Octal, 16-Bit nanoDAC+ with 2 ppm/C Reference, I2CInterface Features: High Performance High relative accuracy (INL): ±3 LSB maximum at 16 bits Total unadjusted error (TUE): ±0.14% of FSR maximum Offset error: ±1.5 mV maximum Gain error: ±0.06% of FSR maximum Low drift 2.5 V reference: 2 ppm/°C typical Wide Operating Ranges −40°C to +125°C temperature range 2.7 V to 5.5 V power supply Easy Implementation User selectable gain of 1 or 2 (GAIN pin/bit) 1.8 V logic compatibility 400 kHz I2C-compatible serial interface 20-lead, RoHS-compliant TSSOP and LFCSP

16-Channel, 12-/16-Bit nanoDAC+ with 2 ppm/C Voltage Reference TC, I2C Interface Features: High relative accuracy (INL): ±4 LSB maximum at 16 bits (AD5677R only) TUE: ±0.14% of FSR maximum Offset error: ±1.5 mV maximum Gain error: ±0.06% of FSR maximum Low drift, 2.5 V voltage reference TC: 2 ppm/°C typical 40 mA short-circuit current Wide operating ranges −40°C to +125°C temperature range 2.7 V to 5.5 V power supply range Simplified implementation User selectable gain of 1 or 2 (GAIN pin) 1.8 V logic compatibility 400 kHz I2C-compatible serial interface 28-lead, 4 mm × 4 mm, RoHS compliant LFCSP

16-Channel, 12-/16-Bit nanoDAC+ with 2 ppm/C VoltageReference Temperature Coefficient, SPI Interface Features: High performance High relative accuracy (INL): ±4 LSB maximum at 16 bits (AD5679/AD5679R) TUE: ±0.14% of FSR maximum Offset error: ±1.5 mV maximum Gain error: ±0.06% of FSR maximum Low drift, 2.5 V voltage reference temperature coefficient: 2 ppm/°C typical 40 mA short-circuit current Wide operating ranges −40°C to +125°C temperature range 2.7 V to 5.5 V power supply range Simplified implementation User selectable gain of 1 or 2 (GAIN pin) 1.8 V logic compatibility 50 MHz serial peripheral interface (SPI) with readback or daisy chain 28-lead, 4 mm × 4 mm, RoHS compliant LFCSP

Dual, 12-BitnanoDAC+ with 2 ppm/C Reference, SPI Interface Features: High relative accuracy (INL): ±2 LSB maximum at 16 bits  Low drift 2.5 V reference: 2 ppm/°C typical Tiny package: 3 mm × 3 mm, 16-lead LFCSP TUE: ±0.1% of FSR maximum  Offset error: ±1.5 mV maximum Gain error: ±0.1% of FSR maximum High drive capability: 20 mA, 0.5 V from supply rails  User-selectable gain of 1 or 2 (GAIN pin)  Reset to zero scale or midscale (RSTSEL pin) 1.8 V logic compatibility 50 MHz SPI with readback or daisy chain Low glitch: 0.5 nV-sec Low power: 3.3 mW at 3 V  2.7 V to 5.5 V power supply −40°C to +105°C temperature range AEC-Q100 qualified for automotive applications

Dual, 16-Bit nanoDAC+ with SPI Interface Features: High relative accuracy (INL): ±2 LSB maximum at 16 bits Tiny package: 3 mm × 3 mm, 16-lead LFCSP TUE: ±0.1% of FSR maximum Offset error: ±1.5 mV maximum Gain error: ±0.1% of FSR maximum High drive capability: 20 mA, 0.5 V from supply rails User-selectable gain of 1 or 2 (GAIN pin) Reset to zero scale or midscale (RSTSEL pin) 1.8 V logic compatibility 50 MHz SPI with readback or daisy chain Low glitch: 0.5 nV-sec Low power: 3.3 mW at 3 V 2.7 V to 5.5 V power supply −40°C to +105°C temperature range

Dual, 16-Bit nanoDAC+ with 2 ppm/C Reference, SPI Interface Features: High relative accuracy (INL): ±2 LSB maximum at 16 bits  Low drift 2.5 V reference: 2 ppm/°C typical Tiny package: 3 mm × 3 mm, 16-lead LFCSP TUE: ±0.1% of FSR maximum  Offset error: ±1.5 mV maximum Gain error: ±0.1% of FSR maximum High drive capability: 20 mA, 0.5 V from supply rails  User-selectable gain of 1 or 2 (GAIN pin)  Reset to zero scale or midscale (RSTSEL pin) 1.8 V logic compatibility 50 MHz SPI with readback or daisy chain Low glitch: 0.5 nV-sec Low power: 3.3 mW at 3 V  2.7 V to 5.5 V power supply −40°C to +105°C temperature range AEC-Q100 qualified for automotive applicationsAD5689R-EP supports defense and aerospace applications (AQEC standard) Download AD5689R-EP Data Sheet (pdf) Temperature range: −55°C to +125°C Controlled manufacturing baseline 1 assembly/test site 1 fabrication site Enhanced product change notification Qualification data available on request V62/14634 DSCC Drawing Number

Dual, 16-Bit nanoDAC+ with 2 ppm/C Reference, SPI Interface Features: High relative accuracy (INL): ±2 LSB maximum at 16 bits  Low drift 2.5 V reference: 2 ppm/°C typical Tiny package: 3 mm × 3 mm, 16-lead LFCSP TUE: ±0.1% of FSR maximum  Offset error: ±1.5 mV maximum Gain error: ±0.1% of FSR maximum High drive capability: 20 mA, 0.5 V from supply rails  User-selectable gain of 1 or 2 (GAIN pin)  Reset to zero scale or midscale (RSTSEL pin) 1.8 V logic compatibility 50 MHz SPI with readback or daisy chain Low glitch: 0.5 nV-sec Low power: 3.3 mW at 3 V  2.7 V to 5.5 V power supply −40°C to +105°C temperature range AEC-Q100 qualified for automotive applicationsAD5689R-EP supports defense and aerospace applications (AQEC standard) Download AD5689R-EP Data Sheet (pdf) Temperature range: −55°C to +125°C Controlled manufacturing baseline 1 assembly/test site 1 fabrication site Enhanced product change notification Qualification data available on request V62/14634 DSCC Drawing Number

Aerospace 12-Bit-ADC w/Microprocessor Interface Features:Complete 12-Bit A/D Converter with Reference and Clock 8- and 16-Bit Microprocessor Bus Interface Guaranteed Linearity Over Temperature No Missing Codes Over Temperature Buried Zener Reference for Long-Term Stability and Low Gain

Single-Channel, 16-Bit Current and Voltage Output DAC with Dynamic Power Control Features: 16-bit resolution and monotonicityPositive and negative DPC for thermal managementCurrent or voltage output available on a single terminalCurrent output ranges: 0 mA to 20 mA, 4 mA to 20 mA, 0 mA to 24 mA, 20 mA, 24 mA, and 1 mA to +22 mAVoltage output ranges (with 20% overrange): 0 V to 5 V, 0 V to 10 V, 5 V, and 10 VUser programmable offset and gain Advanced on-chip diagnostics, including a 12-bit ADC2 external ADC input pinsOn-chip referenceRobust architecture, including output fault protection40C to +115C temperature range40-lead, 6 mm 6 mm LFCSP package

Multiple Range, 16-Bit, Bipolar Voltage Output DACs with 2 PPM/C Reference Features: 8 software-programmable output ranges: 0 V to +5 V, 0 V to +10 V, 0 V to +16 V, 0 V to +20 V, ±3 V, ±5 V, ±10 V, and −2.5 V to +7.5 V; 5% overrange Low drift 2.5 V reference: ±2 ppm/°C typical Total unadjusted error (TUE): 0.1% FSR maximum 16-bit resolution: ±2 LSB maximum INL Guaranteed monotonicity: ±1 LSB maximum Single channel, 16-/12-bit DACs Settling time: 7.5 μs typical Integrated reference buffers Low noise: 35 nV/√Hz Low glitch: 1 nV-sec (0 V to 5 V range) 1.7 V to 5.5 V digital supply range Asynchronous updating via LDAC Asynchronous RESET to zero scale/midscale DSP-/microcontroller-compatible serial interface Robust 4 kV HBM ESD rating 16-lead, 3 mm × 3 mm LFCSP package 16-lead TSSOP package Operating temperature range: −40°C to +125°CAD5761R-EP supports defense and aerospace applications (AQEC standard) Download AD5761R-EP data sheet (pdf) Military temperature range: −55°C to +125°C Controlled manufacturing baseline 1 assembly/test site 1 fabrication site Enhanced product change notification Qualification data available on request V62/17605 DSCC Drawing Number

16-Channel, 16-Bit Voltage Output denseDAC Features: Download AD5766-KGD Data Sheet. Available as Known Good Die and fully guaranteed to data sheet specifications. Complete 16-channel, 16-bit DACs 8 software-programmable output ranges: −20 V to 0 V, −16 V to 0 V, −10 V to 0 V, −10 V to +6 V, −12 V to +14 V, −16 V to +10 V, ±5 V and ±10 V Integrated DAC output buffers with ±20 mA output current capability 4 mm × 4 mm WLCSP package and 40-lead LFCSP package Integrated reference buffers 2 dither signal input pins Channel monitoring multiplexer 1.8 V logic compatibility Temperature range: −40°C to +105°C

High Precision 2.5 V IC Reference Features: Laser Trimmed to High Accuracy: 2.500 V ± 0.4% 3-Terminal Device: Voltage In/Voltage Out Excellent Temperature Stability: 10 ppm/°C (AD580M, U) Low Quiescent Current: 1.5 mA max Excellent Long-Term Stability: 250 µV (25 µV/Month) Small, Hermetic IC Package: TO-52 Can MIL-STD-883 Compliant Versions Available

High Precision 10 V IC Reference Features: Laser trimmed to high accuracy 10.000 V ±5 mV (L and U models) Trimmed temperature coefficient 5 ppm/°C maximum, 0°C to 70°C (L model) 10 ppm/°C maximum, −55°C to +125°C (U model) Excellent long-term stability 25 ppm/1000 hrs (noncumulative) −10 V reference capability Low quiescent current: 1.0 mA maximum 10 mA current output capability 3-pin TO-5 package MIL-STD-883 compliant versions available

Complete Monolithic SHA Circuit Features: 3.0 ms Acquisition Time to 60.01% max Low Droop Rate: 1.0 mV/ms max Sample/Hold Offset Step: 3 mV max Aperture Jitter: 0.5 ns Extended Temperature Range: –55°C to +125°C Internal Hold Capacitor Internal Application Resistors See datasheet for additional features

Complete Monolithic SHA Circuit Features: 3.0 ms Acquisition Time to 60.01% max Low Droop Rate: 1.0 mV/ms max Sample/Hold Offset Step: 3 mV max Aperture Jitter: 0.5 ns Extended Temperature Range: –55°C to +125°C Internal Hold Capacitor Internal Application Resistors See datasheet for additional features

High Precision 5 V Reference Features:Laser Trimmed to High Accuracy 5.00 V 2.0 mV (M Grade) Trimmed Temperature Coefficient 2 ppm/C Max, 0C to 70C (M Grade) 5 ppm/C Max, -40C to +85C (B and L Grades) 10 ppm/C Max, -55C to +125C (T Grade) Low Noise, 100 nV/Hz Noise Reduction Capability Output Trim Capability MIL-STD-883 Compliant Versions Available Industrial Temperature Range SOICs Available Output Capable of Sourcing or Sinking 10 mA

1 MSPS, 12-Bit Impedance Converter, Network Analyzer Features: Chinese data sheet available Programmable output peak-to-peak excitation voltage to a maximum frequency of 100 kHz Programmable frequency sweep capability with serial I2C interface Frequency resolution of 27 bits (<0.1 Hz) Impedance measurement range from 1 kΩ to 10 MΩ Capable of measuring of 100 Ω to 1 kΩ with additional circuitry Internal temperature sensor (±2°C) Internal system clock option Phase measurement capability System accuracy of 0.5% 2.7 V to 5.5 V power supply operation Temperature range: −40°C to +125°C 16-lead SSOP package Qualified for automotive applications

High Precision, Impedance & Electrochemical Front End Features: Analog input 16-bit ADC with both 800 kSPS and 1.6 MSPS options Voltage, current, and impedance measurement capability Internal and external current and voltage channels Ultralow leakage switch matrix and input mux Input buffers and programmable gain amplifier Voltage DACs Dual output voltage DAC with an output range of 0.2 V to 2.4 V 12-bit VBIAS0 output to bias potentiostat 6-bit VZERO0 output to bias TIA Ultra low power: 1 µA 1 high speed, 12-bit DAC Output range to sensor: ±607 mV Programmable gain amplifier on output with gain settings of 2 and 0.05 Amplifiers, accelerators, and references 1 low power, low noise potentiostat amplifier suitable for potentiostat bias in electrochemical sensing 1 low noise, low power TIA, suitable for measuring sensor current output 50 pA to 3 mA range Programmable load and gain resistors for sensor output Analog hardware accelerators Digital waveform generator Receive filters Complex impedance measurement (DFT) engine 1 high speed TIA to handle wide bandwidth input signals from 0.015 Hz up to 200 kHz Digital waveform generator for generation of sinusoid and trapezoid waveforms 2.5 V and 1.82 V internal reference voltage sources System level power savings Fast power-up and power-down analog blocks for duty cycling Programmable AFE sequencer to minimize workload of host controller 6 kB SRAM to preprogram AFE sequences Ultra low power potentiostat channel: 6.5 µAof current consumption when powered on and all other blocks in hibernate mode Smart sensor synchronization and data collection Cycle accurate control of sensor measurement Sequencer controlled GPIOs On-chip peripherals SPI serial input/output Wake-up timer Interrupt controller Power 2.8 V to 3.6 V supply 1.82 V input/output compliant Power-on reset Hibernate mode with low power DAC and potentiostat amplifier powered up to maintain sensor bias Package and temperature range 3.6 mm × 4.2 mm, 56-ball WLCSP 7 mm × 7 mm, 48-lead LFCSP Fully specified for operating temperature range of −40°C to +85°C AD5940 and AD5941 fully specified for operating temperature range of −40°C to +85°C AD5941W fully specified for operating temperature range of −40°C to +105°C AEC-Q100 qualified for automotive applications

Dual, Low Noise, Wideband Variable Gain Amplifier, -10 dB To +30 dB Gain Features: 2 channels with independent gain control Linear in dB gain response 2 gain ranges AD600: 0 dB to 40 dB AD602: -10 dB to +30 dB Accurate absolute gain: ±0.3 dB Low input noise: 1.4 nV/√Hz Low distortion: -60 dBc THD at ±1 V output High bandwidth: dc to 35 MHz (-3 dB) Stable group delay: ±2 ns Low power: 125 mW (maximum) per amplifier Signal gating function for each amplifier Drives high speed ADCs MIL-STD-883-compliant and DESC versions available

Triple Output, Multiphase Synchronous Step-Down Controller Features: Triple, 120° Phased Controllers Reduce Required Input Capacitance and Power Supply Induced Noise Configurable as a 180° Dual Phase Controller Plus a Single Phase Controller The Third Phase Can Regulate Up to a 13.5V Output High Efficiency: Up to 92% RSENSE or DCR Current Sensing ±0.75% 0.8V Output Voltage Accuracy Phase-Lockable Fixed Frequency 250kHz to 750kHz Supports Pre-Biased Outputs Dual N-Channel MOSFET Synchronous Drive Wide VIN Range: 4.5V to 24V Operation (28V Abs Max) Adjustable Soft-Start Current Ramping or Tracking Foldback Output Current Limiting Output Overvoltage Protection Dual Power Good Output Voltage Monitors 40-Lead 6mm × 6mm QFN Package
