RELAY SOCKET; Socket Mounting:DIN Rail; Socket Terminals:Screw; No. of Pins:11Pins; Current Rating:15A; Voltage Rating:110VAC; Product Range:LY Series; Accessory Type:Relay Socket; For Use With:Omron LY Series General Purpose Relays

RELAY SOCKET; Socket Mounting:DIN Rail; Socket Terminals:Screw; No. of Pins:14; Accessory Type:Relay Socket; Current Rating:5A; For Use With:Omron MY4 Series Relays; Voltage Rating:250VAC

RELAY SPDT 240VAC 30VDC 15A; Contact Configuration:SPDT; Coil Voltage:24VAC; Contact Current:15A; Product Range:LY Series; Relay Mounting:Through Hole; Coil Type:Non Latching; Contact Voltage VAC:240VAC; Relay Terminals:Solder

RELAY SOCKET HOLD-DOWN CLIP; Product Range:MKS Series; Relay Clip Type:Hold Down; For Use With:Omron PF083A-E Relay Socket; Accessory Type:Hold Down Clip

TIMER MULTIFUNCTION DPDT; Product Range:H3YN Series; Timer Functions:Multifunction; No. of Timing Ranges:4Ranges; Time Min:0.1s; Time Max:10min; Timer Output:Solid State; Supply Voltage Max:230VAC; Current Rating Nom:5A; Connection / Termination:Plug-In; Panel Cutout Height:25.8mm; Panel Cutout Width:21.4mm; Adjustment Type:Rotary; Coil Voltage VAC Nom:230V; Contact Configuration:DPDT; Contact Current AC Max:5A; Contact Voltage AC Max:250V; Delay Time Range:0.1s to 10min; External Depth:28mm; External Length / Height:56.6mm; External Width:21.5mm; Height:56.6mm; No. of Pins:8Pins; Nom Input Voltage:230VAC; Operating Time Range:0.1-1s 1-10s 0.1m-1m 1-10m; Relay Mounting:Quick Connect; Supply Voltage V AC:230VAC; Timing Adjustment:Knob

TIMER MULTIFUNCTION DPDT; Product Range:-; Timer Functions:Multifunction; No. of Timing Ranges:4Ranges; Time Min:0.1min; Time Max:10h; Timer Output:Solid State; Supply Voltage Max:230VAC; Current Rating Nom:5A; Connection / Termination:Plug-In; Panel Cutout Height:25.8mm; Panel Cutout Width:21.4mm; Adjustment Type:Rotary; Coil Voltage VAC Nom:230V; Contact Configuration:DPDT; Contact Current AC Max:5A; Contact Voltage AC Max:250V; Delay Time Range:0.1min to 10h; External Depth:28mm; External Length / Height:56.6mm; External Width:21.5mm; Height:56.6mm; No. of Pins:8Pins; Nom Input Voltage:230VAC; Operating Time Range:0.1-1m 1-10m 0.1-1h 1-10h; Relay Mounting:Quick Connect; Supply Voltage V AC:230VAC; Timing Adjustment:Knob

TIMER MULTIFUNCTION 4PDT; Product Range:H3YN Series; Timer Functions:Multifunction; No. of Timing Ranges:4Ranges; Time Min:0.1s; Time Max:10min; Timer Output:Solid State; Supply Voltage Max:24VDC; Current Rating Nom:3A; Connection / Termination:Plug-In; Panel Cutout Height:25.8mm; Panel Cutout Width:21.4mm; Adjustment Type:Rotary; Coil Voltage VDC Nom:24V; Contact Configuration:4PCO; Contact Current AC Max:3A; Contact Voltage AC Max:250V; Delay Time Range:0.1s to 10min; External Depth:28mm; External Length / Height:56.6mm; External Width:21.5mm; Height:56.6mm; No. of Pins:14Pins; Nom Input Voltage:24VDC; Operating Time Range:0.1-1s 1-10s 0.1m-1m 1-10m; Relay Mounting:Quick Connect; Supply Voltage V DC:24VDC; Timing Adjustment:Knob

TIMER MULTIFUNCTION 4PDT; Product Range:H3YN Series; Timer Functions:Multifunction; No. of Timing Ranges:4Ranges; Time Min:0.1s; Time Max:10min; Timer Output:Solid State; Supply Voltage Max:230VAC; Current Rating Nom:3A; Connection / Termination:Plug-In; Panel Cutout Height:25.8mm; Panel Cutout Width:21.4mm; Adjustment Type:Rotary; Coil Voltage VAC Nom:230V; Contact Configuration:4PCO; Contact Current AC Max:3A; Contact Voltage AC Max:250V; Delay Time Range:0.1s to 10min; External Depth:28mm; External Length / Height:56.6mm; External Width:21.5mm; Height:56.6mm; No. of Pins:14Pins; Nom Input Voltage:230VAC; Operating Time Range:0.1-1s 1-10s 0.1m-1m 1-10m; Relay Mounting:Quick Connect; Supply Voltage V AC:230VAC; Timing Adjustment:Knob

RELAY VOLTAGE SENSING SPDT 230VAC; Product Range:-; Contact Configuration:SPDT; Contact Current:6A; Relay Mounting:DIN Rail; Contact Voltage VAC:250VAC; Relay Terminals:Screw; Contact Voltage VDC:30VDC; Supply Voltage Max:230VAC; Power Consumption:5VA; Approvals & Standards:-; Contact Current AC Max:6A; Contact Voltage AC Max:250V; Control Voltage Type:AC; External Depth:100mm; External Length / Height:90mm; External Width:22.5mm; Hysteresis:5 to 50% of operating value; Input Voltage Max:230VAC; Input Voltage Min:200VAC; No. of Electrical Operations:50000; Nom Input Voltage:230VAC; Operating Temperature Max:60°C; Operating Temperature Min:-20°C; Supply Voltage:230VAC; Supply Voltage AC Max:230VAC; Supply Voltage AC Min:200VAC

RELAY VOLTAGE SENSING SPDT 230VAC; Product Range:-; Contact Configuration:SPDT; Contact Current:6A; Relay Mounting:DIN Rail; Contact Voltage VAC:250VAC; Relay Terminals:Screw; Contact Voltage VDC:30VDC; Supply Voltage Max:230VAC; Power Consumption:5VA; Approvals & Standards:-; Contact Current AC Max:6A; Contact Voltage AC Max:250V; Control Voltage Type:AC; External Depth:100mm; External Length / Height:90mm; External Width:22.5mm; Hysteresis:5% of operating value; Input Voltage Max:230VAC; Input Voltage Min:200VAC; No. of Electrical Operations:50000; Nom Input Voltage:230V; Operating Temperature Max:60°C; Operating Temperature Min:-20°C; Supply Voltage:230VAC; Supply Voltage AC Max:230VAC; Supply Voltage AC Min:200VAC

CONDUCTIVE LEVEL CONTROLLER 24V; Supply Voltage:24V; Response Time:10s; Power Consumption:5VA; Product Range:-; Approval Bodies:CE; Dielectric Strength VAC:2000V; External Depth:100mm; External Length / Height:90mm; External Width:22.5mm; For Use With:Conductive liquids; Insulation Resistance:100Mohm; Operating Temperature Max:60°C; Operating Temperature Min:-20°C; Output Voltage Max:250VAC; Response Time Max:10s; Response Time Min:0.1s

ELECTROMECHANICAL MULTIFUNCTION TIMER; No. of Digits / Alpha:6; Digit Height:10mm; Supply Voltage Min:12V; Supply Voltage Max:24V; Panel Cutout Height:45mm; Panel Cutout Width:45mm; Operating Temperature Min:-10 C; Product Range:-

ENCLOSURE CONTROL PC YELLOW; For Use With:Omron A22E Series Emergency Stop Push Button Switches

POWER SUPPLY AC-DC 24V 1.5A; No. of Outputs:1Outputs; Output Power Max:30W; Output Voltage - Output 1:24V; Output Current - Output 1:1.5A; Output Voltage - Output 2:-; Output Current - Output 2:-; Output Voltage - Output 3:-

POWER SUPPLY AC-DC 24V 4.5A; No. of Outputs:1 Output; Output Power Max:100W; Output Voltage - Output 1:24V; Output Current - Output 1:4.5A; Output Voltage - Output 2:-; Output Current - Output 2:-; Output Voltage - Output 3:-

POWER SUPPLY AC-DC 24V 20A; No. of Outputs:1 Output; Output Power Max:480W; Output Voltage - Output 1:24V; Output Current - Output 1:20A; Output Voltage - Output 2:-; Output Current - Output 2:-; Output Voltage - Output 3:-; Output Current - Output 3:-; Output Voltage - Output 4:-; Current Output 4:-; Input Voltage AC Min:85V; Input Voltage AC Max:264V; Power Supply Output Type:Adjustable Fixed; Product Range:S8VK-S Series; SVHC:No SVHC (07-Jul-2017)

POWER SUPPLY AC-DC 24V 10A; No. of Outputs:1 Output; Output Power Max:240W; Output Voltage - Output 1:24V; Output Current - Output 1:10A; Output Voltage - Output 2:-; Output Current - Output 2:-; Output Voltage - Output 3:-; Output Current - Output 3:-; Output Voltage - Output 4:-; Current Output 4:-; Input Voltage AC Min:320V; Input Voltage AC Max:576V; Power Supply Output Type:Adjustable Fixed; Product Range:S8VK-T Series; SVHC:No SVHC (07-Jul-2017)

COUNTER ELECTROMAGNETIC 6 DIGITS; No. of Digits / Alpha:6; Digit Height:4mm; Supply Voltage Min:-; Supply Voltage Max:-; Panel Cutout Height:28mm; Panel Cutout Width:49mm; Operating Temperature Min:-10°C; Operating Temperature Max:45°C; Product Range:-; Counting Speed:20Hz; Operating Temperature Range:-10°C to +45°C; Power Consumption:3.5W

POWER SUPPLY UNIT 240VAC CONTROLLER; Current Rating:6A; Product Range:NJ Series

EMERGENCY STOP SW DPST-NC 125V SOLDER; Contact Configuration:DPST-NC; Switch Operation:Pushlock Turn Reset; Switch Terminals:Solder; Contact Current Max:5A; Contact Voltage AC Nom:125V; Contact Voltage DC Nom:-; Pushbutton Actuator Style:Mushroom; IP Rating:IP65; Product Range:A165E Series; SVHC:No SVHC (07-Jul-2017)
