LED, SMD, TRUE GREEN; Product Range:-; LED Colour:Green; Wavelength Typ:528nm; Viewing Angle:120°; Luminous Flux @ Test:39lm; Forward Current If Max:500mA; Forward Current @ Test:350mA; Forward Voltage @ Test:3.8V; Luminous Intensity @ Test:12cd; Power Dissipation Pd:2.3W; Automotive Qualification Standard:-; MSL:-; SVHC:No SVHC (17-Dec-2015); Beam Pattern:Lambertian; Current If @ Vf:350mA; Current If Luminous Intensity:350mA; Current If Min:100mA; Forward Current If:500mA; Forward Voltage VF Max:3.8V; LED Mounting:SMD; Luminous Flux @ Max:39lm; Luminous Intensity:28500mcd; Luminous Intensity Typ:28500mcd; No. of Pins:2Pins; Operating Temperature Max:100°C; Operating Temperature Min:-40°C; Operating Temperature Range:-40°C to +100°C; Peak Forward Current:350mA; Power @ Test:1.3W; Voltage Vf Typ:3.8V

LED, SMD, YELLOW; Product Range:-; LED Colour:Yellow; Wavelength Typ:587nm; Viewing Angle:120°; Luminous Flux @ Test:24lm; Forward Current If Max:400mA; Forward Current @ Test:400mA; Forward Voltage @ Test:2.2V; Luminous Intensity @ Test:6cd; Power Dissipation Pd:1.2W; MSL:MSL 4 - 72 hours; SVHC:No SVHC (17-Dec-2015); Beam Pattern:Lambertian; Current If @ Vf:350mA; Current If Luminous Intensity:350mA; Forward Current If:400mA; Forward Voltage VF Max:2.2V; LED Mounting:SMD; Luminous Flux @ Max:24lm; Luminous Intensity:18500mcd; Luminous Intensity Typ:18500mcd; No. of Pins:2Pins; Operating Temperature Max:100°C; Operating Temperature Min:-40°C; Operating Temperature Range:-40°C to +100°C; Peak Forward Current:400mA; Power @ Test:0.9W; Voltage Vf Typ:2.2V

LED, ULTRAFLUX, RED/ORANGE; Forward Current If:70mA; Forward Voltage:2.9V; Viewing Angle:70°; Lens Shape:Dome; MSL:-; SVHC:No SVHC (17-Dec-2015); Colour:Colourless clear resin; Dominant Wavelength Max:624nm; Dominant Wavelength Min:612nm; Dominant Wavelength Typ:617nm; External Depth:7.62mm; External Length / Height:2.5mm; External Width:7.62mm; Forward Current If Max:70mA; Forward Current If(AV):70mA; Forward Voltage VF Max:2.9V; Luminous Efficiacy:69; Luminous Intensity @ If Max:14000mcd; Luminous Intensity Min:5600mcd; Luminous Intensity Typ:5640mcd; Operating Temperature Max:100°C; Operating Temperature Min:-40°C; Operating Temperature Range:-40°C to +100°C; PIV Max:12V; Peak Pulse Current Ippm:100mA; Peak Wavelength:624nm; Power Dissipation Pd:190mW; Storage Temperature Max:100°C; Storage Temperature Min:-40°C; Voltage Vf Min:1.9V; Voltage Vf Typ:2.25V

LED, HB, WARM WHITE, 2700K, 95LM;

LED, HB, NEUTRAL WHITE, 4000K, 110LM;

LED Single Chip Amber 617nm 70mA 4-Pin PLCC T/R

LED Chip Neutral White 5000K 250mA 2-Pin SMD T/R

LED Chip Warm White 3000K 200mA 2-Pin SMD T/R

LED Chip Cool White 6500K 200mA 2-Pin SMD T/R

LED Chip Cool White 5700K 200mA 2-Pin SMD T/R

DURIS E 2835

DURIS E 2835

DURIS S 8

LED Chip Neutral White 4000K 150mA 2-Pin SMD T/R

LED Chip Cool White 6500K 150mA 2-Pin SMD T/R

LED Chip Warm White 2700K 150mA 2-Pin SMD T/R

LED Chip Warm White 3500K 150mA 2-Pin SMD T/R

LED Chip Warm White 2700K 250mA 2-Pin SMD T/R

LED Chip Neutral White 4000K 250mA 2-Pin SMD T/R

LED Chip Warm White 3500K 250mA 2-Pin SMD T/R
