B22AP
Part Number : B22AP
NKK SwitchesSWITCH TOGGLE DPDT 0.1A 28VAC; Product Range:-; Illumination:Non Illuminated; Contact Configuration:DPDT; Switch Operation:On-None-On; Switch Mounting:Panel; Contact Current Max:100mA; Contact Voltage AC Nom:28V
B18AP
Part Number : B18AP
NKK SwitchesSWITCH TOGGLE SPDT 0.1A 28VAC; Contact Configuration:SPDT; Illumination:Non Illuminated; Switch Operation:(On)-Off-(On); Product Range:-; Switch Mounting:Panel; Contact Current Max:100mA; Contact Voltage AC Nom:28V ;RoHS Compliant: Yes
B13AB
Part Number : B13AB
NKK SwitchesTOGGLE SWITCH SPDT ON-OFF-ON ESD; Contact Configuration:SPDT; Illumination:Non Illuminated; Switch Operation:On-Off-On; Product Range:-; Switch Mounting:Panel; Contact Current Max:100mA; Contact Voltage AC Nom:28V; Switch Terminals:Solder; Contact Voltage DC Nom:28V; SVHC:No SVHC (17-Dec-2015); Actuation Type:Bat; Bush Thread Length:2.7mm; Contact Current AC Max:100mA; Contact Current DC Max:100mA; Contact Resistance Max:50mohm; Contact Voltage AC Max:28VAC; Contact Voltage AC Min:20mV; Contact Voltage DC Max:28VDC; Contact Voltage DC Min:20mV; External Depth:8mm; External Width:10.16mm; Height:13.1mm; Insulation Resistance:500Mohm; Insulation Resistance Voltage:500VDC; Lever Length:10mm; No. of Electrical Operations:50000; Operating Temperature Max:85°C; Operating Temperature Min:-30°C; Shaft Diameter:2.6mm; Switch Action:Nonshorting; Switching Current AC Max:0.1A; Switching Current AC Min:0.1mA; Switching Current DC Max:0.1A; Switching Current DC Min:0.1mA; Switching Power Max:0.4VA
B12AH
Part Number : B12AH
NKK SwitchesTOGGLE SWITCH SPDT R/A ON-ON ESD; Contact Configuration:SPDT; Illumination:Non Illuminated; Switch Operation:On-On; Product Range:B - ESD Series; Switch Mounting:Through Hole; Contact Current Max:100mA; Contact Voltage AC Nom:28V; Switch Terminals:Solder; Contact Voltage DC Nom:28V; SVHC:No SVHC (17-Dec-2015); Actuation Type:Bat; Bush Thread Length:2.7mm; Contact Current AC Max:100mA; Contact Current DC Max:100mA; Contact Resistance Max:50mohm; Contact Voltage AC Max:28VAC; Contact Voltage AC Min:20mV; Contact Voltage DC Max:28VDC; Contact Voltage DC Min:20mV; External Depth:13.9mm; External Width:8.8mm; Height:7.3mm; Insulation Resistance:500Mohm; Insulation Resistance Voltage:500VDC; Lever Length:10mm; No. of Electrical Operations:50000; Operating Temperature Max:85°C; Operating Temperature Min:-30°C; Shaft Diameter:2.6mm; Switch Action:Nonshorting; Switching Current AC Max:0.1A; Switching Current AC Min:0.1mA; Switching Current DC Max:0.1A; Switching Current DC Min:0.1mA; Switching Power Max:0.4VA
