NXP Semiconductors N.V.
The FRDM-KW36 is a development kit enabled by the Kinetis W KW35Z/36Z/35A/36A (KW36) family built on Arm Cortex-M0+ processor with integrated 2.4 GHz transceiver supporting Bluetooth Low Energy (BLE) v5 and Generic FSK. The KW36 integrate CAN/CAN-FD and LIN connectivity.
The FRDM-KW36 kit contains Freedom board that can be used as a development board or a shield to connect to a host processor. The FRDM-KW36 highly sensitive, optimized 2.4 GHz radio features a PCB F-antenna which can be bypassed to test via SMA connection, CAN and LIN transceivers, 4-Mbit external serial flash, multiple power supply options, push/capacitive touch buttons, switches, LEDs and integrated sensors.
Features:
FRDM-KW36 Freedom Development Board includes MKW36Z512VHT4
Can be configured as Host or Shield for connection to Host Processor
Supports all DC-DC configurations
PCB inverted F-type antenna and SMA RF Connector
Minimum number of matching components
FCC Part15 & EN300 328 compliant
Serial Flash for OTA firmware upgrades
Onboard NXP FXOS8700CQ digital sensor, 3D Accelerometer (±2g/±4g/±8g) + 3D Magnetometer
CAN & LIN connectivity support
OpenSDA and JTAG debug
Full MCUXpresso support
Kit contains:
1 FRDM-KW36 Freedom development board
1 USB Cable
