Evaluation Kit SLF3S-1300F
SensirionMultiple Function Sensor Development Tools Flow Meter Kit, Liquid Flow
EVAL01-HMC6981LS6
Analog Devices Inc.The HMC6981 is a four-stage GaAs pHEMT MMIC Power Amplifier with an integrated temperature compensated on-chip Power Detector, which operates between 15 and 20 GHz. The amplifier provides 26 dB of gain, +34.5 dBm of saturated output power, and 25% PAE from a +6V supply. With an excellent output IP3 of +43.5 dBm, the HMC6981 is ideal for linear applications such as high capacity point-to-point or point-to-multi-point radios or SATCOM applications demanding +34.5 dBm of efficient saturated output power. The HMC6981 is housed in a ceramic 6 x 6 mm high frequency air cavity package which exhibits low thermal resistance and is compatible with high volume surface mount manufacturing techniques. The RF I/Os are internally matched to 50 Ohms.Applications Point-to-Point Radios Point-to-Multi-Point Radios SATCOM
KSZ8863RLL-EVAL
Microchip Technology Inc.Ethernet Development Tools 3-Port Copper 10/100 Ethernet Switch with 1x RMII Interface - Evaluation Board
EVM3690-30A-BF-00A
Monolithic Power Systems (MPS)Evaluation Board, MPM3690GBF-30A, Synchronous Step-Down (Buck) Module, Power Management
EVALPASCO2MINIBOARDTOBO1
Infineon Technologies AGMultiple Function Sensor Development Tools Evaluation Kit for plug & play performance assessment (CO2 read-out in ppm)
STEVAL-STWINWFV1
STMicroelectronicsPosition Sensor Development Tools Wi-Fi expansion for the SensorTile Wireless Industrial Node (STWIN) kit
M2GL-EVAL-KIT
AtmelProgrammable Logic IC Development Tools Igloo2 Low Cost Eval KIT / M2GL010T-1FGG484 w/ Flashpro4
KSZ8999-EVAL
Microchip Technology Inc.Ethernet Development Tools KSZ899 Eval, No Power Supply Incl.
EVQ1925-R-00A
Monolithic Power Systems (MPS)100V, 4A, High-Frequency, Half-Bridge Gate Driver Evaluation Board
104898-HMC394LP4
Analog Devices Inc.The HMC394LP4(E) is a low noise GaAs HBT programmable 5-bit counter in 4x4 mm leadless surface mount package. This device allows continuous division from N= 2 to 32 at input frequencies up to 2.2 GHz. The output voltage swing is 800 mV with a duty cycle inversely proportional to N. The low additive SSB phase noise of -153 dBc/Hz at 100 KHz offset makes this counter an excellent choice for low noise synthesizer applications.APPLICATIONSProgrammable divider for offset synthesizer and variable divide by N applications: Satellite Communication Systems Point-to-Point and Point-to-Multi-Point Radios LMDS SONET
104991-HMC327MS8G
Analog Devices Inc.The HMC327MS8G(E) is a high efficiency GaAs InGaP Heterojunction Bipolar Transistor (HBT) MMIC Power amplifier which operates between 3 and 4 GHz. The amplifier is packaged in a low cost, surface mount 8 leaded package with an exposed base for improved RF and thermal performance. With a minimum of external components, the amplifier provides 21 dB of gain, +30 dBm of saturated power at 45% PAE from a +5V supply voltage. Power down capability is available to conserve current consumption when the amplifier is not in use.Applications Wireless Local Loop
105000-HMC413QS16G
Analog Devices Inc.The HMC413QS16G(E) is a high efficiency GaAs InGaP Heterojunction Bipolar Transistor (HBT) MMIC Power amplifier which operates between 1.6 and 2.2 GHz. The amplifier is packaged in a low cost, surface mount 16 leaded package with an exposed base for improved RF and thermal performance. With a minimum of external components, the amplifier provides 23 dB of gain, +29.5 dBm of saturated power at 42% PAE from a +5V supply voltage. The amplifi er can also operate with a 3.6V supply. Vpd can be used for full power down or RF output power/current control.Applications Cellular / PCS / 3G Portable & Infrastructure Wireless Local Loop
105143-HMC194AMS8
Analog Devices Inc.The HMC194AMS8E is a low-cost SPDT switch in an 8-lead MSOP packages for use in applications which require high isolation between two RF paths. The devices can control signals from DC to 3 GHz and have been optimized to provide extremely high isolation with minimal insertion loss in medium and low power applications. On chip circuitry allows positive voltage control operation at very low DC cur- rents with control inputs compatible with CMOS and most TTL logic families. RF1 and RF2 are reflective opens when ?OFF?.APPLICATIONS Cellular/PCS Base Stations Portable Wireless MMDS & WirelessLAN
