SMT Inductors SIMID Series, SIMID 1210-H100

SMT Inductors SIMID Series, SIMID 1210-H100

INDUCTOR POWER 10UH 2.3A 10% SMD; Product Range:B82473M1 Series; Inductance:10µH; RMS Current (Irms):2.3A; Saturation Current (Isat):2.5A; Inductor Construction:Wirewound; DC Resistance Max:0.07ohm; Power Inductor Case:8.3mm x 7.3mm x 5.5mm; Inductance Tolerance:± 10%; Packaging:Cut Tape; SVHC:No SVHC (15-Jun-2015)

INDUCTOR POWER 22UH 1.5A 10% SMD; Product Range:B82473M1 Series; Inductance:22µH; RMS Current (Irms):1.5A; Saturation Current (Isat):1.6A; Inductor Construction:Wirewound; DC Resistance Max:0.11ohm; Power Inductor Case:8.3mm x 7.3mm x 5.5mm; Inductance Tolerance:± 10%; Packaging:Cut Tape; SVHC:No SVHC (15-Jun-2015)

INDUCTOR POWER 68UH 850MA 10% SMD; Product Range:B82473M1 Series; Inductance:68µH; RMS Current (Irms):850mA; Saturation Current (Isat):900mA; Inductor Construction:Wirewound; DC Resistance Max:0.28ohm; Power Inductor Case:8.3mm x 7.3mm x 5.5mm; Inductance Tolerance:± 10%; Packaging:Cut Tape; SVHC:No SVHC (15-Jun-2015)

INDUCTOR POWER 470UH 340MA 10% SMD; Product Range:-; Inductance:470µH; RMS Current (Irms):340mA; Saturation Current (Isat):400mA; Inductor Construction:Wirewound; DC Resistance Max:1.96ohm; Power Inductor Case:8.3mm x 7.3mm x 5.5mm; Inductance Tolerance:± 10%; Packaging:Cut Tape; SVHC:No SVHC (15-Jun-2015)

SMT Power Inductors - Size 10.4 x 10.0 x 5.8 (mm)

INDUCTOR POWER 330UH 520MA 10% SMD; Product Range:B82475M1 Series; Inductance:330µH; RMS Current (Irms):520mA; Saturation Current (Isat):550mA; Inductor Construction:Wirewound; DC Resistance Max:1.15ohm; Power Inductor Case:10.4mm x 10mm x 5.8mm; Inductance Tolerance:± 10%; Packaging:Cut Tape; SVHC:No SVHC (15-Jun-2015)

INDUCTOR POWER +/-20% 4.3A 10UH; Product Range:B82477P2 Series; Inductance:10µH; RMS Current (Irms):4.3A; Saturation Current (Isat):4A; Inductor Construction:Shielded; DC Resistance Max:0.025ohm; Power Inductor Case:12.5mm x 12.5mm x 6mm; Inductance Tolerance:± 20%; Packaging:Each; SVHC:No SVHC (15-Jun-2015); External Depth:6mm; External Length / Height:12.5mm; External Width:12.5mm; Height:12.5mm

INDUCTOR POWER +/-20% 2.4A 47UH; Product Range:-; Inductance:47µH; RMS Current (Irms):2.4A; Saturation Current (Isat):1.9A; Inductor Construction:Shielded; DC Resistance Max:0.07ohm; Power Inductor Case:12.5mm x 12.5mm x 6mm; Inductance Tolerance:± 20%; Packaging:Each; SVHC:No SVHC (15-Jun-2015); External Depth:6mm; External Length / Height:12.5mm; External Width:12.5mm

INDUCTOR POWER 2.0UH 18A 20%; Product Range:B82477R4 Series; Inductance:2µH; RMS Current (Irms):8.9A; Saturation Current (Isat):24A; Inductor Construction:Shielded; DC Resistance Max:8000µohm; Power Inductor Case:12.5mm x 12.5mm x 8.5mm; Inductance Tolerance:± 20%; Packaging:Cut Tape; SVHC:No SVHC (15-Jun-2015)

INDUCTOR POWER 3.0UH 15.5A 20%; Product Range:B82477R4 Series; Inductance:3µH; RMS Current (Irms):8.25A; Saturation Current (Isat):18A; Inductor Construction:Shielded; DC Resistance Max:9000µohm; Power Inductor Case:12.5mm x 12.5mm x 8.5mm; Inductance Tolerance:± 20%; Packaging:Cut Tape; SVHC:No SVHC (15-Jun-2015)

INDUCTOR POWER 3.6UH 13A 20%; Product Range:B82477R4 Series; Inductance:3.6µH; RMS Current (Irms):8.05A; Saturation Current (Isat):16A; Inductor Construction:Shielded; DC Resistance Max:0.01ohm; Power Inductor Case:12.5mm x 12.5mm x 8.5mm; Inductance Tolerance:± 20%; Packaging:Cut Tape; SVHC:No SVHC (15-Jun-2015)

INDUCTOR POWER 10UH 8.5A 20%; Product Range:B82477R4 Series; Inductance:10µH; RMS Current (Irms):5.9A; Saturation Current (Isat):10.25A; Inductor Construction:Shielded; DC Resistance Max:0.0185ohm; Power Inductor Case:12.5mm x 12.5mm x 8.5mm; Inductance Tolerance:± 20%; Packaging:Cut Tape; SVHC:No SVHC (15-Jun-2015)

INDUCTOR POWER 15UH 7.25A 20%; Product Range:B82477R4 Series; Inductance:15µH; RMS Current (Irms):5A; Saturation Current (Isat):8.75A; Inductor Construction:Shielded; DC Resistance Max:0.025ohm; Power Inductor Case:12.5mm x 12.5mm x 8.5mm; Inductance Tolerance:± 20%; Packaging:Cut Tape; SVHC:No SVHC (15-Jun-2015)

INDUCTOR POWER 47UH 4.30A 20%; Product Range:B82477R4 Series; Inductance:47µH; RMS Current (Irms):3.2A; Saturation Current (Isat):4.9A; Inductor Construction:Shielded; DC Resistance Max:0.06ohm; Power Inductor Case:12.5mm x 12.5mm x 8.5mm; Inductance Tolerance:± 20%; Packaging:Cut Tape; SVHC:No SVHC (15-Jun-2015)

INDUCTOR POWER 330UH 1.70A 20%; Product Range:B82477R4 Series; Inductance:330µH; RMS Current (Irms):1.12A; Saturation Current (Isat):1.8A; Inductor Construction:Shielded; DC Resistance Max:0.425ohm; Power Inductor Case:12.5mm x 12.5mm x 8.5mm; Inductance Tolerance:± 20%; Packaging:Cut Tape; SVHC:No SVHC (15-Jun-2015)

SMT Current sense transformers EE 4.2 Core

SMT Current sense transformers EE 4.2 Core

TRANSFORMER CURRENT E4.2 1280UH; Turns Ratio:1:125; DC Resistance:13ohm; Inductance:1.28mH; ET Constant:-; Primary Current:5A; Transformer Mounting:Surface Mount; Product Range:-; SVHC:No SVHC (15-Jun-2015); Depth Max:3.5mm; External Length / Height:4.7mm; External Width:3.5mm; Frequency Max:1MHz; Frequency Min:50kHz; Input Current:5A; Operating Temperature Max:125°C; Operating Temperature Min:-40°C; Secondary Burden Resistance:13ohm; Test Voltage:360VAC; Transformer Type:Current; Type:E 4.2; Weight:0.15g; Winding Resistance Min:2.5mohm
