTC4125 automatically adjusts its driving frequency to match the LC network resonant frequency. This AutoResonant switching allows the device to deliver maximum power from a low voltage input supply (3V to 5.5V) to a tuned receiver. To optimize system efficiency, the LTC4125 employs a periodic transmit power search and adjusts the transmission power based on the receiver load requirements. The device stops delivering power during a fault condition, or if a foreign object is detected.The LTC4125 also includes a programmable maximum average input current limit and an NTC input as additional means for foreign object and overload protection. The LTC4125 is available in a 20-lead low profile (0.75mm) 4mm ? 5mm QFN package.Applications Hermetically and/or Electrically Insulated Devices Military Sensors and Devices Medical Equipment Industrial Handhelds
DC2558A
Analog Devices Inc.The LTC4091 is a 36V Li-Ion battery charger and power backup manager. The integrated step-down switching regulator charges a battery from a primary power source while providing power to the load. If primary power is lost, the load is seamlessly transitioned to the backup Li-ion/polymer battery. To protect sensitive downstream loads, the maximum output voltage is 4.45V.The LTC4091 provides an adaptive output that tracks the battery voltage for high efficiency charging. The charge current is programmable and an end-of-charge status output (CHRG) indicates full charge. Also featured is a termination timer and an NTC thermistor input used to monitor battery temperature while charging.During backup, an internal 75m? ideal diode connects the battery to the load. An optional external ideal diode FET driver is available to reduce the voltage drop even further. 4.1V or 4.2V battery charge voltages can be selected.Applications Fleet and Asset Tracking Automotive GPS Data Loggers Automotive Telematics Systems Battery Backup Systems
DC2568A
Analog Devices Inc.The LTM4622A is a complete dual 2A step-down switching mode ?Module? (micromodule) regulator in a tiny ultrathin 6.25mm ? 6.25mm ? 1.82mm LGA and 2.42mm BGA packages. Included in the package are the switching controller, power FETs, inductor and support components. Operating over an input voltage range of 3.6V to 20V, the LTM4622A supports an output voltage range of 1.5V to 12V, set by a single external resistor. Its high efficiency design delivers dual 2A continuous, 3A peak, output current. Only a few ceramic input and output capacitors are needed.The LTM4622A supports selectable Burst Mode operation and output voltage tracking for supply rail sequencing. Its high switching frequency and current mode control enable a very fast transient response to line and load changes without sacrificing stability.Fault protection features include input overvoltage, output overcurrent and overtemperature protection.The LTM4622A is available with SnPb (BGA) or RoHS compliant terminal finish. Vin Range Vout Range Iout LTM4622 3.6V to 20V 0.6V to 5.5V Dual 2.5A or Single 5A LTM4622A 3.6V to 20V 1.5V to 12V Dual 2A or Single 4A APPLICATIONS General Purpose Point-of-Load Conversion Telecom, Networking and Industrial Equipment Medical Diagnostic Equipment Test and Debug Systems
LT8391AIFE Demo Board | 60V 2MHz Synchronous 1.5A Buck-Boost LED Driver
Analog Devices Inc.Demonstration circuit DC2575A is a 60V 2MHz synchronous buck-boost LED driver featuring the LT8391A. It accepts an input voltage from 4V to 60V and drives a single string of LEDs up to 16V at 1.5A. DC2575A runs at 2MHz switching frequency and features spread spectrum frequency modulation (SSFM) which can be enabled with a simple jumper. SSFM spreads the switching frequency from fSW to fSW + 25% for reduced EMI. SSFM is not necessary in applications where EMI is not important.
LTC6952 Demo Board | Ultralow Jitter, 4.5GHz PLL with 11 Outputs and JESD204B Support
Analog Devices Inc.The LTC6952 is a high performance, ultralow jitter,JESD204B/C clock generation and distribution IC. Itincludes a Phase Locked Loop (PLL) core, consisting ofa reference divider, phase-frequency detector (PFD) witha phase-lock indicator, ultralow noise charge pump andinteger feedback divider. The LTC6952?s eleven outputscan be configured as up to five JESD204B/C subclass1 device clock/SYSREF pairs plus one general purposeoutput, or simply eleven general purpose clock outputs fornon-JESD204B/C applications. Each output has its ownindividually programmable frequency divider and outputdriver. All outputs can also be synchronized and set toprecise phase alignment using individual coarse half-cycledigital delays and fine analog time delays.For applications requiring more than eleven total outputs,multiple LTC6952s can be connected together using theEZSync or ParallelSync synchronization protocols.Applications High Performance Data Converter Clocking Wireless Infrastructure Test and Measurement
LTC6955/LTC6955-1: Ultralow Jitter 11 Output Fanout Buffer
Analog Devices Inc.Demonstration Circuit 2611A features the LTC6955-1, Ultralow Jitter 11 Output Fanout Buffers.
By default, the DC2611A is powered from a single 3.3V supply. An option is provided to power to the DC2611A from dual supplies, allowing for the LTC6955-1’s output supply pins to connect to an LTC Silent Switcher® and the LTC6955-1 input supply pin to connect to a low noise LDO.
The differential inputs and six of the differential outputs are populated with 0.5" spaced SMA connectors. These outputs are AC-coupled with 50Ω transmission lines making them suitable to drive 50Ω impedance instruments. All registered trademarks and trademarks are the property of their respective owners.
The remaining four differential outputs are terminated with 100Ω.
A calibration path is provided to aid in accurate LTC6955-1 propagation delay measurements. The calibration path can be also reconfigured as a DC path, which allows for a convenient method of locking the LTC6955-1 outputs to an external PLL/VCO.
LTC2972 2-Channel PMBus Power System Manager with Eight Power Supply Rails
Analog Devices Inc.The DC2619A is a demonstration system for the LTC2972 power system manager that interfaces to various regulators. The board contains all the circuitry needed to demonstrate a power system that utilizes four 2-channel LTC2972 devices that manage eight power supplies. The eight power supplies include linear and switching regulators or the purpose of demonstrating a variety of methods to sense voltage and current. The demo board provides a sophisticated 8-channel programmable power supply system.
The LTC2972 is a 2-channel I2C/SMBus/PMBus power system manager that features accurate input current and energy measurement. The device monitors input current and input voltage, and calculates input power and energy. The DC2619A demonstrates the ability of the LTC2972 to sequence, trim, margin, supervise, monitor, and log faults for eight power supplies. The LTC2972 monitors each channel’s output voltage and output current and also monitors external temperature sensors and its own internal die temperature.
The DC2619A board contains eight independent power supply rails. The +5V/–5V rails are based on the switched capacitor LTC3260 regulator, the 1.0V/1.2V rails are powered by an LTC3633 switching regulator, the 1.5V/1.8V rails are powered by LTC3405A switching regulators, and the 2.5/3.3V rails are powered by LT3086/LT3055 linear regulators. The board is pre-configured with these voltages and may be re-configured with feedback resistors.
The LTpowerPlay® graphical user interface (GUI) supports this demonstration system and enables complete control of all the features of the LTC2972. Together, the LTpowerPlay software and DC2619A hardware system create a powerful development environment for designing and testing configuration settings of the LTC2972. LTpowerPlay stores these settings in the LTC2972’s internal EEPROM or in a project file. The software displays all of the configuration settings and real time measurements from the power system management IC. Telemetry allows easy access and decoding of the fault log created by the LTC2972. The board comes preprogrammed with the EEPROM values appropriate for the eight power supply rails on the DC2619A. Just plug and play!
Order pre-programmed devices from Linear Express® using LTpowerPlay.
The following items are required:
+12VDC Power Supply
USB-to-I2C/SMBus/PMBus Controller (DC1613)
LTpowerPlay Software
LTM4678 Demo Board | Dual 25A or Single 50A μModule Regulator with Digital Power System Management 4x LTM4678; 200A
Analog Devices Inc.Demonstration circuit 2638A-C is a high efficiency, high density, μModule regulator with 4.5V to 16V input range. The output voltage is adjustable from 0.5V to 3.3V, and it can supply 200A maximum load current. The demo board has four LTM4678 μModule® regulators, and the LTM4678 is a dual 25A or single 50A step-down regulator with PMBus power system management. Please see LTM4678 data sheet for more detailed information.
DC2638A-C powers up to default settings and produce power based on configuration resistors without the need for any serial bus communication. This allows easy evaluation of the DC/DC converter. To fully explore the extensive power system management features of the part, download the GUI software LTpowerPlay® onto your PC and use ADI’s I2C/SMBus/PMBus dongle DC1613A to connect to the board. LTpowerPlay allows the user to reconfigure the part on-the-fly and store the configuration in EEPROM, view telemetry of voltage, current, temperature and fault status.
GUI Download: The software can be downloaded from: LTpowerPlay.
For more details and instructions of LTpowerPlay, please refer to LTpowerPlay GUI for LTM4678 Quick Start Guide.
DC2642A-A
Analog Devices Inc.The LTC4041 is a complete supercapacitor backup system for 2.9V to 5.5V supply rails. It contains a high current step-down DC/DC converter to charge a single supercapacitor or two supercapacitors in series. When input power is unavailable, the step-down regulator operates in reverse as a step-up regulator to backup the systemoutput from the supercapacitor(s).The LTC4041?s adjustable input current limit function reduces charge current to protect the input supply from overload while an external disconnect switch isolates theinput supply during backup. When the input supply drops below the adjustable PFI threshold, the 2.5A boost regulator delivers power from the supercapacitor to the systemoutput.An optional input overvoltage protection (OVP) circuit protects the LTC4041 from high voltage damage at the VIN pin. An internal supercapacitor balancing circuit maintainsequal voltages across each supercapacitor and limits the maximum voltage of each supercapacitor to a pre-determined value. The LTC4041 is available in a low profile (0.75mm) 24-Lead 4mm ? 5mm QFN package.ApplicationsRide-Through ?Dying Gasp? SuppliesHigh Current Ride-Through 3V to 5V UPSPower Meters/Industrial AlarmsServers/Solid State Drives
DC2654A
Analog Devices Inc.The LTC4162-L is an advanced monolithic synchronous step-down switching battery charger and PowerPath? manager that seamlessly manages power distribution between input sources such as wall adapters, backplanes, solar panels, etc., and a rechargeable Lithium-Ion/Polymer battery.A high resolution measurement system provides extensive telemetry information for circuit voltages, currents, battery resistance and temperature which can all be read back over the I2C port. The I2C port can also be used to configure many charging parameters including charging voltages and currents, termination algorithms and numerous system status alerts.The LTC4162-L can charge Lithium-Ion cell stacks from 1 cell to 8 cells with as much as 3.2A of charge current.The power path topology decouples the output voltage from the battery allowing a portable product to start up instantly under very low battery voltage conditions.The LTC4162-L is available in a thermally enhanced 28-pin 4mm ? 5mm ? 0.75mm QFN surface mount package.
VCO Rider Board with Loop Filter
Analog Devices Inc.Demonstration circuit 2664A is a VCO Rider Board with Loop Filter that supports the popular 0.5" × 0.5" VCO package footprint.
The DC2664A expedites evaluation of Phase-Locked Loop (PLL) devices requiring an external Voltage Controlled Oscillator (VCO). Without the DC2664A, each
VCO and PLL combination requires a unique loop filter design, resulting in several PLL demo board modifications to evaluate each VCO. These board modifications
are time consuming and often result in damage to either the PLL or the VCO.
The DC2664A integrates the VCO and loop filter allowing these unique designs to reside on multiple DC2664As. The DC2664A RFOUT and VTUNE SMA connections allow the user to quickly evaluate a PLL with multiple VCOs without risk of damage from multiple board modifications.
VCOs are notoriously sensitive to power supply noise and spurs. The DC2664A resolves the concern of locating a low noise and low spurious lab supply by powering the VCO with an onboard ultralow noise and ultrahigh PSRR LDO, the LT3042. A second LT3042 LDO is available on the DC2664A to power an active loop filter. Both LDOs
are powered from a single supply, simplifying the number of lab supplies required to evaluate a VCO and PLL combination.
The DC2664A was designed to mate directly with the LTC6955 (DC2611A) and LTC6952 (DC2609A) demo boards.
