DATA CABLE FLEX 5PAIR 0.5MM PER M; Jacket Colour:Grey; No. of Pairs:5 Pair; Wire Gauge:20AWG; Conductor Area CSA:0.5mm²; Reel Length (Imperial):-; Reel Length (Metric):-; No. of Max Strands x Strand Size:28 x 0.16mm; Voltage Rating:250V; Jacket Material:PU; Conductor Material:Copper; External Diameter:11.8mm; Product Range:-; SVHC:No SVHC (12-Jan-2017); Cable Type:Braided Shield; Conductor Make-up:28 / 0.15mm; Inductance:0.65µH/m; Nominal Capacitance:60nF/km; Operating Temperature Max:70°C; Operating Temperature Min:-40°C; Outer Diameter:11.8mm; Secondary Insulation Colour:Grey; Secondary Insulation Material:Polyurethane; Wire Size:20AWG

CABLE OLFLEX SERVO 4CORE 6MM 50M; Jacket Colour:Transparent; No. of Cores:4Core; Wire Gauge:10AWG; Conductor Area CSA:6mm²; Reel Length (Imperial):164ft; Reel Length (Metric):50m; No. of Max Strands x Strand Size:84 x 0.32mm; Voltage Rating:1kV; Jacket Material:PVC; Conductor Material:Copper; External Diameter:16.9mm; Product Range:-; SVHC:No SVHC (12-Jan-2017); Cable Type:Braided Shield; Conductor Make-up:84 / 0.3mm; Operating Temperature Max:70°C; Operating Temperature Min:-40°C; Outer Diameter:16.9mm; Secondary Insulation Colour:Transparent; Secondary Insulation Material:PVC; Voltage Rating VAC:1kV

WIRE H05V-K GREY 0.5MM 100M; Jacket Material:PVC; Jacket Colour:Grey; Wire Gauge:-; Conductor Area CSA:0.5mm²; Reel Length (Imperial):328ft; Reel Length (Metric):100m; No. of Max Strands x Strand Size:16 x 0.2mm; Voltage Rating:300V; Conductor Material:Copper; External Diameter:2.1mm; Approval Specification:-; Product Range:H05V-K; SVHC:No SVHC (12-Jan-2017); Operating Temperature Max:+80°C; Operating Temperature Min:-40°C; Outer Diameter:2.1mm; RMS Load Voltage Max:500V; Test Voltage:2000V; Voltage Rating VAC:300V

WIRE H05V-K GREY 1MM 100M; Jacket Material:PVC; Jacket Colour:Grey; Wire Gauge:-; Conductor Area CSA:1mm²; Reel Length (Imperial):328ft; Reel Length (Metric):100m; No. of Max Strands x Strand Size:32 x 0.2mm; Voltage Rating:300V; Conductor Material:Copper; External Diameter:2.6mm; Approval Specification:-; Product Range:H05V-K; SVHC:No SVHC (12-Jan-2017); Operating Temperature Max:+80°C; Operating Temperature Min:-40°C; Outer Diameter:2.6mm; RMS Load Voltage Max:500V; Test Voltage:2000V; Voltage Rating VAC:300V

WIRE H05V-K YELLOW 1MM 100M; Jacket Material:PVC; Jacket Colour:Yellow; Wire Gauge:-; Conductor Area CSA:1mm²; Reel Length (Imperial):328ft; Reel Length (Metric):100m; No. of Max Strands x Strand Size:32 x 0.2mm; Voltage Rating:300V; Conductor Material:Copper; External Diameter:2.6mm; Approval Specification:-; Product Range:H05V-K; SVHC:No SVHC (12-Jan-2017); Operating Temperature Max:+80°C; Operating Temperature Min:-40°C; Outer Diameter:2.6mm; RMS Load Voltage Max:500V; Test Voltage:2000V; Voltage Rating VAC:300V

WIRE H05V-K DK BLUE 1MM 100M; Jacket Material:PVC; Jacket Colour:Blue; Wire Gauge:-; Conductor Area CSA:1mm²; Reel Length (Imperial):328ft; Reel Length (Metric):100m; No. of Max Strands x Strand Size:32 x 0.2mm; Voltage Rating:300V; Conductor Material:Copper; External Diameter:2.6mm; Approval Specification:-; Product Range:H05V-K; SVHC:No SVHC (12-Jan-2017); Operating Temperature Max:+80°C; Operating Temperature Min:-40°C; Outer Diameter:2.6mm; RMS Load Voltage Max:500V; Test Voltage:2000V; Voltage Rating VAC:300V

WIRE H07V-K WHITE 1.5MM 100M; Jacket Material:PVC; Jacket Colour:White; Wire Gauge:16AWG; Conductor Area CSA:1.5mm²; Reel Length (Imperial):328ft; Reel Length (Metric):100m; No. of Max Strands x Strand Size:-; Voltage Rating:750V; Conductor Material:Copper; External Diameter:3.4mm; Approval Specification:-; Product Range:-; SVHC:No SVHC (12-Jan-2017); Operating Temperature Max:80°C; Operating Temperature Min:-30°C; Outer Diameter:3.4mm; Test Voltage:2500V

CABLE POWER UV 4CORE 1MM PER M; Jacket Colour:Black; No. of Cores:4Core; Wire Gauge:18AWG; Conductor Area CSA:1mm²; Reel Length (Imperial):-; Reel Length (Metric):-; No. of Max Strands x Strand Size:32 x 0.2mm; Voltage Rating:1kV; Jacket Material:PVC; Conductor Material:Copper; External Diameter:9.6mm; Product Range:UV Resistant Series; SVHC:No SVHC (12-Jan-2017); Bend Flexing Radius Min:15 x diameter; Cable Type:Unshielded; Conductor Make-up:32 / 0.2mm; Core-Earth / Core-Core Voltage Rating:600/1000V; Installed Bend Radius Min:6 x diameter; Operating Temperature Max:80°C; Operating Temperature Min:-30°C; Outer Diameter:9.6mm; Secondary Insulation Material:PVC

CABLE POWER UV 3CORE 1.5MM PER M; Jacket Colour:Black; No. of Cores:3Core; Wire Gauge:16AWG; Conductor Area CSA:1.5mm²; Reel Length (Imperial):-; Reel Length (Metric):-; No. of Max Strands x Strand Size:30 x 0.25mm; Voltage Rating:1kV; Jacket Material:PVC; Conductor Material:Copper; External Diameter:10.1mm; Product Range:UV Resistant Series; SVHC:No SVHC (12-Jan-2017); Bend Flexing Radius Min:15 x diameter; Cable Type:Unshielded; Conductor Make-up:30 / 0.25mm; Core-Earth / Core-Core Voltage Rating:600/1000V; Installed Bend Radius Min:6 x diameter; Operating Temperature Max:80°C; Operating Temperature Min:-30°C; Outer Diameter:10.1mm; Secondary Insulation Material:PVC

CABLE PROFIBUS 1PAIR 0.64MM PER M; Jacket Colour:Purple; No. of Pairs:1 Pair; Wire Gauge:22AWG; Conductor Area CSA:0.64mm²; Reel Length (Imperial):-; Reel Length (Metric):-; No. of Max Strands x Strand Size:Solid; Voltage Rating:250V; Jacket Material:PVC; Conductor Material:Copper; External Diameter:8mm; Product Range:-; SVHC:No SVHC (12-Jan-2017); Cable Type:Foil + Braided Shield; Conductor Make-up:1 / 0.64mm; Nominal Capacitance:30nF/km; Operating Temperature Max:80°C; Operating Temperature Min:-40°C; Outer Diameter:8mm; Secondary Insulation Colour:Violet; Secondary Insulation Material:PVC Flame Retardent; Velocity of Propagation (%):81%; Wire Size:22AWG

CABLE OLFLEX PU 3CORE 1MM 50M; Jacket Colour:Grey; No. of Cores:3Core; Wire Gauge:18AWG; Conductor Area CSA:1mm²; Reel Length (Imperial):164ft; Reel Length (Metric):50m; No. of Max Strands x Strand Size:32 x 0.2mm; Voltage Rating:500V; Jacket Material:PU; Conductor Material:Copper; External Diameter:6mm; Product Range:-; SVHC:No SVHC (12-Jan-2017); Cable Type:Unshielded; Conductor Make-up:32 / 0.2mm; Current Rating:15A; Operating Temperature Max:80°C; Operating Temperature Min:-40°C; Outer Diameter:6mm; Secondary Insulation Material:Polyurethane Compound TMPU

CABLE OLFLEX PU 7CORE 1MM 50M; Jacket Colour:Grey; No. of Cores:7Core; Wire Gauge:18AWG; Conductor Area CSA:1mm²; Reel Length (Imperial):164ft; Reel Length (Metric):50m; No. of Max Strands x Strand Size:32 x 0.2mm; Voltage Rating:500V; Jacket Material:PU; Conductor Material:Copper; External Diameter:8mm; Product Range:-; SVHC:No SVHC (12-Jan-2017); Cable Type:Unshielded; Conductor Make-up:32 / 0.2mm; Current Rating:15A; Operating Temperature Max:80°C; Operating Temperature Min:-40°C; Outer Diameter:8mm; Secondary Insulation Material:Polyurethane Compound TMPU

CABLE OLFLEX PU 4CORE 1.5MM 50M; Jacket Colour:Grey; No. of Cores:4Core; Wire Gauge:16AWG; Conductor Area CSA:1.5mm²; Reel Length (Imperial):164ft; Reel Length (Metric):50m; No. of Max Strands x Strand Size:30 x 0.25mm; Voltage Rating:500V; Jacket Material:PU; Conductor Material:Copper; External Diameter:7.2mm; Product Range:-; SVHC:No SVHC (12-Jan-2017); Cable Type:Unshielded; Conductor Make-up:30 / 0.25mm; Current Rating:18A; Operating Temperature Max:80°C; Operating Temperature Min:-40°C; Outer Diameter:7.2mm; Secondary Insulation Material:Polyurethane Compound TMPU

CABLE OLFLEX PU 4CORE 2.5MM PER M; Jacket Colour:Grey; No. of Cores:4Core; Wire Gauge:14AWG; Conductor Area CSA:2.5mm²; Reel Length (Imperial):-; Reel Length (Metric):-; No. of Max Strands x Strand Size:50 x 0.25mm; Voltage Rating:500V; Jacket Material:PU; Conductor Material:Copper; External Diameter:8.9mm; Product Range:Olflex PU Series; SVHC:No SVHC (12-Jan-2017); Cable Type:Unshielded; Conductor Make-up:50 / 0.25mm; Current Rating:26A; Operating Temperature Max:80°C; Operating Temperature Min:-40°C; Outer Diameter:8.9mm; Secondary Insulation Material:Polyurethane Compound TMPU

WIRE SILICONE BLUE 0.25MM 100M; Jacket Material:Silicone; Jacket Colour:Blue; Wire Gauge:24AWG; Conductor Area CSA:0.25mm²; Reel Length (Imperial):328ft; Reel Length (Metric):100m; No. of Max Strands x Strand Size:14 x 0.15mm; Voltage Rating:300V; Conductor Material:Copper; External Diameter:1.9mm; Approval Specification:-; Product Range:-; SVHC:No SVHC (12-Jan-2017); Conductor Make-up:14 / 0.15mm; Current Rating:4A; Operating Temperature Max:180°C; Operating Temperature Min:-50°C; Outer Diameter:1.9mm; Voltage Rating VAC:300V

WIRE SILICONE BROWN 0.25MM 100M; Jacket Material:Silicone; Jacket Colour:Brown; Wire Gauge:24AWG; Conductor Area CSA:0.25mm²; Reel Length (Imperial):328ft; Reel Length (Metric):100m; No. of Max Strands x Strand Size:14 x 0.15mm; Voltage Rating:300V; Conductor Material:Copper; External Diameter:1.9mm; Approval Specification:-; Product Range:-; SVHC:No SVHC (12-Jan-2017); Conductor Make-up:14 / 0.15mm; Current Rating:4A; Operating Temperature Max:180°C; Operating Temperature Min:-50°C; Outer Diameter:1.9mm; Voltage Rating VAC:300V

WIRE SILICONE PURPLE 0.25MM 100M; Jacket Material:Silicone; Jacket Colour:Purple; Wire Gauge:24AWG; Conductor Area CSA:0.25mm²; Reel Length (Imperial):328ft; Reel Length (Metric):100m; No. of Max Strands x Strand Size:14 x 0.15mm; Voltage Rating:300V; Conductor Material:Copper; External Diameter:1.9mm; Approval Specification:-; Product Range:-; SVHC:No SVHC (12-Jan-2017); Conductor Make-up:14 / 0.15mm; Current Rating:4A; Operating Temperature Max:180°C; Operating Temperature Min:-50°C; Outer Diameter:1.9mm; Voltage Rating VAC:300V

WIRE SILICONE WHITE 0.25MM 100M; Jacket Material:Silicone; Jacket Colour:White; Wire Gauge:24AWG; Conductor Area CSA:0.25mm²; Reel Length (Imperial):328ft; Reel Length (Metric):100m; No. of Max Strands x Strand Size:14 x 0.15mm; Voltage Rating:300V; Conductor Material:Copper; External Diameter:1.9mm; Approval Specification:-; Product Range:-; SVHC:No SVHC (12-Jan-2017); Conductor Make-up:14 / 0.15mm; Current Rating:4A; Operating Temperature Max:180°C; Operating Temperature Min:-50°C; Outer Diameter:1.9mm; Voltage Rating VAC:300V

WIRE SILICONE GREY 0.5MM 100M; Jacket Material:Silicone; Jacket Colour:Grey; Wire Gauge:21AWG; Conductor Area CSA:0.5mm²; Reel Length (Imperial):328ft; Reel Length (Metric):100m; No. of Max Strands x Strand Size:16 x 0.2mm; Voltage Rating:300V; Conductor Material:Copper; External Diameter:2.1mm; Approval Specification:-; Product Range:-; SVHC:No SVHC (12-Jan-2017); Conductor Make-up:16 / 0.2mm; Current Rating:9A; Operating Temperature Max:180°C; Operating Temperature Min:-50°C; Outer Diameter:2.1mm; Voltage Rating VAC:300V

WIRE SILICONE BLUE 0.75MM 100M; Jacket Material:Silicone; Jacket Colour:Blue; Wire Gauge:19AWG; Conductor Area CSA:0.75mm²; Reel Length (Imperial):328ft; Reel Length (Metric):100m; No. of Max Strands x Strand Size:24 x 0.2mm; Voltage Rating:300V; Conductor Material:Copper; External Diameter:2.4mm; Approval Specification:-; Product Range:-; SVHC:No SVHC (12-Jan-2017); Conductor Make-up:24 / 0.2mm; Current Rating:12A; Operating Temperature Max:180°C; Operating Temperature Min:-50°C; Outer Diameter:2.4mm; Voltage Rating VAC:300V
