Low Signal Relays - PCB SIGNAL

REWORK OF P/N FTP-68EMCL161-R

Automotive Relays AUTO

Automotive Relays AUTO

Automotive Relays AUTO

Power Relay

Fujitsu

Fujitsu

Power Relay

Automotive Relays AUTO

Low Signal Relays - PCB SIGNAL

MCU 16BIT F2MC 56MHZ QFP-100; Controller Family/Series:F2MC-16FX; CPU Speed:56MHz; Program Memory Size:544KB; RAM Memory Size:24KB; No. of Pins:100Pins; MCU Case Style:QFP; No. of I/O's:82I/O's; Embedded Interface Type:CAN I2C USART; Supply Voltage Min:3V; Supply Voltage Max:5.5V; Packaging:Each; Product Range:16FX Proprietary Microcontrollers; Automotive Qualification Standard:-; MSL:-; Flash Memory Size:544KB; Logic Function Number:96F348; MPU Core Size:16bit; No. of ADC Inputs:24; No. of PWM Channels:16; No. of Timers:7; Operating Temperature Max:125°C; Operating Temperature Min:-40°C; Operating Temperature Range:-40°C to +125°C; Oscillator Type:External Internal; Peripherals:ADC DMA Timer; Program Memory Size:544KB; Supply Voltage Range:3V to 5.5V; Termination Type:Surface Mount Device

SOCKET IDC 16WAY; Pitch Spacing:2.54mm; No. of Contacts:16Contacts; Gender:Receptacle; Product Range:-; Contact Termination Type:IDC / IDT; No. of Rows:2Rows; Contact Plating:Gold Plated Contacts; Contact Material:Copper; Approval Bodies:CSA UL; Colour:Black; Connector Mounting Orientation:PC Board; Contact Resistance:20mohm; Contact Termination:IDC / IDT; Current Rating:1A; Dielectric Strength VAC:500V; External Width:24.9mm; Flammability Rating:UL94V-0; IDC Cable Pitch:0.05"; Insulation Resistance:1000Mohm; Lead Spacing:2.54mm; Material:PBT and Polycarbonate; No. of Mating Cycles:500; Operating Temperature Max:105°C; Operating Temperature Min:-55°C; PCB Hole Diameter:0.8mm; Polarisation Type:Bump/Clip; Row Pitch:2.54mm; Termination Method:IDC; Voltage Rating VAC:250V; Wire Size AWG Max:28AWG; Wire Size AWG Min:30AWG; Withstand Voltage:500V

HEADER MINI 10WAY; Pitch Spacing:2.54mm; No. of Contacts:10Contacts; Gender:Header; Product Range:-; Contact Termination Type:Through Hole; No. of Rows:2Rows; Contact Plating:Gold Plated Contacts; Contact Material:Copper Alloy; Approval Bodies:CSA UL; Connector Mounting Orientation:PCB; Contact Resistance:20mohm; Contact Termination:Through Hole Vertical; Current Rating:1A; Cut Thickness for PCBs Max:1.6mm; Dielectric Strength VAC:500V; External Width:20.12mm; Flammability Rating:UL94V-0; Insulation Resistance:1000Mohm; No. of Mating Cycles:500; Operating Temperature Max:105°C; Operating Temperature Min:-55°C; PCB Hole Diameter:0.8mm; Polarisation Type:Bump/Clip; Termination Method:Solder; Voltage Rating VAC:250V; Wire Size AWG Max:28AWG; Wire Size AWG Min:30AWG; Withstand Voltage:500V; Working Voltage:250V

HEADER MINI 16WAY; Pitch Spacing:2.54mm; No. of Contacts:16Contacts; Gender:Header; Product Range:-; Contact Termination Type:Through Hole; No. of Rows:2Rows; Contact Plating:Gold Plated Contacts; Contact Material:Copper; Approval Bodies:CSA UL; Connector Mounting Orientation:PCB; Contact Resistance:20mohm; Contact Termination:Through Hole Vertical; Current Rating:1A; Cut Thickness for PCBs Max:1.6mm; Dielectric Strength VAC:500V; External Width:27.74mm; Flammability Rating:UL94V-0; Insulation Resistance:1000Mohm; Lead Spacing:1.27mm; No. of Mating Cycles:500; Operating Temperature Max:105°C; Operating Temperature Min:-55°C; PCB Hole Diameter:0.8mm; Polarisation Type:Bump/Clip; Termination Method:Solder; Voltage Rating VAC:250V; Wire Size AWG Max:28AWG; Wire Size AWG Min:30AWG; Withstand Voltage:500V; Working Voltage:250V

HEADER IDC 26WAY; Pitch Spacing:1.27mm; No. of Contacts:26Contacts; Gender:Header; Product Range:700 Series; Contact Termination Type:IDC / IDT; No. of Rows:2Rows; Contact Plating:Gold Plated Contacts; Contact Material:Phosphor Bronze; Approval Bodies:CSA UL; Connector Mounting Orientation:PC Board; Contact Resistance:20mohm; Contact Termination:IDC / IDT; Current Rating:1A; Cut Thickness for PCBs Max:1.6mm; Dielectric Strength VAC:500V; Fixing Centres:50.8mm; Flammability Rating:UL94V-0; Insulation Resistance:1000Mohm; No. of Mating Cycles:500; Operating Temperature Max:105°C; Operating Temperature Min:-55°C; PCB Hole Diameter:0.8mm; Polarisation Type:Bump/Clip; Voltage Rating VAC:250V; Wire Size AWG Max:28AWG; Wire Size AWG Min:30AWG; Withstand Voltage:500V

POLARISING CLIP; Accessory Type:Polarising Key; For Use With:700 Series Connectors; Product Range:-

CONNECTOR IDC TRANSITION DIP 10WAY; Pitch Spacing:2.54mm; No. of Contacts:10Contacts; Gender:Header; Product Range:-; Contact Termination Type:IDC / IDT; No. of Rows:2Rows; Contact Plating:Gold Plated Contacts; Contact Material:Copper; Connector Mounting Orientation:PC Board; Contact Current Rating:1A; Contact Resistance:20mohm; Contact Termination:IDC / IDT; Current Rating:1A; Cut Thickness for PCBs Max:1.6mm; Dielectric Strength VAC:500V; External Length / Height:7mm; External Width:19.2mm; Insulation Resistance:1000Mohm; Lead Spacing:2.54mm; No. of Mating Cycles:500; Operating Temperature Max:105°C; Operating Temperature Min:-55°C; PCB Hole Diameter:0.8mm; Termination Method:IDC; Voltage Rating VAC:250V; Wire Size AWG Max:28AWG; Wire Size AWG Min:30AWG; Withstand Voltage:500V

32-bit Microcontroller RR FR81S

32-bit Microcontroller RR FR81S
