Telemecanique Sensors Air, Fresh Water, Gas, Hydraulic Oil, Refrigeration Fluid Pressure Switch, Analogue. Pressure Range: 0 → 400bar. Supply Voltage: 12 → 24 V dc. Minimum Pressure Reading: 0bar. Maximum Pressure Reading: 400bar. Analogue Output: 4 → 20 mA. Electrical Connection: EN 175301-803-A 3 Pin Male Connector. Minimum Operating Temperature: -30°C. Maximum Operating Temperature: +85°C. Accuracy: 0.1 %, ±0.5 (Measurement) %. Response Time: 2 ms. Maximum Current: 23 mA. IP Rating: IP65. Mounting Type: Thread Mount. MPN: XMLP400BC21F

Telemecanique Sensors Encoder. Encoder Technology: Incremental. MPN: XCCPM23121L2

Telemecanique Sensors Inductive Sensor. Body Style: Barrel. Thread Size: M18 x 1. Output Type: PNP-NO. Detection Range: 5 mm. Terminal Type: Cable. Supply Voltage: 12 → 48 V dc. Length: 62mm. Width: 18mm. Maximum DC Voltage: 48V. Mounting Type: Flush Mount. IP Rating: IP68, IP69K. Switching Current: 200 (DC) mA. Housing Material: Brass, Metal, PPS. Maximum Switching Frequency: 2000Hz. Reverse Polarity Protection: Yes. MPN: XS518BLPAL2

Telemecanique Sensors Air, Fresh Water, Gas, Hydraulic Oil, Refrigeration Fluid Pressure Switch, Analogue. Pressure Range: 0 → 10bar. Supply Voltage: 5 V dc. Minimum Pressure Reading: 0bar. Maximum Pressure Reading: 10bar. Electrical Connection: 4 Pin M12 Male Connector. Analogue Output: 0.5 → 4.5 V. Minimum Operating Temperature: -30°C. Maximum Operating Temperature: +85°C. Accuracy: 0.1 %, ±0.5 (Measurement) %. Response Time: 2 ms. Maximum Current: 7 mA. Housing Material: FPM, Stainless Steel 316L. IP Rating: IP65, IP67, IP69K. MPN: XMLP010BD11F

Telemecanique Sensors Air, Fresh Water, Gas, Hydraulic Oil, Refrigeration Fluid Pressure Switch, Analogue. Pressure Range: 0 → 25bar. Supply Voltage: 5 V dc. Minimum Pressure Reading: 0bar. Maximum Pressure Reading: 25bar. Analogue Output: 0.5 → 4.5 V. Electrical Connection: 4 Pin M12 Male Connector. Minimum Operating Temperature: -30°C. Maximum Operating Temperature: +85°C. Accuracy: 0.1 %, ±0.5 (Measurement) %. Response Time: 2 ms. Maximum Current: 7 mA. IP Rating: IP65, IP67, IP69K. Mounting Type: Thread Mount. MPN: XMLP025BD11F

Telemecanique Sensors Air, Fresh Water, Gas, Hydraulic Oil, Refrigeration Fluid Pressure Switch, Analogue. Pressure Range: 0 → 1000psi. Supply Voltage: 24 V dc. Minimum Pressure Reading: 0psi. Maximum Pressure Reading: 1000psi. Electrical Connection: 3 Pin Male Connector. Analogue Output: 0 → 10 V. Minimum Operating Temperature: -30°C. Maximum Operating Temperature: +85°C. Accuracy: 0.1 %, ±0.5 (Measurement) %. Response Time: 2 ms. Maximum Current: 7 mA. Housing Material: Stainless Steel 316L. IP Rating: IP65, IP67. MPN: XMLP1K0PP730

Telemecanique Sensors Air, Fresh Water, Gas, Hydraulic Oil, Refrigeration Fluid Pressure Switch, Analogue. Pressure Range: -1 → 25bar. Supply Voltage: 12 → 24 V dc. Minimum Pressure Reading: -1bar. Maximum Pressure Reading: 25bar. Electrical Connection: 4 Pin M12 Male Connector. Analogue Output: 4 → 20 mA. Minimum Operating Temperature: -30°C. Maximum Operating Temperature: +85°C. Accuracy: 0.1 %, ±0.5 (Measurement) %. Response Time: 2 ms. Maximum Current: 23 mA. Housing Material: FPM, Stainless Steel 316L. IP Rating: IP65, IP67, IP69K. MPN: XMLPM25BD21F

Telemecanique Sensors Air, Fresh Water, Gas, Hydraulic Oil, Refrigeration Fluid Differential Pressure Switch, Analogue. Pressure Range: 0 → 16bar. Supply Voltage: 12 → 24 V dc. Minimum Pressure Reading: 0bar. Maximum Pressure Reading: 16bar. Electrical Connection: 3-Pin Male Connector. Analogue Output: 4 → 20 mA. Minimum Operating Temperature: -30°C. Maximum Operating Temperature: +85°C. Accuracy: ±0.5 %. Response Time: 2 ms. Maximum Current: 20 mA. Housing Material: FPM, Stainless Steel 316L. MPN: XMLP016BC21F

Telemecanique Sensors 4PDT Non-Latching Relay Plug In, 24V dc Coil, 8 A. Coil Resistance: 650 Ω. Series: RXM. Maximum Switching Voltage AC: 250V. Length: 21mm. Depth: 47.7mm. Height: 27mm. Dimensions: 21 x 47.7 x 27mm. Life: 100000 cycles. Coil Power: 900mW. Minimum Operating Temperature: -40°C. MPN: RXM4AB2BD

Telemecanique Sensors Air, Fresh Water, Gas, Hydraulic Oil, Refrigeration Fluid Pressure Switch, Analogue. Pressure Range: 0 → 25bar. Supply Voltage: 12 → 24 V dc. Minimum Pressure Reading: 0bar. Maximum Pressure Reading: 25bar. Process Connection: 7/16 - 20 UNF SAE. Electrical Connection: 4 Pin M12 Male Connector. Analogue Output: 4 → 20 mA. Minimum Operating Temperature: -30°C. Maximum Operating Temperature: +85°C. Accuracy: 0.1 %, ±0.5 (Measurement) %. Response Time: 2 ms. Maximum Current: 23 mA. Housing Material: Stainless Steel 303. MPN: XMLP025BD290

Telemecanique Sensors Air, Fresh Water, Gas, Hydraulic Oil, Refrigeration Fluid Pressure Switch, Analogue. Pressure Range: 0 → 300psi. Supply Voltage: 24 V dc. Minimum Pressure Reading: 0psi. Maximum Pressure Reading: 300psi. Electrical Connection: 3 Pin Male Connector. Analogue Output: 0 → 10 V. Minimum Operating Temperature: -30°C. Maximum Operating Temperature: +85°C. Accuracy: 0.1 %, ±0.5 (Measurement) %. Response Time: 2 ms. Maximum Current: 7 mA. Mounting Type: Thread Mount. IP Rating: IP65, IP67. MPN: XMLP300PP730

Telemecanique Sensors Inductive Sensor. Body Style: Barrel. Thread Size: M30 x 1.5. Output Type: NO. Detection Range: 15 mm. Terminal Type: M12 - 4 Pin. Supply Voltage: 12 → 24 V dc. Length: 54mm. Width: 36mm. Maximum DC Voltage: 48V. Mounting Type: Flush Mount. IP Rating: IP67, IP69K. Switching Current: 100 (DC) mA. Housing Material: Brass, Metal, PPS. Maximum Switching Frequency: 500 (DC)Hz. Reverse Polarity Protection: Yes. MPN: XS630B3DAM12

Telemecanique Sensors Differential for Air, Hydraulic Fluid Pressure Sensor, 1bar Max Pressure Reading. Minimum Pressure Reading: 0.03bar. Accuracy: 2 %. Output Type: Relay. Process Connection: G1/4. Electrical Connection: PG13.5 Cable Gland. Maximum Current: 3 A ac, 100 mA dc. Supply Voltage: 120 → 240 V ac, 250 V dc. Housing Material: Zinc Alloy. IP Rating: IP66. CAD Drawing: 3D CAD Model. Minimum Operating Temperature: -25°C. Maximum Operating Temperature: +70°C. MPN: XMLA001R2S11

Telemecanique Sensors, M12 x 1, NPN-NO Inductive Sensor 37mm Length, 12 → 24 V dc supply voltage. Body Style: Barrel. Detection Range: 8 mm. Maximum DC Voltage: 24V. Mounting Type: Non Flush. IP Rating: IP65, IP67, IP69K. Switching Current: ≤200 mA. Housing Material: Brass (Case), PPS (Sensing Face). Reverse Polarity Protection: Yes. Shielding: Unshielded. Maximum Operating Temperature: +70°C. Short Circuit Overload Protection: Yes. MPN: XS212B4NAL2

Telemecanique Sensors, M12 x 1, PNP-NO Inductive Sensor 51mm Length, 12 → 24 V dc supply voltage. Body Style: Barrel. Detection Range: 8 mm. Terminal Type: M12 - 4 Pin. Maximum DC Voltage: 24V. Mounting Type: Non Flush. IP Rating: IP65, IP67, IP69K. Switching Current: ≤200 mA. Housing Material: Brass (Case), PPS (Sensing Face). Maximum Operating Temperature: +70°C. Standards Met: CE, CSA, E2, UL. Shielding: Unshielded. MPN: XS212B4PAM12

Telemecanique Sensors Air, Corrosive Fluid, Fresh Water, Hydraulic Oil, Sea Water Pressure Switch, Analogue. MPN: XMLG001D21

Telemecanique Sensors Air, Fresh Water Pressure Switch, Analogue 0 → 300psi, 24 V dc. Analogue Output: 4 → 20 mA. Electrical Connection: M12 3-Pin Connector. Minimum Operating Temperature: 0°C. Maximum Operating Temperature: +80°C. Accuracy: ±0.3 %. Response Time: 2 ms. Maximum Current: 20 mA. Housing Material: Stainless Steel. Mounting Type: Thread Mount. MPN: XMLK300P2D23

Telemecanique Sensors Air, Fresh Water, Sea Water Pressure Switch, 2NC 1.3 → 12bar, 230 V ac, 400 V ac. Minimum Pressure Reading: 1.3bar. Process Connection: G1/4. Electrical Connection: Screw Clamp. Minimum Operating Temperature: -25°C. Maximum Operating Temperature: +70°C. Accuracy:

Telemecanique Sensors Air, Hydraulic Oil, Non-Corrosive Fluid Pressure Switch, 1CO 0.07 → 7.6bar, 500 V, 600 V. Minimum Pressure Reading: 0.07bar. Process Connection: G1/4. Electrical Connection: M20 x 1.5 mm Cable Gland. Minimum Operating Temperature: -56°C. Maximum Operating Temperature: +85°C. Maximum Current: 5 A @ 24 V. Housing Material: Zinc Alloy. IP Rating: IP65. Mounting Type: Cable Mount. MPN: ACW1M129012

Telemecanique Sensors Mounting Hardware for use with OsiSense XUW Sensor. Accessory Type: Fixing Clamp. MPN: XUZASW008
