WIRE/CABLE

LAPP 19022000

CABLE, 4C, 600V, 100FT, 4AWG, BLACK; Cable Shielding:Shielded; No. of Conductors:4Conductor; Wire Gauge:4AWG; Conductor Area CSA:21mm²; Reel Length (Imperial):100ft; Reel Length (Metric):30.5m; Jacket Color:Black; Jacket Material:TPE

CABLE, 4C, 600V, 100FT, 2AWG, BLACK; Cable Shielding:Shielded; No. of Conductors:4Conductor; Wire Gauge:2AWG; Conductor Area CSA:33.7mm²; Reel Length (Imperial):100ft; Reel Length (Metric):30.5m; Jacket Color:Black

INSERT SOCKET HDD 42WAY; Product Range:-; Connector Mounting:Panel Mount; Gender:Receptacle; No. of Contacts:42Contacts; Contact Gender:Socket; No. of Rows:6Rows; Contact Termination Type:Crimp; Connector Shell Size:-; Contact Material:Copper; Contact Plating:-; SVHC:No SVHC (12-Jan-2017); Connector Type:Rectangular Power; Contact Termination:Crimp; Current Rating:10A; Degree of Pollution:3; IP / NEMA Rating:IP65; Operating Temperature Max:125°C; Operating Temperature Min:-40°C; Termination Method:Crimp; Test Voltage:4kV; Voltage Rating VAC:250V; Wire Area Size Max:2.5mm²; Wire Area Size Min:0.14mm²; Working Voltage:250V

CABLE

HA PANEL KIT STRT 16-WAY

PLUG WITH CABLE COUPLER 16WAY; Product Range:-; Circular Connector Shell Style:Cable Mount Plug; No. of Contacts:16Contacts; Circular Contact Type:Solder Pin; Coupling Style:-; Connector Body Material:Copper Alloy Body; Connector Body Plating:-; Contact Material:Copper Alloy; Contact Plating:Silver; SVHC:No SVHC (12-Jan-2017); Body Plating:Nickel; Cable Diameter Max:12mm; Cable Diameter Min:8mm; Colour:Nickel; Connector Mounting:Cable Mount; Connector Type:Circular Industrial; Contact Gender:Pin; Contact Plating:Silver Plated Contacts; Contact Resistance:3mohm; Contact Termination:Solder; Contact Termination Type:Solder; Current Rating:7.5A; Flammability Rating:UL94V-0; Gender:Plug; IP / NEMA Rating:IP65; Insulation Resistance:10Mohm; Operating Temperature Max:125°C; Operating Temperature Min:-40°C; Thread Size:PG11; Voltage Rating VAC:250V; Withstand Voltage:1.5kV; Working Voltage:24V

SOCKET THR'HOLE CHS 9WAY; Product Range:Circon R2.5 Series; Circular Connector Shell Style:Panel Mount Receptacle; No. of Contacts:9Contacts; Circular Contact Type:Solder Socket; Coupling Style:-; Connector Body Material:Copper Alloy Body; Connector Body Plating:-; Contact Material:Copper Alloy; Contact Plating:Silver; SVHC:No SVHC (12-Jan-2017); Body Plating:Nickel; Cable Diameter Max:10mm; Cable Diameter Min:6mm; Colour:Nickel; Connector Mounting:Panel Mount; Connector Type:Circular Industrial; Contact Gender:Socket; Contact Plating:Silver Plated Contacts; Contact Resistance:3mohm; Contact Termination:Solder; Contact Termination Type:Solder; Current Rating:7.5A; Flammability Rating:UL94V-0; Gender:Receptacle; IP / NEMA Rating:IP65; Insulation Resistance:10Mohm; Operating Temperature Max:125°C; Operating Temperature Min:-40°C; Thread Size:PG9; Voltage Rating VAC:380V; Withstand Voltage:1.5kV; Working Voltage:24V

COMPLETE CONNECTOR KIT HBE; Product Range:-; Connector Mounting:Panel Mount; Gender:Plug Receptacle; No. of Contacts:6Contacts; Contact Gender:Pin Socket; No. of Rows:2Rows; Contact Termination Type:Screw; Connector Shell Size:HBE 6; Contact Material:Copper; Contact Plating:Silver Plated Contacts; Connector Type:Rectangular; Contact Resistance:2mohm; Contact Termination:Screw; Current Rating:16A; IP / NEMA Rating:IP65; No. of Mating Cycles:100; Operating Temperature Max:125°C; Operating Temperature Min:-40°C; Voltage Rating VAC:400V; Wire Area Size Max:2.5mm²; Wire Area Size Min:0.5mm²; Working Voltage:400V

COMPLETE CONNECTOR KIT HBE; Product Range:EPIC HBE Series; Connector Mounting:Panel Mount; Gender:Plug Receptacle; No. of Contacts:6Contacts; Contact Gender:Pin Socket; No. of Rows:2Rows; Contact Termination Type:Screw; Connector Shell Size:HBE 6; Contact Material:Copper; Contact Plating:Silver Plated Contacts; Connector Type:Rectangular; Contact Resistance:2mohm; Contact Termination:Screw; Current Rating:16A; IP / NEMA Rating:IP65; No. of Mating Cycles:100; Operating Temperature Max:125°C; Operating Temperature Min:-40°C; Voltage Rating VAC:400V; Wire Area Size Max:2.5mm²; Wire Area Size Min:0.5mm²; Working Voltage:400V

HOOD HBE TOP ENTRY; Accessory Type:Top Entry Hood with Cable Gland; For Use With:EPIC HB Series Connector; Connector Shell Size:HB10; Cable Exit Angle:180°; Connector Body Material:Aluminium Body; Product Range:-; SVHC:No SVHC (12-Jan-2017); Colour:Grey; Material:Aluminium Alloy; Operating Temperature Max:125°C; Operating Temperature Min:-40°C; Size:HB10

KIT COVER HBE 10WAY; Accessory Type:Cover; For Use With:EPIC Connectors; Connector Body Material:Thermoplastic Body; Product Range:-; SVHC:No SVHC (12-Jan-2017); Colour:Grey; IP / NEMA Rating:IP65; Material:Thermoplastic Resin; Operating Temperature Max:125°C; Operating Temperature Min:-40°C

COMPLETE CONNECTOR KIT HBE; Product Range:-; Connector Mounting:Panel Mount; Gender:Plug Receptacle; No. of Contacts:16Contacts; Contact Gender:Pin Socket; No. of Rows:2Rows; Contact Termination Type:Screw; Connector Shell Size:HBE 16; Contact Material:Copper; Contact Plating:Silver Plated Contacts; Connector Type:Rectangular; Contact Resistance:2mohm; Contact Termination:Screw; Current Rating:16A; IP / NEMA Rating:IP65; No. of Mating Cycles:100; Operating Temperature Max:125°C; Operating Temperature Min:-40°C; Voltage Rating VAC:400V; Wire Area Size Max:2.5mm²; Wire Area Size Min:0.5mm²; Working Voltage:400V

PANEL MOUNT KIT HA METAL 4WAY; Product Range:-; Connector Mounting:Cable Mount; Gender:Plug Receptacle; No. of Contacts:4Contacts; Contact Gender:Pin Socket; No. of Rows:2Rows; Contact Termination Type:Screw; Connector Shell Size:HA 4; Contact Material:Copper; Contact Plating:Silver Plated Contacts; Connector Type:Rectangular; Contact Resistance:2mohm; Contact Termination:Screw; Current Rating:10A; IP / NEMA Rating:IP65; Operating Temperature Max:125°C; Operating Temperature Min:-40°C; Termination Method:Screw; Voltage Rating VAC:400V; Wire Area Size Max:2.5mm²; Wire Area Size Min:0.5mm²; Working Voltage:400V

HA PANEL MOUNT KIT 3WAY METAL S/ANGLE; Product Range:-; Connector Mounting:Cable Mount; Gender:Plug Receptacle; No. of Contacts:3Contacts; Contact Gender:Pin Socket; No. of Rows:2Rows; Contact Termination Type:Screw; Connector Shell Size:HA 3; Contact Material:Copper; Contact Plating:Silver Plated Contacts; Connector Type:Rectangular; Contact Resistance:2mohm; Contact Termination:Screw; Current Rating:10A; IP / NEMA Rating:IP65; Operating Temperature Max:125°C; Operating Temperature Min:-40°C; Termination Method:Screw; Voltage Rating VAC:400V; Wire Area Size Max:2.5mm²; Wire Area Size Min:0.5mm²; Working Voltage:400V

CONNECTOR KIT KIT13 HA3; Product Range:-; Connector Mounting:Cable Mount; Gender:Plug; No. of Contacts:4Contacts; Contact Gender:Pin; No. of Rows:2Rows; Contact Termination Type:Screw; Connector Shell Size:-; Contact Material:Copper; Contact Plating:Silver Plated Contacts; Connector Type:Rectangular Power; Contact Resistance:4Mohm; Contact Termination:Screw; Current Rating:10A; IP / NEMA Rating:IP65; Operating Temperature Max:125°C; Operating Temperature Min:-40°C; Termination Method:Screw; Voltage Rating VAC:400V; Working Voltage:400V

HOOD HA SIDE ENTRY 10WAY; Accessory Type:Hood with Cable Gland; For Use With:EPIC HA Series Rectangular Connector; Connector Shell Size:HA10; Cable Exit Angle:90°; Connector Body Material:Aluminium Body; Product Range:-; SVHC:No SVHC (12-Jan-2017); Colour:Grey; IP / NEMA Rating:IP65; Material:Aluminium Alloy; Operating Temperature Max:125°C; Operating Temperature Min:-40°C; Range:HA10; Wire Area Size Max:2.5mm²; Wire Area Size Min:0.5mm²

CONNECTOR KIT KIT22 HA16; Product Range:-; Connector Mounting:Panel Mount; Gender:Receptacle; No. of Contacts:16Contacts; Contact Gender:Pin; No. of Rows:2Rows; Contact Termination Type:Screw; Connector Shell Size:-; Contact Material:Copper; Contact Plating:Silver Plated Contacts; Connector Type:Rectangular Power; Contact Termination:Screw; Current Rating:16A; IP / NEMA Rating:IP65; Operating Temperature Max:125°C; Operating Temperature Min:-40°C; Termination Method:Screw; Test Voltage:2kV; Voltage Rating VAC:400V; Wire Area Size Max:2.5mm²; Wire Area Size Min:0.5mm²; Working Voltage:400V

PLUG WITH CABLE COUPLER 9WAY; Product Range:-; Circular Connector Shell Style:Cable Mount Plug; No. of Contacts:9Contacts; Circular Contact Type:Solder Pin; Coupling Style:-; Connector Body Material:Copper Alloy Body; Connector Body Plating:-; Contact Material:Copper Alloy; Contact Plating:Silver; SVHC:No SVHC (12-Jan-2017); Body Plating:Nickel; Cable Diameter Max:10mm; Cable Diameter Min:6mm; Colour:Nickel; Connector Mounting:Cable Mount; Connector Type:Circular Industrial; Contact Gender:Pin; Contact Plating:Silver Plated Contacts; Contact Resistance:3mohm; Contact Termination:Solder; Contact Termination Type:Solder; Current Rating:7.5A; Flammability Rating:UL94V-0; Gender:Plug; IP / NEMA Rating:IP65; Insulation Resistance:10Mohm; Operating Temperature Max:125°C; Operating Temperature Min:-40°C; Thread Size:PG9; Voltage Rating VAC:380V; Withstand Voltage:1.5kV; Working Voltage:24V
