107384-HMC492LP3
Analog Devices Inc.The HMC492LP3(E) is a low noise Divide-by-2 Static Divider utilizing InGaP GaAs HBT technology packaged in leadless 3x3 mm QFN surface mount plastic package. This device operates from DC (with a square wave input) to 18 GHz input frequency from a single +5V DC supply. The low additive SSB phase noise of -150 dBc/Hz at 100 kHz offset helps the user maintain excellent system noise performance.APPLICATIONS Point-to-Point/Multi-Point Radios VSAT Radios Fiber Optic Test Equipment Military
107384-HMC494LP3
Analog Devices Inc.The HMC494LP3(E) is a low noise Divide-by-8 Static Divider utilizing InGaP GaAs HBT technology packaged in leadless 3?3 mm QFN surface mount plastic package. This device operates from DC (with a square wave input) to 18 GHz input frequency from a single +5V DC supply. The low additive SSB phase noise of -150 dBc/Hz at 100 kHz offset helps the user maintain excellent system noise performance.APPLICATIONS Point-to-Point / Multi-Point Radios? VSAT Radios? Fiber Optic? Test Equipment? Military
108349-HMC450QS16G
Analog Devices Inc.The HMC450QS16G(E) is a high efficiency GaAs InGaP HBT Medium Power MMIC amplifier operating between 800 and 1000 MHz. The amplifier is packaged in a low cost, surface mount 16 lead package and offers the same pinout and functionality as the higher band HMC413QS16G 1.6 - 2.3 GHz PA. With a minimum of external components, the amplifier provides 26 dB of gain, +40 dBm OIP3 and +28.5 dBm of saturated power from a +5V supply voltage. The integrated power control (Vpd) can be used for full power down or RF output power/current control. The combination of high gain and high output IP3 make the HMC450QS16G(E) an ideal linear driver for Cellular, PCS & 3G applications.Applications GSM, GPRS, & Edge? CDMA & WCDMA? Base Stations & Repeaters
108648-HMC6380LC4B
Analog Devices Inc.The HMC6380LC4B is a wideband MMIC VoltageControlled Oscillator which incorporates the resonator,negative resistance device, and varactor diode. Outputpower and phase noise performance are excellentover temperature due to the oscillator?s monolithicconstruction. The Vtune port accepts an analog tuningvoltage from 0 to +23V. The HMC6380LC4B VCOoperates from a single +5V supply, consumes only75 mA of current, and is housed in a RoHS compliantSMT package. This wideband VCO uniquely combinesthe attributes of ultra small size, low phase noise, lowpower consumption, and wide tuning range.Applications Industrial/Medical EquipmentMeasurement EquipmentSatcomMilitary Radar, EW, & ECM
109236-HMC549MS8G
Analog Devices Inc.The HMC549MS8GE is a GaAs pHEMT MMIC?Low Noise Amplifier that are ideal pre-amplifiers?for CATV Set Top Box, Home Gateway, and?Digital Television receiver operating between?40 and 960 MHz. This high dynamic range LNA has?been optimized to provide 3.5 dB noise figure and?+27 dBm output IP3 from a single supply of +5V @?120 mA. The outputs of this LNA are extremely well?balanced, and can be used to drive a differential input?tuner with very high input IP2 requirements. This dual?purpose LNA can also be used as an active splitter?driving two single-ended input tuners. This LNA is?housed in a RoHS compliant MSOP8G SMT package?with exposed ground paddle.Applications DTV Receivers? Multi-Tuner Set Top Boxes? PVRs & Home Gateways
109293-HMC535LP4
Analog Devices Inc.The HMC535LP4(E) is a GaAs InGaP Heterojunction Bipolar Transistor (HBT) MMIC PLO. The PLO?s phase noise performance is excellent over temperature, shock, and process due to the oscillator?s monolithic structure. Power output is +9 dBm typical from a +5V supply voltage.All functions (VCO, Op-Amp, PFD, Prescaler) are fully integrated while providing allowances for off-chip customer specific loop components. The PLO MMIC accepts a single-ended or a differential reference oscillator input signal in the range of 230 to 240 MHz, and a digital Lock Detector (LD) output is provided to confirm the status of the loop. The phase-locked oscillator is packaged in a leadless QFN 4?4 mm surface mount package.APPLICATIONS VSAT Radio? Point-to-Point & Point-to-Multi-Point Radio? Test Equipment & Industrial Controls? Military End-Use
109994-HMC453QS16G
Analog Devices Inc.The HMC453QS16G(E) is a high dynamic range GaAs InGaP Heterojunction Bipolar Transistor (HBT) 1.6 watt MMIC power amplifier operating between 0.4 and 2.2 GHz. Packaged in a miniature 16 lead QSOP plastic package, the amplifier gain is typically 21.5 dB at 0.4 GHz and 8 dB at 2.1 GHz. Utilizing a minimum number of external components and a single +5V supply, the amplifier output IP3 can be optimized to +47 dBm at 0.4 GHz or +51 dBm at 2.1 GHz. The power control (VPD) can be used for full power down or RF output power/current control. The high output IP3 and PAE make the HMC453QS16G(E) ideal power amplifier for Cellular/ PCS/3G, WLL, ISM and Fixed Wireless applications.Applications GSM, GPRS & EDGE? CDMA & W-CDMA? CATV/Cable Modem? Fixed Wireless & WLL
110227-HMC507LP5
Analog Devices Inc.The HMC507LP5(E) is a GaAs InGaP Heterojunction Bipolar Transistor (HBT) MMIC VCO. The HMC507LP5(E) integrates resonators, negative resistance devices, varactor diodes and feature a half frequency output. The VCO?s phase noise performance is excellent over temperature, shock, and process due to the oscillator?s monolithic structure. Power output is +13.5 dBm typical from a +5V supply. The voltage controlled oscillator is packaged in a leadless QFN 5x5 mm surface mount package, and requires no external matching components.APPLICATIONS VSAT Radio Point to Point/Multi-Point Radio? Test Equipment & Industrial Controls? Military End-Use
110227-HMC509LP5
Analog Devices Inc.The HMC509LP5(E) is a GaAs InGaP Heterojunction Bipolar Transistor (HBT) MMIC VCOs. The HMC509LP5(E) integrates resonators, negative resistance devices, varactor diodes and feature a half frequency output. The VCO?s phase noise performance is excellent over temperature, shock, and process due to the oscillator?s monolithic structure. Power output is +13 dBm typical from a +5V supply. The voltage controlled oscillator is packaged in a leadless QFN 5x5 mm surface mount package, and requires no external matching components.APPLICATIONS VSAT Radio? Point-to-Point/Multi-Point Radio? Test Equipment & Industrial Controls? Military End-Use
110227-HMC515LP5
Analog Devices Inc.The HMC515LP5(E) is a GaAs InGaP Heterojunction Bipolar Transistor (HBT) MMIC VCO. The HMC515LP5(E) integrates resonators, negative resistance devices, varactor diodes and feature half frequency and divide-by-4 outputs. The VCO?s phase noise performance is excellent over temperature, shock, and process due to the oscillator?s monolithic structure. Power output is +10 dBm typical from a +5V supply voltage. The prescaler function can be disabled to conserve current if not required. The voltage controlled oscillator is packaged in a leadless QFN 5x5 mm surface mount package, and requires no external matching components.APPLICATIONS VSAT Radio? Point-to-Point/Multi-Point Radio? Test Equipment & Industrial Controls? Military End-Use
110227-HMC534LP5
Analog Devices Inc.The HMC534LP5(E) is a GaAs InGaP Heterojunction Bipolar Transistor (HBT) MMIC VCO. The HMC534LP5(E) integrates resonators, negative resistance devices, varactor diodes and feature half frequency and divide-by-4 outputs. The VCO?s phase noise performance is excellent over temperature, shock, and process due to the oscillator?s monolithic structure. Power output is +11 dBm typical from a +5V supply voltage. The prescaler and RF/2 functions can be disabled to conserve current if not required. The voltage controlled oscillator is packaged in a leadless QFN 5x5 mm surface mount package, and requires no external matching components.APPLICATIONS Point-to-Point/Multi-point Radio Test Equipment & Industrial Controls SATCOM Military End-Use
110227-HMC632LP5
Analog Devices Inc.The HMC632LP5(E) is a GaAs InGaP Heterojunction Bipolar Transistor (HBT) MMIC VCO. The HMC632LP5(E) integrates resonators, negative resistance devices, varactor diodes and features half frequency and divide-by-4 outputs. The VCO?s phase noise performance is excellent over temperature, shock, and process due to the oscillator?s monolithic structure. Power output is +9 dBm typical from a +5V supply voltage. The prescaler and RF/2 functions can be disabled to conserve current if not required. The voltage controlled oscillator is packaged in a leadless QFN 5x5 mm surface mount package, and requires no external matching components.APPLICATIONS Point to Point/Multipoint Radio Test Equipment & Industrial Controls SATCOM Military End-Use
110227-HMC734LP5
Analog Devices Inc.The HMC734 is a GaAs InGaP Heterojunction Bipolar Transistor (HBT) MMIC VCO. The HMC734 integrates a resonator, negative resistance device, varactor diode and features a divide-by-4 frequency output. The VCO's phase noise performance is excellent over temperature, shock, and process due to the oscillator's monolithic structure. Power output is +18 dBm typical from a +5V supply voltage. The prescaler function can be disabled to conserve current if not required. The voltage controlled oscillator is packaged in a leadless QFN 5?5 mm surface mount package, and requires no external matching components.APPLICATIONS Point-to-Multi-Point Radios Test Equipment & Industrial Controls SATCOM Military End-Use
112261-HMC738LP4
Analog Devices Inc.The HMC738 is a GaAs InGaP Heterojunction Bipolar Transistor (HBT) MMIC VCO. The HMC738 integrates a resonator, negative resistance device, varactor diode and divide-by-16 prescaler. The VCOs phase noise performance is excellent over temperature, shock, and process due to the oscillator's monolithic structure. Power output is +9 dBm typical from a 5V supply voltage. The voltage controlled oscillator is packaged in a low cost leadless QFN 4x4 mm surface mount package.APPLICATIONS Point-to-Point Radios Point-to-Multi-Point Radios/LMDS VSAT
113589-HMC3653LP3B
Analog Devices Inc.The HMC3653LP 3BE is a HBT Gain Block MMI Camplifier covering 7 GHz to 15 GHz and packagedin a 3x3 mm plastic QFN SM T package. This versatileamplifier can be used as a cascadable IF or RF gainstage in 50 Ohm applications. The HMC3653LP 3BEdelivers 15 dB gain, and +15 dBm output P1dB withonly 4 dB noise figure.Applications Point-to-Point Radios Point-to-Multipoint Radios VSAT LO Driver for HMC Mixers Military EW & ECM
118040-HMC311SC70
Analog Devices Inc.The HMC311SC70(E) is a GaAs InGaP Heterojunction Bipolar Transistor (HBT) Gain Block MMIC SMT DC to 8 GHz amplifier. Packaged in an industry standard SC70, the amplifier can be used as either a cascadable 50 Ohm gain stage or to drive the LO port of HMC mixers with up to +15 dBm output power. The HMC311SC70(E) offers 15 dB of gain and an output IP3 of +30 dBm while requiring only 54 mA from a +5V supply. The Darlington topology results in reduced sensitivity to normal process variations, and yields excellent gain stability over temperature while requiring a minimal number of external bias components.Applications Cellular / PCS / 3G WiBro / WiMAX / 4G Fixed Wireless & WLAN CATV, Cable Modem & DBS Microwave Radio & Test Equipment
118097-HMC646LP2
Analog Devices Inc.The HMC646LP2(E) is an SPDT switch in a leadless DFN surface mount plastic package for use in transmit / receive and LNA protection applications which require very low distortion and high power handling of up to 40 watts with less than 10% duty cycle. This robust switch can control signals from 100 - 2100 MHz* and is ideal for TD-SCDMA / 3G repeaters, PMR, automotive telematics, and satellite subscriber terminal applications. The design provides exceptional P0.1 dB of +46 dBm and +74 dBm IIP3 on the Transmit (Tx) port. The failsafe topology provides a low loss path from Tx to RFC, when no DC power is available.APPLICATIONS LNA Protection & T/R Switching TD-SCDMA / 3G Infrastructure Satellite Subscriber Terminals Private Mobile Radio & Public Safety Handsets Automotive Telematics
118099-HMC646LP2
Analog Devices Inc.The HMC646LP2(E) is an SPDT switch in a leadless DFN surface mount plastic package for use in transmit / receive and LNA protection applications which require very low distortion and high power handling of up to 40 watts with less than 10% duty cycle. This robust switch can control signals from 100 - 2100 MHz* and is ideal for TD-SCDMA / 3G repeaters, PMR, automotive telematics, and satellite subscriber terminal applications. The design provides exceptional P0.1 dB of +46 dBm and +74 dBm IIP3 on the Transmit (Tx) port. The failsafe topology provides a low loss path from Tx to RFC, when no DC power is available.APPLICATIONS LNA Protection & T/R Switching TD-SCDMA / 3G Infrastructure Satellite Subscriber Terminals Private Mobile Radio & Public Safety Handsets Automotive Telematics
119197-HMC655LP2E
Analog Devices Inc.The HMC652LP2E / 653LP2E / 654LP2E / 655LP2E are a line of wideband fixed value SMT 50 Ohm matched attenuators which offer attenuation levels of 2, 3, 4 and 6 dB respectively. These passive attenuators are ideal for military, test equipment, and other wideband applications where extremely flat attenuation, and excellent VSWR vs. frequency are required.These wideband attenuators handle up to +25 dBm of input power, and are compatible with high volume surface mount manufacturing techniques.APPLICATIONS Fiber Optics Microwave Radio Military & Space Test & Measurement Scientific Instruments RF/Microwave Circuit Prototyping
119935-HMC685LP4
Analog Devices Inc.The HMC685LP4(E) is a high dynamic range passive MMIC mixer with integrated LO amplifier in a 4x4 SMT QFN package covering 1.7 to 2.2 GHz. Excellent input IP3 performance of +32 dBm for down conversion is provided for 3G & 4G GSM/CDMA applications at an LO drive of 0 dBm. With an input 1 dB compression of +27 dBm, the RF port will accept a wide range of input signal levels. Conversion loss is 8 dB typical. The DC to 500 MHz IF frequency response will satisfy GSM/CDMA transmit or receive frequency plans. The HMC685LP4(E) is pin for pin compatible with the HMC684LP4(E) which is a 700 - 1000 MHz mixer with LO amplifier.APPLICATIONS Cellular/3G & LTE/WiMAX/4G Basestations & Repeaters GSM, CDMA & OFDM Transmitters and Receivers
