NTC THERMISTOR; Product Range:B57550G Series; Zero Power Resistance at 25 C:100kohm; Beta Value (K):4092K; Thermistor Mounting:Through Hole; Thermistor Case Style:-; Thermistor Terminals:Radial Leaded; Operating Temperature Min:-55 C;RoHS Compliant: Yes

CAPACITOR POLYPROPYLENE PP FILM 5UF 630V 10% RADIAL; Product Range:B32674 Series; Capacitance:5 F; Capacitance Tolerance: 10%; Capacitor Dielectric Type:PP (Polypropylene); Voltage Rating:630V; Capacitor Case Style:-

THERMISTOR NTC 1R 20A; Product Range:B57464S0 Series; Disc Size:26mm; Zero Power Resistance at 25°C:1ohm; Approvals:-; Maximum Energy Rating at 25°C:-; Maximum Steady State Current at 25°C:20A; SVHC:No SVHC (15-Jun-2015); Beta Value (K):2800K; Beta Value Lower Limit Temperature:25°C; Body Diameter:26mm; Current Max:20A; Lead Length:32mm; No. of Pins:2Pins; Operating Temperature Max:170°C; Operating Temperature Min:-55°C; Operating Temperature Range:-55°C to +170°C; Operating Voltage:265V; Resistance:1ohm; Resistance Tolerance:± 20%; Temperature Upper Limit Beta Value:100°C; Thermistor Case Style:Radial Leaded; Thermistor Tolerance:-20% to +20%; Thermistor Type:NTC

CAPACITOR ELECTROLYTIC SMD 25V 220UF; AE Capacitor Case:Radial Can - SMD; Capacitance:220µF; Voltage Rating:25V; ESR:0.14ohm; Product Range:-; Packaging:Cut Tape; Lifetime @ Temperature:3000 hours @ 105°C; Operating Temperature Min:-55°C; Operating Temperature Max:105°C; Ripple Current AC:600mA; Diameter:8mm; Height:10mm; Automotive Qualification Standard:-; MSL:-; SVHC:No SVHC (15-Jun-2015); AC Ripple Current @ 100Hz:600mA; Capacitance Tolerance:± 20%; Capacitance Tolerance ±:± 20%; Capacitor Case Style:Radial Can - SMD; ESR Temperature:20°C; External Length / Height:10mm; Impedance:0.16ohm; Impedance Frequency:100kHz; Impedance Temperature:20°C; Operating Temperature Range:-55°C to +105°C; Ripple Current Temperature:105°C

VARISTOR 0402 11V; Voltage Rating VAC:11V; Voltage Rating V DC:14V; Product Range:-; Clamping Voltage Vc Max:35V; Varistor Case Style:0402 [1005 Metric]; Varistor Type:Multilayer Varistor (MLV); Peak Surge Current @ 8/20µs:20A; Operating Temperature Min:-40°C; Operating Temperature Max:85°C; Peak Energy (10/1000uS):7.5mJ; Automotive Qualification Standard:-; SVHC:No SVHC (15-Jun-2015); Capacitance:3000pF; Clamping Voltage:35V; Clamping Voltage @ 8/20µs Max:35V; Operating Temperature Range:-40°C to +85°C; Peak Pulse Current IPP @ 8/20µs:20A; Suppressor Type:Varistor; Surge Current:20A; Transient Energy:7.5mJ; Varistor Voltage @ 1mA Max:18.4V; Varistor Voltage Tolerance +:10%

THERMISTOR NTC 4K7 0603; Zero Power Resistance at 25°C:4.7kohm; Product Range:B57301V2 Series; Beta Value (K):3650K; Thermistor Mounting:SMD; Thermistor Case Style:0603 [1608 Metric]; Thermistor Terminals:-; Operating Temperature Min:-55°C; Operating Temperature Max:125°C; Automotive Qualification Standard:-; SVHC:No SVHC (15-Jun-2015); Beta Value Lower Limit Temperature:25°C; Operating Temperature Range:-55°C to +125°C; Power Dissipation Ptot Max:180mW; Resistance:4.7kohm; Resistance Tolerance:± 5%; Temperature Upper Limit Beta Value:100°C; Thermistor Tolerance:-5% to +5%; Thermistor Type:NTC

THERMISTOR 10K 5% NTC 0603; Zero Power Resistance at 25°C:10kohm; Product Range:B57371V2 Series; Beta Value (K):4480K; Thermistor Mounting:SMD; Thermistor Case Style:0603 [1608 Metric]; Thermistor Terminals:-; Operating Temperature Min:-55°C; Operating Temperature Max:125°C; Automotive Qualification Standard:-; SVHC:No SVHC (15-Jun-2015); Resistance:10kohm; Thermistor Tolerance:-5% to +5%; Thermistor Type:NTC

THERMISTOR NTC 22K 0603; Zero Power Resistance at 25°C:22kohm; Product Range:B57371V2 Series; Beta Value (K):4480K; Thermistor Mounting:SMD; Thermistor Case Style:0603 [1608 Metric]; Thermistor Terminals:-; Operating Temperature Min:-55°C; Operating Temperature Max:125°C; Automotive Qualification Standard:-; SVHC:No SVHC (15-Jun-2015); Beta Value Lower Limit Temperature:25°C; Operating Temperature Range:-55°C to +125°C; Power Dissipation Ptot Max:180mW; Resistance:22kohm; Resistance Tolerance:± 5%; Temperature Upper Limit Beta Value:100°C; Thermistor Tolerance:-5% to +5%; Thermistor Type:NTC

THERMISTOR NTC 100K 0603; Zero Power Resistance at 25°C:100kohm; Product Range:B57371V2 Series; Beta Value (K):4480K; Thermistor Mounting:SMD; Thermistor Case Style:0603 [1608 Metric]; Thermistor Terminals:-; Operating Temperature Min:-55°C; Operating Temperature Max:125°C; Automotive Qualification Standard:-; SVHC:No SVHC (15-Jun-2015); Beta Value Lower Limit Temperature:25°C; Operating Temperature Range:-55°C to +125°C; Power Dissipation Ptot Max:180mW; Resistance:100kohm; Resistance Tolerance:± 5%; Temperature Upper Limit Beta Value:100°C; Thermistor Tolerance:-5% to +5%; Thermistor Type:NTC

THERMISTOR NTC 100K 0805; Zero Power Resistance at 25°C:100kohm; Product Range:B57471V2 Series; Beta Value (K):4480K; Thermistor Mounting:SMD; Thermistor Case Style:0805 [2012 Metric]; Thermistor Terminals:-; Operating Temperature Min:-55°C; Operating Temperature Max:125°C; Automotive Qualification Standard:-; SVHC:No SVHC (15-Jun-2015); Beta Value Lower Limit Temperature:25°C; Operating Temperature Range:-55°C to +125°C; Power Dissipation Ptot Max:210mW; Resistance:100kohm; Resistance Tolerance:± 5%; Temperature Upper Limit Beta Value:100°C; Thermistor Tolerance:-5% to +5%; Thermistor Type:NTC

THERMISTOR NTC 470K 0805; Zero Power Resistance at 25°C:470kohm; Product Range:-; Beta Value (K):4480K; Thermistor Mounting:SMD; Thermistor Case Style:0805 [2012 Metric]; Thermistor Terminals:-; Operating Temperature Min:-55°C; Operating Temperature Max:125°C; Automotive Qualification Standard:-; SVHC:No SVHC (15-Jun-2015); Beta Value Lower Limit Temperature:25°C; Operating Temperature Range:-55°C to +125°C; Packaging:Cut Tape; Power Dissipation Ptot Max:210mW; Resistance:470kohm; Resistance Tolerance:± 5%; Temperature Upper Limit Beta Value:100°C; Thermistor Tolerance:-5% to +5%; Thermistor Type:NTC

THERMISTOR NTC 4K7 1206; Zero Power Resistance at 25°C:4.7kohm; Product Range:B57621C5 Series; Beta Value (K):3520K; Thermistor Mounting:SMD; Thermistor Case Style:1206 [3216 Metric]; Thermistor Terminals:-; Operating Temperature Min:-55°C; Operating Temperature Max:125°C; Automotive Qualification Standard:-; SVHC:No SVHC (15-Jun-2015); Beta Value Lower Limit Temperature:25°C; Operating Temperature Range:-55°C to +125°C; Power Dissipation Ptot Max:300mW; Resistance:4.7kohm; Resistance Tolerance:± 5%; Temperature Upper Limit Beta Value:100°C; Thermistor Tolerance:-5% to +5%; Thermistor Type:NTC

THERMISTOR NTC 10K 1206; Zero Power Resistance at 25°C:10kohm; Product Range:B57621C5 Series; Beta Value (K):3530K; Thermistor Mounting:SMD; Thermistor Case Style:1206 [3216 Metric]; Thermistor Terminals:-; Operating Temperature Min:-55°C; Operating Temperature Max:125°C; Automotive Qualification Standard:-; SVHC:No SVHC (15-Jun-2015); Beta Value Lower Limit Temperature:25°C; Operating Temperature Range:-55°C to +125°C; Power Dissipation Ptot Max:300mW; Resistance:10kohm; Resistance Tolerance:± 5%; Temperature Upper Limit Beta Value:100°C; Thermistor Tolerance:-5% to +5%; Thermistor Type:NTC

THERMISTOR NTC 33R 1.3A; Product Range:B57153S0 Series; Disc Size:8.5mm; Zero Power Resistance at 25°C:33ohm; Approvals:UL; Maximum Energy Rating at 25°C:-; Maximum Steady State Current at 25°C:1.3A; SVHC:No SVHC (15-Jun-2015); Beta Value (K):3000K; Beta Value Lower Limit Temperature:25°C; Body Diameter:8.5mm; Current Max:1.3A; Lead Length:25mm; Lead Spacing:5mm; No. of Pins:2Pins; Operating Temperature Max:170°C; Operating Temperature Min:-55°C; Operating Temperature Range:-55°C to +170°C; Operating Voltage:265V; Power Dissipation Ptot Max:1.4W; Resistance:33ohm; Resistance Tolerance:± 20%; Temperature Upper Limit Beta Value:100°C; Thermistor Case Style:Radial Leaded; Thermistor Tolerance:-20% to +20%; Thermistor Type:NTC

THERMISTOR NTC 80R 1.6A; Product Range:B57236S0 Series; Disc Size:11.5mm; Zero Power Resistance at 25°C:80ohm; Approvals:UL; Maximum Energy Rating at 25°C:-; Maximum Steady State Current at 25°C:1.6A; SVHC:No SVHC (15-Jun-2015); Beta Value (K):3300K; Beta Value Lower Limit Temperature:25°C; Body Diameter:11.5mm; Current Max:1.6A; Lead Length:25mm; Lead Spacing:5mm; No. of Pins:2Pins; Operating Temperature Max:170°C; Operating Temperature Min:-55°C; Operating Temperature Range:-55°C to +170°C; Operating Voltage:265V; Power Dissipation Ptot Max:2.1W; Resistance:80ohm; Resistance Tolerance:± 20%; Temperature Upper Limit Beta Value:100°C; Thermistor Case Style:Radial Leaded; Thermistor Tolerance:-20% to +20%; Thermistor Type:NTC

CAPACITOR POLY FILM 0.1UF 250V 5% RAD; CAPACITOR POLY FILM 0.1UF 250V 5% RADIAL; Product Range:EPCOS - B32520 Series; Capacitance:0.1µF; Capacitance Tolerance:± 5%; Capacitor Dielectric Type:Polyester (PET); Voltage Rating:250V; Capacitor Case Style:-; Packaging:Each

CAPACITOR POLYESTER FILM 0.1UF 250V 5% RADIAL; Capacitance:0.1 F; Capacitor Dielectric Type:PET (Polyester); Voltage Rating:250V; Product Range:B32522 Series; Capacitance Tolerance: 5%; Capacitor Terminals:Radial Leaded

CAPACITOR POLYESTER FILM 0.47UF 63V 5%; CAPACITOR POLYESTER FILM 0.47UF 63V 5% RADIAL; Capacitance:0.47 F; Capacitor Dielectric Type:PET (Polyester); Voltage Rating:63V; Product Range:B32520 Series; Capacitance Tolerance: 5%; Capacitor Terminals:Radial Leaded

CAPACITOR POLY FILM 3.3UF 100V 5% RADIAL; Capacitance:3.3µF; Capacitance Tolerance:± 5%; Capacitor Dielectric Type:Polyester; Voltage Rating:100V; Life Time @ Temperature:200000 hours @ 40°C; Capacitor Terminals:Radial Leaded

CAPACITOR POLYESTER FILM 4700PF 630V ; CAPACITOR POLYESTER FILM 4700PF 630V 5% RADIAL; Capacitance:4700pF; Capacitor Dielectric Type:PET (Polyester); Voltage Rating:630V; Product Range:B32529 Series; Capacitance Tolerance: 5%; Capacitor Terminals:Radial Leaded
