AC/DC PSU DUAL O/P 15W ENCAPS; No. of Outputs:2 Output; Output Power Max:15W; Output Voltage - Output 1:15V; Output Current - Output 1:500mA; Output Voltage - Output 2:-15V; Output Current - Output 2:500mA; Output Voltage - Output 3:-; Output Current - Output 3:-; Power Supply Output Type:Adjustable Fixed; Input Voltage AC Min:85V; Input Voltage AC Max:264V; Width:33.5mm; Height:24.4mm; Depth:65mm; Product Range:ECL Series; Input Frequency:63Hz; Length:65mm; No. of Outputs:2Outputs

AC/DC PSU DUAL O/P 15W ENCAPS; No. of Outputs:2 Output; Output Power Max:15W; Output Voltage - Output 1:5V; Output Current - Output 1:1.5A; Output Voltage - Output 2:12VDC; Output Current - Output 2:625mA; Output Voltage - Output 3:-; Output Current - Output 3:-; Power Supply Output Type:Adjustable Fixed; Input Voltage AC Min:85V; Input Voltage AC Max:264V; Width:33.5mm; Height:24.4mm; Depth:65mm; Product Range:ECL Series; Input Frequency:63Hz; Length:65mm; No. of Outputs:2Outputs

AC-DC CONVERTER PCB MOUNT 1 O/P 10W 3A 3.3V; No. of Outputs:1 Output; Output Power Max:10W; Output Voltage - Output 1:3.3V; Output Current - Output 1:3A; Output Voltage - Output 2:-; Output Current - Output 2:-; Width:30.7mm ;RoHS Compliant: Yes

PSU SCREW TERMINAL 15W 5V; No. of Outputs:1Outputs; Output Power Max:15W; Output Voltage - Output 1:5V; Output Current - Output 1:3A; Output Voltage - Output 2:-; Output Current - Output 2:-; Output Voltage - Output 3:-; Output Current - Output 3:-; Output Voltage - Output 4:-; Current Output 4:-; Input Voltage AC Min:85V; Input Voltage AC Max:264V; Power Supply Output Type:Fixed; Product Range:ECL Series; Applications:General Purpose; Efficiency:78%; Height:26.4mm; Input Voltage DC Max:370VDC; Input Voltage DC Min:120VDC; Length:34.5mm; No. of Outputs:1 Output; Output Current Max:3A; Peak Output Current:3.9A; Power Rating:15W; Supply Voltage Typ:110V AC 230V AC; Width:84mm

AC-DC CONVERTER PCB MOUNT 1 O/P 15W 1.67A 9V; Power Supply Output Type:Adjustable Fixed; No. of Outputs:1 Output; Input Voltage AC Min:85V; Input Voltage AC Max:264V; Output Power Max:15W; Output Voltage - Output 1:9V ;RoHS Compliant: Yes

AC-DC CONVERTER PCB MOUNT 1 O/P 15W 1A 15V; No. of Outputs:1 Output; Output Power Max:15W; Output Voltage - Output 1:15V; Output Current - Output 1:1A; Output Voltage - Output 2:-; Output Current - Output 2:-; Width:33.3mm ;RoHS Compliant: Yes

PSU SCREW TERMINAL 15W 15V; No. of Outputs:1Outputs; Output Power Max:15W; Output Voltage - Output 1:15V; Output Current - Output 1:1A; Output Voltage - Output 2:-; Output Current - Output 2:-; Output Voltage - Output 3:-; Output Current - Output 3:-; Output Voltage - Output 4:-; Current Output 4:-; Input Voltage AC Min:85V; Input Voltage AC Max:264V; Power Supply Output Type:Fixed; Product Range:ECL Series; Applications:General Purpose; Efficiency:80%; Height:26.4mm; Input Voltage DC Max:370VDC; Input Voltage DC Min:120VDC; Length:34.5mm; No. of Outputs:1 Output; Output Current Max:1A; Peak Output Current:1.3A; Power Rating:15W; Supply Voltage Typ:110V AC 230V AC; Width:84mm

AC/DC PSU 3 O/P 15W ENCAPS; No. of Outputs:3 Output; Output Power Max:15W; Output Voltage - Output 1:5V; Output Current - Output 1:2A; Output Voltage - Output 2:15VDC; Output Current - Output 2:150mA; Output Voltage - Output 3:-15V; Output Current - Output 3:150mA; Power Supply Output Type:Adjustable Fixed; Input Voltage AC Min:85V; Input Voltage AC Max:264V; Width:33.5mm; Height:24.4mm; Depth:65mm; Product Range:ECL Series; Input Frequency:63Hz; Length:65mm; No. of Outputs:3Outputs; Power Rating:15W

PSU 25W 5V ENCAPS PCB MOUNT; No. of Outputs:1 Output; Output Power Max:25W; Output Voltage - Output 1:5V; Output Current - Output 1:5A; Output Voltage - Output 2:-; Output Current - Output 2:-; Output Voltage - Output 3:-; Output Current - Output 3:-; Power Supply Output Type:Adjustable Fixed; Input Voltage AC Min:85V; Input Voltage AC Max:264V; Width:38.1mm; Height:27.9mm; Depth:78.7mm; Product Range:ECL Series; Approval Bodies:CSA cUL EN UL; Efficiency:78%; External Depth:27.9mm; External Length / Height:78.7mm; External Width:38.1mm; Input Current:0.4mA; Input Frequency:63Hz; Inrush Current:20A; Isolation Voltage:3000V; Length:27.9mm; No. of Outputs:1Outputs; Operating Temperature Max:70°C; Operating Temperature Min:-20°C; Output Current Max:5A; Output Ripple Voltage pk-pk:50mV; Peak Output Current:6.5A; Power Rating:25W; Power Supply Type:Switch Mode; Supply Frequency Max:63Hz; Supply Frequency Min:47Hz; Supply Voltage:264V; Supply Voltage Max:264V; Supply Voltage Min:85V

PSU 25W 9V ENCAPS PCB MOUNT; No. of Outputs:1 Output; Output Power Max:25W; Output Voltage - Output 1:9V; Output Current - Output 1:2.8A; Output Voltage - Output 2:-; Output Current - Output 2:-; Output Voltage - Output 3:-; Output Current - Output 3:-; Power Supply Output Type:Adjustable Fixed; Input Voltage AC Min:85V; Input Voltage AC Max:264V; Width:38.1mm; Height:27.9mm; Depth:78.7mm; Product Range:ECL Series; Approval Bodies:CSA cUL EN UL; Efficiency:80%; External Depth:27.9mm; External Length / Height:78.7mm; External Width:38.1mm; Input Current:0.4mA; Input Frequency:63Hz; Inrush Current:20A; Isolation Voltage:3000V; Length:27.9mm; No. of Outputs:1Outputs; Operating Temperature Max:70°C; Operating Temperature Min:-20°C; Output Current Max:2.8A; Peak Output Current:3.64A; Power Rating:25W; Power Supply Type:Switch Mode; Supply Frequency Max:63Hz; Supply Frequency Min:47Hz; Supply Voltage:264V; Supply Voltage Max:264V; Supply Voltage Min:85V; Supply Voltage Typ:110V AC 230V AC

PSU 25W 9V MINI OPEN FRAME; No. of Outputs:1 Output; Output Power Max:25W; Output Voltage - Output 1:9V; Output Current - Output 1:2.8A; Output Voltage - Output 2:-; Output Current - Output 2:-; Output Voltage - Output 3:-; Output Current - Output 3:-; Output Voltage - Output 4:-; Current Output 4:-; Input Voltage AC Min:85V; Input Voltage AC Max:264V; Power Supply Output Type:Adjustable Fixed; Product Range:ECL Series; Applications:General Purpose; Approval Bodies:CSA cUL EN UL; Efficiency:80%; External Depth:25.4mm; External Length / Height:88.9mm; External Width:35.6mm; Height:88.9mm; Input Current:0.4mA; Input Frequency:63Hz; Inrush Current:20A; Isolation Voltage:3000V; Length:25.4mm; No. of Outputs:1Outputs; Operating Temperature Max:70°C; Operating Temperature Min:-20°C; Output Current Max:2.8A; Peak Output Current:3.64A; Power Rating:25W; Power Supply Type:Switch Mode; Supply Frequency Max:63Hz; Supply Frequency Min:47Hz; Supply Voltage:264V; Supply Voltage Max:264V; Width:35.6mm

AC-DC CONVERTER OPEN FRAME 1 O/P 25W 2.1A 12V; No. of Outputs:1 Output; Output Power Max:25W; Output Voltage - Output 1:12V; Output Current - Output 1:2.1A; Output Voltage - Output 2:-; Output Current - Output 2:-; Height:25.4mm;RoHS Compliant: Yes

PSU 25W 48V ENCAPS PCB MOUNT; No. of Outputs:1 Output; Output Power Max:25W; Output Voltage - Output 1:48V; Output Current - Output 1:520mA; Output Voltage - Output 2:-; Output Current - Output 2:-; Output Voltage - Output 3:-; Output Current - Output 3:-; Power Supply Output Type:Adjustable Fixed; Input Voltage AC Min:85V; Input Voltage AC Max:264V; Width:38.1mm; Height:27.9mm; Depth:78.7mm; Product Range:ECL Series; Approval Bodies:CSA cUL EN UL; Efficiency:82%; External Depth:27.9mm; External Length / Height:78.7mm; External Width:38.1mm; Input Current:0.4mA; Input Frequency:63Hz; Inrush Current:20A; Isolation Voltage:3000V; Length:27.9mm; No. of Outputs:1Outputs; Operating Temperature Max:70°C; Operating Temperature Min:-20°C; Output Current Max:520mA; Output Ripple Voltage pk-pk:200mV; Peak Output Current:0.68A; Power Rating:25W; Power Supply Type:Switch Mode; Supply Frequency Max:63Hz; Supply Frequency Min:47Hz; Supply Voltage:264V; Supply Voltage Max:264V; Supply Voltage Min:85V

AC/DC PSU DUAL O/P 30W ENCAPS; No. of Outputs:2 Output; Output Power Max:30W; Output Voltage - Output 1:15V; Output Current - Output 1:1A; Output Voltage - Output 2:-15V; Output Current - Output 2:1A; Output Voltage - Output 3:-; Output Current - Output 3:-; Power Supply Output Type:Adjustable Fixed; Input Voltage AC Min:85V; Input Voltage AC Max:264V; Width:38.1mm; Height:28mm; Depth:78.7mm; Product Range:ECL Series; Input Frequency:63Hz; Length:78.7mm; No. of Outputs:2Outputs; Power Rating:30W

AC/DC PSU DUAL O/P 30W PCB MOUNT; No. of Outputs:2 Output; Output Power Max:30W; Output Voltage - Output 1:15V; Output Current - Output 1:1A; Output Voltage - Output 2:-15V; Output Current - Output 2:1A; Output Voltage - Output 3:-; Output Current - Output 3:-; Power Supply Output Type:Adjustable Fixed; Input Voltage AC Min:85V; Input Voltage AC Max:264V; Width:34.6mm; Height:22.3mm; Depth:75.2mm; Product Range:ECL Series; Input Frequency:63Hz; Length:75.2mm; No. of Outputs:2Outputs; Power Rating:30W

AC/DC PSU 3 O/P 30W SCREW TERM; No. of Outputs:3Outputs; Output Power Max:30W; Output Voltage - Output 1:5V; Output Current - Output 1:3A; Output Voltage - Output 2:12VDC; Output Current - Output 2:630mA; Output Voltage - Output 3:-12V; Output Current - Output 3:630mA; Output Voltage - Output 4:-; Current Output 4:-; Input Voltage AC Min:85V; Input Voltage AC Max:264V; Power Supply Output Type:Fixed; Product Range:ECL Series; Applications:General Purpose; Height:28.5mm; Input Frequency:63Hz; Length:96mm; Output Current Max:3A; Power Rating:30W; Width:40mm

AC/DC PSU 3 O/P 30W CHASSIS MOUNT; No. of Outputs:3 Output; Output Power Max:30W; Output Voltage - Output 1:5V; Output Current - Output 1:3A; Output Voltage - Output 2:12VDC; Output Current - Output 2:630mA; Output Voltage - Output 3:-12V; Output Current - Output 3:630mA; Output Voltage - Output 4:-; Current Output 4:-; Input Voltage AC Min:85V; Input Voltage AC Max:264V; Power Supply Output Type:Adjustable Fixed; Product Range:ECL Series; Applications:General Purpose; Height:25.4mm; Input Frequency:63Hz; Length:87.9mm; No. of Outputs:3Outputs; Power Rating:30W; Width:34.6mm

AC/DC PSU 3 O/P 30W ENCAPS; No. of Outputs:3 Output; Output Power Max:30W; Output Voltage - Output 1:5V; Output Current - Output 1:3A; Output Voltage - Output 2:15VDC; Output Current - Output 2:500mA; Output Voltage - Output 3:-15V; Output Current - Output 3:500mA; Power Supply Output Type:Adjustable Fixed; Input Voltage AC Min:85V; Input Voltage AC Max:264V; Width:38.1mm; Height:28mm; Depth:78.7mm; Product Range:-; Input Frequency:63Hz; Length:78.7mm; No. of Outputs:3Outputs; Power Rating:30W

Power Supply Accessory Cover Kit ECM100 Series ;RoHS Compliant: Yes

AC-DC Power Supplies IT, Medical & SEMI F47 Approvals / 3 Year Warranty 5-70 W Chassis / Open Frame Input: 90-264 VAC Output: 28 V/3.6 A Power: 100 W
