Cree XD16AWT-H0-0000-00000BKE5, XLamp XD16 4000K White LED, 1616 (0606) SMD package. Mounting Type: Surface Mount. Forward Voltage: 2.73 → 2.98 V. Number of Pins: 2. Viewing Angle: 135 °. Luminous Flux: 170 lm. Lens Shape: Square. Dimensions: 1.6 x 1.6 x 0.7mm. Forward Current: 1500mA.

Cree XPGBWT-HE-0000-00HE7, XP-G2 3000K White LED, SMD SMD package. Mounting Type: Surface Mount. Number of LEDs: 1. Forward Voltage: 3 V. Viewing Angle: 125 °. Luminous Flux: 153 lm. Lens Shape: Dome. Dimensions: 3.45 x 3.45 x 2.26mm. Forward Current: 2000mA.

Cree XPGDWT-BS-0000-00MDV, XP-G3 6000K White LED, 3-Pin SMD package. Mounting Type: Surface Mount. Number of LEDs: 1. Forward Voltage: 3.06 V. Viewing Angle: 125 °. Luminous Flux: 187 (Minimum) lm. Lens Shape: Dome. Dimensions: 3.45 x 3.45 x 2.26mm. Forward Current: 2000mA. Lens Colour: Yellow.

Cree XD16AWT-H0-0000-00000HGE3, XLamp XD16 5000K White LED, 1616 (0606) SMD package. Mounting Type: Surface Mount. Forward Voltage: 2.73 → 2.98 V. Number of Pins: 2. Viewing Angle: 135 °. Luminous Flux: 142 lm. Lens Shape: Square. Dimensions: 1.6 x 1.6 x 0.7mm. Forward Current: 1500mA.

Standard LEDs - Through Hole White Round LED

Product Range:XLamp XM-L Series; LED Color:Warm White; Wavelength Typ:-; Viewing Angle:125°; Luminous Flux @ Test:200lm; Forward Current If Max:3A; Forward Current @ Test:700mA; Forward Voltage @ Test:2.9V; Power Dissipation Pd:- RoHS Compliant: Yes

COB LED 4000K NEUTRAL WHITE 5147LM; COB Colour:Neutral White; Color Rendering Index Max:92; Power Rating:87W; Luminous Flux @ Test:5147lm; Forward Current @ Test:1.1A; Viewing Angle:115°; Forward Voltage VF Typ:34.7V; Nominal CCT (K):4000 K; COB Length:17.85mm; COB Width:17.85mm; Opto Case Style:SMD-2 No Lead; Lumens / Watt @ Current Test:59.16lm/W; Light Emitting Surface:14mm; Lens Type:-; Lens Shape:Round with Flat Top; Height:1.7mm; Product Range:XLamp eTone CMA1840 Series; SVHC:No SVHC (15-Jan-2019)

COB LED 4000K NEUTRAL WHITE 3807LM; COB Colour:Neutral White; Color Rendering Index Max:92; Power Rating:77W; Luminous Flux @ Test:3807lm; Forward Current @ Test:800mA; Viewing Angle:115°; Forward Voltage VF Typ:34.4V; Nominal CCT (K):4000 K; COB Length:19mm; COB Width:19mm; Opto Case Style:SMD-2 No Lead; Lumens / Watt @ Current Test:49.44lm/W; Light Emitting Surface:14.5mm; Lens Type:-; Lens Shape:Round with Flat Top; Height:1.45mm; Product Range:XLamp eTone CMT1930 Series; SVHC:No SVHC (15-Jan-2019)

COB LED 3000K WARM WHITE 1659LM; COB Colour:Warm White; Color Rendering Index Max:92; Power Rating:22W; Luminous Flux @ Test:1659lm; Forward Current @ Test:700mA; Viewing Angle:115°; Forward Voltage VF Typ:17.2V; Nominal CCT (K):3000 K; COB Length:15.85mm; COB Width:15.85mm; Opto Case Style:SMD-2 No Lead; Lumens / Watt @ Current Test:75.41lm/W; Light Emitting Surface:9mm; Lens Type:-; Lens Shape:Round with Flat Top; Height:1.7mm; Product Range:XLamp eTone CXB1512 Series; SVHC:No SVHC (15-Jan-2019)

COB LED 4000K NEUTRAL WHITE 1705LM; COB Colour:Neutral White; Color Rendering Index Max:92; Power Rating:22W; Luminous Flux @ Test:1705lm; Forward Current @ Test:700mA; Viewing Angle:115°; Forward Voltage VF Typ:17.2V; Nominal CCT (K):4000 K; COB Length:15.85mm; COB Width:15.85mm; Opto Case Style:SMD-2 No Lead; Lumens / Watt @ Current Test:77.5lm/W; Light Emitting Surface:9mm; Lens Type:-; Lens Shape:Round with Flat Top; Height:1.7mm; Product Range:XLamp eTone CXB1512 Series; SVHC:No SVHC (15-Jan-2019)

COB LED 4000K NEUTRAL WHITE 2182LM; COB Colour:Neutral White; Color Rendering Index Max:92; Power Rating:34W; Luminous Flux @ Test:2182lm; Forward Current @ Test:450mA; Viewing Angle:115°; Forward Voltage VF Typ:35V; Nominal CCT (K):4000 K; COB Length:17.85mm; COB Width:17.85mm; Opto Case Style:SMD-2 No Lead; Lumens / Watt @ Current Test:64.18lm/W; Light Emitting Surface:12mm; Lens Type:-; Lens Shape:Round with Flat Top; Height:1.7mm; Product Range:XLamp eTone CXB1816 Series; SVHC:No SVHC (15-Jan-2019)

LED HB 2700K WARM WHITE 139LM; Product Range:XLamp XP-G2 Series; LED Colour:Warm White; Viewing Angle:125°; Luminous Flux @ Test:139lm; CCT:2700K; Forward Current If Max:2A; Forward Voltage @ Test:2.73V; Forward Current @ Test:350mA; Power Dissipation Pd:6W; SVHC:No SVHC (15-Jan-2019)

LED HB 2700K WARM WHITE 114LM; Product Range:XLamp XP-G2 Series; LED Colour:Warm White; Viewing Angle:125°; Luminous Flux @ Test:114lm; CCT:2700K; Forward Current If Max:2A; Forward Voltage @ Test:2.73V; Forward Current @ Test:350mA; Power Dissipation Pd:6W; SVHC:No SVHC (15-Jan-2019)

SILICONCARBIDE SCHOTTKY DIODE, 24A, 650V

LED Blue/Green/Red 475nm/535nm/625nm 4-Pin SMD T/R

EVALUATION BOARD, SIC MOSFET ROHS COMPLIANT: YES

MOSFET, N-CH, 1.2KV, 175DEG C, 283W ROHS COMPLIANT: YES

MOSFET, N-CH, 1.2KV, 175DEG C, 469W ROHS COMPLIANT: YES
