Teltonika
Teltonika OTD500 5G Outdoor IP55 Router
Connectivity: 5G, LTE, 3G with 4 SIM card slots
Security Features: Firewall, VPN support (OpenVPN, IPsec, PPTP, L2TP)
Design: Rugged IP55 rated, suitable for outdoor use
Performance: MediaTek processor, 0.88 GHz, DDR3 RAM
Power: PoE support, 9 W power consumption
Management: Web-based management, supports HTTP, HTTPS, SNMP
Dimensions: 110 x 235 x 49.3 mm
Kit Contents
OTD500 router
Router holder
Quick Start Guide (QSG)
Packaging box
Features:
Mobile:
5G sub-6GHz SA/NSA 2.4/3.4Gbps DL (4x4 MIMO), 900/550Mbps UL (2x2), 4G LTE - LTE Cat 19 1.6Gbps DL/200Mbps UL, and 3G up to 42Mbps DL/5.76Mbps UL
eSIM:
Consumer type eSIM, profile download, removal operations, and up to 7 eSIM profiles
Supports sending and reading Unstructured Supplementary Service Data (USSD) data messages
Band management:
Band lock and used band status display
Direct connection (bridge) between mobile ISP and device on LAN
SIM PIN code management:
SIM PIN code management enables setting, changing, or disabling the SIM card's PIN
Ethernet:
2 x ETH ports (can be configured as WAN), 10/100/1000Mbps, compliance with IEEE 802.3, IEEE 802.3u, 802.3az standards, and supports auto MDI/MDIX crossover
Security:
Port and tag-based VLAN separation VLAN
Mobile quota control:
Mobile data limit, customizable period, start time, warning limit, and phone number
Identification and authentication module, TPM 2.0 standard
Flexible access control of SSH, Web interface, CLI, and Telnet
Network:
Firewall:
Port forward, traffic rules, custom rules, and TTL target customization
Network backup:
VRRP and wired options, each of which can be used as an automatic failover
Static routing, dynamic routing (BGP, OSPF v2, RIP v1/v2, EIGRP, NHRP), and policy-based routing
VoIP passthrough support :
H.323 and SIP-alg protocol NAT helpers, allowing proper routing of VoIP packets
PoE In:
1 x PoE In port
802.3af/at PoE standards
PoE out:1 x PoE out port
802.3af Alternative B PoE standards
15W maximum (power supply unit dependent)
VPN:
OpenVPN multiple clients and a server can run simultaneously, 27 encryption methods
GRE:
GRE tunnel and GRE tunnel over IPsec support
SSTP client instance support
ZeroTier VPN client support
WireGuard VPN client and server support
Client/Server instances can run simultaneously, L2TPv3, and L2TP over IPsec support
System characteristics:
CPU:
MediaTek, dual-core, 880MHz, and MIPS1004Kc
RAM:
256MB and DDR3
16MB serial NOR flash and 256MB serial NAND flash
Power:
RJ45 socket
42.5VDC to 57VDC input voltage range, reverse polarity protection, and voltage surge/transient protection
Power consumption:
2.5W/9W idle maximum and 24W PoE maximum
Operating environment:
-40°C to 55°C temperature range
10% to 90% non-condensing humidity
IP55 rating
CE, UKCA, RCM, CB, EAC, UCRF, and WEEE regulation
