DLP LightCrafter Display 2010 is an easy to use, plug and play evaluation platform for the DLP2010 chipset, which includes the DLP2010 ( .2 WVGA) DMD, DLPC3435 display controller and DLPA2005 PMIC/LED driver. This EVM comes equipped with an optical engine that enables quick evaluation of the DLP2010 chipset for ultra-mobile and ultra-low power display applications. Its modular design allows the exchange of multiple light engines to fit diverse equipment design needs.
Two versions of the evaluation module are available:
DLPDLCR2010EVM: Full-featured version that includes boards, optical engine, DMD, flex and LED cables
DLPDLCR2010EVM-PCB: Includes the PCB main and display boards only (does not include optical engine, DMD, flex or LED cables)
EVM compatible with wide range of optical modules
Standard HDMI-input interface offers plug-and-play functionality with various devices.
Get started quickly with simple yet powerful USB-based GUI
Comes powered with IntelliBright suite of image processing algorithm to dynamically optimize system brightness or power
DLP2010, DLP 0.2 WVGA DMD
DLPC3435, Digital Controller for the DLP2010 DMD
DLPA2005, PMIC/LED Driver for the DLP2010 DMD and DLPC3435 controller
Optical engine from Asia Optical
DLP2010, DLPC3435 Configuration and Support Firmware
1 HDMI cable
1 USB Cable ( for communication with USB based GUI tool)
Power supply sold separately.
