DRV5011 and DRV5012 Ultra-Low Power, Digital-Latch Hall Effect Sensor Evaluation Module

Texas Instruments

Description

The DRV5011-5012EVM facilitates evaluation of the DRV5012 and DRV5011 Hall effect sensors. The DRV5012 is an ultra-low-power digital-latch Hall effect sensor with a pin-selectable sampling rate. The DRV5011 is an ultra-low-power digital-latch Hall effect sensor.  These sensors change their output states as magnets reverse polarity or magnetic fields reach certain thresholds to trigger the sensor logic.

Features:

  • Easy evaluation and demonstration of the DRV5011 with included magnet and USB cable
  • Three of each DRV5011 and DRV5012 are provided on breakaway boards to integrate directly into a system for prototype evaluation
  • Vias are provided to attach wires to the breakaway boards

What's included:

  • EVM PCB
  • USB Cable
  • Magnet


Type: Evaluation Modules & Boards

Part number: DRV5011-5012EVM

More details from Texas Instruments

Inventory

Distributor SKU Stock Cost
Digi-Key 296-49620-ND 2 $30.00 Buy
Texas Instruments DRV5011-5012EVM 68 $25.00 Buy
Texas Instruments DRV5011-5012EVM 68 $25.00 Buy
Mouser Electronics 595-DRV5011-5012EVM 9 $32.76 Buy
Verical Marketplace DRV5011-5012EVM 20 $26.07 Buy
AVNET Express DRV5011-5012EVM $29.50 Buy
Arrow North American Components DRV5011-5012EVM 0 $30.00 Buy
