ADMV7310-EVALZ
Analog Devices Inc.The ADMV7310 is a fully integrated system in package (SiP),in phase/quadrature (I/Q) upconverter that operates betweenan intermediate frequency (IF) input range of dc to 2 GHz anda radio frequency (RF) output range of 71 GHz to 76 GHz. Thedevice uses an image rejection mixer that is driven by a 6? localoscillator (LO) multiplier. The mixer RF output is followed by avariable gain amplifier (VGA) and a power amplifier (PA),providing a conversion gain of 35 dB typical. Differential I andQ mixer inputs are provided and can be driven with differentialI and Q baseband waveforms for direct conversion applications.Alternatively, the inputs can be driven using an external 90? hybridand two external 180? hybrids for single-ended applications.The ADMV7310 comes in a fully integrated, surface-mount,50-terminal, 16.00 mm ? 14.00 mm, chip array small outline nolead cavity (LGA_CAV) package. The ADMV7310 operatesover the ?40?C to +85?C temperature range.APPLICATIONS E-band communication systems High capacity wireless backhauls Test and measurement Aerospace and defense
ADMV8818-EVALZ
Analog Devices Inc.The ADMV8818-EP is a fully monolithic microwave integrated circuit (MMIC) that features a digitally selectable frequency of operation. The device features four independently controlled high-pass filters (HPFs) and four independently controlled low-pass filters (LPFs) that span the 2 GHz to 18 GHz frequency range.The flexible architecture of the ADMV8818-EP allows the 3 dB cutoff frequency (f3dB) of the high-pass and low-pass filters to be controlled independently to generate up to 4 GHz of bandwidth. The digital logic control on each filter is 4 bits wide (16 states) and controls the on-chip reactive elements to adjust the f3dB. The typical insertion loss is 9 dB, and the wideband rejection is 35 dB, which is ideally suited for minimizing system harmonics.This tunable filter can be used as a smaller alternative to large switched filter banks and cavity tuned filters, and this device provides a dynamically adjustable solution in advanced communications applications.APPLICATIONSTest and measurement equipment Military radar, electronic warfare, and electronic countermeasures Satellite communications and space Industrial and medical equipment
ADN4605-EVALZ
Analog Devices Inc.The ADN4605 is a 40 ? 40 asynchronous, protocol agnostic,?digital crosspoint switch, with 40 differential PECL/CML-compatible inputs and 40 differential programmable CML outputs.The ADN4605 is optimized for NRZ signaling with data rates of up to 4.25 Gbps per port. Each port offers adjustable levels of input equalization, programmable output swing, and output preemphasis/deemphasis.The ADN4605 nonblocking switch core implements a 40 ? 40?crossbar and supports independent channel switching through serial and parallel control interfaces. The ADN4605 has low?latency and very low channel-to-channel skew.An I2C, SPI, or parallel interface is used to communicate with the device for control of connectivity and other features.The ADN4605 is assembled in a 35 mm ? 35 mm, 352 BGA?package and operates over a temperature range of ?40?C to +85?C.APPLICATIONS Digital video (HDMI, DVI, DisplayPort, 3G/HD/SD-SDI) Fiber optic network switching High-speed serial backplane routing to OC-48 with FEC XAUI, 4x Fibre Channel, Infiniband?, and GbE over backplane Data storage networks
ADN8835CP-EVALZ
Analog Devices Inc.The ADN8835 is a monolithic TEC controller with an integrated TEC controller. It has a linear power stage, a pulse-width modulation (PWM) power stage, and two zero-drift, rail-to-rail chopper amplifiers. The linear controller works with the PWM driver to control the internal power MOSFETs in an H bridge configuration. By measuring the thermal sensor feedback voltage and using the integrated operational amplifiers as a proportional integral differential (PID) compensator to condition the signal, the ADN8835 drives current through a TEC to settle the temperature of a laser diode or a passive component attached to the TEC module to the programmed target temperature.The ADN8835 supports negative temperature coefficient (NTC) thermistors as well as positive temperature coefficient (PTC) resistive temperature detectors (RTDs). The target temperature is set as an analog voltage input either from a digital-to-analog converter (DAC) or from an external resistor divider.The temperature control loop of the ADN8835 is stabilized by PID compensation utilizing the built in, zero-drift chopper amplifiers. The internal 2.50 V reference voltage provides a 1% accurate output that biases a thermistor temperature sensing bridge as well as a voltage divider network to program the maximum TEC current and voltage limits for both the heating and cooling modes. With the zero-drift chopper amplifiers, excellent long-term temperature stability is maintained via an autonomous analog temperature control loop.APPLICATIONS TEC temperature control Optical modules Optical fiber amplifiers Optical networking systems Instruments requiring TEC temperature control
ADP1031CP-1-EVALZ
Analog Devices Inc.The ADP1031 is a high performance, isolated micropowermanagement unit (PMU) that combines an isolated flybackdc-to-dc regulator, an inverting dc-to-dc regulator, and abuck dc-to-dc regulator, providing three isolated power rails.Additionally, the ADP1031 contains four, high speed, serialperipheral interface (SPI) isolation channels and three general-purpose isolators for channel to channel applications where lowpower dissipation and small solution size is required.Operating over an input voltage range of +4.5 V to +60 V, theADP1031 generates isolated output voltages of +6 V to +28 V(adjustable version) or+ 21 V and +24 V (fixed versions) forVOUT1, factory programmable voltages of +5.15 V, +5.0 V, or+3.3 V for VOUT2, and an adjustable output voltages of ?24 V to?5 V for VOUT3.By default, the ADP1031 flyback regulator operates at a 250 kHzswitching frequency and the buck and inverting regulators operateat 125 kHz. All three regulators are phase shifted relative to eachother to reduce electromagnetic interference (EMI). The ADP1031can be driven by an external oscillator in the range of 350 kHzto 750 kHz to ease noise filtering in sensitive applications.The digital isolators integrated in the ADP1031 use AnalogDevices, Inc., iCoupler? chip scale transformer technology,optimized for low power and low radiated emissions.The ADP1031 is available in a 9 mm ? 7 mm, 41-lead LFCSP andis rated for a ?40?C to +125?C operating junction temperaturerange.Applications Industrial automation and process control Instrumentation and data acquisition systems Data and power isolation
ADP1032CP-3-EVALZ
Analog Devices Inc.The ADP1032 is a high performance, isolated micropower management unit (PMU) that combines an isolated flyback and a dc-to-dc regulator providing two isolated power rails. Additionally, the ADP1032 contains four high speed serial peripheral interface (SPI) isolation channels and three general-purpose isolators for channel to channel applications where low power dissipation and small solution size is required. Operating over an input voltage range of 4.5 V to 60 V, the ADP1032 generates isolated output voltages of 6 V to 28 V (adjustable version) or 24 V (fixed version) for VOUT1, and factory programmable voltages of 5.15 V, 5.0 V, or 3.3 V for VOUT2.?By default, the ADP1032 flyback regulator operates at a 250 kHz switching frequency, and the buck regulator operates at 125 kHz.?The two regulators are phase shifted relative to each other to reduce electromagnetic interference (EMI). The ADP1032 can be driven by an external oscillator in the range of 350 kHz to 750 kHz to ease noise filtering in sensitive applications.?The digital isolators integrated in the ADP1032 use Analog Devices, Inc., iCoupler? chip scale transformer technology, optimized for low power and low radiated emissions. The ADP1032 is available in a 9 mm ? 7 mm, 41-lead LFCSP and is rated for a ?40?C to +125?C operating junction temperature range.?
LTC3375EUK Demo Board 8-Channel Programmable, Parallelable, 1A Buck DC/DCs (DC590 Companion board)
Analog Devices Inc.Demonstration circuit 1921A is a digitally programmable 8-output power supply with a pushbutton controller and watchdog timer, featuring the LTC3375. The LTC3375 has eight synchronous buck regulators, each with an independent VIN supply. The buck regulators may be paralleled together to create a higher power buck regulator with a single inductor. The input range of the LTC3375 is ideal for single cell Li-Ion/Polymer battery applications. The switching regulator settings, such as enables, feedback voltages, operating modes, phasing and other functions, can be controlled via I2C. The buck regulators can also be enabled via external precision threshold enable pins to allow hardwired power-up sequences.
DC1924A
Analog Devices Inc.The LT8705 is a high performance buck-boost switching regulator controller that operates from input voltages above, below or equal to the output voltage. The part has integrated input current, input voltage, output current and output voltage feedback loops. With a wide 2.8V to 80V input and 1.3V to 80V output range, the LT8705 is compatible with most solar, automotive, telecom and battery-powered systems.The LT8705 includes servo pins to indicate which feedback loops are active. The MODE pin selects among Burst Mode? operation, discontinuous or continuous conduction mode at light loads. Additional features include a 3.3V/12mA LDO, a synchronizable fixed operating frequency, onboard gate drivers, adjustable UVLO, along with input and output current monitoring with programmable maximum levels. LT8705 LT8705A Improved, pin-to-pin compatible version of LT8705. Recommended for all new designs Applications High Voltage Buck-Boost Converters Input or Output Current Limited Converters
DC1925A-A
Analog Devices Inc.The LTC2378-20 is a low noise, low power, high speed 20-bit successive approximation register (SAR) ADC. Operating from a 2.5V supply, the LTC2378-20 has a ?VREF fully differential input range with VREF ranging from 2.5V to 5.1V. The LTC2378-20 consumes only 21mW and achieves ?2ppm INL maximum, no missing codes at 20 bits with 104dB SNR.The LTC2378-20 has a high speed SPI-compatible serial interface that supports 1.8V, 2.5V, 3.3V and 5V logic while also featuring a daisy-chain mode. The fast 1Msps throughput with no cycle latency makes the LTC2378-20 ideally suited for a wide variety of high speed applications. An internal oscillator sets the conversion time, easing external timing considerations. The LTC2378-20 automatically powers down between conversions, leading to reduced power dissipation that scales with the sampling rate.The LTC2378-20 features a unique digital gain compression (DGC) function, which eliminates the driver amplifier?s negative supply while preserving the full resolution of the ADC. When enabled, the ADC performs a digital scaling function that maps zero-scale code from 0V to 0.1 ? VREF and full-scale code from VREF to 0.9 ? VREF. For a typical reference voltage of 5V, the full-scale input range is now 0.5V to 4.5V, which provides adequate headroom for powering the driving amplifier from a single 5.5V supply.Applications Medical Imaging High Speed Data Acquisition Portable or Compact Instrumentation Industrial Process Control Low Power Battery-Operated Instrumentation ATE
LTC4353DE Demo Board | Dual Low Voltage Ideal Diode Controller
Analog Devices Inc.DC1926A: Demo Board for the LTC4353 Dual Low Voltage Ideal Diode Controller.
DC1928A
Analog Devices Inc.The LTC3867 is a current mode synchronous step-down switching regulator controller that drives all N-channel power MOSFET stages. Output voltage transient excursions are minimized by use of a nonlinear control architecture to eliminate clock latency issues.The maximum current sense voltage is programmable from 30mV to 75mV, allowing the use of either a discrete sense resistor or the inductor DCR as the sensing element. Programmable DCR temperature compensation allows constant current limit regardless of inductor temperature. Programmable inductor temperature-based thermal shutdown protects the power components from thermal stress. Soft recovery from output shorts or overcurrent minimizes output overshoot.The LTC3867 features a precision 0.6V reference and can regulate output voltages up to 14V from a wide 4V to 38V input supply range. The LTC3867 includes a high speed differential remote sense amplifier. Burst Mode? operation, continuous and pulse-skipping modes are supported. The LTC3867 is available in a 24-lead (4mm ? 4mm) QFN package.Applications Automotive Systems Telecom Systems Industrial Equipment Distributed DC Power Systems
LTC3891EUDC Demo Board: 16V to 60V Input, VOUT = 12V at 15A
Analog Devices Inc.Demonstration circuit 1940A is a low quiescent current, synchronous buck converter featuring the LTC3891EUDC. This demo board converts a 16V to 60V voltage to a 12V at 15A output. The main features of this board include an internal LDO for gate drive power from VIN or EXTVCC, RUN and PGOOD pins, a mode selector that allows the converter to run in constant current mode (CCM), pulse-skipping or Burst Mode® operation, and selectable current limit. The DC1940A supports an adjustable output voltage, soft-start and tracking. The wide input voltage range of 16V to 60V is suitable for double battery automotive and distributed DC power systems where low quiescent current is important.
DC1942C
Analog Devices Inc.The LTC6804 is a 3rd generation multicell battery stack monitor that measures up to 12 series connected battery cells with a total measurement error of less than 1.2mV. The cell measurement range of 0V to 5V makes the LTC6804 suitable for most battery chemistries. All 12 cell voltages can be captured in 290?s, and lower data acquisition rates can be selected for high noise reduction.Multiple LTC6804 devices can be connected in series, permitting simultaneous cell monitoring of long, high voltage battery strings. Each LTC6804 has an isoSPI interface for high speed, RF-immune, local area communications. Using the LTC6804-1, multiple devices are connected in a daisy-chain with one host processor connection for all devices. Using the LTC6804-2, multiple devices are connected in parallel to the host processor, with each device individually addressed.Additional features include passive balancing for each cell, an onboard 5V regulator, and 5 general purpose I/O lines. In sleep mode, current consumption is reduced to 4?A. The LTC6804 can be powered directly from the battery, or from an isolated supply.Applications Electric and Hybrid Electric Vehicles Backup Battery Systems Grid Energy Storage High Power Portable Equipment
DC1954A-C
Analog Devices Inc.The LTC6954 is a family of very low phase noise clock distribution parts. Each part has three outputs and each output has an individually programmable frequency divider and delay. There are four members of the family, differing in their output logic signal type:LTC6954-1: Three LVPECL outputsLTC6954-2: Two LVPECL and one LVDS/CMOS outputsLTC6954-3: One LVPECL and two LVDS/CMOS outputsLTC6954-4: Three LVDS/CMOS outputsEach output is individually programmable to divide the input frequency by any integer from 1 to 63, and to delay each output by 0 to 63 input clock cycles. The output duty cycle is always 50%, regardless of the divide number. The LVDS/CMOS outputs are jumper selectable via the OUTxSEL pins to provide either an LVDS logic output or a CMOS logic output.The LTC6954 also features Linear Technology?s EZSync system for perfect clock synchronization and alignment every time.All device settings are controlled through an SPI-compatible serial port.Applications Clocking High Speed, High Resolution ADCs, DACs?and Data Acquisition Systems Low Jitter Clock Distribution
DC1959A-C
Analog Devices Inc.The LTC6948 is a high performance, low noise, 6.39GHz phase-locked loop (PLL) with a fully integrated VCO, including a reference divider, phase-frequency detector (PFD), ultralow noise charge pump, fractional feedback divider, and VCO output divider.The fractional divider uses an advanced, 4th order ?? modulator which provides exceptionally low spurious levels. This allows wide loop bandwidths, producing extremely low integrated phase noise values.The programmable VCO output divider, with a range of 1 through 6, extends the output frequency range.Applications Wireless Basestations (LTE, WiMAX, W-CDMA, PCS) Microwave Data Links Military and Secure Radio Test and Measurement
DC1964A
Analog Devices Inc.The LTC3110 is a 2A bidirectional buck-boost DC/DC regulator with capacitor charger and balancer. Its wide 0.1V to 5.5V capacitor/battery voltage and 1.8V to 5.25V system backup voltage ranges make it well suited to a wide variety of backup applications using supercapacitors or batteries. A proprietary low noise switching algorithm optimizes efficiency with capacitor/battery voltages that are above, below or equal to the system output voltage.The LTC3110 can autonomously transition from charge to backup mode or switch modes based on an external command. Pin-selectable Burst Mode operation reduces standby current and improves light-load efficiency, which combined with a 1?A shutdown current make the LTC3110 ideally suited for backup applications. Additional features include voltage supervisors for direction control and end of charge, and a general purpose comparator with open-collector output for interfacing with a ?C. The LTC3110 is available in thermally enhanced, low profile 24-lead TSSOP and 4mm ? 4mm QFN packages.Applications Supercapacitor Backup Converter and Charger Battery Backup Converter and Charger Servers, RAID Systems RF Systems with Battery/Capacitor Backup
DC196A-A
Analog Devices Inc.The LTC1543 is a 3-driver/3-receiver multiprotocol transceiver that operates from a single 5V supply. The LTC1543 and LTC1544 form the core of a complete software-selectable DTE or DCE interface port that supports the RS232, RS449, EIA530, EIA530-A, V.35, V.36 or X.21 protocols. Cable termination may be implemented using the LTC1344A software-selectable cable termination chip or by using existing discrete designs.The LTC1543 runs from a single 5V supply using an internal charge pump that requires only five space-saving surface mounted capacitors. The part is available in a 28-lead SSOP surface mount package.Applications Data Networking CSU and DSU Data Routers
LTC2974 Demo Board Kit (Includes DC1809 + DC1810), Requires DC1613
Analog Devices Inc.DC1978A: Demo Board for the LTC2974 4-Channel PMBus Power System Manager Featuring Accurate Output Current Measurement.
LTC5510 | Demo Board - (High Frequency) Input Frequency Range 30MHz to 3GHz; Output Range 1.2GHz to 2.1GHz
Analog Devices Inc.DC1983A: Demo Board for the LTC5510 1MHz to 6GHz Wideband High Linearity Active Mixer.
DC1984A
Analog Devices Inc.The LTC5510 is a high linearity mixer optimized for applications requiring very wide input bandwidth, low distortion, and low LO leakage. The chip includes a double-balanced active mixer with an input buffer and a high speed LO amplifier. The input is optimized for use with 1:1 transmission line baluns, allowing very wideband impedance matching. The mixer can be used for both up- and down-conversion and can be used in wideband systems.The LO can be driven differentially or single-ended and requires only 0dBm of LO power to achieve excellent distortion and noise performance, while also reducing external drive circuit requirements. The LTC5510 offers low LO leakage, greatly reducing the need for output filtering to meet LO suppression requirements.The LTC5510 is optimized for 5V but can also be used with a 3.3V supply with slightly reduced performance. The shutdown function allows the part to be disabled for further power savings.Applications Wideband Receivers/Transmitters Cable Downlink Infrastructure HF/VHF/UHF Mixer Wireless Infrastructure
