Telemecanique Sensors Absolute Encoder 6000rpm CANOpen Solid 24 V dc. Output Signal Type: CANOpen 25-bit. Resolution: 8192 (Point). IP Rating: IP64. Overall Height: 95mm. Overall Width: 60mm. Overall Depth: 110mm. Minimum Operating Temperature: -40°C. Maximum Operating Temperature: +85°C. Current Rating: 100 (No Load) mA. Series: XCC. MPN: XCC3510PS84CBN

Telemecanique Sensors 4PDT Non-Latching Relay Plug In, 24V dc Coil, 8 A. Coil Resistance: 650 Ω. Series: RXM. Maximum Switching Voltage AC: 250V. Length: 21mm. Depth: 47.7mm. Height: 27mm. Dimensions: 21 x 47.7 x 27mm. Life: 100000 cycles. Coil Power: 900mW. Minimum Operating Temperature: -40°C. MPN: RXM4AB2BD

Telemecanique Sensors Air, Fresh Water, Gas, Hydraulic Oil, Refrigeration Fluid Pressure Switch, Analogue. Pressure Range: 0 → 25bar. Supply Voltage: 12 → 24 V dc. Minimum Pressure Reading: 0bar. Maximum Pressure Reading: 25bar. Process Connection: 7/16 - 20 UNF SAE. Electrical Connection: 4 Pin M12 Male Connector. Analogue Output: 4 → 20 mA. Minimum Operating Temperature: -30°C. Maximum Operating Temperature: +85°C. Accuracy: 0.1 %, ±0.5 (Measurement) %. Response Time: 2 ms. Maximum Current: 23 mA. Housing Material: Stainless Steel 303. MPN: XMLP025BD290

Telemecanique Sensors Air, Fresh Water, Gas, Hydraulic Oil, Refrigeration Fluid Pressure Switch, Analogue. Pressure Range: 0 → 300psi. Supply Voltage: 24 V dc. Minimum Pressure Reading: 0psi. Maximum Pressure Reading: 300psi. Electrical Connection: 3 Pin Male Connector. Analogue Output: 0 → 10 V. Minimum Operating Temperature: -30°C. Maximum Operating Temperature: +85°C. Accuracy: 0.1 %, ±0.5 (Measurement) %. Response Time: 2 ms. Maximum Current: 7 mA. Mounting Type: Thread Mount. IP Rating: IP65, IP67. MPN: XMLP300PP730

Telemecanique Sensors Inductive Sensor. Body Style: Barrel. Thread Size: M30 x 1.5. Output Type: NO. Detection Range: 15 mm. Terminal Type: M12 - 4 Pin. Supply Voltage: 12 → 24 V dc. Length: 54mm. Width: 36mm. Maximum DC Voltage: 48V. Mounting Type: Flush Mount. IP Rating: IP67, IP69K. Switching Current: 100 (DC) mA. Housing Material: Brass, Metal, PPS. Maximum Switching Frequency: 500 (DC)Hz. Reverse Polarity Protection: Yes. MPN: XS630B3DAM12

Telemecanique Sensors XY2CZ3020 Rope Pull Cable, For Use With XY2C Rope Pull Switch. Size: 20.5m.

Telemecanique Sensors Air, Fresh Water, Gas, Hydraulic Oil, Refrigeration Fluid Pressure Switch, Analogue. Pressure Range: 0 → 3000psi. Supply Voltage: 5 V dc. Minimum Pressure Reading: 0psi. Maximum Pressure Reading: 3000psi. Electrical Connection: 4 Pin M12 Male Connector. Analogue Output: 0.5 → 4.5 V. Minimum Operating Temperature: -30°C. Maximum Operating Temperature: +85°C. Accuracy: 0.1 %, ±0.5 (Measurement) %. Response Time: 2 ms. Maximum Current: 7 mA. Housing Material: Stainless Steel 316L. IP Rating: IP65, IP67, IP69K. MPN: XMLP3K0PD130

Telemecanique Sensors Encoder. MPN: XCCR158RDA06

Telemecanique Sensors Pressure Switch. Pressure Range: 30 → 500bar. Media Measured: Hydraulic Oil. Supply Voltage: 500 V. Minimum Pressure Reading: 30bar. Maximum Pressure Reading: 500bar. Electrical Connection: Screw Clamp Terminal. Minimum Operating Temperature: -25°C. Maximum Operating Temperature: +70°C. Accuracy:

Telemecanique Sensors Air, Fresh Water, Gas, Hydraulic Oil, Refrigeration Fluid Differential Pressure Switch, Analogue. Pressure Range: 0 → 16bar. Supply Voltage: 12 → 24 V dc. Minimum Pressure Reading: 0bar. Maximum Pressure Reading: 16bar. Electrical Connection: 3-Pin Male Connector. Analogue Output: 4 → 20 mA. Minimum Operating Temperature: -30°C. Maximum Operating Temperature: +85°C. Accuracy: ±0.5 %. Response Time: 2 ms. Maximum Current: 20 mA. Housing Material: FPM, Stainless Steel 316L. MPN: XMLP016BC21F

Telemecanique Sensors Differential for Air, Hydraulic Fluid Pressure Sensor, 1bar Max Pressure Reading. Minimum Pressure Reading: 0.03bar. Accuracy: 2 %. Output Type: Relay. Process Connection: G1/4. Electrical Connection: PG13.5 Cable Gland. Maximum Current: 3 A ac, 100 mA dc. Supply Voltage: 120 → 240 V ac, 250 V dc. Housing Material: Zinc Alloy. IP Rating: IP66. CAD Drawing: 3D CAD Model. Minimum Operating Temperature: -25°C. Maximum Operating Temperature: +70°C. MPN: XMLA001R2S11

Telemecanique Sensors Limit Switch Lever Arm for use with 9007C. MPN: 9007CA11

XCSA Safety Interlock Switch, Zamak, 2NC/1NO. Connection Type: Cable. Lock Style: Key. Maximum AC Voltage: 240V. Maximum DC Voltage: 250V. Range: Preventa. Actuator Included: Yes. Number of Head Directions: 8. IP Rating: IP67. Dimensions: 114 x 40 x 44 mm. Minimum Operating Temperature: -25°C. Depth: 44mm. Maximum Current: 6 A. MPN: XCSA713, Telemecanique Sensors

Telemecanique Sensors Pressure Sensor. Pressure Reading Type: Differential. Accuracy: ±1 %. Output Type: Analogue. Media Measured: Fluid. Process Connection: G1/4. Electrical Connection: M12 Male Connector. Analogue Output: 4 → 20 mA. Response Time: 5 ms. Maximum Current: 20 mA. Supply Voltage: 24 V dc. Housing Material: Ceramic, Nitrile (NBR), Stainless Steel. IP Rating: IP65. Series: XMLK. Minimum Operating Temperature: 0°C. Maximum Pressure Setting: 16bar. MPN: XMLK016B2D21

Telemecanique Sensors, M30 x 1.5, NO Inductive Sensor 55mm Length. Body Style: Barrel. Detection Range: 10 mm. Terminal Type: Cable. Supply Voltage: 24 → 210 V dc, 24 → 240 V ac. Maximum AC Voltage: 264V. Maximum DC Voltage: 264V. Mounting Type: Flush Mount. Switching Current: 200 (dc) mA, 300 (ac) mA. IP Rating: IP68. Housing Material: Nickel Plated Brass. Maximum Operating Temperature: +70°C. Maximum Switching Frequency: 2kHz. MPN: XS1M30MA250

Preventa XCS-DM Magnetic Safety Switch, Coded Actuator, Plastic, 24 V dc. IP Rating: IP66, IP67, IP69K. Depth: 32mm. Dimensions: 100 x 34 x 32 mm. Length: 100mm. Number of Approach Directions: 9. Width: 34mm. MPN: XCSDM480102, Telemecanique Sensors

Telemecanique Sensors, M12 x 1, NPN-NO Inductive Sensor 37mm Length, 12 → 24 V dc supply voltage. Body Style: Barrel. Detection Range: 8 mm. Maximum DC Voltage: 24V. Mounting Type: Non Flush. IP Rating: IP65, IP67, IP69K. Switching Current: ≤200 mA. Housing Material: Brass (Case), PPS (Sensing Face). Reverse Polarity Protection: Yes. Shielding: Unshielded. Maximum Operating Temperature: +70°C. Short Circuit Overload Protection: Yes. MPN: XS212B4NAL2

Telemecanique Sensors Air, Fresh Water, Gas, Hydraulic Oil, Refrigeration Fluid Pressure Switch, Analogue. Pressure Range: 0 → 10bar. Supply Voltage: 12 → 24 V dc. Minimum Pressure Reading: 0bar. Maximum Pressure Reading: 10bar. Process Connection: 7/16 - 20 UNF SAE. Analogue Output: 4 → 20 mA. Electrical Connection: EN 175301-803-A 3 Pin Male Connector. Minimum Operating Temperature: -30°C. Maximum Operating Temperature: +85°C. Accuracy: 0.1 %, ±0.5 (Measurement) %. Response Time: 2 ms. Maximum Current: 23 mA. Housing Material: Stainless Steel 303. MPN: XMLP010BC290

Telemecanique Sensors Air, Fresh Water, Gas, Hydraulic Oil, Refrigeration Fluid Pressure Switch, Analogue. Pressure Range: 0 → 160bar. Supply Voltage: 5 V dc. Minimum Pressure Reading: 0bar. Maximum Pressure Reading: 160bar. Analogue Output: 0.5 → 4.5 V. Electrical Connection: 4 Pin M12 Male Connector. Minimum Operating Temperature: -30°C. Maximum Operating Temperature: +85°C. Accuracy: 0.1 %, ±0.5 (Measurement) %. Response Time: 2 ms. Maximum Current: 7 mA. Mounting Type: Thread Mount. IP Rating: IP65, IP67, IP69K. MPN: XMLP160BD11F

Telemecanique Sensors Encoder. Encoder Technology: Incremental. MPN: XCCPM23121L2
