INDUCTOR POWER 1UH 3A 20%; Product Range:-; Inductance:1µH; RMS Current (Irms):3A; Saturation Current (Isat):5.1A; Inductor Construction:Unshielded; DC Resistance Max:5.1ohm; Power Inductor Case:6mm x 6mm x 2.5mm; Inductance Tolerance:± 20%; Packaging:Cut Tape; SVHC:No SVHC (15-Jun-2015); Inductance Measurement Frequency:0.1MHz; Inductor Type:Power; No. of Pins:2Pins

INDUCTOR POWER 3.3UH 2A 20%; Product Range:-; Inductance:3.3µH; RMS Current (Irms):2A; Saturation Current (Isat):2.05A; Inductor Construction:Shielded; DC Resistance Max:0.04ohm; Power Inductor Case:6.3mm x 6.3mm x 2.5mm; Inductance Tolerance:± 20%; Packaging:Cut Tape; SVHC:No SVHC (15-Jun-2015); Inductance Measurement Frequency:0.1MHz; Inductor Type:Power; No. of Pins:2Pins

INDUCTOR POWER 330UH 0.2A 20%; Product Range:-; Inductance:330µH; RMS Current (Irms):220mA; Saturation Current (Isat):200mA; Inductor Construction:Shielded; DC Resistance Max:3.25ohm; Power Inductor Case:6.3mm x 6.3mm x 2.5mm; Inductance Tolerance:± 20%; Packaging:Cut Tape; SVHC:No SVHC (15-Jun-2015); Inductance Measurement Frequency:0.1MHz; Inductor Type:Power; No. of Pins:2Pins

INDUCTOR POWER 6.8UH 1.45A 20%; Product Range:-; Inductance:6.8µH; RMS Current (Irms):1.45A; Saturation Current (Isat):1.48A; Inductor Construction:Shielded; DC Resistance Max:0.078ohm; Power Inductor Case:6.3mm x 6.3mm x 2.5mm; Inductance Tolerance:± 20%; Packaging:Cut Tape; SVHC:No SVHC (15-Jun-2015); Inductance Measurement Frequency:0.1MHz; Inductor Type:Power; No. of Pins:2Pins

INDUCTOR POWER 3.3UH 5.4A 20%; Product Range:-; Inductance:3.3µH; RMS Current (Irms):5.4A; Saturation Current (Isat):6.4A; Inductor Construction:Wirewound; DC Resistance Max:0.0135ohm; Power Inductor Case:12.95mm x 9.4mm x 5.08mm; Inductance Tolerance:± 20%; Packaging:Cut Tape; SVHC:No SVHC (15-Jun-2015); Inductor Type:Power; No. of Pins:2Pins

INDUCTOR POWER 1000UH 1.3A 20%; Product Range:-; Inductance:1mH; RMS Current (Irms):400mA; Saturation Current (Isat):-; Inductor Construction:Shielded; DC Resistance Max:1.53ohm; Power Inductor Case:12.3mm x 12.3mm x 6mm; Inductance Tolerance:± 20%; Packaging:Cut Tape; SVHC:No SVHC (15-Jun-2015); Inductor Type:Power; No. of Pins:2Pins

INDUCTOR 0805 5600NH 5%; Product Range:-; Inductance:5.6µH; DC Current Rating:85mA; High Frequency Inductor Case:0805 [2012 Metric]; Inductor Construction:Wirewound; DC Resistance Max:4.3ohm; Inductance Tolerance:± 5%; Self Resonant Frequency Min:180MHz; Packaging:Cut Tape; SVHC:No SVHC (15-Jun-2015); Inductor Case Style:0805 [2012 Metric]

INDUCTOR 0805 5.6NH 5%; Product Range:-; Inductance:5.6nH; DC Current Rating:900mA; High Frequency Inductor Case:0805 [2012 Metric]; Inductor Construction:Wirewound; DC Resistance Max:0.04ohm; Inductance Tolerance:± 10%; Self Resonant Frequency Min:7GHz; Packaging:Cut Tape; SVHC:No SVHC (15-Jun-2015); Inductor Case Style:0805 [2012 Metric]

INDUCTOR 0805 82NH 5% ;ROHS COMPLIANT: YES

VARISTOR 2220 11V; Voltage Rating VAC:11V; Voltage Rating V DC:14V; Product Range:-; Clamping Voltage Vc Max:33V; Varistor Case Style:2220 [5650 Metric]; Varistor Type:Multilayer Varistor (MLV); Peak Surge Current @ 8/20µs:1.2kA; Operating Temperature Min:-55°C; Operating Temperature Max:125°C; Peak Energy (10/1000uS):5.4J; Automotive Qualification Standard:-; SVHC:No SVHC (15-Jun-2015); Capacitance:0.012µF; Clamping Voltage:33V; Clamping Voltage @ 8/20µs Max:33V; Operating Temperature Range:-55°C to +125°C; Peak Pulse Current IPP @ 8/20µs:1200A; Suppressor Type:Varistor; Surge Current:1.2kA; Transient Energy:5.4J; Varistor Voltage @ 1mA Max:18V; Varistor Voltage Tolerance +:10%

THERMISTOR NTC 2K2 0805; Zero Power Resistance at 25°C:2.2kohm; Product Range:B57421V2 Series; Beta Value (K):4000K; Thermistor Mounting:SMD; Thermistor Case Style:0805 [2012 Metric]; Thermistor Terminals:-; Operating Temperature Min:-55°C; Operating Temperature Max:125°C; Automotive Qualification Standard:-; SVHC:No SVHC (15-Jun-2015); Beta Value Lower Limit Temperature:25°C; Operating Temperature Range:-55°C to +125°C; Power Dissipation Ptot Max:210mW; Resistance:2.2kohm; Resistance Tolerance:± 5%; Temperature Upper Limit Beta Value:100°C; Thermistor Tolerance:-5% to +5%; Thermistor Type:NTC

THERMISTOR NTC 10K 0805; Zero Power Resistance at 25°C:10kohm; Product Range:B57471V2 Series; Beta Value (K):4480K; Thermistor Mounting:SMD; Thermistor Case Style:0805 [2012 Metric]; Thermistor Terminals:-; Operating Temperature Min:-55°C; Operating Temperature Max:125°C; Automotive Qualification Standard:-; SVHC:No SVHC (15-Jun-2015); Beta Value Lower Limit Temperature:25°C; Operating Temperature Range:-55°C to +125°C; Power Dissipation Ptot Max:210mW; Resistance:10kohm; Resistance Tolerance:± 5%; Temperature Upper Limit Beta Value:100°C; Thermistor Tolerance:-5% to +5%; Thermistor Type:NTC

THERMISTOR NTC 1K 1206; Zero Power Resistance at 25°C:1kohm; Product Range:B57621C5 Series; Beta Value (K):3450K; Thermistor Mounting:SMD; Thermistor Case Style:1206 [3216 Metric]; Thermistor Terminals:-; Operating Temperature Min:-55°C; Operating Temperature Max:125°C; Automotive Qualification Standard:-; SVHC:No SVHC (15-Jun-2015); Beta Value Lower Limit Temperature:25°C; Operating Temperature Range:-55°C to +125°C; Power Dissipation Ptot Max:300mW; Resistance:1kohm; Resistance Tolerance:± 5%; Temperature Upper Limit Beta Value:100°C; Thermistor Tolerance:-5% to +5%; Thermistor Type:NTC

THERMISTOR NTC 4R7 3A; Product Range:B57153S0 Series; Disc Size:8.5mm; Zero Power Resistance at 25°C:4.7ohm; Approvals:UL; Maximum Energy Rating at 25°C:-; Maximum Steady State Current at 25°C:3A; SVHC:No SVHC (15-Jun-2015); Beta Value (K):2800K; Beta Value Lower Limit Temperature:25°C; Body Diameter:8.5mm; Current Max:3A; Lead Length:25mm; Lead Spacing:5mm; No. of Pins:2Pins; Operating Temperature Max:170°C; Operating Temperature Min:-55°C; Operating Temperature Range:-55°C to +170°C; Operating Voltage:265V; Power Dissipation Ptot Max:1.4W; Resistance:4.7ohm; Resistance Tolerance:± 20%; Temperature Upper Limit Beta Value:100°C; Thermistor Case Style:Radial Leaded; Thermistor Tolerance:-20% to +20%; Thermistor Type:NTC

THERMISTOR NTC 2R5 5.5A; Product Range:B57236S0 Series; Disc Size:11.5mm; Zero Power Resistance at 25°C:2.5ohm; Approvals:UL; Maximum Energy Rating at 25°C:-; Maximum Steady State Current at 25°C:5.5A; SVHC:No SVHC (15-Jun-2015); Beta Value (K):2700K; Beta Value Lower Limit Temperature:25°C; Body Diameter:11.5mm; Current Max:5.5A; Lead Length:25mm; Lead Spacing:5mm; No. of Pins:2Pins; Operating Temperature Max:170°C; Operating Temperature Min:-55°C; Operating Temperature Range:-55°C to +170°C; Operating Voltage:265V; Power Dissipation Ptot Max:2.1W; Resistance:2.5ohm; Resistance Tolerance:± 20%; Temperature Upper Limit Beta Value:100°C; Thermistor Case Style:Radial Leaded; Thermistor Tolerance:-20% to +20%; Thermistor Type:NTC

B573xxV2 Series 0603 10 kO ?5% 3980K Surface Mount NTC Thermistor

CAPACITOR POLYESTER FILM 0.015UF 63V 5; CAPACITOR POLYESTER FILM 0.015UF 63V 5% RADIAL; Capacitance:0.015 F; Capacitor Dielectric Type:PET (Polyester); Voltage Rating:63V; Product Range:B32529 Series; Capacitance Tolerance: 5%; Capacitor Terminals:Radial Leaded

CAPACITOR POLYESTER FILM 2200PF 63V 5; CAPACITOR POLYESTER FILM 2200PF 63V 5% RADIAL; Capacitance:2200pF; Capacitor Dielectric Type:PET (Polyester); Voltage Rating:63V; Product Range:B32529 Series; Capacitance Tolerance: 5%; Capacitor Terminals:Radial Leaded

Film Capacitors 0.1uF 450volts 5%

NTC THERMISTOR; Zero Power Resistance at 25 C:10kohm; Product Range:B57703M Series; Beta Value (K):3988K; Thermistor Mounting:Through Hole; Thermistor Case Style:-; Thermistor Terminals:Wire Leaded; Operating Temperature Min:-55 C
