POWER SUPPLY AC-DC MEDICAL 5V 20A; No. of Outputs:1 Output; Output Power Max:130W; Output Voltage - Output 1:5V; Output Current - Output 1:20A; Output Voltage - Output 2:-; Output Current - Output 2:-; Output Voltage - Output 3:-; Output Current - Output 3:-; Output Voltage - Output 4:-; Current Output 4:-; Input Voltage AC Min:90V; Input Voltage AC Max:264V; Power Supply Output Type:Fixed; Product Range:JPS Series; Approval Bodies:CE CSA EN UL; Approvals / Standards:CSA 22.2 No. 60601 EN 60601 UL 60601; Efficiency:90%; External Depth:127mm; External Length / Height:32.4mm; External Width:76.2mm; Height:32.4mm; Input Frequency:63Hz; Leakage Current:250µA; Length:127mm; Line Regulation:0.5%; Load Regulation:1%; No. of Outputs:1Outputs; Operating Temperature Max:70°C; Operating Temperature Min:0°C; Output Current Max:20A; Output Ripple and Noise Voltage pk-pk:1%; Power Rating:130W; Power Supply Type:Switch Mode; Supply Frequency Max:63Hz; Supply Frequency Min:47Hz; Supply Voltage:264V; Width:76.2mm

POWER SUPPLY AC-DC MEDICAL 3O/P 130W; No. of Outputs:3Outputs; Output Power Max:130W; Output Voltage - Output 1:5V; Output Current - Output 1:10A; Output Voltage - Output 2:12V; Output Current - Output 2:3A; Output Voltage - Output 3:-12V; Output Current - Output 3:800mA; Output Voltage - Output 4:-; Current Output 4:-; Input Voltage AC Min:90V; Input Voltage AC Max:264V; Power Supply Output Type:Fixed; Product Range:-; Approval Bodies:CE CSA EN UL; Approvals / Standards:CSA 22.2 No. 60601 EN 60601 UL 60601; External Depth:127mm; External Length / Height:34.4mm; External Width:76.2mm; Height:34.4mm; Input Frequency:63Hz; Length:127mm; Power Rating:130W; Power Supply Type:Switch Mode; Supply Frequency Max:63Hz; Supply Frequency Min:47Hz; Supply Voltage:264V; Supply Voltage Max:264V; Supply Voltage Min:90V; Supply Voltage Typ:110V AC 230V AC; Width:76.2mm

PSU OPEN FRAME 250W 12V; No. of Outputs:1 Output; Output Power Max:250W; Output Voltage - Output 1:12V; Output Current - Output 1:17A; Output Voltage - Output 2:-; Output Current - Output 2:-; Output Voltage - Output 3:-; Output Current - Output 3:-; Output Voltage - Output 4:-; Current Output 4:-; Input Voltage AC Min:85V; Input Voltage AC Max:264V; Power Supply Output Type:Fixed; Product Range:-; Applications:General Purpose; Approval Bodies:CE CSA EN TUV UL; Efficiency:86%; External Depth:203.2mm; External Length / Height:38.1mm; External Width:106.7mm; Frequency Max:63Hz; Frequency Min:47Hz; Height:40.6mm; Input Current:1.4A; Input Frequency:63Hz; Leakage Current:2mA; Length:203.2mm; Line Regulation:0.5%; Load Regulation:1%; No. of Outputs:1Outputs; Operating Temperature Max:70°C; Operating Temperature Min:0°C; Output Current Max:17A; Output Current Min:17A; Output Power:250W; Power Factor:0.99; Power Rating:250W; Power Supply Type:Switch Mode; Storage Temperature Max:85°C

AC-DC Power Supplies Zero Voltage Switching Technology / Meets 1U, Low Profile Requirements 150-250 W Chassis / Open Frame Input: 85-264 VAC Output: 5.0 V/35.0 A, 12.0 V/8.0 A, 24.0 V/4.0 A, -12.0 V/3.0 A Power: 350 W

AC/DC 350W POWER SUPPLY W/COVER / BOX

DC-DC Converters -40 C to +100 C Operating Temperature / 3 Year Warranty 3-10 Watts Through Hole Mount Input: 18-75 VDC Output: +/-12V/+/-0.42A Power: 10 W

DC-DC Converters -40 C to +100 C Operating Temperature / 3 Year Warranty 3-10 Watts Through Hole Mount Input: 9-36 VDC Output: 15V/1A Power: 15 W

DC-DC Converters -40 C to +100 C Operating Temperature / 3 Year Warranty 3-10 Watts Through Hole Mount Input: 18-75 VDC Output: 3.3V/3A Power: 15 W

DC-DC Converters -40 C to +100 C Operating Temperature / 3 Year Warranty 3-10 Watts Through Hole Mount Input: 9-36 VDC Output: +/-5V/+/-2A Power: 20 W

CONVERTER DC/DC 1O/P 3W 15V; No. of Outputs:1 Output; Output Power Max:3W; Output Voltage - Output 1:15V; Output Current - Output 1:200mA; Output Voltage - Output 2:-; Output Current - Output 2:-; Output Voltage - Output 3:-; Output Current - Output 3:-; Product Range:JTB03/05 Series; Input Voltage DC Min:18V; Input Voltage DC Max:72V; DC / DC Converter Output Type:Fixed; DC / DC Converter Type:DIP; DC / DC Converter Mounting:Through Hole; Approvals & Standards:-; Width:20.3mm; Height:10.2mm; Depth:31.8mm; Efficiency:77%; External Depth:10.2mm; External Length / Height:31.8mm; External Width:20.3mm; Isolation Voltage:500V; Line Regulation:0.5%; No. of Outputs:1Outputs; Off Load Current:7.5mA; Operating Temperature Max:100°C; Operating Temperature Min:-25°C; Output Ripple Voltage pk-pk:100mV; Power Rating:3W; Supply Voltage:48V

CONVERTER DC/DC 1O/P 5W 3.3V; No. of Outputs:1 Output; Output Power Max:5W; Output Voltage - Output 1:3.3V; Output Current - Output 1:1A; Output Voltage - Output 2:-; Output Current - Output 2:-; Output Voltage - Output 3:-; Output Current - Output 3:-; Product Range:JTB05 Series; Input Voltage DC Min:9V; Input Voltage DC Max:36V; DC / DC Converter Output Type:Fixed; DC / DC Converter Type:DIP; DC / DC Converter Mounting:Through Hole; Approvals & Standards:-; Width:20.3mm; Height:10.2mm; Depth:31.8mm; Efficiency:72%; External Depth:10.2mm; External Length / Height:31.8mm; External Width:20.3mm; Isolation Voltage:1.5kV; Line Regulation:0.5%; Load Regulation:0.5%; No. of Outputs:1Outputs; Off Load Current:15mA; Operating Temperature Max:100°C; Operating Temperature Min:-25°C; Output Ripple Voltage pk-pk:100mV; Power Rating:5W; Supply Voltage:24V

DC-DC CONVERTER ISO POL 2 O/P 5W 5V -5V; DC / DC Converter Output Type:Fixed; No. of Outputs:2 Output; Input Voltage DC Min:18V; Input Voltage DC Max:72V; Output Power Max:5W; Output Voltage - Output 1:5V; Width:20.3mm ;RoHS Compliant: Yes

DC-DC CONVERTER ISO POL 1 O/P 5W 470mA 12V; No. of Outputs:1 Output; Output Power Max:5W; Output Voltage - Output 1:12V; Output Current - Output 1:470mA; Output Voltage - Output 2:-; Output Current - Output 2:-; Width:20.3mm ;RoHS Compliant: Yes

DC-DC CONVERTER ISO POL 1 O/P 5W 1A 3.3V; No. of Outputs:1 Output; Output Power Max:5W; Output Voltage - Output 1:3.3V; Output Current - Output 1:1A; Output Voltage - Output 2:-; Output Current - Output 2:-; Width:20.3mm ;RoHS Compliant: Yes

DC-DC Converters DIP-24 Metal Package / 3 Year Warranty 3-10 Watts Through Hole Mount Input: 9-36 VDC Output: 24.0 V/0.084 A Power: 4 W

DC-DC Converters DIP-24 Metal Package / 3 Year Warranty 3-10 Watts Through Hole Mount Input: 9-36 VDC Output: 9.0 V/0.455 A Power: 4 W

DC-DC Converters DIP-24 Metal Package / 3 Year Warranty 3-10 Watts Through Hole Mount Input: 18-72 VDC Output: 5.0 V/0.400 A Power: 4 W

DC-DC Converters DIP-24 Metal Package / 3 Year Warranty 3-10 Watts Through Hole Mount Input: 9-36 VDC Output: 3.3 V/0.909 A Power: 6 W

DC-DC Converters DIP-24 Metal Package / 3 Year Warranty 3-10 Watts Through Hole Mount Input: 9-36 VDC Output: 24.0 V/0.125 A Power: 6 W

DC-DC Converters DIP-24 Metal Package / 3 Year Warranty 3-10 Watts Through Hole Mount Input: 18-72 VDC Output: 9.0 V/0.333 A Power: 6 W
