CAP FILM PP 1UF 1.25KV SOLDER; Capacitance:1µF; Voltage Rating V DC:1.25kV; Capacitor Dielectric Type:PP (Polypropylene); Capacitance Tolerance:± 5%; Product Range:B32656S Series; Capacitor Case Style:-; Capacitor Terminals:Solder Lug; Lead Spacing:37.5mm; Operating Temperature Min:-55°C; Operating Temperature Max:100°C; Packaging:Each; Automotive Qualification Standard:-; SVHC:No SVHC (15-Jun-2015); Capacitance Tolerance ±:± 5%; Capacitor Mounting:Through Hole; Climatic Category:55/100/56; Dissipation Factor:0.5%; Dissipation Factor Frequency:1kHz; Dissipation Factor Temperature:25°C; External Depth:28mm; External Length / Height:37mm; External Width:42mm; Flammability Rating:UL94V-0; Height:37mm; No. of Pins:2Pins; Operating Temperature Range:-55°C to +100°C; Operating life Time:200000h; Rate of Voltage Change dv / dt:140V/µs; Tolerance +:5%; Tolerance -:5%; Voltage Rating:1.25kV; Voltage Rating VAC:500V

CAP FILM PP 1UF 560V RAD; Capacitance:1µF; Suppression Class:X2; Voltage Rating X:305V; Voltage Rating Y:-; Capacitor Dielectric Type:PP (Polypropylene); Capacitance Tolerance:± 20%; Product Range:B32924A Series; dv/dt Rating:120V/µs; Capacitor Case Style:-; Capacitor Terminals:Radial Leaded; Operating Temperature Min:-; Operating Temperature Max:110°C; Packaging:Each; Automotive Qualification Standard:-; SVHC:No SVHC (15-Jun-2015); Capacitor Application:Safety / Suppression; Climatic Category:40/100/21; External Depth:12.5mm; External Length / Height:21.5mm; External Width:31.5mm; Flammability Rating:UL94V-0; Height:21.5mm; Lead Diameter:0.8mm; Lead Length:6mm; Lead Spacing:27.5mm; Operating Temperature Range:-40°C to +125°C; Voltage Rating VAC:305V

VARISTOR 3225 4.2J 130VAC; Voltage Rating V AC:130V; Voltage Rating V DC:170V; Product Range:-; Clamping Voltage Vc Max:340V; Varistor Case Style:3225; Varistor Type:Metal Oxide Varistor (MOV); Peak Surge Current @ 8/20µs:400A; Operating Temperature Min:-40°C; Operating Temperature Max:85°C; Peak Energy (10/1000uS):4.2J; Automotive Qualification Standard:-; SVHC:No SVHC (15-Jun-2015); Capacitance:100pF; Clamping Voltage:340V; Clamping Voltage @ 8/20µs Max:340V; MSL:MSL 2A - 4 weeks; Operating Temperature Range:-40°C to +85°C; Packaging:Cut Tape; Peak Pulse Current IPP @ 8/20µs:400A; Suppressor Type:Varistor; Surge Current:400A; Transient Energy:4.2J; Varistor Voltage:205V; Varistor Voltage @ 1mA:194.5V; Varistor Voltage @ 1mA Max:225.5V; Varistor Voltage Tolerance +:10%; Varistor Voltage Tolerance -:10%

THERMISTOR NTC 15K RADIAL LEADED; Zero Power Resistance at 25 C:15kohm; Product Range:B57164K Series; Beta Value (K):4250K; Thermistor Mounting:Through Hole; Thermistor Case Style:-; Thermistor Terminals:Radial Leaded; Operating ;RoHS Compliant: Yes

THERMISTOR NTC 3.3K RADIAL LEADED; Zero Power Resistance at 25°C:3.3kohm; Product Range:B57164K Series; Beta Value (K):3950K; Thermistor Mounting:Through Hole; Thermistor Case Style:-; Thermistor Terminals:Radial Leaded; Operating Temperature Min:-55°C; Operating Temperature Max:125°C; Automotive Qualification Standard:-; SVHC:No SVHC (20-Jun-2016); MSL:MSL 1 - Unlimited

THERMISTOR NTC 22K RADIAL LEADED; Zero Power Resistance at 25 C:22kohm; Product Range:B57891M Series; Beta Value (K):4300K; Thermistor Mounting:Through Hole; Thermistor Case Style:-; Thermistor Terminals:Radial Leaded; Operating ;RoHS Compliant: Yes

TRANSFORMER COIL FORMER P22 X 13; For Use With:P22 x 13 Type B65661 Series Ferrite Cores; Product Range:B65662 Series; SVHC:No SVHC (20-Jun-2016); MSL:MSL 1 - Unlimited ;RoHS Compliant: Yes

TRANSFORMER COIL FORMER RM6 6-PIN; For Use With:RM6 Type B65807 Series Ferrite Cores; Product Range:B65808 Series; SVHC:No SVHC (20-Jun-2016); MSL:MSL 1 - Unlimited ;RoHS Compliant: Yes

COIL FORMER E13 Valox 420SE0 STICK IN STYRENE BOARD

TRANSFORMER COIL FORMER E20/10 12PIN; For Use With:E 20/10/6 Type B66311 Series Ferrite Cores; Product Range:B66206 Series; SVHC:No SVHC (20-Jun-2016); MSL:MSL 1 - Unlimited ;RoHS Compliant: Yes

TRANSFORMER COIL FORMER E 16/8/5 8PIN; For Use With:E 16/8/5 Type B66307 Series Ferrite Cores; Product Range:B66308 Series; SVHC:No SVHC (20-Jun-2016); MSL:MSL 1 - Unlimited ;RoHS Compliant: Yes

INDUCTOR SMD 1UH 250MA 5% 350MHZ FULL REEL; Product Range:EPCOS - B82498B Series; Inductance:1µH; Inductance Tolerance:± 5%; High Frequency Inductor Case:0805 [2012 Metric]; Self Resonant Frequency Min:350MHz; No. of Pins:2 ;RoHS Compliant: Yes

INDUCTOR 100UH 1.8A +20% FULL REEL; Product Range:B82479A1 Series; Inductance:100 H; Inductance Tolerance: 20%; Inductor Construction:Wirewound; DC Resistance Max:0.19ohm; RMS Current (Irms):1.8A; Saturation Current (Isat):3A

SMT Power Inductors Size 18.54 x 15.24 x 7.11 (mm)

SMT Power Inductors Size 18.54 x 15.24 x 7.11 (mm)

SMT Power Inductors Size 18.54 x 15.24 x 7.11 (mm)

INDUCTOR 22UH 3500MA; Product Range:-; Inductance:22µH; RMS Current (Irms):3.5A; Saturation Current (Isat):7A; Inductor Construction:Wirewound; DC Resistance Max:0.047ohm; Power Inductor Case:18.54mm x 15.24mm x 7.11mm; Inductance Tolerance:± 20%; Packaging:Cut Tape; SVHC:No SVHC (15-Jun-2015); Climatic Category:40/85/56; Inductance Measurement Frequency:100kHz; Inductor Type:Power Inductor; No. of Pins:2Pins; Resonant Frequency:20MHz; Termination Type:Surface Mount Device; Tolerance +:20%

INDUCTOR 220UH 1200MA 20% FULL REEL; Product Range:-; Inductance:220µH; RMS Current (Irms):1.2A; Saturation Current (Isat):2.4A; Inductor Construction:Unshielded; DC Resistance Max:0.38ohm; Power Inductor Case:18.54mm x 15.24mm x 7.11mm; Inductance Tolerance:± 20%; Packaging:Tape & Reel; SVHC:No SVHC (15-Jun-2015); Core Material:Ferrite; DC Current Rating:1.2A; Inductor Case Style:SMD; Reel Quantity:250

INDUCTOR 330UH 1000MA 20% FULL REEL; Product Range:-; Inductance:330µH; RMS Current (Irms):1A; Saturation Current (Isat):1.9A; Inductor Construction:Unshielded; DC Resistance Max:0.56ohm; Power Inductor Case:18.54mm x 15.24mm x 7.11mm; Inductance Tolerance:± 20%; Packaging:Tape & Reel; SVHC:No SVHC (15-Jun-2015); Core Material:Ferrite; DC Current Rating:1A; Inductor Case Style:SMD; Reel Quantity:250

SMT Power Inductors Size 18.5 x 15.24 x 7.25(mm)
