ADAPTOR REDUCER PG11 / PG9; Conduit Component Type:Reducer; Converts From:PG 11; Converts To:PG 9; Conduit Material:Brass; For Use With:Lapp Kabel SKINDICHT Cable Glands; Product Range:-; Accessory Type:Adaptor; Body

ADAPTOR REDUCER PG13.5 / PG9; Conduit Component Type:Reducer; Converts From:PG 13.5; Converts To:PG 9; Conduit Material:Brass; For Use With:Lapp Kabel SKINDICHT Cable Glands; Product Range:-; Accessory Type:Adaptor; Body

ÖLFLEX® 150 QUATTRO

CABLE CTRL 4 CORE 2.5MM PER M; Jacket Colour:Grey; No. of Cores:4Core; Wire Gauge:14AWG; Conductor Area CSA:2.5mm²; Reel Length (Imperial):-; Reel Length (Metric):-; No. of Max Strands x Strand Size:4 x 2.5mm²; Voltage Rating:600V; Jacket Material:PVC; Conductor Material:Copper; External Diameter:10.7mm; Product Range:4 Core Series; SVHC:No SVHC (12-Jan-2017); Cable Type:Unshielded; Conductor Make-up:4 G 2.5mm²; External Length / Height:1m; Outer Diameter:10.7mm; Secondary Insulation Material:PVC; Test Voltage:3000V; Wire Size:14AWG

CABLE YY 12CORE 0.75MM PER M; Jacket Colour:Grey; No. of Cores:12Core; Wire Gauge:19AWG; Conductor Area CSA:0.75mm²; Reel Length (Imperial):-; Reel Length (Metric):-; No. of Max Strands x Strand Size:25 x 0.2mm; Voltage Rating:500V; Jacket Material:PVC; Conductor Material:Copper; External Diameter:9.9mm; Product Range:YY Series; SVHC:No SVHC (12-Jan-2017); Bend Radius Min:15mm; Cable Type:Unshielded; Conductor Make-up:25 / 0.2mm; Core-Earth / Core-Core Voltage Rating:300/500 V; Flexing Temperature Max:70°C; Flexing Temperature Min:-5°C; Installed Bend Radius Min:4; Insulation Resistance:20Gohm; Operating Temperature Max:70°C; Operating Temperature Min:-5°C; Outer Diameter:9.9mm; Secondary Insulation Colour:Grey; Secondary Insulation Material:PVC; Test Voltage:4000V; Voltage Rating VAC:500V

CABLE YY 7CORE 1MM PER M; Jacket Colour:Grey; No. of Cores:7Core; Wire Gauge:18AWG; Conductor Area CSA:1mm²; Reel Length (Imperial):-; Reel Length (Metric):-; No. of Max Strands x Strand Size:32 x 0.2mm; Voltage Rating:500V; Jacket Material:PVC; Conductor Material:Copper; External Diameter:8mm; Product Range:YY Series; SVHC:No SVHC (12-Jan-2017); Bend Radius Min:15mm; Cable Type:Unshielded; Conductor Make-up:32 / 0.2mm; Core-Earth / Core-Core Voltage Rating:300/500 V; Flexing Temperature Max:70°C; Flexing Temperature Min:-5°C; Installed Bend Radius Min:4; Insulation Resistance:20Gohm; Operating Temperature Max:70°C; Operating Temperature Min:-5°C; Outer Diameter:8mm; Secondary Insulation Colour:Grey; Secondary Insulation Material:PVC; Test Voltage:4000V; Voltage Rating VAC:500V

CABLE WELDING BLACK 35MM PER M; Jacket Material:Polychloroprene; Jacket Colour:Black; Wire Gauge:2AWG; Conductor Area CSA:35mm²; Reel Length (Imperial):-; Reel Length (Metric):-; No. of Max Strands x Strand Size:1100 x 0.21mm; Voltage Rating:100V; Conductor Material:Copper; External Diameter:14.2mm; Approval Specification:-; Product Range:-; SVHC:No SVHC (12-Jan-2017); Conductor Make-up:1100 / 0.21mm; External Length / Height:1m; Operating Temperature Max:85°C; Operating Temperature Min:-25°C; Outer Diameter:14.2mm; Outside Diameter Max:14.2mm; Outside Diameter Min:11.4mm; Primary Insulation Thickness:2mm; Test Voltage:1000V

CABLE GLAND METAL PG11; Thread Size - Imperial:-; Thread Size - Metric:PG11; Cable Diameter Min:4mm; Cable Diameter Max:10mm; Cable Gland Material:Brass; Gland Colour:Metallic - Nickel Finish; IP / NEMA Rating:IP68; Product Range:-; SVHC:No SVHC (12-Jan-2017); AF Body Width:20mm; Accessory Type:Gland; Body Plating:Nickel; Cable Diameter:10mm; Cable Diameter Max - Imperial:0.394"; Cable Diameter Max - Metric:10mm; Cable Diameter Min - Imperial:0.158"; Cable Diameter Min - Metric:4mm; Clamp Opening:10mm; Colour:Silver; For Use With:Manufacturing of Machineries and Equipments; Material:Brass; Mounting Hole Dia:18.6mm; Panel Thickness Max:12mm; Thread Length:6mm; Thread Size:PG11

CABLE GLAND MSR M32; Thread Size - Imperial:-; Thread Size - Metric:M32 x 1.5; Cable Diameter Min:7mm; Cable Diameter Max:15mm; Cable Gland Material:Brass; Gland Colour:Metallic - Nickel Finish; IP / NEMA Rating:IP68 IP69K; Product Range:-; SVHC:No SVHC (12-Jan-2017); AF Width:36mm; Accessory Type:Gland; Body Plating:Nickel; Cable Diameter Max - Imperial:0.591"; Cable Diameter Max - Metric:15mm; Cable Diameter Min - Imperial:0.276"; Cable Diameter Min - Metric:7mm; For Use With:Smaller Outer Diameter Cables; Mounting Hole Dia:32mm; Thread Length:9mm

CABLE GLAND MSR M50; Thread Size - Imperial:-; Thread Size - Metric:M50 x 1.5; Cable Diameter Min:22mm; Cable Diameter Max:29mm; Cable Gland Material:Brass; Gland Colour:Metallic - Nickel Finish; IP / NEMA Rating:IP68 IP69K; Product Range:-; SVHC:No SVHC (12-Jan-2017); AF Width:54mm; Accessory Type:Gland; Body Plating:Nickel; Cable Diameter Max - Imperial:1.142"; Cable Diameter Max - Metric:29mm; Cable Diameter Min - Imperial:0.866"; Cable Diameter Min - Metric:22mm; For Use With:Smaller Outer Diameter Cables; Mounting Hole Dia:50mm; Thread Length:10mm

LOCKNUT BRASS M32; Material:Brass; Locknut Plating:Nickel; Thread Size - Imperial:-; Thread Size - Metric:M32; Thickness:4mm; Product Range:-; SVHC:No SVHC (12-Jan-2017); AF Size - Metric:36mm; Accessory Type:Locknut; Body Plating:Nickel; Type:SM-M

CABLE GLAND BRASS 5MM M20; Thread Size - Imperial:-; Thread Size - Metric:M20 x 1.5; Cable Diameter Min:7mm; Cable Diameter Max:12.5mm; Cable Gland Material:Brass; Gland Colour:Metallic - Nickel Finish; IP / NEMA Rating:IP68; Product Range:-; SVHC:No SVHC (12-Jan-2017); Cable Diameter Max - Imperial:0.492"; Cable Diameter Max - Metric:12.5mm; Cable Diameter Min - Imperial:0.197"; Cable Diameter Min - Metric:5mm

CABLE

SKINTOP LIQUID TIGHT NON METAL C/W NPT THREAD BLK

CABLE GLANDS

22 AWG STRANDED UL/CSA/CE ORANGE

CABLE SILICONE 2CORE 0.75MM PER M; Jacket Colour:Red; No. of Cores:2Core; Wire Gauge:19AWG; Conductor Area CSA:0.75mm²; Reel Length (Imperial):-; Reel Length (Metric):-; No. of Max Strands x Strand Size:24 x 0.2mm; Voltage Rating:500V; Jacket Material:Silicone Rubber; Conductor Material:Copper; External Diameter:6.4mm; Product Range:00460 Series; SVHC:No SVHC (12-Jan-2017); Cable Type:Unshielded; Conductor Make-up:24 / 0.2mm; Current Rating:12A; Operating Temperature Max:180°C; Operating Temperature Min:-50°C; Outer Diameter:6.4mm; Outside Diameter Max:6.4mm; Secondary Insulation Material:Silicone

LAPP 10191100

IN STOCK SHIP TODAY

CABLE SPIRAL 4C 0.75MM 1.0-3.0M; Jacket Colour:Grey; No. of Cores:4Core; Wire Gauge:19AWG; Conductor Area CSA:0.75mm²; Reel Length (Imperial):9ft; Reel Length (Metric):3m; No. of Max Strands x Strand Size:4 x 0.75mm²; Voltage Rating:500V; Jacket Material:PU; Conductor Material:Copper; External Diameter:6.2mm; Product Range:70002 Series; SVHC:No SVHC (12-Jan-2017); Cable Type:Spiral Shield; Closed Length:1m; Conductor Make-up:4 G 0.75mm²; Extended Length:3m; Operating Temperature Max:50°C; Operating Temperature Min:5°C; Outer Diameter:6.2mm; Test Voltage:3000V
