TOGGLE SWITCH DPDT VERT ON-ON; Contact Configuration:DPDT; Illumination:Non Illuminated; Switch Operation:On-On; Product Range:D2 Series; Switch Mounting:Panel; Contact Current Max:100mA; Contact Voltage AC Nom:48V; Switch Terminals:Solder; Contact Voltage DC Nom:48V; SVHC:No SVHC (17-Dec-2015); Actuation Type:Bat; Bush Thread Length:7.2mm; Contact Current AC Max:100mA; Contact Current DC Max:100mA; Contact Resistance Max:50mohm; Contact Voltage AC Max:48VAC; Contact Voltage AC Min:20mV; Contact Voltage DC Max:48VDC; Contact Voltage DC Min:20mV; Dielectric Strength VDC:1000VAC; External Depth:13.9mm; External Length / Height:14.4mm; External Width:12.4mm; Flammability Rating:UL94V-0; Insulation Resistance:1000Mohm; Insulation Resistance Voltage:500VDC; Lead Spacing:5.08mm; Lever Length:10.5mm; No. of Electrical Operations:50000; No. of Mechanical Operations:100000; Operating Temperature Max:70°C; Operating Temperature Min:-10°C; Panel Cutout Diameter:6.5mm; Pin Diameter:0.8mm; Pin Length:3.6mm

Toggle Switches DPDT ON-OFF-(ON) .394" BAT RIGHT ANGLE PC TERMINALS

TOGGLE SWITCH SPDT VERT ON-OFF-ON; Contact Configuration:SPDT; Illumination:Non Illuminated; Switch Operation:On-Off-On; Product Range:D2 Series; Switch Mounting:Panel; Contact Current Max:100mA; Contact Voltage AC Nom:48V; Switch Terminals:Solder; Contact Voltage DC Nom:48V; SVHC:No SVHC (17-Dec-2015); Actuation Type:Bat; Bush Thread Length:7.2mm; Contact Current AC Max:100mA; Contact Current DC Max:100mA; Contact Resistance Max:50mohm; Contact Voltage AC Max:48VAC; Contact Voltage AC Min:20mV; Contact Voltage DC Max:48VDC; Contact Voltage DC Min:20mV; Dielectric Strength VDC:1000VAC; External Depth:13.9mm; External Length / Height:14.4mm; External Width:7mm; Flammability Rating:UL94V-0; Insulation Resistance:1000Mohm; Insulation Resistance Voltage:500VDC; Lead Spacing:5.08mm; Lever Length:10.5mm; No. of Electrical Operations:50000; No. of Mechanical Operations:100000; Operating Temperature Max:70°C; Operating Temperature Min:-10°C; Panel Cutout Diameter:6.5mm; Pin Diameter:0.8mm; Pin Length:3.6mm

TOGGLE SWITCH SPDT MOM-OFF-MOM ESD; Contact Configuration:SPDT; Illumination:Non Illuminated; Switch Operation:(On)-Off-(On); Product Range:-; Switch Mounting:Through Hole; Contact Current Max:100mA; Contact Voltage AC Nom:28V; Switch Terminals:Solder; Contact Voltage DC Nom:28V; SVHC:No SVHC (17-Dec-2015); Actuation Type:Bat; Bush Thread Length:2.7mm; Contact Current AC Max:100mA; Contact Current DC Max:100mA; Contact Resistance Max:50mohm; Contact Voltage AC Max:28VAC; Contact Voltage AC Min:20mV; Contact Voltage DC Max:28VDC; Contact Voltage DC Min:20mV; External Depth:8mm; External Width:10.16mm; Height:13.1mm; Insulation Resistance:500Mohm; Insulation Resistance Voltage:500VDC; Lever Length:10mm; No. of Electrical Operations:50000; Operating Temperature Max:85°C; Operating Temperature Min:-30°C; Shaft Diameter:2.6mm; Switch Action:Nonshorting; Switching Current AC Max:0.1A; Switching Current AC Min:0.1mA; Switching Current DC Max:0.1A; Switching Current DC Min:0.1mA; Switching Power Max:0.4VA

Contact Configuration:SPST-NO; Contact Voltage VDC:12V; Contact Current Max:100mA; Switch Terminals:Through Hole; Display Type:LCD; Viewing Area (H x W):15mm x 10.8mm; Pixel Size (H x W):0.2mm x 0.27mm; Product Range:-

SWITCH ROCKER OLED PROG SP3T; Contact Configuration:SP3T; Contact Voltage VDC:-; Contact Current Max:-; Switch Terminals:Connector; Display Type:OLED; Viewing Area (H x W):13.22mm x 19.16mm; Pixel Size (H x W):0.16mm x 0.177mm

POWER ROCKER/SNAP-IN

SWITCH PUSHBUTTON ILLUMINATED SPDT 0.1A 28V; Product Range:-; Contact Configuration:SPDT; Switch Operation:On-On; Contact Current Max:100mA; Contact Voltage AC Nom:28V; Illumination Color:Red; Contact Voltage DC Nom:28V

MINIATURE PUSHBUTTON/ILLUMINATED/PANEL MOUNT

SWITCH PUSHBUTTON ILLUMINATED DPDT 0.1A 28V RED; Product Range:-; Contact Configuration:DPDT; Switch Operation:On-(On); Contact Current Max:100mA; Contact Voltage AC Nom:28V; Illumination Color:-; Contact Voltage DC Nom:28V ;RoHS Compliant: Yes

SWITCH PUSHBUTTON ILLUMINATED SPDT 3A 250V; Contact Configuration:SPDT; Switch Operation:On-(On); Contact Voltage AC Nom:250V; Contact Voltage DC Nom:30V; Contact Current Max:3A; Switch Terminals:Quick Connect Solder

SWITCH PUSHBUTTON ILLUMINATED SPDT 0.1A 28V; Product Range:-; Contact Configuration:SPDT; Switch Operation:On-(On); Contact Current Max:100mA; Contact Voltage AC Nom:28V; Illumination Color:Amber; Contact Voltage DC Nom:28V

SWITCH PUSHBUTTON ILLUMINATED SPDT 3A 250V; Contact Configuration:SPDT; Switch Operation:On-(On); Contact Voltage AC Nom:250V; Contact Voltage DC Nom:30V; Contact Current Max:3A; Switch Terminals:Quick Connect Solder

SWITCH PUSHBUTTON ILLUMINATED SPDT 0.1A 28V; Product Range:-; Contact Configuration:SPDT; Switch Operation:On-(On); Contact Current Max:100mA; Contact Voltage AC Nom:28V; Illumination Color:Red; Contact Voltage DC Nom:28V ;RoHS Compliant: Yes

SWITCH PUSHBUTTON ILLUMINATED SPDT 0.1A 28V; Contact Configuration:SPDT; Switch Operation:On-(On); Contact Voltage AC Nom:28V; Contact Voltage DC Nom:28V; Contact Current Max:100mA; Switch Terminals:Quick Connect Solder

SWITCH PUSHBUTTON ILLUMINATED SPDT 0.1A 28V; Contact Configuration:SPDT; Switch Operation:On-On; Contact Voltage AC Nom:28V; Contact Voltage DC Nom:28V; Contact Current Max:100mA; Switch Terminals:Quick Connect Solder

SWITCH PUSHBUTTON ILLUMINATED SPDT 0.1A 28V; Contact Configuration:SPDT; Switch Operation:On-On; Contact Voltage AC Nom:28V; Contact Voltage DC Nom:28V; Contact Current Max:100mA; Switch Terminals:Quick Connect Solder

SWITCH PUSHBUTTON ILLUMINATED SPDT 0.1A 28V; Contact Configuration:SPDT; Switch Operation:On-On; Contact Voltage AC Nom:28V; Contact Voltage DC Nom:28V; Contact Current Max:100mA; Switch Terminals:Quick Connect Solder

SWITCH PUSHBUTTON ILLUMINATED SPDT 3A 250V RED; Contact Configuration:SPDT; Switch Operation:On-On; Contact Voltage AC Nom:250V; Contact Voltage DC Nom:30V; Contact Current Max:3A; Switch Terminals:Quick Connect Solder

SWITCH PUSHBUTTON ILLUMINATED DPDT 3A 250V; Product Range:-; Contact Configuration:DPDT; Switch Operation:On-(On); Contact Current Max:3A; Contact Voltage AC Nom:250V; Illumination Color:Green; Contact Voltage DC Nom:30V
