CRYSTAL FREQUENCY 25MHZ; Frequency Nom:25MHz; Crystal Case:SMD 11.4mm x 4.9mm; Frequency Stability + / -:50ppm; Load Capacitance:16pF; Frequency Tolerance + / -:30ppm; Product Range:HC-49/4HSMX Series; Operating Temperature Min:-10°C; Operating Temperature Max:60°C; SVHC:No SVHC (12-Jan-2017); Accuracy:± 30ppm; Crystal Mounting Type:SMD; Frequency:25MHz; Frequency Stability:± 50ppm; No. of Pins:2Pins; Operating Temperature Range:-30°C to +80°C; Output Frequency:25MHz

CRYSTAL 3.6864MHZ 16PF HC-49S; Frequency Nom:3.6864MHz; Crystal Case:SMD 11.4mm x 4.9mm; Frequency Stability + / -:50ppm; Load Capacitance:16pF; Frequency Tolerance + / -:30ppm; Product Range:HC-49/4HSMX Series; ESR:200ohm ;RoHS Compliant: Yes

CRYSTAL 12MHZ 16PF HC-49S; Frequency Nom:12MHz; Crystal Case:SMD 11.4mm x 4.9mm; Frequency Stability + / -:50ppm; Load Capacitance:16pF; Frequency Tolerance + / -:30ppm; Product Range:HC-49/4HSMX Series; Crystal Mounting Type:SMD;RoHS Compliant: Yes

CRYSTAL 16MHZ 16PF 13 X 5MM; Frequency Nom:16MHz; Crystal Case:SMD 13mm x 5mm; Frequency Stability + / -:50ppm; Load Capacitance:16pF; Frequency Tolerance + / -:100ppm; Product Range:86SMX Series; Operating Temperature Min:-20 C ;RoHS Compliant: Yes

HCMOS 50ppm 0 to 70C 3.3V

HCMOS 50ppm 0 to 70C 3.3V

CMOS 50ppm -40 to 85C 3.3V

3.2 x 2.5 mm 50 MHz 3.3 V ?50 ppm -40 to +85?C SMT Crystal Clock Oscillator

20/-/-/12.5

30/50/-10 to 60C/16 FUND

HC49 Series 11.0592 MHz 16 pF ?30 ppm -10 to +60?C Quartz Crystal Unit

0.032768MHz ?20ppm (Tol) 12.5pF FUND 80000Ohm 2-Pin Crystal

CRYSTAL QUARTZ SMD 32.768KHZ; Frequency Nom:32.768kHz; Crystal Case:Cylinder Radial 6mm x 2mm Dia; Frequency Stability + / -:-; Load Capacitance:12.5pF; Frequency Tolerance + / -:20ppm; Product Range:CFPX-56 Series; Operating ;RoHS Compliant: Yes

CRYSTAL 12SMX (B) 8.0MHZ 16PF SMD; Frequency Nom:8MHz; Crystal Case:SMD 7mm x 5mm; Frequency Stability + / -:50ppm; Load Capacitance:16pF; Frequency Tolerance + / -:30ppm; Product Range:12SMX Series; Operating Temperature Min:-20°C; Operating Temperature Max:70°C; SVHC:No SVHC (12-Jan-2017)

CRYSTAL 20.00MHZ 16PF SMD; Frequency Nom:20MHz; Crystal Case:SMD 11.4mm x 4.9mm; Frequency Stability + / -:50ppm; Load Capacitance:16pF; Frequency Tolerance + / -:30ppm; Product Range:-; Operating Temperature Min:-10°C; Operating Temperature Max:60°C; SVHC:No SVHC (12-Jan-2017); Crystal Mounting Type:SMD; Frequency:20MHz; Frequency Stability:± 50ppm; No. of Pins:2Pins

OSC CFPS-9 50M SMD 5X3.2; Frequency Nom:50MHz; Frequency Stability + / -:50ppm; Oscillator Case:SMD 5mm x 3.2mm; Supply Voltage Nom:3.3V; Product Range:CFPS-9 Series; Operating Temperature Min:-40°C; Operating Temperature Max:85°C; Oscillator Output Compatibility:CMOS; SVHC:No SVHC (12-Jan-2017); Crystal Case:CFPS-9; Duty Cycle Lower Limit:45%; Duty Cycle Upper Limit:55%; Fall Time tf:6ns; Frequency:50MHz; Frequency Stability:± 50ppm; Load Capacitance:15pF; No. of Pins:4Pins; Operating Temperature Range:-40°C to +85°C; Output Frequency:50MHz; Resonator Case:SMD; Rise Time:6ns; Temperature Stability + @:50ppm; Temperature Stability - @:50ppm; Type:SPXO

OSC CFPS-107 32.768K SMD 2.6 X 2.1 1; Frequency Nom:32.768kHz; Frequency Stability + / -:50ppm; Oscillator Case:SMD 2.5mm x 2mm; Supply Voltage Nom:1.8V; Product Range:CFPS-107 Series; Operating Temperature Min:-40°C; Operating Temperature Max:85°C; Oscillator Output Compatibility:CMOS; SVHC:No SVHC (12-Jan-2017); Crystal Case:CFPS-107; Duty Cycle Lower Limit:40%; Duty Cycle Upper Limit:60%; Fall Time tf:50ns; Frequency:32.768kHz; Frequency Stability:± 50ppm; Load Capacitance:15pF; No. of Pins:4Pins; Operating Temperature Range:0°C to +70°C; Output Frequency:32.768kHz; Resonator Case:SMD; Rise Time:50ns; Supply Current Max:1.5mA; Temperature Stability + @:50ppm; Temperature Stability - @:50ppm; Type:SPXO

OSC CFPS-108 32.768K SMD 2.6 X 2.1 2; Frequency Nom:32.768kHz; Frequency Stability + / -:50ppm; Oscillator Case:SMD 2.5mm x 2mm; Supply Voltage Nom:2.5V; Product Range:CFPS-108 Series; Operating Temperature Min:-40°C; Operating Temperature Max:85°C; Oscillator Output Compatibility:CMOS; SVHC:No SVHC (12-Jan-2017); Crystal Case:CFPS-108; Duty Cycle Lower Limit:40%; Duty Cycle Upper Limit:60%; Fall Time tf:50ns; Frequency:32.768kHz; Frequency Stability:± 50ppm; Load Capacitance:15pF; No. of Pins:4Pins; Operating Temperature Range:0°C to +70°C; Output Frequency:32.768kHz; Resonator Case:SMD; Rise Time:50ns; Supply Current Max:2.5mA; Temperature Stability + @:50ppm; Temperature Stability - @:50ppm; Type:SPXO

Standard Clock Oscillators 32.0MHz 3.2 x 2.5 x 1.2mm

CRYSTAL 6MHZ 16PF HC49; Frequency Nom:6MHz; Crystal Case:SMD 11.4mm x 4.9mm; Frequency Stability + / -:50ppm; Load Capacitance:16pF; Frequency Tolerance + / -:20ppm; Product Range:HC-49/4HSMX Series; Operating Temperature Min:-10°C; Operating Temperature Max:60°C; SVHC:No SVHC (12-Jan-2017); Crystal Mounting Type:SMD; Frequency:6MHz; Frequency Stability:± 50ppm; No. of Pins:2Pins
