CABLE CTRL CY 3CORE 1.5MM 100M; Jacket Colour:Grey; No. of Cores:3Core; Wire Gauge:16AWG; Conductor Area CSA:1.5mm²; Reel Length (Imperial):328ft; Reel Length (Metric):100m; No. of Max Strands x Strand Size:30 x 0.25mm; Voltage Rating:500V; Jacket Material:PVC; Conductor Material:Copper; External Diameter:7.5mm; Product Range:-; SVHC:No SVHC (12-Jan-2017); Bend Radius Min:20mm; Cable Type:Braided Shield; Conductor Make-up:30 / 0.25mm; Core-Earth / Core-Core Voltage Rating:300/500; Current Rating:16A; Flexing Temperature Max:70°C; Flexing Temperature Min:-5°C; Installed Bend Radius Min:6; Insulation Resistance:20Gohm; Operating Temperature Max:70°C; Operating Temperature Min:-30°C; Outer Diameter:7.5mm; Secondary Insulation Colour:Grey; Secondary Insulation Material:PVC; Shield Material:Tinned Copper; Shield Type:Tinned Copper Braid; Test Voltage:4000V

GLAND VITON M20 6.8-8.8MM; Thread Size - Imperial:-; Thread Size - Metric:M20 x 1.5; Cable Diameter Min:6.8mm; Cable Diameter Max:8.8mm; Cable Gland Material:Brass; Gland Colour:Metallic - Nickel Finish; IP / NEMA Rating:IP68; Product Range:-; SVHC:No SVHC (12-Jan-2017); Accessory Type:Gland; Body Plating:Nickel; Cable Diameter:8.8mm; Cable Diameter Max - Imperial:0.346"; Cable Diameter Max - Metric:8.8mm; Cable Diameter Min - Imperial:0.268"; Cable Diameter Min - Metric:6.8mm; Colour:Silver; External Length / Height:31mm; Material:Brass; Mounting Hole Dia:20mm; Operating Temperature Max:200°C; Operating Temperature Min:-15°C; Thread Length:6mm; Thread Size:M20 x 1.5

CABLE YY 4 CORE 1MM 50M; Jacket Colour:Grey; No. of Cores:4Core; Wire Gauge:18AWG; Conductor Area CSA:1mm²; Reel Length (Imperial):164ft; Reel Length (Metric):50m; No. of Max Strands x Strand Size:-; Voltage Rating:500V; Jacket Material:PVC; Conductor Material:Copper; External Diameter:6.5mm; Product Range:YY Series; SVHC:No SVHC (12-Jan-2017); Bend Flexing Radius Min:15; Cable Type:Unshielded; Core-Earth / Core-Core Voltage Rating:300/500 V; Flexing Temperature Max:70°C; Flexing Temperature Min:-5°C; Installed Bend Radius Min:4; Insulation Resistance:20Gohm; Operating Temperature Max:80°C; Operating Temperature Min:-40°C; Outer Diameter:6.5mm; Secondary Insulation Colour:Grey; Secondary Insulation Material:PVC; Test Voltage:4000V; Voltage Rating VAC:500V

CABLE YY 4 CORE 1.5MM 50M; Jacket Colour:Grey; No. of Cores:4Core; Wire Gauge:16AWG; Conductor Area CSA:1.5mm²; Reel Length (Imperial):164ft; Reel Length (Metric):50m; No. of Max Strands x Strand Size:-; Voltage Rating:500V; Jacket Material:PVC; Conductor Material:Copper; External Diameter:7.2mm; Product Range:YY Series; SVHC:No SVHC (12-Jan-2017); Bend Flexing Radius Min:15; Cable Type:Unshielded; Core-Earth / Core-Core Voltage Rating:300/500 V; Flexing Temperature Max:70°C; Flexing Temperature Min:-5°C; Installed Bend Radius Min:4; Insulation Resistance:20Gohm; Operating Temperature Max:80°C; Operating Temperature Min:-40°C; Outer Diameter:7.2mm; Secondary Insulation Colour:Grey; Secondary Insulation Material:PVC; Test Voltage:4000V; Voltage Rating VAC:500V

ENLARGER BRASS ATEX M25/M32; Thread Size - Imperial:-; Thread Size - Metric:-; Cable Diameter Min:-; Cable Diameter Max:-; Cable Gland Material:Brass; Gland Colour:Grey; IP / NEMA Rating:-; Product Range:-; SVHC:No SVHC (12-Jan-2017); Accessory Type:Enlarger; Colour:Grey; For Use With:Cable Glands; Inner Thread Size:M32 x 1.5; Material:Brass; Outer Thread Size:M25 x 1.5

REDUCER BRASS ATEX M20/M16; Thread Size - Imperial:-; Thread Size - Metric:-; Cable Diameter Min:-; Cable Diameter Max:-; Cable Gland Material:Brass; Gland Colour:Silver; IP / NEMA Rating:-; Product Range:-; SVHC:No SVHC (12-Jan-2017); Accessory Type:Reducer; Colour:Silver; Inner Thread Size:M16 x 1.5; Material:Brass; Outer Thread Size:M20 x 1.5

O-RING M50 2.0MM PK25; Seal Material:NBR (Nitrile Butadiene Rubber); Internal Diameter:46mm; External Diameter:-; Shaft Diameter:-; Product Range:-; SVHC:No SVHC (12-Jan-2017); Body Material:NBR (Nitrile Butadiene Rubber); Material:NBR; Material Thickness:2mm; Operating Temperature Max:100°C; Operating Temperature Min:-30°C; Size:M50 x 2; Thread Size:M50

CABLE DATA 2 CORE 1MM 50M; Jacket Colour:Grey; No. of Cores:2Core; Wire Gauge:18AWG; Conductor Area CSA:1mm²; Reel Length (Imperial):164ft; Reel Length (Metric):50m; No. of Max Strands x Strand Size:-; Voltage Rating:350V; Jacket Material:PVC; Conductor Material:Copper; External Diameter:5.6mm; Product Range:2 Core Series; SVHC:No SVHC (12-Jan-2017)

CABLE DATA 5 CORE 1MM 50M; Jacket Colour:Grey; No. of Cores:5Core; Wire Gauge:18AWG; Conductor Area CSA:1mm²; Reel Length (Imperial):164ft; Reel Length (Metric):50m; No. of Max Strands x Strand Size:-; Voltage Rating:350V; Jacket Material:PVC; Conductor Material:Copper; External Diameter:7.3mm; Product Range:-; SVHC:No SVHC (12-Jan-2017)

CABLE DATA SCRN 2CORE 0.75MM 50M; Jacket Colour:Grey; No. of Cores:2Core; Wire Gauge:19AWG; Conductor Area CSA:0.75mm²; Reel Length (Imperial):164ft; Reel Length (Metric):50m; No. of Max Strands x Strand Size:-; Voltage Rating:350V; Jacket Material:PVC; Conductor Material:Copper; External Diameter:6mm; Product Range:Unitronic LiYCY; SVHC:No SVHC (12-Jan-2017); Cable Type:Braided Shield; Operating Temperature Max:80°C; Operating Temperature Min:-40°C

CABLE DATA SCRN 4CORE 0.75MM 50M; Jacket Colour:Grey; No. of Cores:4Core; Wire Gauge:19AWG; Conductor Area CSA:0.75mm²; Reel Length (Imperial):164ft; Reel Length (Metric):50m; No. of Max Strands x Strand Size:-; Voltage Rating:350V; Jacket Material:PVC; Conductor Material:Copper; External Diameter:7mm; Product Range:Unitronic LiYCY; SVHC:No SVHC (12-Jan-2017); Cable Type:Braided Shield; Operating Temperature Max:80°C; Operating Temperature Min:-40°C

CABLE DATA 2 PAIR 0.14MM 50M; Jacket Colour:Grey; No. of Pairs:2 Pair; Wire Gauge:26AWG; Conductor Area CSA:0.14mm²; Reel Length (Imperial):164ft; Reel Length (Metric):50m; No. of Max Strands x Strand Size:-; Voltage Rating:1.2kV; Jacket Material:PVC; Conductor Material:Copper; External Diameter:4.8mm; Product Range:-; SVHC:No SVHC (12-Jan-2017); Cable Type:Unshielded; Outer Diameter:4.8mm

CABLE DATA 10 PAIR 0.14MM 50M; Jacket Colour:Grey; No. of Pairs:10 Pair; Wire Gauge:26AWG; Conductor Area CSA:0.14mm²; Reel Length (Imperial):164ft; Reel Length (Metric):50m; No. of Max Strands x Strand Size:-; Voltage Rating:1.2kV; Jacket Material:PVC; Conductor Material:Copper; External Diameter:8mm; Product Range:-; SVHC:No SVHC (12-Jan-2017); Cable Type:Unshielded; Outer Diameter:8mm

CABLE DATA 4 PAIR 0.25MM 50M; Jacket Colour:Grey; No. of Pairs:4 Pair; Wire Gauge:24AWG; Conductor Area CSA:0.25mm²; Reel Length (Imperial):164ft; Reel Length (Metric):50m; No. of Max Strands x Strand Size:-; Voltage Rating:1.5kV; Jacket Material:PVC; Conductor Material:Copper; External Diameter:6.9mm; Product Range:-; SVHC:No SVHC (12-Jan-2017); Cable Type:Unshielded; Outer Diameter:6.9mm

CABLE DATA 6 PAIR 0.25MM 50M; Jacket Colour:Grey; No. of Pairs:6 Pair; Wire Gauge:24AWG; Conductor Area CSA:0.25mm²; Reel Length (Imperial):164ft; Reel Length (Metric):50m; No. of Max Strands x Strand Size:-; Voltage Rating:1.5kV; Jacket Material:PVC; Conductor Material:Copper; External Diameter:7.8mm; Product Range:-; SVHC:No SVHC (12-Jan-2017); Cable Type:Unshielded; Outer Diameter:7.8mm

Multiconductor Unshielded Cable Sensor Actuator Per M 4 22 AWG ;RoHS Compliant: Yes

ENLARGER BRASS M40/M50; Thread Size - Imperial:-; Thread Size - Metric:-; Cable Diameter Min:-; Cable Diameter Max:-; Cable Gland Material:Brass; Gland Colour:Silver; IP / NEMA Rating:-; Product Range:-; SVHC:No SVHC (12-Jan-2017); Accessory Type:Enlarger; Colour:Silver; For Use With:Cable Glands; Inner Thread Size:M50 x 1.5; Material:Brass; Outer Thread Size:M40 x 1.5

CABLE WELDING BLACK 25MM PER M; Jacket Material:Polychloroprene; Jacket Colour:Black; Wire Gauge:4AWG; Conductor Area CSA:25mm²; Reel Length (Imperial):-; Reel Length (Metric):-; No. of Max Strands x Strand Size:760 x 0.21mm; Voltage Rating:100V; Conductor Material:Copper; External Diameter:12.7mm; Approval Specification:-; Product Range:-; SVHC:No SVHC (12-Jan-2017); Conductor Make-up:760 / 0.21mm; External Length / Height:1m; Operating Temperature Max:85°C; Operating Temperature Min:-25°C; Outer Diameter:12.7mm; Outside Diameter Max:12.7mm; Outside Diameter Min:10.1mm; Primary Insulation Thickness:2mm; Test Voltage:1000V

CABLE CTRL 4 CORE 1.5MM PER M; Jacket Colour:Grey; No. of Cores:4Core; Wire Gauge:16AWG; Conductor Area CSA:1.5mm²; Reel Length (Imperial):-; Reel Length (Metric):-; No. of Max Strands x Strand Size:4 x 1.5mm²; Voltage Rating:600V; Jacket Material:PVC; Conductor Material:Copper; External Diameter:8.9mm; Product Range:4 Core Series; SVHC:No SVHC (12-Jan-2017); Cable Type:Unshielded; Conductor Make-up:4 G 1.5mm²; External Length / Height:1m; Outer Diameter:8.9mm; Secondary Insulation Material:PVC; Test Voltage:3000V; Wire Size:16AWG
